key battery HONDA CIVIC SEDAN 2013 Owner's Manual (in English)

99Continued
Controls
Locking and Unlocking the Doors
Key Types and Functions
This vehicle comes with the following key:Use the keys to start and stop the engine, to
lock and unlock the doors and to open the
trunk. You can also use the remote
transmitter
* to lock and unlock the doors and
to open the trunk.
■Master Keys
1 Key Types and Functions
All of the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.
2 Immobilizer System P. 112
The keys contain precision electronics.
Adhere to the following advice to prevent damage to
the electronics:
•Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.
•Do not drop the keys or set heavy objects on them.•Keep the keys away from liquids.•Do not take the keys apar t except for replacing the
battery.
If the circuits in the keys are damaged, the engine
may not start, and the re mote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.
Black
* Not available on all models

113
uuSecurity System uSecurity System Alarm*
Controls
■Setting the security system alarm
The security system alarm automatically se ts when the following conditions have
been met:
• The ignition switch is in LOCK
(0, and the key has b een removed from the
ignition switch.
• The hood and trunk are closed.
• All doors are locked with the key or the remote transmitter.
■When the security system alarm sets
The security system indicato r in the instrument panel blinks. When the blinking
interval changes after about 15 seco nds, the security system is set.
■To cancel the security system alarm
The security system is cancel ed when the vehicle is unlocked using the key or remote
transmitter, or the ignition switch is turned to ON
(w. The security system indicator
goes off at the same time.
■The PANIC button on the remote
transmitter
If you press the PANIC button for
approximately one seco nd, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.
■Canceling panic mode
Press any button on the remote transmitter, or turn the ignition switch to ON
(w.
■Panic Mode
1Security System Alarm*
Do not set the security sy stem alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:
•Unlocking the door with the lock tab.•Opening the trunk with the trunk release or the
emergency trunk opener.
If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key or remote transmitter.
Do not attempt to alter th is system or add another
device to it.
PANIC
Button
* Not available on all models

118
uuOperating the Switches Around the Steering Wheel uTurn Signals
Controls
Turn Signals
The turn signals can be used when the ignition
switch is in ON
(w.
■One-touch turn signal
When you lightly push up or down and release
the turn signal lever, th e exterior turn signals
and turn signal indica tor blink three times.
This feature can be used when signaling for a
lane change.
Light Switches
Rotating the light swit ch turns the lights on
and off, regardless of the position of the
ignition switch.
■High beams
Push the lever forward until you hear a click.
■Low beams
When in high beams, pull the lever back to
return to low beams.
■Flashing the high beams
Pull the lever back, and release it.
Right Turn
Left Turn
■Manual Operation1 Light Switches
If you remove the key from the ignition switch while
the lights are on, a chime sounds when the driver’s
door is opened.
When the lights are on, the lights on indicator in the
instrument panel will be on.
2 Lights On Indicator P. 72
Do not leave the lights on when the engine is off
because it will cause th e battery to discharge.
If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.
High Beams
Flashing the high beams
Low Beams
Turns on parking, side marker,
tail, and rear license plate lights
Turns on headlights, parking, side
marker, tail, and rear license plate
lights

307
Maintenance
Remote Transmitter Care*
Replacing the Button Battery
If the indicator does not come on when the button is pressed, replace the battery.
1. Unscrew the cover wi th a small Phillips-
head screwdriver. Pr ess a button to pry
open the transmitter.
2. Open the keypad.
u Separate the inner cover from the
keypad by releasing the two tabs on the
cover.
3. Make sure to replace the battery with the
correct polarity.1Replacing the Button Battery
NOTICEAn improperly disposed of battery can damage the
environment. Always conf irm local regulations for
battery disposal.
Replacement batteries are commercially available or
at a dealer.
Keypad
Screw
Battery type: CR1616
Battery
Tab
* Not available on all models

