Page 251 of 292
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action. Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(see on page
). If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
1. 2. 3. 4.
204
159
262
L ow Oil Pressure Indicator
Emergency T owingCharging System Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
253
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
— —
y
y
( y y
Page 252 of 292
If your vehicle has an automatic
transmission, the malf unction
indicator lamp may also come on
with the ‘‘D’’ indicator.
If you have recently ref ueled your
vehicle, the indicator coming on
could be due to a loose or missing
f uel f ill cap. You will also see a
‘‘CHECK FUEL CAP’’ message on
the inf ormation display. Tighten the
cap until it clicks at least once.
Tightening the cap will not turn the
indicator of f immediately; it can take
several days of normal driving. If the indicator comes on repeatedly,
even though it may go of f as you
continue driving, have your vehicle
checked by a dealer as soon as
possible.
If this indicator comes on
while driving, it means one
of the engine’s emissions control
systems may have a problem. Even
though you may f eel no dif f erence in
your vehicle’s perf ormance, it can
reduce your f uel economy and cause
increased emissions. Continued
operation may cause serious damage.
Yo ur vehic le has c ertain ‘‘readiness
c o des’’ that are part o f the o n-bo ard
diag no stic s fo r the emissio ns
systems. In so me states and
pro vinc es, part o f the emissio nstesting is to make sure
thesec o des
are set. If they are no t set, the test
c anno t be c o mpleted.
If the battery in your vehicle has
been disconnected or gone dead,
these codes are erased. It can take
several days of driving under various
conditions to set the codes again.
To check if they are set, turn the
ignition switch to the ON (II)
position, without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks f ive times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissio ns test until the readiness
c o des are set. Refer to Em is s ions
for more info rmatio n
info rmatio n ( see pag e ) .
277
Readines s Codes Tes ting
Malf unct ion Indicat or L amp
254
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
— —
y
y
( y y
Page 253 of 292
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.If the ABS indicator comes on with
this indicator, have the vehicle
inspected by your dealer
immediately.
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (see
on page ).
The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and as
a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads/shoes. 215 262
Emergency
Towing
Brake System Indicator
T aking Care of t he Unexpect ed
255
U.S. Canada
— —
y
y
( y y
Page 254 of 292
Use a screwdriver or coin to
remove the round plug in the
center of the headliner.
Insert the moonroof wrench into
the socket behind this plug. Turn
the wrench until the moonroof is
f ully closed.
Remove the wrench. Reinstall the
round plug.If you need to close the moonroof
manually, it means the moonroof
opening/closing f unction is
developing a problem. Have your
vehicle checked by your dealer.
Get the moonroof wrench out of
the tool kit in the trunk.
Try closing the moonroof . If the
new f use blows immediately or the
moonroof motor still does not
operate, you can close the
moonroof manually.
Check the f use f or the moonroof
motor (see page ). If the f use
is blown, replace it with one of the
same or lower rating.
If the electric motor will not close
the moonroof , do the f ollowing:
5. 6.4.
3.
1.2.
261
If equipped
Closing t he Moonroof
256
ROUND PLUG
SOCKET
— —
y
y
( y
y
Page 255 of 292
The interior f use box is on the
driver’s lower lef t side. To remove
the f use box lid, pull it toward you
and take it out of its hinges.The under-hood f use box is located
near the back of the engine compart-
ment on the driver’s side. To open it,
pushthetabsasshown.If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages
and , or the diagram on the
f use box lid, which f use or f uses
control that component. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
not the cause. Replace any blown
f uses and check if the device works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.
1. 2. 261
260
CONT INUED
Fuses
Checking and Replacing Fuses
T aking Care of t he Unexpect ed
257
INTERIOR UNDER-HOOD
TAB
— —
y
y
( y y
Page 256 of 292
Check each of the large f uses in
the under-hood f use box by
looking at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the under-hood
fuse box.
Look f or a burned wire inside the
f use. If it is burned out, replace it
withoneof thesparefusesof the
same rating or lower.
3.
4. 5.
