Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.With the trunk lid open, air f low can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
trunk lid open, open all the windows
and set the heating and cooling
system as shown below.
If you must sit in your parked vehicle,
even in an unconf ined area, with the
engine running, adjust the heating
and cooling system as f ollows:
Select the Fresh Air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
Have the exhaust system inspected
f or leaks whenever:
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the under-
side. 1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety46
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil.Remove the dipstick (orange loop).
Wipe the dipstick with a clean
cloth or paper towel.
Insert it all the way back in its tube. Remove the dipstick again and
check the level. It should be
between the upper and lower
marks.
If it is near or below the lower mark,
see on page . Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page f or
inf ormation on adding the proper
coolant.
Refer to on page f or inf ormation
on checking other items in your
Honda.
2.
3. 1.
4.
152 155
146
Oil Check
A dding Oil A dding
Engine Coolant Engine Coolant Check
Owner’s Maintenance
Checks
Service Station Procedures
Bef ore Driving118
DIPSTICK
UPPER MARK
LOWER MARKRESERVE TANK
MINMAX

̵
µ
µ
µ
µ µ
Your authorized Honda dealer
knows your vehicle best and can
provide competent, ef f icient service.
However, service at a dealer is not
mandatory to keep your warranties
in effect. Maintenance may be done
by any qualif ied service f acility or
skilled person to keep your
warranties in ef f ect. Keep all the
receipts as proof of completion, and
have the person who does the work
f ill out the Maintenance Record.
Check your warranty booklet f or
more inf ormation.
We recommend the use of Honda
parts and f luids whenever you have
maintenance done. U.S. Vehicles:
According to state and federal
regulations, f ailure to perf orm
maintenance on the items marked
with will not void your emissions
warranties. However, Honda
recommends that all maintenance
services be perf ormed at the
recommended time or mileage
period to ensure long-term reliability.
Youshouldcheckthefollowing
items at the specif ied intervals. If
you are unsure of how to perf orm
any check, turn to the appropriate
page listed.
Engine oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you f ill the f uel tank. See page .
Brakes Check the f luid level
monthly. See page .
Tires Check the tire pressure
monthly. Examine the tread f or
wear and foreign objects. See page .
Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page . Automatic transmission (CVT)
Check the f luid level monthly. See
page . 118
118
158 160
169
161
Maintenance Schedule
Maint enance
Servicing Your Vehicle Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.Owner’s Maintenance Checks
146

Ì
Î ÎÌ Ì
Î
Î
µ
Follow the Normal Maintenance
Schedule if the severe driving
conditions specif ied in the Severe
Conditions Maintenance Schedule on
the next page do not apply.
NOT E: If you only OCCASIONALLY
drive under a ‘‘severe’’ condition, you
should f ollow the Normal Conditions
Maintenance Schedule.
Follow the
Maintenance Schedule f or Severe
Conditions.
Maint enance
Canadian Owners
147
miles x 1,000
km x 1,000
Service the items listed at the indicated distance (or time, if given).
( (
O
O t
th
h e
er
rw
w i
is
se e a
ad
d j
ju
u s
stt o
o n
nl
ly
y i
if
f n
n o
oi
is
sy y )
)
Every 10,000 miles (16,000 km)(
(O
O r
re
ev
ve
er
ry
y 1
1y
ye
ea
ar
r,
, w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
Check inflation and condition once a month Check oil and coolant at each fuel stop
10
16
20
32 40
6450
80 70
112 80
128 100
160
( (
O
O r
re
ev
ve
er
ry
y 2
2y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
130
208 140
224
( (
O
O r
re
ev
ve
er
ry
y 1
1y
ye
ea
ar
r,
, w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
Every 160,000 miles (256,000 km)
30
48
60
96
( (
O
O r
re
ev
ve
er
ry
y 6
6y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
120
192
90
144 150
240
( (
O
O r
re
ev
ve
er
ry
y 2
2y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
See information on maintenance and
emission warranty on page .
At 120,000 miles (192,000 km) or 10 years, then every 60,000 miles (96,000 km) or 5 years
Every 3 years (independent of mileage) 110
176
Check engine oil and coolant
Check tires
Replace engine oil
Rotate tires (follow pattern on page 172)
Replace engine oil filter
Check front and rear brake wear
Check parking brake adjustment
Inspect the following items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections
Inspect and adjust drive belts
Replace dust and pollen filter
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Replace CVT fluid
Replace manual transmission fluid
Inspect idle speed
Inspect idle speed
Replace engine coolant
Replace brake fluid :
1: 2: For ULEV model 146
For AT-PZEV model
1
2
Maintenance Schedule for Normal Conditions