360
Index
Brake System............................................. 241
Anti-lock Brake System (ABS) ................... 243
Brake Assist System ................................. 244
Fluid ........................................................ 280
Foot Brake ............................................... 242
Indicator ............................................ 66, 339
Parking Brake .......................................... 241
Brightness Control (Instrument Panel) .... 123
Bulb Replacement ..................................... 282
Brake/Taillights, Rear Turn Signal Lights and
Rear Side Marker Lights ......................... 291
Fog Lights ................................................ 286
Front Turn Signal/Parking/Side Marker
Lights..................................................... 289
Headlights ............................................... 282
High-Mount Brake Light .... ...................... 294
Rear License Plate Lights .......................... 293
Taillights and Back-Up Ligh ts ................... 292
Bulb Specifications ............................ 346, 348
C
Carbon Monoxide Gas ................................ 62
Carrying Cargo .................................. 215, 217
CD Player ........................................... 155, 162
Center Pocket ............................................ 137
Certification Label .................................... 350
Changing Bulbs ......................................... 282
Charging System Indicator ................. 67, 337
Child Safety ................................................. 50
Childproof Door Locks ............................. 104 Emergency Trunk Opener ........................ 111
Child Seat .................................................... 50
Booster Seats ............................................ 61
Child Seat for Infants................................. 52
Child Seat for Small Children ..................... 53
Installing a Child Seat with a Lap/Shoulder Seat Belt .................................................. 57
Larger Children ......................................... 60
Rear-facing Child Seat ......................... ...... 52
Selecting a Child Seat ................................ 54
Using a Tether ........................................... 59
Childproof Door Locks ............................. 104
Cleaning the Exterior ............................... 311
Cleaning the Interior ................................ 309
Climate Control System ............................ 146
Changing the Mode ................................ 146
Defrosting the Windshield and Windows ........................................ 147
Dust and Pollen Filter............................... 308
Recirculation/Fresh Air Mode ................... 147
Sensors ................................................... 148
Using Automatic Climate Control ............ 146
Clock ............................................................ 98
Clutch Fluid ............................................... 280
Coat Hook ................................................. 140
Compact Spare Tire .................. 315, 347, 349
Console Compartment ............................. 136
Controls ....................................................... 97
Coolant (Engine) ...................................... 275
Adding to the Radiator .... ........................ 276
Adding to the Reserve Tank..................... 275 High Temperature Indicator ...................... 69
Low Temperature Indicator ....................... 73
Overheating ............................................ 335
Creeping (Automatic Transmission) ........ 226
Cruise Control .......................................... 233
Indicator ................................................... 74
Cup Holders .............................................. 138
Customer Service Information ................ 358
Customized Features ................................. 85
D
Daytime Running Lights .......................... 121
Dead Battery ............................................ 331
Defrosting the Windshield
and Windows ................................. 145, 147
Devices that Emit Radio Waves ............... 351
Dimming
Headlights .............................................. 118
Rearview Mirror ...................................... 126
Dipstick (Engine Oil) ................................ 269
Directional Signals (Turn Signal) ............. 118
Display/Information Button ...................... 81
Door Mirrors ............................................. 126
Doors .......................................................... 99
Auto Door Locking.................................. 105
Auto Door Unlocking .............................. 105
Door Open Indicator ........................... 29, 70
Keys.......................................................... 99
Locking/Unlocking the Doors
from the Inside...................................... 103

363
Index
Information.............................................. 345
Information Display ................................... 79
Instant Fuel Economy .......................... 77, 84
Instrument Panel ........................................ 65
Brightness Control .................................. 123
intelligent Multi-Information Display (i-MID) ....................................................... 81
Interior Lights ........................................... 135
Interior Rearview Mirror ......................... 126
i-VTEC and REV Indicators ......................... 78
J
Jack (Wheel Nut Wrench)........................ 318
Jump Starting ........................................... 331
K
Key Number Tag ...................................... 100
Keyless Lockout Prevention ..................... 102
Keys ............................................................. 99
Lockout Prevention .......... ....................... 102
Master Keys .............................................. 99
Number Tag............................................ 100
Rear Door Won’t Open .... ....................... 104
Remote Transmitter ................................ 101
Types and Functions.................................. 99
Valet Key ................................................ 100
Won’t Turn ............................................... 20
Kickdown (Automat ic Transmission)...... 226
L
Language (HFL)......................................... 182
LATCH (Child Seats) .................................... 55
Lights ................................................. 118, 282
Automatic ............................................... 119
Bulb Replacement.................................... 282
Daytime Running Lights . .......................... 121
Fog Lights................................................ 121
High Beam Indicator .................................. 72
Interior .................................................... 135
Light Switches ......................................... 118
Lights On Indicator .................................... 72
Turn Signals............................................. 118
Load Limits ................................................ 217
Locking/Unlocking ...................................... 99
Auto Door Locking/Unlocking .................. 105
Childproof Door Locks ............................. 104
From Inside.............................................. 103
From Outside........................................... 101
Keys .......................................................... 99
Using a Key ............................................. 102
Lockout Preven tion System...................... 102
Low Battery Charge .................................. 337
Low Fuel Indicator ...................................... 68
Low Oil Pressure Indicator ................. 66, 337
Lower Anchors ............................................ 55
Lubricant Specifications Chart ......... 346, 348
Luggage (Maximum Load Limit) ............. 217
M
Maintenance............................................. 253
Battery .................................................... 306
Brake/Clutch Fluid ................................... 280
Cleaning ................................................. 309
Climate Control System ........................... 308
Coolant ................................................... 275
Heating and Cooling System ................... 308
Maintenance Minder
TM............................ 257
Oil ........................................................... 269
Precautions ............................................. 254
Radiator .................................................. 276
Remote Transmitter ................................. 307
Replacing Light Bulbs .............................. 282
Safety...................................................... 255
Service Items ................................... 259, 263
Tires ........................................................ 297
Transmission Fluid ................................... 277
Under the Hood ...................................... 265
Malfunction Indicator Lamp .............. 67, 338
Manual Transmission ............................... 229
Map Lights ................................................ 135
Maximum Load Limit ............................... 217
Meters, Gauges ........................................... 77
Mirrors ...................................................... 126
Adjusting ................................................ 126
Door ....................................................... 126
Exterior ................................................... 126
Interior Rearview ..................................... 126
Modifications (and Accessories) .............. 251
Moonroof ................................................. 116
