octane HONDA ACCORD COUPE 2001 CF / 6.G Owners Manual

Break-in Period, Gasoline, Service Station Procedures

Break-in Period
Help assure your car's future
reliability and performance by paying
extra attention to how you drive
during the first 600 miles (1,000 km).
During this period: Avoid full-throttle starts and rapid

acceleration.
Avoid hard braking. New brakes
need to be broken-in by moderate
use for the first 200 miles (300
km).

Do not change the oil until the

recommended time or mileage

interval shown in the maintenance
schedule.

You should follow these same re-
commendations with an overhauled
or exchanged engine, or when the

brakes are relined.
Gasoline

Your Honda is designed to operate on unleaded gasoline with a pump
octane number of 86 or higher. Useof a lower octane gasoline can cause
a persistent, heavy metallic rapping
noise in the engine that can lead to
mechanical damage.
We recommend gasolines containing detergent additives that help prevent
fuel system and engine deposits. Using gasoline containing lead willdamage your car's emissions
controls. This contributes to air
pollution.
In Canada, some gasolines contain
an octane-enhancing additive called
MMT. If you use such gasolines,
your emission control system performance may deteriorate and
the Malfunction Indicator Lamp on
your instrument panel may turn on.If this happens, contact your
authorized Honda dealer for service. Filling the Fuel Tank
1. Because the fuel fill cap is on the driver's side of the car, park with
that side closest to the service

station pumps.

2. Open the fuel fill door by pushing on the handle to the left of the
driver's seat.
Before Driving

Maintenance Schedule

The Maintenance Schedule specifies how often you should have your carserviced and what things need
attention. It is essential that you have
your car serviced as scheduled to retain its high level of safety,dependability, and emissions control
performance.
The services and time or distance
intervals shown in the maintenanceschedule assume you will use your
vehicle as normal transportation for passengers and their possessions.
You should also follow these
recommendations:

Avoid exceeding your car's loadlimit. This puts excess stress onthe engine, brakes, and many
other parts of your car. The load
limit is shown on the label on thedriver's doorjamb.
Operate your car on reasonableroads within the legal speed limit.
Drive your car regularly over a
distance of several miles (kilometers).
Always use unleaded gasoline with the proper octane rating (see page
178). Which Schedule to Follow:
Service your car according to the
time and mileage periods on one of the Maintenance Schedules on the
following pages. Select the schedule for "Severe Conditions" if most of
your driving is done under one or more of the conditions listed on that
page. Otherwise, follow the schedule
for "Normal Conditions."

Maintenance

Oxygenated Fuels

Some conventional gasolines are
being blended with alcohol or an
ether compound. These gasolines

are collectively referred to as

oxygenated fuels. To meet clean air
standards, some areas of the United

States and Canada use oxygenated

fuels to help reduce emissions.

If you use an oxygenated fuel, be

sure it is unleaded and meets the

minimum octane rating requirement.

Before using an oxygenated fuel, try

to confirm the fuel's contents. Some
states/provinces require this
information to be posted on the
pump.
The following are the U.S. EPA and
Canadian CGSB approved
percentages of oxygenates:
ETHANOL (ethyl or grain alcohol)
You may use gasoline containing up to 10 percent ethanol by volume.Gasoline containing ethanol may be
marketed under the name "Gasohol."
MTBE (Methyl Tertiary Butyl
Ether)
You may use gasoline containing up
to 15 percent MTBE by volume.
METHANOL (methyl or wood
alcohol)

Your vehicle was not designed to use fuel that contains methanol.Methanol can corrode metal parts in
the fuel system, and also damage
plastic and rubber components. This damage would not be covered by
your warranties. If you notice any undesirable
operating symptoms, try another
service station or switch to another
brand of gasoline.
Fuel system damage or performance
problems resulting from the use ofan oxygenated fuel containing more
than the percentages of oxygenates
given above are not covered under
warranty.
Technical Information

Driving in Foreign Countries

If you are planning to take yourHonda outside the U.S. or Canada,
contact the tourist bureaus in the
areas you will be traveling in to find
out about the availability of unleaded
gasoline with the proper octane

rating.

