Page 361 of 395
µµ µ
Automatic Transmission:
5-speed Manual Transmission:
There are three popular types of
prof essional towing equipment.
The operator
loads your car on the back of a truck.
The tow
truck uses two pivoting arms that go
under the tires (f ront or rear) and lif t
them of f the ground. The other two
tires remain on the ground. The tow
truck uses metal cables with hooks
on the ends. These hooks go around
parts of the f rame or suspension and
the cables lif t that end of the car of f
the ground. Your car’s suspension
and body can be seriously damaged.
If your Honda cannot be transported
by f lat-bed, it should be towed by
wheel-lif t equipment with the f ront
wheels of f the ground. If due to
damage, your car must be towed
with the f ront wheels on the ground,
do the f ollowing:
Release the parking brake.
Shif t the transmission to Neutral. With the f ront wheels on the ground,
it is best to tow the car no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
If your car needs to be towed, call a
prof essional towing service or, if you
belong to one, an organization that
provides roadside assistance. Never
tow your car behind another vehicle
with just a rope or chain. It is very
dangerous.
Release the parking brake.
Start the engine.
ShifttoD,thentoN.
Turn of f the engine.
Flat -bed EquipmentWheel-lif t Equipment Sling-t ype Equipment
This is the best way to transport
your Honda.
T his is
an acceptable way to tow your
Honda. T his method of towing is
unacceptable.
Emergency T owing
T aking Care of t he Unexpect ed358
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
car must be transported with the f ront
wheels of f the ground.
Page 362 of 395
If you decide to tow your car with all
f our wheels on the ground, make
sure you use a properly-designed and
attached tow bar. Prepare the car for
towing as described above, and leave
the ignition switch in Accessory (I)
so the steering wheel does not lock.
Make sure the radio and any items
plugged into the accessory power
socket are turned of f so they do not
rundownthebattery.
Emergency T owing
T aking Care of t he Unexpect ed359
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in Accessory (I), and
make sure the steering wheel turns
f reely bef ore you begin towing.Trying to lif t or tow your car by the
bumpers will cause serious damage.
The bumpers are not designed to
support the car’s weight.
Page 363 of 395
360
Page 364 of 395
Thediagramsinthissectiongive
you the dimensions and capacities of
your Honda, and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your car’s tires and
emissions control systems.................
Identif ication Numbers . 362
................................
Specif ications .364
DOT Tire Quality Grading ............................
(U.S.Cars) .367
.................................
Treadwear .367
......................................
Traction .367
.............................
Temperature .368 .........................
Oxygenated Fuels .369
......
Driving in Foreign Countries . 370
.......................
Emissions Controls .371
.....................
The Clean Air Act .371
Crankcase Emissions Control ....................................
System .371
Evaporative Emissions Control ....................................
System .371
Onboard Ref ueling Vapor ................................
Recovery .371
...
Exhaust Emissions Controls . 372
....................
PGM-FI System .372
Ignition Timing Control ................................
System .372
Exhaust Gas Recirculation ...................
(EGR) System . 372
Three Way Catalytic ...........................
Converter .372
....................
Replacement Parts . 372
..
Three Way Catalytic Converter . 373
..............
State Emissions Testing . 374
T echnical Inf ormat ion
T echnical Inf ormation361
Page 365 of 395
Your car has several identif ying
numbers located in various places.
The Vehicle Identif ication Number
(VIN) is the 17-digit number your
Honda dealer uses to register your
car f or warranty purposes. It is also
necessary f or licensing and insuring
your car. The easiest place to find
the VIN is on a plate fastened to the
top of the dashboard. You can see it
by looking through the windshield
on the driver’s side. It is also on the
Certification label attached to the
driver’s doorjamb, and is stamped on
the engine compartment bulkhead.
The VIN is also provided in bar code
on the Certification label.
Identif ication Numbers
T echnical Inf ormation362
VEHICLE IDENTIFICATION NUMBERCERTIFICATION LABEL
Page 366 of 395
The Transmission Number is on a
label on top of the transmission. The Engine Number is stamped into
the engine block. It is on the f ront.
Identif ication Numbers
T echnical Inf ormation
4-cylinder Models6-cylinder Models
363
AUTOMATIC TRANSMISSION NUMBER
ENGINE NUMBER
AUTOMATIC TRANSMISSION NUMBER
MANUAL
TRANSMISSION
NUMBER ENGINE
NUMBER
Page 367 of 395
µµ
µµ
Î Î
Î
Î
ÎÎ
Î
Î
Î
Î
Î
Î
Specif ications
T echnical Inf ormation364
Capacities
Weights
Air Conditioning
Capacities Dimensions 1.35 US gal (5.1
)
1.32 US gal (5.0)
1.90 US gal (7.2
)
4.4 US qt (4.2
)
4.2 US qt (4.0
)
5.6 US qt (5.3
)
2.0 US qt (1.9
)
2.2 US qt (2.1)
2.6 US qt (2.5
)
Excluding the oil remaining in the engine. Including the coolant in the reserve tank and that remaining in the
engine.
