set clock HONDA ACCORD 2006 CL7 / 7.G Owners Manual

ÛÝ
The climate control system f or your
vehicle can also be operated using
the voice control system. See the
Navi section in your Quick Start
Guide f or an overview of this system,
and the Navigation System manual
f or complete details.
Turn this dial to increase or decrease
the fan speed and airflow.
You can manually select the f an
speed by pressing the f an control
buttons. The f an speed is
represented by vertical bars in the
display. You can manually select the f an
speed by pressing the A/C button
next to the display and then,
pressing the f an control icons.
Turning this dial clockwise increases
the temperature of the airflow.
The driver and passenger can select
independent temperature settings by
selecting the DUAL button.
Push the DUAL button. When the
indicator in the button is on, turn the
dials to adjust the temperature.Press the DUAL button. The
indicator in the button will come on.
The driver and passenger can each
select the temperature control
buttons ( or ) to the
desired setting.
When the indicator in the DUAL
button is off, both sides adjust to the
driver’s side temperature.
Only on models equipped with
Navigation System EX-L and EX-V6 without Navigation
System
Except EX-L and EX-V6 with NavigationSystem
EX-L and EX-V6
EX-L and EX-V6 without NavigationSystem EX-L and EX-V6 with Navigation System
EX-L and EX-V6
EX-L and EX-V6 with Navigation System
U.S. VP, LX, SE, EX and LX-V6
Canadian DX-G, SE and SE-V6
Vents, Heating, and A/C
Voice Control System
Fan Control T emperature Control
104
——yy
(y
y

µµµ
CONT INUED
The
seek/skip f unction selects the
various categories in XM, such as
Jazz/Blues, Rock, Classical, etc.
Push the to change the
category f orward. Push the to
change the category backward. To
search f or channels within a
category, turn the TUNE knob
clockwiseorpresstheTUNEbar . The scan f unction samples
all channels f or 5 seconds. To
activate the f unction, push the SCAN
button. Push it again to get out of the
sequence.
Each preset icon or button
canstoreonechannelinXM1and
one in XM2.
Use the TUNE, SEEK or SCAN
function to tune the radio to a
desired channel.
Pick a preset icon or button and
hold it until you hear a beep.
Repeat steps 1 to 3 to store a total
of six stations on XM1 and XM2. Once your XM channels are preset,
pressing the CH DISC button will
select your preset channels.
Push the CD/AUX XM button.
(You will see XM1 or XM2.)
1. 2. 3. 4.For Vehicles with Navigation System
Playing the XM Satellite Radio
SEEK /SK IP (CA T EGORY) SCA N
Preset
Features
137
TM
——yy
(y
y

You can quickly set the time to the
nearest hour. Pressing and holding
the SOUND button, then pressing
theR(Preset6)sideof thebarsets
the clock back to the previous hour.
If the displayed time is after the half
hour, the clock sets the clock
f orward to the beginning of the next
hour.For example:
1:06 would RESET to 1:00.
1:52 would RESET to 2:00.
Ref er to the Navigation System
Owner’s Manual to set up the time.
Press and hold the SOUND button
until you hear a beep. The displayed
time begins to blink. Press on the H
(Preset 4) side of the bar until the
numbers advance to the desired time.
Change the minutes by pressing the
M (Preset 5) side of the bar until the
numbers advance to the desired time.
When you are f inished, press the
SOUND button again to set the time.
If your vehicle’s battery is
disconnected or goes dead, you will
need to set the clock.
For Vehicles without Navigation System
For Vehicles with Navigation System
Setting the Clock
Features
143
DIGITAL CLOCKSOUND BUTTON PRESET BARS
For Vehicles without Navigation System
——yy
(y
y

To remove the burned out bulb,
push it in and turn it
counterclockwise until it unlocks.
Install the new bulb and turn it
clockwise to lock it in place.
Insert the socket into the
headlight assembly. Turn it
clockwise to lock it in place.
Put the inner f ender cover in place.
Install and lock each holding clip
bypushingonthecenter.
Testthenewbulbtomakesureit
works.
Set the lining back.
Remove the socket by turning it
one-quarter turn counterclockwise,
and pull the bulb straight out of its
socket.
Push a new bulb straight into the
socket until it bottoms, and
reinstall the socket into the light
assembly by turning it clockwise
until it locks.
Open the trunk.
Remove the holding clips f rom the
lining by using a f lat-tipped
screwdriver.
Testthenewbulbtomakesureit
works.
5. 6. 7. 8. 9.
2.
1.
4.
3. 5. 6.
Lights
Replacing Rear T urn Signal L ight Bulbs
222
HOLDING CLIPS
BULB
SOCKET
——yy
(yy

Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.
Start the engine and set the
temperature control dial to
maximum (climate control to
FULL AUTO at 90°F/32°C). Add
coolant to the radiator up to the
base of the f iller neck. If you do
not have the proper coolant
mixture available, you can add
plain water. Remember to have
the cooling system drained and
ref illed with the proper mixture as
soon as you can.Put the radiator cap back on
tightly. Run the engine, and watch
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (see
on page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
If you do not f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator.
7.
6.
8. 9.10. 11.
255
Emergency
Towing
If theEngineOverheats
T aking Care of t he Unexpect ed
249
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
——yy
(yy