If unleaded gasoline is not available,
be aware that using leaded gasoline in your Honda will affect perfor-mance and fuel mileage, and damage
its emissions controls. It will no
longer comply with U.S. andCanadian emissions regulations, and
will be illegal to operate in North America. To bring your car back into compliance will require the replace-
ment of several components, such as
the oxygen sensors and the three
way catalytic converter. These re- placements are not covered under
warranty.
Technical Information

Index
Driving............................................ 191 Economy..................................... 185
In Bad Weather.......................... 209
In Foreign Countries................. 332
Economy, Fuel............................... 185
Emergencies on the Road............. 295 Battery, Jump Starting.............. 304
Brake System Indicator............ 313Changing a Flat Tire................. 297
Charging System Indicator...... 310
Checking the Fuses................... 316
Low Oil Pressure Indicator...... 309
Malfunction Indicator Lamp.... 311 Manually Closing Moonroof.... 314
Overheated Engine................... 307
Emergency Brake.......................... 101
Emergency Flashers....................... 66
Emergency Towing....................... 320
Emissions Controls........................ 333
Engine
Belts.............................................266

Coolant Temperature Gauge ..... 59 Malfunction Indicator
Lamp................................. 55, 311
Oil Pressure Indicator......... 54, 309 Oil, What Kind to Use............... 234
Overheating................................ 307
Specifications............................. 327
Speed Limiter..................... 196, 200
Starting........................................ 193
Engine Speed Limiter........... 196, 200
Ethanol in Gasoline ....................... 331
Evaporative Emissions Controls.. 333
Exhaust Fumes................................ 49
Expectant Mothers, Use of Seat Belts by......................................... 17
Exterior, Cleaning the................... 290
Fabric, Cleaning............................. 291

Fan, Interior.................................... 110

Features, Comfort and Convenience............................... 109

Filling the Fuel Tank..................... 178
Filter
Air Conditioning........................ 266
Oil................................................ 234 5-speed Manual Transmission
Checking Fluid Level................ 249
5-speed Manual Transmission Shifting the................................. 195
Flashers, Hazard Warning.............. 66
Flat Tire, Changing a.................... 297
Fluids Automatic Transmission .. 247, 248
Brake...........................................251
Clutch.......................................... 252
Manual Transmission............... 249 Power Steering........................... 252
Windshield Washer................... 246
FM Stereo Radio Reception.................................... 158
Folding Rear Seat............................ 92
Foreign Countries, Driving in...... 332
Four-way Flashers........................... 66
Fuel.................................................. 178 Fill Door and Cap....................... 178Gauge............................................ 58
Octane Requirement................. 178
Oxygenated................................ 331
Tank, Filling the......................... 178
Fuses, Checking the...................... 316
CONTINUED

Index

Headlights......................................... 62Aiming......................................... 276
Automatic Lighting Off............... 63Daytime Running Lights............. 63
Lights On Indicator..................... 53
Low Beams, Turning on............. 62
Reminder Chime.......................... 62
Replacing Halogen Bulbs ......... 278

Turning on.................................... 62

Head Restraints............................... 92
Heating and Cooling...................... 110
High Altitude, Starting at.............. 194
HomeLink Universal Transmitter.................................. 83
Hood, Opening the ........................ 180
Hydraulic Clutch............................ 252
Hydroplaning.................................. 210
Identification Number, Vehicle.... 326
Ignition

Keys............................................... 71

Switch............................................ 73

Timing Control System............. 336

Immobilizer System......................... 72
Important Safety Precautions.......... 6
Indicators, Instrument Panel.......... 53
Infant Restraint................................ 28

Infant Seats....................................... 28
Tether Anchorage Points........... 39
Inflation, Proper Tire .................... 268
Inside Mirror.................................... 98

Inspection, Tire.............................. 270

Instrument Panel............................. 53
Instrument Panel Brightness......... 63 Interior Cleaning............................ 290
Interior Lights................................ 106
Introduction......................................... i

Jacking up the Car......................... 209

Jack, Tire........................................ 298

Jump Starting................................. 304
Keys................................................... 71