Reserve tank capacity: 0.16 US gal (0.6
)
Engine
coolant
Engine oil
Manual trans-
mission oil
Automatic
transmission
fluid
Windshield
washer
reservoir
1.77 US gal (6.7
)
1.88 US gal (7.1
)
2.22 US gal (8.4)
4.5 US qt (4.3
)
5.3 US qt (5.0
)
3.0 US qt (2.8
)
3.1 US qt (2.9)
6.9 US qt (6.5)
7.6 US qt (7.2)
4.8 US qt (4.5
)
189.5 in (4,813 mm)
71.7 in (1,820 mm)
57.2 in (1,453 mm)
Gross vehicle weight rating See the certification label attached to the driver’s doorjamb.
HFC-134a (R-134a)
25 27 oz (700 750 g)
16 18 oz (450 500 g) ND-OIL8
Refrigerant type
Charge quantity
Lubricant type
Fuel tank
17.09 US gal (64.7
)
Length
Width
Height
Wheelbase
Track
107.9 in (2,740 mm)
61.1 in (1,553 mm)
61.2 in (1,554 mm)
Approx.
Front
Rear
1 : 6-cylinder models Change
Manual
Automatic
Total Manual
Automatic
Change Including
filter
Without
filter
Total
Change
Total
Change
Total
U.S. Cars
Canada Cars
2:
3:
2
3 1
1
1
1
1
1
1
Page 368 of 395
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Î Î
Î
Î
Î
Î
Î
CONT INUED
Specif ications
T echnical Inf ormation365
Fuses Battery Lights
Alignment Engine3.43 x 3.9 in (87.0 x 99.0 mm)143.6 cu-in (2,354 cm
)
12 V 60 W (HB3)
12 V 51 W (HB4)
12 V 24/2.2 CP
9.7 : 1
3.39 x 3.39 in (86.0 x 86.0 mm)
182.8 cu-in (2,997 cm)
10 : 1
12 V
12 V
12 V
12 V 12 V
12 V
12 V 21 W
21/5 W
3CP
21 W
21 W
3CP
8W
Interior
Under-hood 52 AH/5 HR 38 AH/5 HR
12 V
12 V
Capacity 12 V 12 V
12 V
1.1 W
2CP
5W 8W
8W
12 V 12 V
Headlights
Front turn signal/
Front parking lights
Rear turn signal lights
Stop/Taillights
Taillights
High-mount brake light
Back-up lights
License plate light
Ceiling light
Spotlights
Spotlights/Front ceiling lights
Trunk light
Door courtesy light
Vanity mirror lights
Toe-in
Camber
Caster Type
BorexStroke
Displacement
Compression ratio
Spark plugs
0.00 in (0.0 mm)
0.08 in (2.0 mm)0°1°
3°15’
See page 357or the fuse label
attached to the inside of the fuse
box door on each side of the
dashboard.
See page 356or the fuse box
cover. See spark plug maintenance sec-
tion pages 291 and 293 .
Water cooled 4-stroke, DOHC
i-VTEC 4-cylinder, SOHC VTEC
6-cylinder (V6), gasoline engine
Front
Rear
Front
Rear
Front
High
Low
4-cylinder
6-cylinder
1: LX
2: EX (Amber)
3 : 6-cylinder models33
3
1
2
Page 369 of 395
Î
Î
ÎÎ
Î
Î
Î
Î
Î
Î
Specif ications
T echnical Inf ormation366
Tires T135/90D15
P195/65R15 89H
P205/60R16 91V
P205/65R15 92H
Size
Pressure
30 psi (210 kPa , 2.1 kgf/cm
)
32 psi (220 kPa , 2.2 kgf/cm)
30 psi (210 kPa , 2.1 kgf/cm
)
60 psi (420 kPa , 4.2 kgf/cm
)
29 psi (200 kPa , 2.0 kgf/cm)
Front/Rear
Spare
Front
Rear
Spare
1: DX
2: LX
3 : All EX and V6 models
1
2
3
1, 3
2
1, 3
2
Page 370 of 395
µ
The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under controlled
conditions on a specif ied government
test course. For example, a tire
graded 150 would wear one and one-
half (1 1/2) times as well on the
government course as a tire graded
100. The relative perf ormance of
tires depends upon the actual condi-
tions of their use, however, and may
depart signif icantly f rom the norm
due to variations in driving habits,
service practices and dif f erences in
road characteristics and climate. The traction grades, f rom highest to
lowest, are AA, A, B, and C. Those
grades represent the tire’s ability to
stop on wet pavement as measured
under controlled conditions on
specif ied government test surf aces
of asphalt and concrete. A tire
marked C may have poor traction
perf ormance.
Warning: The traction grade
assignedtothistireisbasedon
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
All passenger car tires must conf orm
to Federal Saf ety Requirements in
addition to these grades. Quality grades can be f ound where
applicable on the tire sidewall
between the tread shoulder and the
maximum section width. For
example: The tires on your car meet all U.S.
Federal Saf ety Requirements. All
tires are also graded for treadwear,
traction, and temperature perform-
ance according to Department of
Transportation (DOT) standards.
The f ollowing explains these
gradings.
T echnical Inf ormation
Treadwear Traction AA, A, B, C
T readwear 200
Traction AA
Temperature A
Unif orm T ire Quality Grading
DOT T ire Quality Grading (U.S. Cars)
367
