2005 Civic Sedan Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through this reference. For a printed owner's manual, click on authorized manuals or go to www.helmi\
nc.com. If you havea Civic GX refer to Civic Sedan GX Owner's Manual Supplement for additional information.
Contents
Introduction ........................................................................\
................................................................. i
A Few Words About Safety........................................................................\
.........................................ii
Your Vehicle at a Glance........................................................................\
.............................................4
Driver and Passenger Safety ........................................................................\
......................................7
Seat belts, SRS, and child protection
Instruments and Controls........................................................................\
.........................................51
Indicators, gauges, dashboard, and steering column
Features .......................................................................................................................\
.......................87
Climate, audio, steering wheel, security, cruise control, and HomeLink
Before Driving........................................................................\
..........................................................121Fuel, vehicle break-in, and cargo loading
Driving ........................................................................\
......................................................................133
Engine and transmission operation
Maintenance........................................................................\
.............................................................145
Schedules, fluid checking, minor services, and vehicle storage
Taking Care of the Unexpected........................................................................\
..............................181
Flat tire, dead battery, overheating, fuses
Technical Information........................................................................\
.............................................205
Vehicle specifications, tires, fuels, and emissions controls
Warranty and Customer Relations (U.S. and Canada)................................................................221
Warranty and contact information
Authorized Manuals (U.S. only)........................................................................\
..............................225How to order
Index........................................................................\
.............................................................................. I
Service Information Summary
Fluid capacities and tire pressures
Owner's Identification Form
Page 12 of 236
Your vehicle has a Supplemental
Restraint System (SRS) with f ront
airbags to help protect the heads and
chests of the driver and a front seat
passenger during a moderate to
severe f rontal collision (see pagef or more inf ormation on how
your f ront airbags work). The most important things you need
to know about your airbags are:
They are designed to supplement
the seat belts.
Your vehicle also has side airbags to
help protect the upper torso of the
driver or a f ront seat passenger
during a moderate to severe side
impact. (See page f or more
information on how your side airbags
work.) To do
their job, airbags must inf late with
tremendous f orce. So while
airbags help save lives, they can
cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly.
Always wear
your seat belt properly, and sit
upright, and as f ar back f rom the
steering wheel while allowing f ull
control of the vehicle. A f ront
passenger should move their seat as
f ar back f rom the dashboard as
possible.
23
26Only models equipped with side airbags.
Airbags
Airbags do not replace seat belts.
A irbags of f er no prot ect ion in rearimpact s, or minor f ront al or sidecollisions.A irbags can pose hazards.
What you should do:
Your Vehicle’s Saf ety Features
Driver and Passenger Saf ety
11
Page 13 of 236
µ
The rest of this section gives more
detailed inf ormation about how you
can maximize your saf ety.
Af ter everyone has entered the
vehicle, be sure the doors are closed
and locked.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash and it
helps prevent passengers f rom
accidentally opening and f alling out.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop.
See page f or how to lock the
doors.Adjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have a front passenger adjust their
seat as far to the rear as possible.
If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating f ront
airbag, or by striking the steering
wheel or dashboard.
Remember however, that no saf ety
system can prevent all injures or
deaths that can occur in severe crash,
even when seat belts are properly
worn and the airbags deploy.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle. The f ollowing pages provide
instructions on how to properly
protect the driver, adult passengers,
and teenage children who are large
enough and mature enough to drive
or ride in the f ront.
72
3430 Close and L ock the Doors
A djust the Front Seats
Introduction 1.
2.
Protecting A dults and Teens
12
Page 14 of 236
The National Highway Traffic Safety
Administration and Transport
Canada recommend that drivers
allow at least 10 inches (25 cm)
between the center of the steering
wheel and the chest.
If you cannot get f ar enough away
f rom the steering wheel and still
reach the controls, we recommend
that you investigate whether some
type of adaptive equipment may help.Once your seat is adjusted correctly,
rock it back and f orth to make sure
the seat is locked into position. See
page f or how to adjust the f ront
seats.
76
Protecting A dults and Teens
Driver and Passenger Saf ety
13
Sitting too close to a front
airbag can result in serious
injury or death if the front
airbags inflate.
Always sit as far back from the
front airbags as possible.
Page 15 of 236
Adjust the driver’s seat-back to a
comf ortable, upright position,
leaving ample space between your
chest and the airbag cover in the
center of the steering wheel.
Passengers with adjustable seat-
backs should also adjust their seat-
back to a comf ortable, upright
position.Reclining a seat-back so that the
shoulder part of the belt no longer
rests against the occupant’s chest
reduces the protective capability of
the belt. It also increases the chance
of sliding under the belt in a crash
and being seriously injured. The
farther a seat-back is reclined, the
greater the risk of injury.