Î
Î
Î
Ì Î
ÌÌÎ
Î
Î Î
µ
Follow the Severe Maintenance
Schedule if you drive your vehicle
MAINLY under one or more of the
f ollowing conditions:
Driving less than 5 miles (8 km) per
trip or, in f reezing temperatures,
driving less than 10 miles (16 km)
per trip.
Driving in extremely hot [over 90°F
(32°C)] conditions.
Extensive idling or long periods of
stop and go driving, such as a taxi or
a commercial delivery vehicle.
Driving with a roof rack, or driving
in mountainous conditions.
Driving on muddy, dusty, or de-iced
roads. Follow the
Maintenance Schedule f or Severe
Conditions.
Maint enance Canadian Owners
148
miles x 1,000
km x 1,000
( (
O
O r
re
ev
ve
er
ry
y 2
2y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
10
16 20
32 40
6450
80 70
112 80
128 100
160
Check oil and coolant at each fuel stop 130
208
140
224
Service the items listed at the indicated distance (or time, if given).
Every 10,000 miles (16,000 km)
Check inflation and condition once a month
Every 5,000 miles (8,000 km) or every 6 months, whichever comes first
( (O
O r
re
ev
ve
er
ry
y 1
1y
ye
ea
ar
r,
, w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
(
( O
O r
re
ev
ve
er
ry
y 1
1y
ye
ea
ar
r,
, w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
At 120,000 miles (192,000 km) or 10 years, then every
60,000 miles (96,000 km) or 5 years
Every 3 years (independent of mileage) Every 15,000 miles (24,000 km)
Check engine oil and coolant
Check tires
Replace engine oil
Rotate tires (follow pattern on page
172)
Replace engine oil filter
Check front and rear brake wear
Lubricate all hinges, locks and latches
Inspect the following items: Tie rod ends, steering gear box, and boots
Suspension components, Driveshaft boots
Check parking brake adjustment
Inspect the following items: Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Exhaust system , Fuel lines and connections
Lights and controls/vehicle underbody
Inspect and adjust drive belts
Replace dust and pollen filter
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Replace CVT fluid
Replace manual transmission fluid
Inspect idle speed
Inspect idle speed
Replace engine coolant
Replace brake fluid
( ( O
O t
th
h e
er
rw
w i
is
se e a
ad
d j
ju
u s
stt o
o n
nl
ly
y i
if
f n
n o
oi
is
sy y )
)
(
( O
O r
re
ev
ve
er
ry
y 2
2y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
(
( O
O r
re
ev
ve
er
ry
y 3
3y
ye
ea
ar
rs
s, , w
w h
hi
ic
ch h e
ev
ve
er
r c
coo m
m e
es
s f
fi
ir
r s
st t)
)
30
48 60
9690
144 110
176120
192 150
240
Every 160,000 miles (256,000 km) See dust and pollen filter on page for
replacement information under special
driving conditions.
Use normal schedule except in dusty
condition.
See information on maintenance and
emission warranty on page .
1:
2:
3:
: For ULEV model
4 : For AT-PZEV model
146167
1
3
4 2
Maintenance Schedule for Severe Conditions

Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill. Clean up any spills
immediately. Spilled oil could
damage components in the engine
compartment. Install the engine oil
f ill cap and tighten it securely. Wait a
f ew minutes and recheck the oil level.
Do not f ill above the upper mark; you
could damage the engine.The oil viscosity or weight is
provided on the container’s label.
A very low-viscosity, f uel-ef f icient
0W-20 oil is the pref erred engine
lubricant f or your Civic Hybrid. This
special oil is f ormulated to help your
engine use less fuel. It is available at
your Honda dealer. A 5W-20 oil may
be used if 0W-20 is not available.
Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 0W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
Honda Motor Oil is the pref erred
0W-20 lubricant f or your vehicle. It is
highly recommended that you use
Honda Motor Oil in your vehicle f or optimum engine protection. Make
sure the API Certif ication Seal says
‘‘For Gasoline Engines’’.
A dding Engine Oil
Maint enance
Recommended Engine Oil
152
API CERTIFICATION SEAL
ENGINE OIL
FILL CAP
Ambient Temperature

If Honda antif reeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporaryreplacement.Makesureit
is a high-quality coolant
recommended f or aluminum engines.
Continued use of any non-Honda
coolant can result in corrosion,
causing the cooling system to
malf unction or f ail. Have the cooling
system f lushed and ref illed with
Honda antif reeze/coolant as soon as
possible.
If the coolant level in the reserve
tank is at or below the MIN line, add
coolant to bring it up to the MAX line.
Inspect the cooling system f or leaks.
Always use Honda All Season
Antif reeze/Coolant Type 2. This
coolant is pre-mixed with 50 percent
antif reeze and 50 percent water.
Never add straight antifreeze or
plain water.
Turn of f the engine, let it sit f or
several minutes, then check the oil
level on the dipstick. If necessary,
add more oil.
Put the under-cover back in place
and reinstall the nine holding clips.
Locktheclipssecurelybypushing
on the center of each clip.
11.
12.
CONT INUED
Maint enance
A dding Engine Coolant
Changing the Oil and Filter, Engine Coolant
155
NOTICE:
RESERVE TANK
Improper disposal of engine
oil can be harmf ul to the environment.
If you change your own oil, please
dispose of the used oil properly. Put it
in a sealed container and take it to a
recycling center. Do not discard it in a
trash bin or dump it on the ground.

