coolant temperature HONDA ACCORD 2004 CL7 / 7.G Owners Manual

¶¶µµµµ
µ µµµ This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
There are two trip meters: Trip A
and Trip B. Switch between these
displays and the odometer/outside
temperature display by pressing the
Select/Reset knob repeatedly. Each
trip meter works independently, so
you can keep track of two dif f erent
distances.
This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise into the
upperhalfofthegauge.Ifitreaches
the red (Hot) mark, pull safely to the
side of the road. Turn to page f or
instructions and precautions on
checking the engine’s cooling
system.
If the outside temperature is
incorrectly displayed, you can adjust
it up to 5°F ( 3°C) warmer or
cooler.
NOTE: The temperature must be
stabilized bef ore doing this
procedure.
Select the outside temperature
display, then press the Select/Reset
knob f or ten seconds. The f ollowing
sequence will appear f or one second
each:0,1,2,3,4,5, 5, 4, 3, 2,
1, 0, 1 (0, 1, 2, 3, 3, 2, 1, 0, 1).
When it reaches the desired value,
release the Select/Reset knob. You
should see the new outside
temperature displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace. When you turn the ignition switch to
ON (II), what you last selected is
displayed.
To reset a trip meter, display it and
then press and hold the Select/Reset
knob until the number resets to ‘‘0.0’’.
Both trip meters will reset if the
vehicle’s battery goes dead or is
disconnected. 257
Trip Meter Temperature Gauge
Gauges
Inst rument s and Cont rols69
——y


y
(
yy

ÛÝ
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally.
Turn on the A/C by pressing the
button. The light above or in the
button comes on when a f an speed
is selected.
Make sure the temperature
control dial or button is set to their
lower limit.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed. Press the A/C button, the Manual
Operation A/C screen will appear.
Select the ON icon on the display.
Select the desired temperature
and MODE selections. If the
outside air is humid, select the
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in Fresh Air mode.
Select .
When you select , the system
automatically switches to the
Fresh Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
Press the A/C button, the manual
operation of A/C screen will
appear.
Select the desired mode and f an
speed icons on the display.
Adjustforwarmthwiththe
temperature buttons ( or ). To cool the interior with MAX A/C:
Set the f an to the desired speed.
Select the MAX A/C mode.
The system automatically turns on
the A/C, selects and
switches to Recirculation mode.
Make sure the temperature
control dial is all the way to the left.
1. 2. 3. 4. 5.
1.2. 3. 1.2. 3.
1. 2. 3. 1.2. 3.
69
If the interior is very warm,
On all models except EX-L and EX-V6
Except EX-L and EX-V6 with Navigation
System Except EX-L and EX-V6 with Navigation
SystemEX-L and EX-V6 with Navigation System
EX-L and EX-V6 with Navigation System
Using the Heater Using the A /C
Vents, Heating, and A/C
Features115
——y

y
(
y

y

CONT INUED
Saf ely pull to the side of the road.
Put the transmission in Neutral or
Park, and set the parking brake.
Turn of f all accessories, and turn
on the hazard warning indicators.
If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.If you do not see steam or spray,
leave the engine running, and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
If the temperature gauge stays at
the red mark, turn of f the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (see
on page ).
The pointer of the vehicle’s
temperature gauge should stay in
the midrange. If it climbs to the red
mark, you should determine the
reason (hot day, driving up a steep
hill, etc.).
If your vehicle overheats, you should
take immediate action. The only
indication may be the temperature
gauge climbing to or above the red
mark. Or you may see steam or
spray coming f rom under the hood.
1. 2.3. 4. 5.
264
If theEngineOverheats
T aking Care of t he Unexpect ed
Emergency
Towing
257
NOTICE: Steam and spray from an
overheated engine can
seriously scald you.
Do not open the hood if steam
is coming out.
Driving with the temperature
gauge pointer at the red mark can
cause serious damage to your engine.
——y
y
(
yy

If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank (see page). Add coolant if the level is
below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator. Using gloves or large heavy cloth,
turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.
Start the engine and set the
temperature control dial to
maximum (climate control to
FULL AUTO at 90°F/32°C). Add
coolant to the radiator up to the
base of the f iller neck. If you do
not have the proper coolant
mixture available, you can add
plain water. Remember to have
the cooling system drained and
ref illed with the proper mixture as
soon as you can.Put the radiator cap back on
tightly. Run the engine, and watch
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (see
on page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
7.
6.
8. 9.10. 11.
219
264
If theEngineOverheats
T aking Care of t he Unexpect ed
Emergency
Towing
258
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
——y

