To load or play CDs, the ignition
switch must be in the ACCESSORY
(I) or ON(II) position.
You operate the CD player/CD
changer with the same controls used
for the radio. To select the CD
player/CD changer, press the CD
button. The number of the track
playing is shown in the display. With
the in-dash CD changer, the disc and
track numbers are displayed. The
system will continuously play a CD
until you change modes.To listen to satellite radio when a CD
is playing, press the CD/AUX XM
button.
To play the tape when a CD is
playing, insert a tape in the player
(optional). If a tape is in the player,
press the AUX button. Press the CD
button again to switch back to the
CD player. The cassette player is
optional on all U.S. models.
If you turn the system of f while a CD
is playing, either with the PWR/VOL
knob or by turning off the ignition,
the disc will stay in the drive. When
youturnthesystembackon,theCD
will begin playing where it lef t of f .
To play the radio when a CD is
playing, press the AM/FM button.
Press the CD button again to switch
back to the CD player.
Insert a CD into the CD slot. The
drive will pull the CD in the rest of
the way to play it. When the system
reaches the end of the disc, it will
return to the beginning and play the
disc again.
For Vehicles without in-dash CD
changer For Vehicles with Satellite RadioTo Play a CD
Playing a CD, CD Changer
124
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
— — y
y
( y
y
Page 121 of 281
µµ
µ Touch the icon to
continuously replay the current CD.
Touch again to turn it of f .
Touch the icon to
play the current CD in random order.
Touch again to stop.
Selects an icon and
plays the disc. If a tape is in the optional tape player,
press the AUX button to switch to
the tape while a CD is playing. Press
the CD button again to switch back
to the CD player.
If you turn the system of f while a CD
is playing, the CD will stay in the
drive. When you turn the system
back on, the CD will begin playing
where it lef t of f .
PresstheAM/FMorXM/CD
buttontoswitchtotheradioor
satellite radio while a CD is playing.
Press the CD button again to play
the CD.
Press the eject button ( ) to
remove the CD. If you eject the CD,
but do not remove it f rom the slot,
the system will automatically reload
the CD af ter 15 seconds and put it in
pause mode. To begin playing, press
the CD button. To remove a dif f erent disc f rom the
changer,firstselectitwiththe
appropriate preset bar or icon. When
that CD begins playing, press the
eject button. Continue pressing the
EJECT button to remove all the discs
f rom the changer.
To remove the disc currently playing,
press the EJECT button. When a
disc is removed f rom a slot, the
system automatically begins the load
sequence so you can load another
CD in that position. If you do not
remove the disc f rom the changer
within 15 seconds, the system
returns to the previous mode (AM/
FM or satellite radio). The disc will
reload into the system and will
remainthereinapausemode.
For Vehicles with CD Player or
Changer U.S. EX-L and EX-V6
U.S. EX-L and EX-V6Canadian EX-L, SE-V6 and EX-V6
DISC RPT
TRACK RDM
CH DISC
To Stop Playing a CD Removing CDs f rom the Changer
Playing a CD, CD Changer
Features
127
— — y
y
( y
y
Page 122 of 281
µ´
Load the desired CDs in the
magazine, and load the magazine in
the changer according to the
instructions that came with the unit.
To select the CD changer, press the
CD button. The disc and track
numbers will be displayed. To select
a dif f erent disc, use Preset 5 (DISC
), f or a previous disc; or Preset 6
(DISC ), to select the next disc in
sequence.
If you select an empty slot in the
magazine, the changer will search
f or the next available CD to load and
play. On LX model, if there are no CDs in
the changer, the display will f lash,
and you will have to select another
mode.
An optional six or eight disc CD
changer is available f or your vehicle
f rom your dealer.
This disc changer uses the same
controls used f or the in-dash CD
player/changer or the radio.
U.S. VP and LX
Canadian DX-G and SE
Operating the Optional CD
Changer
Playing a CD, CD Changer
128
— — y
y
( y
y
Page 123 of 281
If you see an error message in the
display while playing a CD, f ind the
cause in the chart to the right. If you
cannot clear the error message, take
the vehicle to your dealer.Cause Solution
Error Message
FOCUS Error
Mechanical Error
No CD in the CD
Changer
High Temperature Press the CD eject button and pull out the CDs.