Gas Mileage, Improving................ 185

Gasohol........................................... 331

Gasoline.......................................... 178

Gauge............................................ 58

Octane Requirement................. 178

Tank, Filling the......................... 178

Gas Station Procedures................. 178

Gauges
Engine Coolant Temperature .... 59
Fuel................................................59

Speedometer................................ 58
Tachometer.................................. 58
Gearshift Lever Positions Automatic Transmission........... 1975-speed Manual Transmission.......................... 195
Glass Cleaning............................... 292
Glove Box......................................... 82

Halogen Headlight Bulbs.............. 278
Hazard Warning Flashers............... 66

Index

Label, Certification........................ 324
Lane Change, Signaling.................. 64
Lap/Shoulder Belts......................... 40
Lights Bulb Replacement..................... 278
Indicator........................................ 53
Parking.......................................... 62
Turn Signal................................... 64
LOCK (Ignition Key Position)....... 73

Locks
Anti-theft Steering Column........ 73Fuel Fill Door............................. 178Glove Box..................................... 82
Power Door.................................. 75

Trunk............................................
80

Low Coolant Level......................... 184

Lower Gear, Downshifting to a.... 195

Low Oil Pressure Indicator.... 52, 309

Lubricant Specifications Chart.... 326

Luggage.......................................... 188
Maintenance................................... 219
Owner Maintenance Checks.... 231

Record......................................... 229

Required Indicator....................... 60

Safety...........................................220

Schedule............................
224 -
228

Malfunction Indicator Lamp.. 55, 311
Manual Transmission.................... 195
Manual Transmission Fluid ......... 249
Meters, Gauges................................ 57
Methanol in Gasoline.................... 331
Mirrors, Adjusting......................... 100
Moonroof.......................................... 88
Closing Manually....................... 314
Operation...................................... 98

Neutral Gear Position.................... 198

New Vehicle Break-in................... 178

Normal Shift Speeds...................... 196

NOTICE, Explanation of................... ii

Numbers, Identification................ 324
Octane Requirement, Gasoline.... 178
Odometer.......................................... 58

Odometer, Trip................................ 59

Oil Change, How to ......................... 235
Change, When to....................... 224
Checking Engine....................... 182
Pressure Indicator............... 54, 309
Selecting Proper Viscosity Chart....................................... 235
ON (Ignition Key Position) ............ 74
Operation in Foreign Countries... 332 Outside Mirrors............................... 99
Overheating, Engine..................... 306
Owner Maintenance Checks........ 231
Oxygenated Fuel........................... 331

Panel Brightness Control............... 63

Park Gear Position......................... 198

Parking............................................ 202

CONTINUED

Service Information Summary

Gasoline:

Unleaded gasoline, pump octane
number of 86 or higher.
Fuel Tank Capacity:
17.12 US gal (64.8 l, 14.26 Imp gal)
Recommended Engine Oil:
API Premium grade 5W-20
detergent oil (see page 235 ).
Oil change capacity (including

filter):

4-cylinder models
4.5 US qt (4.3 l, 3.8 imp qt)
6-cylinder models4.6 US qt (4.4 l, 3.9 Imp qt)
Automatic Transmission Fluid:
Honda ATF-Z1 (Automatic
Transmission Fluid) preferred,

or a DEXRON® III ATF as a
temporary replacement (see

pages 247 and 248).

5-speed Manual Transmission

Fluid:

Honda Manual Transmission
Fluid preferred, or an API service
SG, SH or SJ, SAE 10W-30 or
10W- 40 motor oil as a temporary
replacement (see page 249).
Capacity:
2.0 US qt (1.9 l,1.7 Imp qt)
Power Steering Fluid:
Honda Power Steering Fluid
preferred, or another brand
of power steering fluid as a
temporary replacement. Do not

use ATF (see page 252).

Brake Fluid:
Honda DOT 3 Brake Fluid
preferred, or a DOT 3 or DOT 4
brake fluid as a temporary
replacement (see page 251).
Tire Pressure (measured cold):

DX

29 psi (200 kPa , 2.0 kgf/cm2)

LX,
EX,
LX
V-6,
EX V-6
30 psi (210 kPa , 2.1 kgf/cm2)
