If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
The operator
loads your vehicle on the back of a
truck.
Therearetwowaystotowyour
vehicle: If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Release the parking brake.
Shif t the transmission to neutral.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
The tow
truck uses two pivoting arms that go
under the f ront tires and lif t them of f
the ground. The rear tires remain on
the ground. With the f ront wheels on the ground,
do not tow the vehicle more than 50
miles (80 km), and keep the speed
below35mph(55km/h).
Start the engine.
Press on the brake pedal. Move
the shif t lever through all its
positions.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Release the parking brake.
Turn of f the engine.
Shif t to D position f or 5 seconds,
then to N.
Manual transmission:
Automatic transmission:
Flat -bed Equipment
Wheel-lif t Equipment
T his is the best way to
transport your vehicle.
This is an acceptable
way to tow your vehicle.
Emergency Towing
358
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
vehicle must be transported with the
f ront wheels of f the ground.
\f—\f—\fy

\fy
(#\fy\fy
2009 Civic Sedan

Do not tie down the vehicle at an
angle that would allow the towing
cables to contact the vehicle’s f ront
bumper. To avoid possible damage,
protect the f ront bumper with tape.
If your vehicle is equipped with a
f ront spoiler, remove it bef ore
towing so it is not damaged.
Emergency Towing
T aking Care of t he Unexpect ed
359
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
Trying to lif t or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicle’s weight.
\f—\f—\fy

y
(#\fy\fy
2009 Civic Sedan

360
\f—\f—\fy

y
(#\fy\fy
2009 Civic Sedan

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers .362
................................
Specif ications .364
DOT Tire Quality Grading
......................
(U.S. Vehicles) .367
.................................
Treadwear .367
......................................
Traction .367
.............................
Temperature .368
.................................
Tire Labeling .369
Tire Pressure Monitoring
System (TPMS) Required .............
Federal Explanation .370 .......................
Emissions Controls .372
.....................
The Clean Air Act .372
Crankcase Emissions Control
....................................
System .372
Evaporative Emissions Control ....................................
System .372
Onboard Ref ueling Vapor ................................
Recovery .372
...
Exhaust Emissions Controls .373
....................
PGM-FI System .373
Ignition Timing Control
................................
System .373
Exhaust Gas Recirculation ...................
(EGR) System .373
Three Way Catalytic ...........................
Converter .373
....................
Replacement Parts .373
..
Three Way Catalytic Converter .374
........................
Emissions Testing .375
T echnical Inf ormation
Technical Inf ormation
361
\f—\f—\fy

y
(#\fy\fy
2009 Civic Sedan

Your vehicle has several identif ying
numbers in various places.
The vehicle identif ication number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
f or warranty purposes. It is also
necessary f or licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
seeitbylookingthroughthe
windshield on the driver’s side. It is
also on the certification label
attached to the driver’s doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certif ication label.
The VIN is also located on the
engine bulkhead. Slide the cover on
the engine compartment bulkhead to
view the VIN. Always close the cover
when f inished.
Identif ication Numbers
362
CERTIFICATION LABEL
COVER
VEHICLE IDENTIFICATION
NUMBER (VIN)
\f—\f—\fy
y
(#\fy\fy
2009 Civic Sedan

The engine number is stamped into
the engine block. It is on the f ront.
The transmission number is on a
label on top of the transmission.
Identif ication Numbers
Technical Inf ormation
363
MANUAL TRANSMISSION
NUMBER
ENGINE NUMBER
ENGINE NUMBER
AUTOMATIC/MANUAL
TRANSMISSION NUMBER
Except Si
Si
\f—\f—\fy

y
(#\fy\fy
2009 Civic Sedan

ÃŽ
ÃŽÃŽÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ ÃŽ
ÃŽ
ÃŽ
ÃŽ
Specif ications
364
Dimensions
Weights Engine
Seating Capacities 177.3 in (4,504 mm)
69.0 in (1,752 mm)
56.5 in (1,435 mm)
106.3 in (2,700 mm)
59.0 in (1,499 mm)
60.2 in (1,528 mm)
Length
Width
Height
Wheelbase
Track
Gross vehicle weight rating See the certification label attached
to the driver’s doorjamb. Type
BorexStroke
Displacement
Compression ratio
Spark plugs
Spark plugs
3.19 x 3.44 in (81.0 x 87.3 mm)
3.39x3.39in(86x86mm) 110 cu-in (1,799 cm
)
122 cu-in (1,998 cm)
10.5
11.0
IZFR6K11S
NGK:
DENSO: SKJ20DR-M11S
IFR7G11KS
SK22PR-M11S
Total
Front
Rear 5
2
3 Water cooled 4-stroke
SOHC i-VTEC , DOHC i-VTEC 4-cylinder gasoline engine
Front
Rear
NGK:
DENSO:
1:
2: Except Si
Si
1
2 12
1
2
1
2 2
1
\f—\f—\fy
y
(#\fy\fy
2009 Civic Sedan