Check for an error indication. Insert the CDs
again. If the code does not disappear or the
CDs cannot be pulled out, consult your dealer.
Press the CD eject button and pull out the CDs.
Check for an error indication. Insert the CDs
again. If the code does not disappear or the
CDs cannot be pulled out, consult your dealer.
Insert CDs.
Will disappear when the temperature returns to
normal.
CD Player Error Messages
Features
129
— — y
y
( y
y
Page 124 of 281
When using CD-R discs, use only
high quality CDs labeled f or audio
use.
When recording a CD-R, the
recording must be closed f or it to
be used by the system.
CD-RW discs will not work in this
unit.
Play only standard round CDs.
Odd-shaped CDs may jam in the
driveorcauseotherproblems.When a CD is not being played, store
it in its case to protect it f rom dust
and other contamination. To prevent
warpage, keep CDs out of direct
sunlight and extreme heat.
To clean a CD, use a clean sof t cloth.
Wipe across the CD f rom the center
to the outside edge.
AnewCDmayberoughonthe
inner and outer edges. The small
plastic pieces causing this roughness
can f lake of f and f all on the re-
cording surf ace of the CD, causing
skipping or other problems. Remove
these pieces by rubbing the inner
and outer edges with the side of a
pencil or pen.
Never try to insert f oreign objects in
the CD player or the magazine.
Handle a CD by its edges; never
touch either surf ace. Do not place
stabilizer rings or labels on the CD.
These, along with contamination
f rom f ingerprints, liquids, and f elt-tip
pens, can cause the CD to not play
properly, or possibly jam in the drive.
Handle your CDs properly to
prevent damage and skipping. See
this page.
General Inf ormation Protecting CDs
Protecting Your CDs
130
— — y y
( y
y
Page 126 of 281
ÛÎ
Î
The ignition switch must be in
ACCESSORY (I) or ON (II). Make
sure the open side of the tape is
facing right, then insert the tape
most of the way into the slot. The
system will pull the tape in the rest
of the way, and begin to play it.
The tape direction indicator will light
to show you which side of the tape is
playing. The indicates the side
youinsertedupwardinnowplaying.
If you want to play the other side,
press the Preset 3 (PLAY/PROG)
side of the preset bar or press the
AUDIO DISPLAY button and touch
the PROG icon. When the player
reaches the end of the tape, it will
automatically reverse direction and
play the other side. Dolby noise reduction turns on
when you insert a tape. The
indicator will light in the
display. If the tape was not recorded
in Dolby, turn it of f by pressing the
Preset 4 (NR) side of the preset bar
or touching the NR icon. Dolby
remains of f until you press the
preset bar or the icon again.
Dolby noise reduction
manuf actured under license f rom
Dolby laboratories licensing
Corporation. ‘‘Dolby’’ and the
double-D symbol are trademarks
of the Dolby Laboratories
Licensing Corporation. To remove the tape, press the
EJECT button on the cassette player.
If you want to turn the player of f ,
press the PWR/VOL knob or turn
of f the ignition. The tape will remain
in the drive.
When you turn the system back on,
the tape player will be in pause mode.
Press the Preset 3 (PLAY/PROG)
side of the preset bar or touch the
PROG icon on vehicles with
navigation system to resume play.
To switch to the radio or CD player
while a tape is playing, press the
AM/FM, or CD/AUX button or CD/
AUX XM button. To change back to
thetapeplayer,pushtheCD/AUX
button or CD/AUX XM button.
Optional on all U.S. models
To Play a Tape
To Stop Playing a Tape
Playing a T ape (U.S. Vehicles)
132
— — y
y
( y
y
Page 128 of 281
If the tape is loose, tighten it by
turning the hub with a pencil or your
f inger. If the label is peeling of f ,
remove it or it could cause the tape
to jam in the player. Never try to
insert a warped or damaged tape in
the player.
Store tapes in their cases to protect
them f rom dust and moisture. Never
place tapes where they will be
exposed to direct sunlight, high heat,
or high humidity. If a tape is exposed
to extreme heat or cold, let it reach a
moderate temperature bef ore
inserting it into the player.
Thetapeplayerpicksupdirtand
oxides f rom the tape. This
contamination builds up over time
and causes the sound quality to
degrade. To prevent this, you should
clean the player af ter every 30 hours
of use.