See page f or how to adjust the
seat-backs.76
Adjust the Seat-Backs
3.
Protecting A dults and Teens
14
Reclining the seat-back too far
can result in serious injury or
death in a crash.
Adjust the seat-back to an
upright position, and sit well
back in the seat.
Page 24 of 236
Your airbag system includes:Two SRS (Supplemental Restraint
System) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG.’’
Automatic seat belt tensioners
(see page ). In models with side airbags, one
for the driver and one for a front
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page ).
Sensors that can detect a
moderate to severe front impact,
or side impact in models with side
airbags. an
indicator on the dashboard that
alerts you that the passenger’s
side airbag has been turned of f
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
An indicator on the instrument
panel that alerts you to a possible
problem with your airbags,
sensors, or seat belt tensioners
(see page ). In models with side airbags,
sensors that can detect whether
a child is in the passenger’s side
airbag path and automatically
turn the airbag off (see page ).
A sophisticated electronic system
that continually monitors and
records inf ormation about the
sensors, the control unit, the
airbag activators, the seat belt
tensioners, and driver and f ront
passenger seat belt use when the
ignition is in the ON (II) position.
21 26
27 28
26
In models with side airbags,A irbag System Components
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
23
Page 52 of 236
This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .52
............................
Instrument Panel .53
..........
Instrument Panel Indicators . 56
..
Maintenance Required Indicator . 60
.............................................
Gauges .61
.....................................
Odometer .61
...................................
Trip Meter .61
..................................
Fuel Gauge .61
...................
Temperature Gauge . 62
Controls Near the Steering ...........................................
Wheel .63
.
Windshield Wipers and Washers . 64
...........
Turn Signal and Headlights . 65
........
Instrument Panel Brightness . 66
...................
Hazard Warning Light . 67
.................
Rear Window Def ogger . 67
..........
Steering Wheel Adjustment . 68
...............................
Keys and Locks .69
........................
Immobilizer System .70
................................
Ignition Switch .71
......................................
Door Locks .72
......................
Power Door Locks .72
..............
Childproof Door Locks . 72
...........................................
Trunk .73
........
Emergency Trunk Opener . 73
.......................
Remote Transmitter .74 .................................................
Seats .76
..............................
Power Windows .80
.........................................
Moonroof .81
.............................................
Mirrors .81
.................................
Parking Brake .83
.................................
Interior Lights .84
...........
Interior Convenience Items . 85
.......................
Beverage Holders .86
..........
Accessory Power Sockets . 86
....................................
Glove Box .86
...............
Console Compartment . 86
Instruments and Controls
Inst rument s and Cont rols
51
Page 64 of 236
Controls Near the Steering Wheel
Inst rument s and Cont rols
63
MOONROOFHAZARD WARNING
LIGHTS
TILT ADJUSTMENT
MIRROR CONTROLS HEADLIGHTS/
TURN SIGNALS
CRUISE CONTROL
SWITCHESREAR WINDOW
DEFOGGER
WINDSHIELD
WIPERS/WASHERS
CRUISE CONTROL
MASTER SWITCH HORN
(P.
81) (P.
65)
(P.64) (P.
67)
(P.67)
(P. 117)
(P.
68)
(P.
82)
(P.
117)
Page 69 of 236
To adjust the steering wheel upward
or downward:Push the lever under the steering
column all the way down. Push the lever up to lock the
steering wheel in that position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up and down.
Make any steering wheel adjustment
bef ore you start driving.
Move the steering wheel up or
down to the desired position.
Make sure you can see the
instrument panel gauges and the
indicator lights.
1. 4.
2. 3.
Steering Wheel A djustment
68
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
Page 72 of 236
µ
µ
µ
µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
You can
operate the audio system and the
accessory power sockets in this
position.
Use this position
only to start the engine. The switch
returns to ON (II) when you let go of
the key. You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or
ACCESSORY (I) position and open
the driver’s door. Remove the key to
turn of f the beeper.
If your vehicle has an automatic
transmission, the shif t lever must be
in Park bef ore you can remove the
key f rom the ignition switch.
This is the normal key
position when driving. Several of the
indicators on the instrument panel
come on as a test when you turn the
ignition switch f rom ACCESSORY
(I) to ON (II).
You can insert or
remove the key only in this position.
To turn the key, push it in slightly. If
your vehicle has an automatic
transmission, the shif t lever must
also be in park.
Ignition Switch
A CCESSORY (I)
ST A RT (III) ON (II)
LOCK (0)
Inst rument s and Cont rols
71
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control.
Remove the key from the
ignition switch only when
parked.