Check the f luid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground. Remove the under-
cover to access the transmission
housing(seepage ).Removethe
transmission f iller bolt and caref ully
f eel inside the bolt hole with your
f inger. The f luid level should be up
to the edge of the bolt hole. If it is
not, add Honda Manual Transmis-
sion Fluid (MTF) until it starts torun out of the hole. Reinstall the
f iller bolt and tighten it securely.
If Honda MTF is not available, you
may use an SAE 10W-30 or 10W-40
viscosity motor oil with the API
Certif ication seal that says ‘‘FOR
GASOLINE ENGINES’’ as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stiffer shifting. Replace as
soon as it is convenient.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
153
Maint enance
5-speed Manual Transmission
Manual T ransmission Fluid
159
Correct Level FILLER BOLT

The engine running generates the oil
pressure. When the Auto Idle Stop is
activated, the engine is stopped, the
oil pressure is dropped, and the low
oil pressure indicator does not light.
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving.
(See on page
).
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ). Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers. Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning indicators.
This light should never
come on when the engine is
running. If it starts f lashing
or stays on, the oil pressure has
dropped very low or lost pressure.
Serious engine damage is possible
and you should take immediate
action. 1.
2.
3.
4.118
199 152
T aking Care of t he Unexpect ed
L ow Oil Pressure Indicator
Emergency T owing
190
NOTICE:
Running the engine with low
oil pressure can cause serious
mechanical damage almost immediately.
Turn of f the engine as soon as you can
saf ely get the vehicle stopped.

CONT INUED
....................................
Accessories .121
ACCESSORY (Ignition Key .......................................
Position) .72
...............
Accessory Power Socket . 85
....................
Additives, Engine Oil . 153
.............................
Airbag (SRS) .10, 22
...
Airbags, Additional Information . 22
...
Additional Safety Precautions . 28
.............................
Airbag Service .28
How the Side Airbag Cutof f ......................
Indicator Works .27
..
How the SRS Indicator Works . 26
How Your Front Airbags .........................................
Work .22
...
How Your Side Airbags Work . 25
........................
SRS Components .22
................
Air Conditioning System . 88
.......................
Air Pressure, Tires .170
..................
High Speed Driving . 170
.........................
Normal Driving .170
......................................
Antif reeze .155
Anti-lock Brakes (ABS) ...............................
Indicator .54, 141
...................................
Operation .141 ..............
Anti-thef t, Audio System . 107
Anti-thef t Steering Column ..............................................
Lock .72
..................................
Audio System .94
........................
Auto Idle Stop .131, 137
...
Automatic Seat Belt Tensioners . 20
.............
Automatic Speed Control . 109
..............
Automatic Transmission . 133
..........................
Capacity, Fluid .204
...............
Checking Fluid Level . 158
.......................................
Shif ting .133
.
Shif t Lever Position Indicator . 133
................
Shif t Lever Positions . 133
....................
Shif t Lock Release . 136
Battery Charging System ...........................
Indicator .54, 191
............................
Jump Starting .186
..............................
Maintenance .175
............................
Specif ications .205
..............................
Bef ore Driving .113
....................................
Belts,Seat .8,19
.............................
Beverage Holder .85 ..................................
Booster Seats .43
Brakes ...........
Anti-lock System (ABS) . 141
.............
Break-in, New Linings . 114
....................
Bulb Replacement .161
...........................................
Fluid .160
.........................................
Parking .82
.................
System Indicator . 54,193
........................
Wear Indicators .140
.............................
Braking System .140
.................
Break-in, New Vehicle . 114
..
Brightness Control, Instruments . 67
........................
Brights, Headlights .66
Bulb Replacement ..........................
Back-up Lights .165
..............................
Brake Lights .164
................
Front Parking Lights . 163
........
Front Side Marker Lights . 163
.................................
Headlights .161
.........
High-mount Brake Light . 165
.........
Rear Side Marker Lights . 164
............................
Specif ications .205
Bulb Replacement ....................
Turn Signal Lights . 163
..............................
Bulbs, Halogen .161
Index
A
B
I
