auto HONDA CR-V 2002 RD4-RD7 / 2.G User Guide

Canadian models only
With the headlight switch off, the
high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) and
release the parking brake. They
remain on until you turn the ignition
of f , even if you set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.Turntheknobontheleftsideof the
instrument panel to adjust the
brightness of the instrument panel
lights.Signal a turn or lane change with this
lever. Push down on the lever to
signal a lef t turn, and up to signal a
right turn. If you push it up or down
all the way, the turn signal continues
to blink even when you release the
lever. It shuts off automatically as
you complete the turn.
CONT INUED
Instrument Panel Brightness
Daytime Running L ights T urn Signals
Controls Near the Steering Wheel
Inst rument s and Cont rols77
T TU
UR RNN S
SIIGGN NAAL
L L
LEE V
V E
ER
R

µµ
µ µ
You can insert or
remove the key only in this position.
To switch f rom ACCESSORY to
LOCK, you must push the key in
slightly as you turn it. If your vehicle
has an automatic transmission, the
shif t lever must also be in Park. The
anti-thef t lock will lock the steering
column when you remove the key.
If the f ront wheels are turned, the
anti-thef t lock may sometimes make
it difficult to turn the key from
LOCK to ACCESSORY. Firmly turn
the steering wheel to the lef t or to
the right as you turn the key. Use this position
only to start the engine. The switch
returns to ON (II) when you let go of
the key.
You will hear a reminder beeper if
you leave the key LOCK (0) or
ACCESSORY (I) position and open
thedriver’sdoor.Removethekeyto
turn of f the beeper. The engine will not start if the
Immobilizer System does not
recognize the key’s coding (see page ).
This is the normal key
position when driving. All f eatures
and accessories on the vehicle are
usable. Several of the lights on the
instrument panel come on as a test
when you turn the ignition switch
f rom ACCESSORY to ON. In this position,
you can operate the audio system
and the accessory power sockets. 85
Keys and Locks
Inst rument s and Cont rols
L OCK (0)
ST A RT (III)
ON (II) A CCESSORY (I)
87
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control.
Remove the key from the
ignition switch only when
parked.

The ceiling light (if the light switch
is in the center position) will come
on when you press the UNLOCK
button. If you do not open any of the
doors or the tailgate, the light will
f ade out in about 30 seconds, the
doors and the tailgate automatically
relock. If you relock the doors and
the tailgate with the remote
transmitter before 30 seconds have
elapsed, the light will go of f
immediately.
You cannot lock the doors and the
tailgate with the remote transmitter
if any door or the tailgate is not f ully
closed. You cannot lock or unlock
thedoorsandthetailgatewiththe
key in the ignition switch.To open the hatch glass, push the
Hatch Glass Release button for
about two seconds. The hatch glass
willnotopenif thekeyisinthe
ignition switch.
Even if the hatch glass is opened, the
tailgate can be locked with the
remote transmitter. Make sure to
check the hatch glass manually.
Panic mode allows you to remotely
activate your vehicle’s horn and
lights to attract attention. When
activated, the horn will sound, and
the headlights, parking lights, side
marker lights, taillights and
instrument panel lights will f lash f or
about 30 seconds. To activate panic
mode,pressandholdthePANIC
button f or about one second.
To cancel Panic mode bef ore 30
seconds, press any button on the
remote transmitter. You can also
turn the ignition switch to ON (II).
Panic mode will not activate if the
ignition switch is in the ON (II)
position.
Keys and Locks
Inst rument s and Cont rols
Panic Mode
90

To adjust the height of the driver’s
seat, turn the dial on the outside of
theseatbottom.Eachfrontseathasanarmreston
thesideof theseat-back.Touseit,
pivotitdown.Only on vehicles with an automatic
transmission
Driver’s Seat Height Adjustment Front Seat Armrests
Inst rument s and Cont rols
Seats
98

µ
The master control panel also con-
tains these extra features:
To open the driver’s
window f ully, push the window
switch f irmly down, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To close the driver’s window f ully,
pull back the window switch f irmly,
then release it. The window
automatically goes all the way up. To
stop the window f rom going all the
way up, push down on the window
switch brief ly. To open or close the driver’s window
partially, push down or pull back on
the window switch lightly and hold it.
The window will stop when you
release the switch.
The light inside the AUTO switch
comes on when you turn the ignition
switch to ON (II).
The MAIN switch controls power to
the passengers’ windows. When you
push in the MAIN switch, the
passengers’ windows cannot be
raised or lowered. The MAIN switch
does not af f ect the driver’s window.
To cancel this f eature, push on the
switch again. Keep the MAIN switch
pushed in when you have children in
the vehicle so they do not injure
themselves by operating the
windows unintentionally.
Power Windows
Inst rument s and Cont rols
AUTO
111

If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use. You should do
the f ollowing.Start the engine. Push down on
the driver’s window switch until
the window is f ully open.
Pull back on the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by a Honda dealer.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If the driver’s window runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
window, remove the obstacle, then
use the window switch again.
1.
2.
Power Windows
Inst rument s and Cont rols
Auto Reverse
112

The center table has a beverage
holder f or the f ront passengers.The rear seat also has a beverage
holder in the center armrest. To use
it, pivot the armrest down.
To use the f ront beverage holder,
pull on the handle. Push the holder
all the way in to close it.Only on vehicles with an automatic
transmission
Inst rument s and Cont rols
Beverage Holders
116

Be sure to lock the legs of the
table.
Do not stand on the table.
Do not put a weight of over 44 lbs
(20kg)onthetable.
Hot items such as pots, pans, or
kettles should not be placed
directly on the table top.A storage box is located under the
f ront passenger’s seat. To use it, pull
upward slightly on the f ront center
edge of the box and slide it out.
Open the center pocket by pulling
thehandle.Closeitwithafirmpush.
CONT INUED
Only on vehicles with an automatic
transmission
Inst rument s and Cont rols
Storage Box
Center Pocket
Using the Built-in T able
Built-in Table, Center Pocket, Storage Box
119

These sockets are intended to supply
power f or 12 volt DC accessories
that are rated 120 watts or less (10
amps). To power an accessory, the
ignition switch must be in
ACCESSORY (I) or ON (II).
When both sockets are being used,
the combined power rating of both
accessories should be 120 watts or
less (10 amps).
They will not power an automotive
type cigarette lighter element.
Your vehicle has two accessory
power sockets. One is located on the
dashboard, and the other is on the
lef t side of the cargo area. To use an accessory power socket,
pull up on the cover.
Inst rument s and Cont rols
A ccessory Power Socket s
122
F Fr
roo n
nt
t R
Reeaarr
P
P u
ul
lll u
u p
p P
P
u
ul
lll u
u p
p

The system automatically
turns on the A/C and switches to
Recirculation mode. Air f lows f rom
the center and side vents in the
dashboard.
Air flows from the center
and corner vents in the dashboard.
Air f low is divided between
the vents in the dashboard and the
f loor vents.
Air f lows f rom the f loor
vents.
Air f low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Air f lows f rom the def roster
vents at the base of the windshield. When you select or ,
the system automatically switches to
Fresh Air mode and turns on the
A/C.With these two modes, the A/C
stays on.
Heating and Cooling
Comf ort and Convenience Feat ures129
