bolt pattern HONDA CIVIC HYBRID 2004 7.G Owners Manual

Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel wrench
until the wheel is f irmly against
the hub. Do not try to tighten
them f ully.
Lower the vehicle to the ground
and remove the jack.Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
f acility.
Tighten the wheel nuts to:
Remove the center cap before
storing the f lat tire in the trunk
well.Place the flat tire face down in the
spare tire well.
Remove the spacer cone f rom the
wing bolt, turn it over, and put it
back on the bolt.
Secure the f lat tire by screwing
the wing bolt back into its hole.
12.
13. 14.
15.16.
17.
18.
Changing a Flat T ire
T aking Care of t he Unexpect ed182
WING BOLT
SPACER
CONE
80 lbf·ft (108 N·m , 11 kgf·m)
