HONDA CIVIC COUPE 2015 9.G Navigation Manual

190
uuBluetooth ® HandsFreeLink ®u HFL Menus
Bluetooth ® HandsFreeLink ®
■Phone menu screen
1.Select HOME and then select
Phone .
2. Select MENU .
Display the last 20 outgoing, incoming and missed calls. Select a phone number from the call
history to store as a speed dial number.
Call Hi story*1
Speed Dial*1
All
Manual Input
Dialed
Received
Display the last 20 outgoing calls.
Display the last 20 incoming calls.
New Entry
Import from Call Hi
story
Import from PhonebookSelect a phone number from the
phonebook to store as a speed dial
number.
Enter a phone number to store as a speed
dial number.
*1: Appears only when a phone is connected to HFL.
Mi
ssed
Display the last 20 missed calls.
Dial
*1
Redial*1
Enter a phone number to dial.
2 Entering a Phone Number P. 185
Redial the last number dialed in the phone’s history.
(Exi
sting entry li st)
Dial the selected number in the speed dial list.
Phonebook
*1Display the paired phone’s phonebook.
2 Using the Phonebook P. 184
2Using Speed
Dial P. 186
2 Using Call
His tory P. 186
SearchSelect a name by entering the name directly.
15 CIVIC NAVI-31TR38300.book 190 ページ ２０１４年８月７日　木曜日　午前１１時４９分

191
uuBluetooth ® HandsFreeLink ®u HFL Menus
Bluetooth ® HandsFreeLink ®
Make a call to the sender.
(Existing me ssage list)Reply
Dial
Reply to a received message using
one of six fixed phrases.
2 Replying to the Message P. 193
System reads received message
aloud, or stop message from being
read.
Read/Stop
Select AccountSelect a mail or text message account.
Text/Email
*1
*1: Appears only when a phone is connected to HFL.
15 CIVIC NAVI-31TR38300.book 191 ページ ２０１４年８月７日　木曜日　午前１１時４９分

192
Bluetooth® HandsFreeLink ®
Text/E-mail Message
If your paired phone is MAP-compatible, you can receive and hear text or e-mail
messages and reply to them using fixed reply messages.
2 Pairing a Phone P. 170
If a text message is received, the following screen is displayed.
1.Select Read.
u The text message is read aloud.
u Select Ignore to check the text
message later.
u If the phone number of the
sender is stored to the
Phonebook, the name is
displayed.
2. Select an item.
u The entire message body is not
displayed while driving.
The following items are available:
• Read : Reads the text message aloud. Select Stop to stop reading. Adjust the
volume using VOL (Volume).
• Reply : Replies to the message using a fixed reply message. You cannot create
your own messages.
2 Replying to the Message P. 193
•Dial : Dials the sender.
1Text/E-mail Message
You can control the text messages feature using
voice commands.
To use this feature, you need a Bluetooth- and MAP
(Message Access Profile)-c ompatible cell phone. For a
list of compatible phon es and special feature
capabilities:
•U.S.: Visit handsfreelink.honda.com.
•Canada: Visit www.handsfreelink.ca .
State (provincial in Canada) or local laws may limit
your use of the HFL text/E-m ail message feature. Only
use the text/E-mail message feature when conditions
allow you to do so safely.
Text/Email on the Phone menu is grayed out if your
connected phone is not compatible.
Select Text/Email from the Phone me nu to view a list
of the 20 most recently re ceived text and e-mail
messages. You can select each one to read, reply, or
call back. The list cannot be scrolled while the vehicle
is moving.
15 CIVIC NAVI-31TR38300.book 192 ページ ２０１４年８月７日　木曜日　午前１１時４９分

193
uuText/E-mail Message u
Bluetooth® HandsFreeLink ®
1.Select the message you want to
use.
2. Select Send.
■Replying to the Message1
Text/E-mail Message
You can set up text messa ge notification when the
first message for the pair ed phone is received. You
can change the setting fr om the Phone settings
screen. 2 Text/Email Setting P. 194
If you delete a message on the phone, the message is
also deleted in the system. If you send a message
from the system, the message goes to your phone’s
outbox.
15 CIVIC NAVI-31TR38300.book 193 ページ ２０１４年８月７日　木曜日　午前１１時４９分

194
uuText/E-mail Message uText/Email Setting
Bluetooth ® HandsFreeLink ®
Text/Email Setting
HHOME uSetting su Phone uText/Email
Select an item.
The following items are available:
• Enable Text/Email: Turns the Text/Email feature on or off.
On (factory default): Text or e- mail messages can be received.
Off : Disables the feature.
• Select Account : Selects an account to be active and receive notifications. Select
Text Messages for SMS or an E-mail message account you want. Only one
account can be active at a time.
• New Message Notification : Sets whether to give an incoming message
notification.
On : Gives an incoming message notification.
Off : Messages are still received, but without notification.
15 CIVIC NAVI-31TR38300.book 194 ページ ２０１４年８月７日　木曜日　午前１１時４９分

