Quick Reference Guide19
Handling the Unexpected
(P 313)
Flat Tire
(P 315, 322)
● Park in a safe location and replace the
flat tire with the compact spare tire
* in
the trunk, or repair the flat tire using the
tire repair kit
*.
Indicators Come On (P 337)
● Identify the indicator and consult the
owner's manual.
Engine Won't Start (P 330)
● If the battery is dead, jump start using a
booster battery.Blown Fuse
(P 341)
● Check for a blown fuse if an electrical
device does not operate.
Overheating
(P 335)
● Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.
Emergency Towing (P 344)
●Call a professional towing service if you
need to tow your vehicle.
* Not available on all models

101
uuLocking and Unlocking the Doors uLocking/Unlocking the Doors from the Outside
Continued
Controls
Locking/Unlocking the Doors from the Outside
■Locking the doors
Press the lock button.
Once: uSome exterior lights flash, all the doors
lock, and the security system sets.
Twice (within five seconds after the first
push):
uA beeper sounds and verifies the security
system is set.■Unlocking the doors
Press the unlock button.
Once:
uSome exterior lights flash twice, and the
driver's door unlocks.
Twice: uThe remaining doors unlock.
■Using the Remote Transmitter
*
1Using the Remote Transmitter
*
If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.
You can change the relock timer setting.
2 Customized Features P. 85
If the interior light switch is in the door activated
position, the interior lights come on when you press
the unlock button.
No doors opened: The lights fade out after 30
seconds.
Doors relocked with the remote: The lights go off
immediately. 2 Interior Lights P. 135
The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.
The remote will not lock the vehicle when a door is
open.
If the distance at which it works varies, the battery is
probably low.
If the LED does not come on when you press a
button, the battery is dead. 2 Replacing the Button Battery P. 307
You can customize the door unlock mode setting. 2 Customized Features P. 85Models with i-MID
LED
Unlock
Button Lock
Button* Not available on all models

113
uuSecurity System uSecurity System Alarm
*
Controls
■Setting the security system alarm
The security system alarm automatically sets wh en the following conditions have
been met:
• The ignition switch is in LOCK
(0, and the key has been removed from the
ignition switch.
• The hood and trunk are closed.
• All doors are locked with the key or the remote transmitter.
■When the security system alarm sets
The security system indicator in the instrument panel blinks. When the blinking
interval changes after about 15 seconds, the security system is set.■To cancel the security system alarm
The security system is canceled when the vehicle is unlocked using the key or remote
transmitter, or the ignition switch is turned to ON
(w. The security system indicator
goes off at the same time.
■The PANIC button on the remote
transmitter
If you press the PANIC button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.
■Canceling panic mode
Press any button on the remote transmitter, or turn the ignition switch to ON
(w.
■Panic Mode
1 Security System Alarm
*
Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:•Unlocking the door with the lock tab.•Opening the trunk with the trunk release or the
emergency trunk opener.
If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key or remote transmitter.
Do not attempt to alter this system or add another
device to it.
PANIC
Button* Not available on all models

152
uuAudio System uAudio System Theft Protection
*
Features
Audio System Theft Protection
*
The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead.■Reactivating the audio system
1. Turn the ignition switch to ON
(w, and turn on the audio system.
u If you turn the ignition switch to ACCESSORY
(q, you will be requested to
enter the audio security code. See step 3.
2. Press and hold the power button again for more than two seconds.
u The audio system is reactivated when the system’s control unit recognizes that
the system is in your vehicle.
If the control unit fails to recognize, ENTER CODE appears on the i-MID.
3. Enter the audio security code using the preset buttons. If you enter an incorrect
digit, continue to the last digit, then try again. If you do not enter code correctly
after 10 tries, leave the system for one hour before trying again, or visit a dealer
to have the system reset.
■Entering the audio security code
ENTER CODE appears on the display when the power is reconnected.
1. Turn on the audio system.
2. Enter the audio security code using the preset buttons. If you enter an incorrect
digit, continue to the last digit, then try again. If you do not enter the code
correctly after 10 tries, leave the system for one hour before trying again, or visit
a dealer to have the system reset.
1Audio System Theft Protection
*
Find the audio system's security code and serial
number label in your owner’s manual kit.
We recommend that you write down the serial
number in this owner’s manual.
Do not store the label in your vehicle. If you lose the
label, you must first retrieve the serial number, and
then obtain the code.
You can find out about your serial number and
security code from a dealer.
You can register the security code at Owner Link
(owners.honda.com. ), and find information on how
to retrieve the serial number and obtain the code at
radio-navicode.honda.com .U.S. models
Models with i-MIDModels with information display* Not available on all models

306Maintenance
BatteryChecking the Battery
Check the battery condition monthly. Look at
the test indicator window and check the
terminals for corrosion.
If your vehicle's battery is disconnected or goes dead:
• The audio system is disabled.
2 Reactivating the audio system P. 152
2 Entering the audio security code P. 152
•The clock
* resets.
2 Setting the Clock P. 98
•The navigation system
* is disabled.
2 Refer to the navigation system manual
Charging the BatteryDisconnect both battery cables to prevent damaging your vehicle's electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.
1BatteryWARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.The test indicator's color information is on the
battery.
When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean the terminal with a damp towel. Cloth/towel
dry the battery. Coat the terminals with grease to
help prevent future corrosion.
3
WARNING
The battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.
When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.
Test Indicator window
* Not available on all models

