radio controls HONDA ACCORD SEDAN 2008 Owner's Manual (in English)

The heating and air conditioning
system in your vehicle provides a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to dis-
courage vandalism and thef t of your
vehicle..............
Vents, Heating, and A/C .120
...............
Climate Control System .125
..........
Dual Temperature Control .130
..............
Climate Control Sensors .132
................................
Audio System .133
..........
Playing the FM/AM Radio .134
................................
Playing a Disc .141
.......
Disc Player Error Messages .148
................................
Audio System .149
..........
Playing the FM/AM Radio .150
.
Playing the XM
Satellite Radio .157
.................................
Playing Discs .163
...
Disc Changer Error Messages .173
................................
Audio System .174
..........
Playing the FM/AM Radio .175
.
Playing the XM
Satellite Radio .187
.................................
Playing Discs .194
...
Disc Changer Error Messages .205
..................
Protecting Your Discs .206
............
FM/AM Radio Reception .209
................
Remote Audio Controls .211
......................
Auxiliary Input Jack .212 .................
Radio Thef t Protection .213
..........................
Setting the Clock .214
............................
Security System .217
.........................................
Compass .219
...............................
Cruise Control .223
HomeLink
Universal
................................
Transceiver .226
.......
Bluetooth
HandsFreeLink.231
LX and LX-P models
EX, EX-L and V6 models without navigation system
Models with navigation system
Except LX and LX-P
Except LX and LX-P
Features
Features
119
\f—\f—
y


y
)\f\f\fy\f
y
2008 Accord Sedan

µ
µ µ
µ
µ Adjusts the volume level
basedonthevehiclespeed.
Press the SOUND (TUNE) knob
repeatedly to display the BASS,
TREBLE, FADER, BALANCE, and
SVC (speed-sensitive volume
compensation) settings. Eachmodeisshowninthedisplayas
it changes. Turn the TUNE knob to
adjust the setting to your liking.
You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page ). The audio system
illuminates when the parking lights
are on, even if the radio is turned of f .
This f unction is set to MID as the
def ault setting when the vehicle
leaves the factory.
The SVC has f our modes; SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. Turn the TUNE knob to adjust the setting to your liking. If
you f eel the sound is too loud,
choose low. If you f eel the sound is
too quiet, choose high.
The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases.
When the level reaches the center,
you will see ‘‘C’’ in the display.
Adjusts the bass.
Adjusts the treble.
Adjusts the front-to-back
strength of the sound.
Adjusts the side-to-
side strength of the sound. The system will return to the audio
display about 10 seconds af ter you
stop adjusting a mode.72
Except SVC adjustment
Adjusting the Sound SVC
A udio System L ighting
BASS
TREBLE
FADER
BAL ANCE
Speed-sensit ive Volume
Compensat ion (SVC)
Playing the FM/AM Radio (LX model)
140
\f—\f—
y

y
)\f\f\fy\f
y
2008 Accord Sedan

µ
µ
µ
µ
To load or play a disc, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position. The specif ications of the compatible
MP3 f ile are:
Sampling f requency:
32/44.1/48 kHz (MPEG1)
24/22.05/16 kHz (MPEG2)
Bit rate:
32/40/48/56/64/80/96/112/128/
160/192/224/256/320 kbps
(MPEG1)
8/16/24/32/40/48/56/64/80/96/
112/128/160 kbps (MPEG2)
Compatible with variable bit rate
and multi-session
Maximum layers
(including ROOT): 8 layers
This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. When
playing a disc in MP3, you will see
‘‘MP3’’ in the display. In WMA
f ormat, ‘‘WMA’’ will appear in the
display. You can select up to 99
f olders, or up to 255 tracks/f iles.
Video CDs and DVD discs do not
work in this unit.
You operate the disc player with the
same controls used f or the radio. To
select the disc player, press the CD
button. You will see ‘‘CD’’ in the
display. NOTE:
If a f ile on an MP3 or WMA disc is
protected by digital rights
management (DRM), the audio unit
displays UNSUPPORTED, and then
skips to the next f ile.
To Play a Disc
Playing a Disc (L X model)
142
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
\f—\f—
y