Fuses
258
BLOWN
BLOWN BLOWN
— —
y
y
( y y
Page 257 of 292
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits with
the f use puller provided in the under-
hood f use box. Make sure you can
do without that circuit temporarily
(such as the accessory power socket
or radio).If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
6.
Fuses
T aking Care of t he Unexpect ed
259
FUSE PULLER
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
— —
y
y
( y y
Page 258 of 292
ÎÎ Î Î
Î
Î
Î
Î
µ µ
´
Î Î Î
No. Amps. Circuits Protected No. Amps. Circuits Protected No. Amps. Circuits Protected
1234567
10 A
(30A)
10 A
15 A
10 A
10 A
7.5 A Left Headlight Low
(Rear Defroster Coil)
Left Headlight Hi
Small Light
Right Headlight Hi
Right Headlight Low
Back Up 89
1011 12 13 15 A
20 A
20 A
30 A
7.5 A 20 A FI ECU
Condenser fan
Not Used
Cooling Fan
Cooling Fan
MG. Clutch
Horn, Stop 14151617 1819 202122 23
40 A
40 A
15 A
30 A
30 A
20 A
40 A
40 A
40 A
40 A
100 A
50 A
50 A Rear Defroster
Back Up, ACC
Hazard
ABS Motor
VSA Motor
ABS F/S
VSA
Driver’s Power Seat
Passenger’s Power Seat
Heater Motor
Battery
Not Used
BIG1Main
Power Window Main
1: 2:
3 :
V6 mo dels 4-c ylinder mo dels
Canadian SE, EX-L, and V6 mo dels
U.S. EX, EX-L, and V6 mo dels
1
23 2
3
2
3
1
Fuse Locations
260
UNDER-HOOD FUSE/RELAY BOX
— —
y
y
( y y
Page 259 of 292
µµ µµ
Î
Î
Î
Î Î
Î
Î
No. Circuits Protected No. Amps. No. Amps.
Amps. Circuits Protected
Circuits Protected
1 2345678 DrivebyWire
Ignition Coil
Day Light
Laf Heater
Radio
Interior Light
Back-Up Lights
Door Lock 9
10111213 14 15 15 A
7.5 A 30 A
(20 A)
(20 A)
(20 A) 161718192021222324252627282930313233
(20 A)
(20 A)
15 A
15 A
7.5 A
7.5 A
10 A
7.5 A
(20 A)
(20 A) 20 A
20 A
(20 A)
7.5 A
7.5 A
(15 A)
15 A
(10 A) 15 A
10 A
7.5 A 10 A
(20 A) Driver’s Power Seat Recline
Passenger’s Power Seat Slide
ACG
Fuel Pump
Washer
Meter
SRS
IGP
Left Rear Power Window
Right Rear Power Window
Passenger’s Power Window
Driver’s Power Window
Moonroof
Not Used
IG A/C
Not Used
ACC
Not Used
Front Accessory SocketsOPDS
Wiper
Not Used
Passenger’s Power Seat
Recline
Driver’s Power Seat Slide
Heated Seat :
U.S. EX, EX-L and V6 mo dels
Canadian SE, EX-L, and V6 mo dels
Fuse Locations
T aking Care of t he Unexpect ed
261
INTERIOR FUSE BOX
— —
y
y
( y y
Page 260 of 292
µµ
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
The operator
loads your vehicle on the back of a
truck.
Therearetwowaystotowyour
vehicle: If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Release the parking brake.
Shif t the transmission to neutral.
The tow
truck uses two pivoting arms that go
under the tires (f ront) and lif t them
of f the ground. The other two tires
remain on the ground. Turn of f the engine.
ShifttoD,thentoN.
Start the engine.
Release the parking brake.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock. With the f ront wheels on the ground,
do not tow the vehicle more than 50
miles (80 km), and keep the speed
below35mph(55km/h).
Manual transmission:
Automatic transmission:
Flat -bed Equipment
Wheel-lif t Equipment
T his is the best way to
transport your vehicle.
T his is an
acceptable way to tow your
vehicle.
Emergency Towing
262
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
vehicle must be transported with the
f ront wheels of f the ground.
— —
y
y
( y y