330Handling the Unexpected
Engine Does Not StartChecking the EngineIf the engine does not start, check the starter.
Starter condition
Checklist
Starter doesn’t turn or turns
over slowly.
The battery may be dead. Check
each of the items on the right and
respond accordingly.
Check brightness of the interior light.
Turn on interior lights and check brightness.●If the interior lights are dim or do not come on at all
2Battery P. 306
●If the interior lights come on normally
2 Fuses P. 341
The starter turns over normally
but the engine doesn’t start.
There may be a problem with the
fuse. Check each of the items on
the right and respond accordingly.
Review the engine start procedure.
Follow its instructions, and try to start the engine again.2 Starting the Engine P. 223Check the immobilizer system indicator.
When the immobilizer system indicator is blinking, the engine cannot be started.2Immobilizer System P. 112Check the fuel level.
There should be enough fuel in the tank.2 Fuel Gauge P. 77Check the fuse.
Check all fuses, or have the vehicle checked by a dealer.2Inspecting and Changing Fuses P. 343If the problem continues:2Emergency Towing P. 344
1Checking the Engine
If you must start the vehicle immediately, use an
assisting vehicle to jump start it.
2 Jump Starting P. 331

353
Continued
Information
Emissions TestingTesting of Readiness CodesYour vehicle uses “readiness codes,” as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle's emissions
components are working properly.
The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.
To check if they are set, turn the ignition switch to ON
(w, without starting the
engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are
not set.
If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:
1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the engine off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5. Keep the vehicle in
(P (automatic transmission) or
(N (manual transmission).
Increase the engine speed to 2,000 rpm, and hold it there for about 3 minutes.
6. Let the engine idle with your foot off the accelerator for 20 seconds.
1Testing of Readiness Codes
The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.
If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.
If the testing facility determines the readiness codes
are still not set, see a dealer.

360Index
Brake System............................................. 241
Anti-lock Brake System (ABS) ................... 243
Brake Assist System ................................. 244
Fluid ........................................................ 280
Foot Brake ............................................... 242
Indicator ............................................ 66, 339
Parking Brake .......................................... 241
Brightness Control (Instrument Panel) .... 123
Bulb Replacement ..................................... 282
Brake/Taillights, Rear Turn Signal Lights and
Rear Side Marker Lights ......................... 291
Fog Lights ................................................ 286
Front Turn Signal/Parking/Side Marker
Lights..................................................... 289
Headlights ............................................... 282
High-Mount Brake Light .......................... 294
Rear License Plate Lights .......................... 293
Taillights and Back-Up Lights ................... 292
Bulb Specifications ............................ 346, 348CCarbon Monoxide Gas ................................ 62
Carrying Cargo .................................. 215, 217
CD Player ........................................... 155, 162
Center Pocket ............................................ 137
Certification Label .................................... 350
Changing Bulbs ......................................... 282
Charging System Indicator ................. 67, 337
Child Safety ................................................. 50
Childproof Door Locks ............................. 104 Emergency Trunk Opener ........................ 111
Child Seat .................................................... 50
Booster Seats ............................................ 61
Child Seat for Infants................................. 52
Child Seat for Small Children ..................... 53
Installing a Child Seat with a Lap/Shoulder Seat Belt .................................................. 57
Larger Children ......................................... 60
Rear-facing Child Seat ............................... 52
Selecting a Child Seat ................................ 54
Using a Tether ........................................... 59
Childproof Door Locks ............................. 104
Cleaning the Exterior ............................... 311
Cleaning the Interior ................................ 309
Climate Control System ............................ 146
Changing the Mode ................................ 146
Defrosting the Windshield and Windows ........................................ 147
Dust and Pollen Filter............................... 308
Recirculation/Fresh Air Mode ..... .............. 147
Sensors ................................................... 148
Using Automatic Climate Control ............ 146
Clock ............................................................ 98
Clutch Fluid ............................................... 280
Coat Hook ................................................. 140
Compact Spare Tire .................. 315, 347, 349
Console Compartment ............................. 136
Controls ....................................................... 97
Coolant (Engine) ...................................... 275
Adding to the Radiator ......... ............... .... 276
Adding to the Reserve Tank..................... 275 High Temperature Indicator ...................... 69
Low Temperature Indicator ....................... 73
Overheating ............................................ 335
Creeping (Automatic Transmission) ........ 226
Cruise Control .......................................... 233
Indicator ................................................... 74
Cup Holders .............................................. 138
Customer Service Information ................ 358
Customized Features ................................. 85
DDaytime Running Lights .......................... 121
Dead Battery ............................................ 331
Defrosting the Windshield
and Windows ................................. 145, 147
Devices that Emit Radio Waves ............... 351
Dimming
Headlights .............................................. 118
Rearview Mirror ...................................... 126
Dipstick (Engine Oil) ................................ 269
Directional Signals (Turn Signal) ............. 118
Display/Information Button ...................... 81
Door Mirrors ............................................. 126
Doors .......................................................... 99
Auto Door Locking.................................. 105
Auto Door Unlocking .............................. 105
Door Open Indicator ........................... 29, 70
Keys.......................................................... 99
Locking/Unlocking the Doors
from the Inside...................................... 103