y
(
y
y

Î
..................
Childproof Door Locks . 85
.......................................
Child Seats . 34
...........
Lower Anchorage Points . 46
..........
Tether Anchorage Points . 50
..............
Climate Control Sensors . 121
.........................
Clock, Setting the . 153
...................................
Clutch Fluid . 226
........................
CO in the Exhaust . 282
............
Cold Weather, Starting in . 179
..............................
Compact Spare . 248
.................
Console Compartment . 107
...............
Consumer Inf ormation . 288
.............
Controls, Instruments and . 59
Coolant
........................................
Adding . 219
....................................
Checking . 169
.........................
Proper Solution . 219
...................
Temperature Gauge . 69
Crankcase Emissions Control ........................................
System . 282
............
Cruise Control Operation . 155
.............
Customer Service Of f ice . 288
................
DANGER, Explanation of . ii .......................................
Dashboard . 60
................
Daytime Running Lights . 76
............
Def ects, Reporting Saf ety . 290
................
Def ogger, Rear Window . 77
....................................
Dimensions . 274
...............
Dimming the Headlights . 74
Dipstick
.
Automatic Transmission . 221, 222
..................................
Engine Oil . 168
..........................
Directional Signals . 74
........
Disc Brake Wear Indicators . 188
.....................
Disposal of Used Oil . 217
Doors
..............
Locking and Unlocking . 83
..........
DOT Tire Quality Grading . 277
Downshif ting, 5-speed Manual
.............................
Transmission . 180
...........
Driver and Passenger Safety . 5
...........................................
Driving . 177
....................................
Economy . 170
................
In Foreign Countries . 281
..........
Dual Temperature Control . 119
..................
Dust and Pollen Filter . 235 ..............................
Economy, Fuel . 170
............
Emergencies on the Road . 247
.............
Battery, Jump Starting . 255
...........
Brake System Indicator . 262
................
Changing a Flat Tire . 249
.....
Charging System Indicator . 260
..................
Checking the Fuses . 265
.....
Low Oil Pressure Indicator . 259
...
Malf unction Indicator Lamp . 260
...
Manually Closing Moonroof . 263
..................
Overheated Engine . 257
.........................
Emergency Brake . 103
......................
Emergency Flashers . 76
......................
Emergency Towing . 264
.......................
Emissions Controls . 282Engine
....
Coolant Temperature Gauge . 69
Malf unction Indicator
................................
Lamp . 62, 260
........
Oil Pressure Indicator . 62, 259
..............
Oil, What Kind to Use . 214
...............................
Overheating . 257
............................
Specif ications . 274
....................
Speed Limiter . 181, 184
Index
D E
II
——y


y
(
yy

CONT INUED
...............
Gas Mileage, Improving . 170
..........................................
Gasohol . 280
.........................................
Gasoline . 164
...........................................
Gauge . 70
................
Octane Requirement . 164
........................
Tank, Filling the . 165
................
Gas Station Procedures . 165
Gauges
...
Engine Coolant Temperature . 69
...............................................
Fuel . 70 ...............................
Speedometer . 68
.................................
Tachometer . 68
Gearshif t Lever Positions ..........
Automatic Transmission . 182
5-speed Manual
.........................
Transmission . 180
......................................
Glove Box . 108
.............
Halogen Headlight Bulbs . 228
..............
Hazard Warning Flashers . 76
........................................
Headlights . 74
........................................
Aiming . 228
..............
Automatic Lighting Off . 75
............
Daytime Running Lights . 76
............
Low Beams, Turning on . 74
.........................
Reminder Chime . 74
........
Replacing Halogen Bulbs . 228
...................................
Turning on . 74
..............................
Head Restraints . 94
.....................
Heating and Cooling . 110
.................................
Heated Mirror . 99
..........................
Fan, Interior . 110, 111
.........................................
Features . 109
....................
Filling the Fuel Tank . 165
Filter
.........................
Dust and Pollen . 235
...............................................
Oil . 216
5-speed Manual Transmission ...............
Checking Fluid Level . 224
5-speed Manual Transmission ................................
Shif ting the . 180
.............
Flashers, Hazard Warning . 76
...................
Flat Tire, Changing a . 249
Fluids
.
Automatic Transmission . 221, 222
..........................................
Brake . 225
.........................................
Clutch . 226 ..............
Manual Transmission . 224
..........................
Power Steering . 226
..................
Windshield Washer . 218
...........................
Folding Rear Seat . 95
.....
Foreign Countries, Driving in . 281
..........................
Four-way Flashers . 76
.................................................
Fuel . 164
......................
Fill Door and Cap . 165
...........................................
Gauge . 70
................
Octane Requirement . 164
...............................
Oxygenated . 280
........................
Tank, Filling the . 165
.....................
Fuses, Checking the . 265
.......................................
Starting . 179
..........
Engine Speed Limiter . 181, 184
......................
Ethanol in Gasoline . 280
.
Evaporative Emissions Controls . 282
...............................
Exhaust Fumes . 56
Expectant Mothers, Use of Seat
........................................
Belts by . 17
Index
F
G H
III
——y

y
(
yy