.......................................
Child Seats . 34
...........
Lower Anchorage Points . 43
..........
Tether Anchorage Points . 47
..............
Climate Control Sensors . 113
.........................
Clock, Setting the . 143
...................................
Clutch Fluid . 216
........................
CO in the Exhaust . 274
............
Cold Weather, Starting in . 169
..............................
Compact Spare . 238
...................
Console Compartment . 99
.................
Consumer Inf ormation . 280
.............
Controls, Instruments and . 55
Coolant
........................................
Adding . 208
....................................
Checking . 160
.........................
Proper Solution . 208
...................
Temperature Gauge . 65
Crankcase Emissions Control ........................................
System . 274
............
Cruise Control Operation . 145
.............
Customer Service Of f ice . 280
................
DANGER, Explanation of . ii
...................................
Dashboard . 4, 56 ................
Daytime Running Lights . 70
............
Def ects, Reporting Saf ety . 282
................
Def ogger, Rear Window . 72
....................................
Dimensions . 266
...............
Dimming the Headlights . 69
Dipstick
.
Automatic Transmission . 210, 211
..................................
Engine Oil . 159
..........................
Directional Signals . 69
........
Disc Brake Wear Indicators . 179
.....................
Disposal of Used Oil . 206
Doors
..............
Locking and Unlocking . 77
..........
DOT Tire Quality Grading . 269
Downshif ting, Manual
.............................
Transmission . 170
...........
Driver and Passenger Safety . 7
...........................................
Driving . 167
....................................
Economy . 161
..........
Dual Temperature Control . 111
..............................
Economy, Fuel . 161
............
Emergencies on the Road . 237
.............
Battery, Jump Starting . 245 ...........
Brake System Indicator . 253
................
Changing a Flat Tire . 239
.....
Charging System Indicator . 251
..................
Checking the Fuses . 257
.....
Low Oil Pressure Indicator . 250
...
Malf unction Indicator Lamp . 251
...
Manually Closing Moonroof . 254
..................
Overheated Engine . 248
...........................
Emergency Brake . 95
......................
Emergency Flashers . 71
......................
Emergency Towing . 255
.......................
Emissions Controls . 274Engine
....
Coolant Temperature Gauge . 65
Malf unction Indicator
......................................
Lamp . 251
.......................
Oil Lif e Indicator . 193
..............
Oil Pressure Indicator . 250
..............
Oil, What Kind to Use . 203
...............................
Overheating . 248
............................
Specif ications . 266
....................
Speed Limiter . 172, 175
.......................................
Starting . 169
..........
Engine Speed Limiter . 172, 175
.
Evaporative Emissions Controls . 274
...............................
Exhaust Fumes . 52
Index
D E
II
——y

y
(yy

µ
µ
......................................
Saf ety Belts . 10
............
Safety Defects, Reporting . 282
.................................
Saf ety Features . 9
.........................................
Airbags . 11
.....................................
Seat Belts . 10
.............
Saf ety Labels, Location of . 53
...............................
Saf ety Messages . ii
................................
Satellite Radio . 135
.........................................
Seat Belts . 10
...............
Additional Information . 20
Automatic Seat Belt
...............................
Tensioners . 21
......................
Lap/Shoulder Belt . 20
................................
Maintenance . 22
Reminder Light and
................................
Beeper . 20, 58
...................
System Components . 20
...............
Use During Pregnancy . 18
...
Wearing a Lap/Shoulder Belt . 20
................
Seats, Adjusting the . 85 87
............................
Security System . 144
.....................
Selecting a Child Seat . 41
...............................
Serial Number . 264
....................
Service Minder . 193 198 .............................
Service Manual . 283
...........
Service Station Procedure . 156
..........................
Setting the Clock . 143
.....
Shif t Lever Position Indicator . 173
........................
Shif t Lock Release . 176
..............................
Side Airbags . 11, 28
...
How Your Side Airbags Work . 28
How the Side Airbag Of f
......................
Indicator Works . 29
................
Side Curtain Airbags . 11, 30
How Your Side Curtain ..........................
Airbags Work . 30
...............................
Signaling Turns . 69
.....................................
Snow Tires . 232
.......
Sound System . 114, 122, 131, 135
Spare Tire
......................................
Inf lating . 238
............................
Specif ications . 268
....................
Specif ications Charts . 266
................................
Speed Control . 145
........................
Speed Limiter . 172, 175
...................................
Speedometer . 64
..........
SRS, Additional Inf ormation . 23
...
Additional Safety Precautions . 33
.............................
Airbag Service . 32 How the Passenger Airbag Of f
......................
Indicator Works . 31
How Your SRS Indicator .......................................
Works . 30
How Your Front Airbags .......................................
Works . 25
How Your Side Airbags .......................................
Works . 28
........................
SRS Components . 23
.............................
SRS Indicator . 30, 59
....
START (Ignition Key Position) . 76
.......................
Starting the Engine . 169
................
With a Dead Battery . 245
........
Steam Coming f rom Engine . 248
Steering Wheel
..................................
Adjustment . 73
.............
Anti-theft Column Lock . 76
Stereo Sound ...............
System . 114, 122, 131, 135
..........................................
Sun Visor . 96
........................
Sunglasses Holder . 100
Supplemental Restraint
................................
System . 11, 23
......................................
Servicing . 32
.........................
SRS Indicator . 30, 59
...................
System Components . 23
Index
S
VI
——y

y
(y
y