µµ
ÃŽ
ÃŽ
ÃŽ
Î µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µÎÎ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽÃŽ
Specif ications
Technical Inf ormation
365
Air Conditioning
Capacities
Lights
Refrigerant type
Charge quantity
Lubricant oil typeHFC-134a (R-134a)
14.1 15.9 oz (400 450 g) SP-10
12 V 60 W (HB3) 12 V 51 W (HB4)
12 V 24/2 CP
12 V 21 W
12 V 21/5 W
12 V 2 CP
12 V 21 W
12 V 3 CP
12 V 21 W
4.8 US qt (4.5
)
1.8 US qt (1.7
)
1.6 US qt (1.5
)
1.19 US gal (4.5
)
1.80 US gal (6.8
)
4.6 US qt (4.4
)
4.4 US qt (4.2
)
5.8 US qt (5.5
)
6.2 US qt (5.9
)
2.5 US qt (2.4)
1.40 US gal (5.3
)
1.77 US gal (6.7
)
2.6 US qt (2.5
)
1.7 US qt (1.6
)
1.5 US qt (1.4
)
1.37 US gal (5.2
)
1.72 US gal (6.5
)
3.9 US qt (3.7
)
3.7 US qt (3.5
)
4.8 US qt (4.5
)
13.2 US gal (50
)
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity: 0.11 US gal (0.4
)
Excluding the oil remaining in the engine
Fuel tank
Engine
coolant
Engine oil
Manual
transmission
fluid
Automatic
transmission
fluid
Windshield
washer
reservoir
Headlights
Front turn signal/side marker/
Parking lights
Rear turn signal lights
Stop/Taillights
Rear side marker lights
Back-up lights
Taillights
High-mount brake light
Fog lights
License plate lights
Ceiling light
Spotlights
Trunk light 12 V
12 V
12 V
12 V
5W
8W
8W
5W
12 V 55 W
High
Low
A/T
M/T
A/T
M/T
Change
Total
U.S. Vehicles
Canada
Vehicles Approx.
1:
2:
3:
4: Except Si
Si Change
Including filter
Without filter
Total
Change
Total
Change
Total (Amber)
(Amber)
(H11)
13 3
4
3
3
4
3
4
3
4
3
4
3
4
3
4
2
34
\f—\f—\fy
\fy
(#\fy\f\fy
2009 Civic Sedan

µ
µ
µ
µ
µ
µ
µ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽ
ÃŽÃŽ
ÃŽÃŽ
ÃŽ
Specif ications
366
Fuses
Alignment
Battery
Tires
P195/65R15 89H
Interior
Under-hood
Toe-in
Camber
Caster 7°24’ 0°45’0°
0.08 in (2.0 mm)
0.00 in (0.0 mm)
Capacity 12 V
12 V
12 V36 AH/5 HR
38 AH/5 HR
45 AH/20 HR
47 AH/20 HR
12 V
12 V 38 AH/5 HR
47 AH/20 HR
12 V T135/80R16 101MT125/70D15 95M
215/45ZR17 91W P215/45R17 87V
P205/55R16 89H P195/65R15 89S
See page357or the fuse label
attached to the inside of the fuse
box door under the steering
column.
See page356or the fuse box
cover. Size
Pressure 30 psi (210 kPa , 2.1 kgf/cm)
32 psi (220 kPa , 2.2 kgf/cm)
33 psi (230 kPa , 2.3 kgf/cm)
60 psi (420 kPa , 4.2 kgf/cm)
Front
Rear
Front
Rear
Front Front/Rear
Spare
Si
Optional for Si (summer tires)
U.S.
Vehicles
Canada
Vehicles
Front/Rear
Spare
Si (all season tires)
Canadian DX-G with manual transmission
DX, Canadian DX-G with automatic transmission
EX-L, Si
1:
2:
3:
4:
5:
6:
7:
8:
Except EX-L, Si
EX-L, U.S. LX, LX-S, EX, Canadian Sport
3
1
2
4
5
7
7
3
6
1, 2
4, 6
8
\f—\f—\fy
y
(#\fy\f
y
2009 Civic Sedan

Quality grades can be f ound where
applicable on the tire sidewall
between tread shoulder and
maximum section width. For
example:
All passenger car tires must conf orm
to Federal Saf ety Requirements in
addition to these grades.The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under controlled
conditions on a specif ied government
test course. For example, a tire
graded 150 would wear one and one-
half (1 1/2) times as well on the
government course as a tire graded
100. The relative perf ormance of
tires depends upon the actual condi-
tions of their use, however, and may
depart signif icantly f rom the norm
due to variations in driving habits,
service practices and dif f erences in
road characteristics and climate.
The traction grades, f rom highest to
lowest, are AA, A, B, and C. Those
grades represent the tire’s ability to
stop on wet pavement as measured
under controlled conditions on
specif ied government test surf aces
of asphalt and concrete. A tire
marked C may have poor traction
perf ormance.
Warning: The traction grade
assignedtothistireisbasedon
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
The tires on your vehicle meet all
U.S. Federal Saf ety Requirements.
All tires are also graded f or
treadwear, traction, and temperature
perf ormance according to
Department of Transportation
(DOT) standards. The f ollowing
explains these gradings.
Unif orm T ire Quality Grading
T readwear 200
Traction AA
Temperature A T readwear T raction