y
)\f\f\fy\f
y
2008 Accord Sedan

µ
µ
µ
µWith the f older name, you will see
the FOLDER indicator in the display.
The TRACK indicator is shown with
the file or track name.
Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3 or WMA, the numbers
of the current f older and f ile are
shown. The system will continuously
play a disc until you change modes.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
The specif ications of the compatible
WMA f ile are:
Bit rate:
32/40/48/64/80/96/128/160/192
kbps
Maximum layers
(including ROOT): 8 layers
Compatible with variable bit rate
and multi-session
Sampling f requency:
32/44.1/48 kHz
For inf ormation on how to handle
and protect compact discs, see page. You can see the album, artist, and
track name in the display. If a disc is
recorded in MP3 or WMA, you can
see the f older and f ile name, and the
artist, album, and track tag.
Each time you press the TITLE
button, the display shows you the
text data on a disc, if the disc was
recorded with text data.
206
CONT INUED
Playing a Disc (L X model)
T ext Data Display Function
To Load a Disc
Features
143
\f—\f—
y

\fy
)\f\f\fy\f
y
2008 Accord Sedan

µµ
µ
µ µ
µ
Adjusts the bass. The SVC has f our modes; SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. Turn the selector knob to
adjust the setting to your liking. If
you f eel the sound is too loud,
choose low. If you f eel the sound is
too quiet, choose high.
This f unction is set to MID as the
def ault setting when the vehicle
leaves the factory.
You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page ). The audio system
illuminates when the parking lights
are on, even if the radio is turned of f .
Adjusts the side-to-
side strength of the sound. Adjusts the front-to-back
strength of the sound. Adjusts the treble. Adjusts the strength of
sound f rom the subwoof er speaker.
Adjusts the volume level
basedonthevehiclespeed.
Eachmodeisshowninthedisplayas
it changes. Turn the selector knob to
adjust the setting to your liking.
When the level reaches the center,
you will see ‘‘C’’ in the display.
To return to the normal playing,
push the RETURN or MENU button
af ter you stop adjusting a mode.
The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases. 72
If equipped
Playing the FM/AM Radio (EX, EX-L and V6 models without navigation system)
BASS
A udio System L ighting
BAL ANCE
FADER
TREBLE SUBW
SVC
Speed-sensit ive Volume
Compensat ion (SVC)
156
SUBWOOFER is selectable.
\f—\f—y
\f\fy
)\f\f\fy\f

y
2008 Accord Sedan

This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. When
playing a disc in MP3, you will see
‘‘MP3’’ in the display. In WMA
f ormat, ‘‘WMA’’ will appear in the
display. The disc, f older and track
numbers are displayed. You can
select up to 255 f olders or tracks.
To load or play discs, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.
Video CDs and DVD discs do not
work in this unit.
The specif ications of the compatible
MP3 f ile are:
Sampling f requency: 32/44.1/48 kHz
(MPEG1)
16/22.05/24 kHz (MPEG2)
Bit rate: 32/40/48/56/64/80/96/
112/128/160/192/224/256/320 kbps
Compatible with variable bit rate and
multi-session
Maximum layers
(including ROOT): 8 layersThe specif ications of the compatible
WMA f ile are:
Compatible with variable bit rate and
multi-session
Maximum layers
(including ROOT): 8 layers
Sampling f requency:
22.05/32/44.1/48 kHz
Bit rate:
48/64/80/96/128/160/192 kbps
You operate the disc changer with
the same controls used f or the radio.
To select the disc changer, press the
CD/AUX or CD button. You will see
‘‘CD’’ in the display. The disc and
track numbers, and the elapsed time
areshowninthedisplay.Youcan
also select the displayed inf ormation
with the TITLE button (see page
). The system will continuously
play a disc until you change modes. 166
To Play a Disc
Playing Discs (EX, EX-L and V6 models without navigation system)
164
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
\f—\f—
y