195
Bluetooth® HandsFreeLink ®
HondaLink Assist
If your vehicle’s airbags deploy or if the unit detects that the vehicle is severely
impacted, your vehicle automatically will attempt to connect to the HondaLink
operator. Once connected, information about your vehicle, its positioning, and its
condition will be sent to the operator; you also can speak to the operator when
connected.
To use this function, you need to connect a phone via Bluetooth® in advance.
2Pairing a Phone P. 170
1.Select Call Now .
u If you do not select Call Now,
HondaLink Assist automatically
calls emergency services after
10 seconds.
2. Talk to the operator.
u When an emergency call is
connected, the talk with the
operator begins as necessary.
u Select Talk Now to talk to the
operator immediately.
u The talk with the operator may
be interrupted to confirm the
information about your vehicle
position.
u Select Hang Up or press the
(Hang-Up/Back) button
to hang up the call.
1 HondaLink Assist
IMPORTANT: Owner ac tivation constitutes
authorization for Honda to collect information from
your vehicle needed to provide the service, and
agreement to the Terms and Conditions at
www.hondalink.com/TermsAndConditions . In a
crash, HondaLink Assist will attempt to notify
emergency services but NEITHER Honda NOR ITS
SERVICE PROVIDERS GUARANTEE THAT SUCH
NOTIFICATION WILL OCCUR.
This function may not wo rk properly depending on
the phone, carrier, or contract conditions.
Your vehicle may not be able to connect to the operator
if the battery level is low, the line is disconnected, or you
do not have adequate cellular coverage.
You cannot use emergency services when:
•You travel outside the H ondaLink service coverage
areas.
•There is a problem with th e connecting devices, such
as the microphones, speakers, or the unit itself.
You cannot operate othe r navigation- or phone-
related functions using the screens while talking to
the operator.
If the unit fails to connect to the operator, it
repeatedly tries until it succeeds.
If you select Cancel or press the (Hang-Up/
Back) button before callin g the operator, you can
cancel to call.
15 CIVIC NAVI-31TR38300.book 195 ページ ２０１４年８月７日　木曜日　午前１１時４９分

196
15 CIVIC NAVI-31TR38300.book 196 ページ ２０１４年８月７日　木曜日　午前１１時４９分

197
Other Features
This section describes the useful functions incorporated into thenavigation system.
Trip Computer....................................... 198
Information Function s.......................... 199
System/Device Information ................... 200
Multi-View Rear Camera ...................... 202
15 CIVIC NAVI-31TR38300.book 197 ページ ２０１４年８月７日　木曜日　午前１１時４９分

198
Other Features
Trip Computer
HHOME uInfo uMENU uTrip Computer
View the distance traveled and average fuel consumption. Select an item.
The following items are available:
• Current Drive : Displays the current trip information.
• History of Trip A : Displays information for th e three previous drives. The
information is stored every time you reset Trip A.1 Trip Computer
Displays the following trip information:
•Instant Fuel Economy : The current estimated
instant fuel economy.
•Average Fuel Economy : The average fuel
economy since the last key cycle.
•1st, 2nd, 3rd Prev. : The previous average fuel
consumption.
•Range : The estimated distan ce you can travel on
the fuel remaining in the tank.
These values are estimates only.
Select Delete history to delete the trip information.
15 CIVIC NAVI-31TR38300.book 198 ページ ２０１４年８月７日　木曜日　午前１１時４９分

199
Other Features
Information Functions
HHOME uInfo uMENU
Check the information about th e system or the vehicle.
Select an item.
The following items are available:
• Trip Computer : Displays the distance traveled and average fuel consumption.
2Trip Computer P. 198
•Traffic Incidents : Displays a list of the traffic incidents around your current
location or on your route.
2 Traffic ReroutingTM Manually P. 110
•System/Device Information : Displays the system and USB device information.
2System/Device Information P. 200
•Clock/Wallpaper : Displays the clock/wallpaper screen.
2Clock Adju stment P. 70
•Voice Info : Displays the voice commands list.
2Voice Help P. 15
1Information Functions
Info Screen Preference
You can set the Info screen type.
1. Select HOME and then select Settings.
2. Select Clock/Info . Select Info tab, and then select
Info Screen Preference .
3. Select one of the following options:
•Info Top : Displays the pop-up window to prompt
you to select Trip Computer or Clock/Wallpaper.
•Info Menu: Displays the pop-up window of the
Info Menu.
•Off (factory default): Does not display any pop-up
window.
If you set Remember Last Screen to On , the pop-up
windows are not displayed on some screens.
Traffic Incidents is available on U.S. models only.
