The under-hood fuse box is on the
driver’s side. To open it, push the
tabs as shown. If
something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine from the chart on pages
and , or the diagram on the
f use box lid, which f use or f uses
control that device. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
the cause. Replace any blown f uses,
and check if the device works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
The interior f use box is on the
driver’s lower lef t side. To remove
the f use box lid, put your f inger in
the notch on the lid, and pull it
upward slightly, then pull it toward
you and take it out of its hinges. The vehicle’s f uses are contained in
two f use boxes.
Remove the cover f rom the f use
box.
1.
2. 283 284
Checking and Replacing Fuses
Fuses
280
INTERIOR
UNDER-HOOD
TAB
NOTCH