\fy
)\f\f\fy\f
y
2008 Accord Sedan

µµµ
To adjust bass
and treble, select BASS or TREBLE,
andpressENTERontheinterface
selector. The current setting is
shownonthedisplay.Turnthe
interf ace knob to the desired level,
and enter your selection by pressing
ENTER on the interf ace selector. These
modes adjust the strength of the
sound coming f rom each speaker.
Fader adjusts the f ront-to-back
strength, while balance adjusts the
side-to-side strength. To adjust f ader
and balance, select FADER or
BALANCE, then press ENTER on
the interf ace selector. The current
setting is shown on the screen. Turn
the interface knob to the desired
level, and enter your selection by
pressing ENTER on the interf ace
selector. To equalize the f ader or
balance, turn the interf ace knob until
the marks on the sound grid come to
the center of the adjustment bar.
To adjust the
strength of the sound f rom the
subwoof er speaker, select it and
press ENTER on the interf ace
selector. Turn the interf ace knob to
the desired level, and enter your
selection by pressing ENTER on the
interf ace selector. The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases.
The SVC has f our modes; SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. The def ault setting is MID.
To change the SVC mode, select
SVC, then press ENTER on the
interf ace selector. The current
setting is shown on the screen. Turn
the interface knob to the desired
level, and enter your selection by
pressing ENTER on the interf ace
selector. If you f eel the sound is too
loud, choose low. If you f eel the
sound is too quiet, choose high.
BASS/TREBL E FADER/BAL ANCE
SUBWOOFERSpeed-sensit ive VolumeCompensat ion (SVC)
Playing the FM/A M Radio (Models with navigation system)
186
\f—\f—
y

\fy
)\f\f\fy\f

y
2008 Accord Sedan

Your vehicle’s audio system has an
in-dash disc changer with the same
controls used f or the radio. To
operate the disc changer, the ignition
switch must be in the ACCESSORY
(I) or the ON (II) position.
The disc changer can play these disc
formats:CD (CD-DA)
MP3/WMA The disc packages or jackets should
have one of these marks.
When playing a disc in MP3, you will
see ‘‘MP3’’ in the display. In WMA
f ormat, ‘‘WMA’’ will appear in the
display.
The changer can also play MP3 or
WMA format (see page ). NOTE:
If a f ile on an MP3 or WMA disc is
protected by digital rights
management (DRM), the audio
system displays UNSUPPORTED in
the center display, and then skips to
the next f ile.
Video CDs and DVD discs will not
work in this unit.
Some CD-DA and CD-ROM mixed
discs are not playable.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
201
Playing Discs (Models with navigation system)
Features
195
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
\f—\f—
y

\fy
)\f\f\fy\f\f\fy
2008 Accord Sedan

ÛÝ´
µ ´µ ´
µ
The VOL button adjusts the volume
up ( ) or down ( ). Press the top
or bottom of the button, hold it until
the desired volume is reached, then
release it.
Three controls f or the audio system
are mounted in the steering wheel
hub. These let you control basic
f unctions without removing your
hand f rom the wheel. The MODE button changes the
mode. Pressing the button
repeatedly selects FM1, FM2, AM,
or disc (if a disc(s) is loaded). On
models with satellite radio system,
you can also select XM1 and XM2.
If you are listening to the radio, use
the CH button to change stations.
Each time you press the top ( ) of
the button, the system goes to the
next preset station on the band you
are listening to. Press the bottom
( ) to go back to the previous
station.If youpressandholdtheCH
button ( ) or ( ), the system goes
into the skip (seek) mode. It f inds a
station with a strong signal.If you are playing a disc, the system
skips to the beginning of the next
track (f ile in MP3 or WMA f ormat)
each time you press the top ( ) of
the CH button. Press the bottom
( ) to return to the beginning of the
current track/f ile. Press it twice to
return to the previous track/f ile.
You will see the track/f ile number
and the elapsed time. If the disc has
text data or is compressed in MP3 or
WMA, you can also see any other
inf ormation (track title, f ile name,
f older name, etc.).
CONT INUED
Remote Audio Controls
Features
211
MODE BUTTON
VOL BUTTON CH BUTTON
\f—\f—
y

\fy
)\f\f\fy\f
y
2008 Accord Sedan