If you do not clean the tape player
regularly, it may eventually become
impossible to remove the
contamination with a normal
cleaning kit. Your dealer has a
cleaning kit available.
Use 100-minute or shorter tapes.
Tapes longer than that may break or
jam the drive.
Never try to insert f oreign objects
into the tape player.
Caring f or the T ape and Player
Playing a T ape (U.S. Vehicles)
134
— — y y
( y
y
Page 135 of 281
ÛÝ´µ
´ µ
´
µ
The VOL button adjusts the volume
up ( ) or down ( ). Press the top
or bottom of the button, hold it until
the desired volume is reached, then
release it.
If youareplayingaCD,thesystem
skips to the beginning of the next
track each time you press the top
( ) of the CH button. Press the
bottom ( ) to return to the
beginning of the current track. Press
it twice to return to the previous
track. You will see the disc and track
numbers in the display.
If youareplayingatapeinthe
optional tape player, press the top
( ) of the CH button to advance to
the next selection. Press the bottom
( ) to go back to the previous
selection. The system senses a silent
period, then resumes playing.
The MODE button changes the
mode. Pressing the button
repeatedly selects FM1, FM2, AM,
XM1, XM2, CD, or a tape.
If you are listening to the radio, use
the CH button to change stations.
Each time you press the top ( ) of
the button, the system goes to the
next preset station on the band you
are listening to. Press the bottom
( ) to go back to the previous
station.
Three controls f or the audio system
are mounted in the steering wheel
hub. These let you control basic
f unctions without removing your
hand f rom the wheel.
U.S. SE, EX, EX-L, LX-V6 and EX-V6
Canadian EX-L, SE-V6 and EX-V6
Steering Wheel Controls
Features
141
MODE BUTTON
CH BUTTON
VOL BUTTON
— — y y
( y
y
Page 271 of 281
CONT INUED
....................................
Accessories . 162
ACCESSORY (Ignition Key
.......................................
Position) . 76
...............
Accessory Power Socket . 99
....................
Additives, Engine Oil . 204
...................................
Airbag (SRS) . 11
..........
Airbag System Components . 23
............................
Air Conditioning . 105
.........................................
Usage . 107
.......................
Air Pressure, Tires . 228
Anti-lock Brakes (ABS)
...............................
Indicator . 59, 180
...................................
Operation . 180
.
Anti-thef t Steering Column Lock . 78
........
Audio System . 114, 122, 131, 135
.............
Automatic Speed Control . 145
..............
Automatic Transmission . 173
..........................
Capacity, Fluid . 266
.......................................
Shif ting . 173
.
Shif t Lever Position Indicator . 173
................
Shif t Lever Positions . 173
....................
Shif t Lock Release . 176 ............................
Capacities Chart . 266
.............
Carbon Monoxide Hazard . 52
.............................
Carrying Cargo . 164
..............
CAUTION, Explanation of . ii
...................................
CD Changer . 128
.......................................
CD Player . 122
..........................
CD Pocket, Center . 99
........................
Certif ication Label . 264
............................................
Chains . 232
....................
Changing a Flat Tire . 239
Changing Oil
........................................
How to . 205
......................................
When to . 193
...
Charging System Indicator . 58, 251
............
Checklist, Bef ore Driving . 168
..................
Childproof Door Locks . 78
Battery
Charging System
...........................
Indicator . 58, 251
............................
Jump Starting . 245
..............................
Maintenance . 234
............................
Specif ications . 267
..............................
Bef ore Driving . 153
........................................
Belts, Seat . 10
Brakes
...........
Anti-lock System (ABS) . 180
.............
Break-in, New Linings . 154
...........................................
Fluid . 215
.........................................
Parking . 99
.........................
System Indicator . 59
........................
Wear Indicators . 179
.............................
Braking System . 179
........................
Break-in, New Car . 154
..
Brightness Control, Instruments . 72
........................
Brights, Headlights . 70
Bulb Replacement
..........................
Back-up Lights . 223
..............................
Brake Lights . 223
................
Front Parking Lights . 221
.................................
Headlights . 218 ............................
Specif ications . 267
............
Turn Signal Lights . 221, 222
..............................
Bulbs, Halogen . 218
Index
AB
C
INDEX
I
— — y
y
( y y
