Canadian models only
With the headlight switch off, the
high beam headlights come on with
reduced brightness when you turn
the ignition switch to ON (II) and
release the parking brake. They
remain on until you turn the ignition
of f , even if you set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.Turntheknobontheleftsideof the
instrument panel to adjust the
brightness of the instrument panel
lights.Signal a turn or lane change with this
lever. Push down on the lever to
signal a lef t turn, and up to signal a
right turn. If you push it up or down
all the way, the turn signal continues
to blink even when you release the
lever. It shuts off automatically as
you complete the turn.
CONT INUED
Instrument Panel Brightness
Daytime Running L ights T urn Signals
Controls Near the Steering Wheel
Inst rument s and Cont rols77
T TU
UR RNN S
SIIGGN NAAL
L L
LEE V
V E
ER
R

To signal a lane change, push lightly
on the turn signal lever in the proper
direction and hold it. The lever will
return to the center position as soon
as you release it.This lever controls the windshield
wipers and washers. It has five
positions:MIST: mist
OFF: off
INT: intermittent
LO: low speed
HI: high speed
To select a position, push the lever
up or down. In intermittent, the wipers operate
every f ew seconds. In low speed and
high speed, the wipers run continu-
ously.
Controls Near the Steering Wheel
Inst rument s and Cont rols
Windshield Wipers
78

To operate the wipers in mist mode,
push the control lever up f rom the
OFF position. The wipers run at high
speed until you release the lever.
This gives you a quick way to clear
the windshield.To clean the windshield, pull back on
the wiper control lever. The washers
spray until you release the lever.The wipers run at low speed while
you’re pulling the lever, then
complete one more sweep of the
windshield af ter you release it.
Controls Near the Steering Wheel
Inst rument s and Cont rols
Windshield Washers
79

Therotatingswitchontheright
lever controls the rear window wiper
and washer.
To activate the rear windshield wiper,
rotate the switch to ‘‘ON’’. The wiper
operates every seven seconds after
completing two sweeps. When you
turn the wiper switch to the ‘‘OFF’’
position or turn of f the ignition
switch, the wiper will return to its
parked position.To use the wiper and washer, rotate
and hold the switch one position up
f rom ‘‘ON’’. The wiper opreates
while you are holding the switch,
then completes two more sweeps
after you release it. To use the
washer only, rotate and hold the
switch one position down f rom
‘‘OFF’’.
The rear wiper will not work if the
hatch glass is not f ully closed.
If you open the hatch glass while the
rear wiper is operating, the wiper will
stop. To return the wiper to its
parked position, close the hatch
glass, and then rotate the switch to
the ‘‘OFF’’ position.
Therearwindowwasherusesthe
same f luid reservoir as the wind-
shield washer.
Controls Near the Steering Wheel
Rear Window Wiper and Washer
Inst rument s and Cont rols80

Push the button between the center
air vents to turn on the hazard
warning lights (f our-way f lashers).
This causes all f our outside turn
signals and both indicators in the
instrument panel to f lash. Use the
hazard warning lights if you need to
park in a dangerous area near heavy
traf f ic, or if your vehicle is disabled.The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and of f . The light in the
button lights to show the def ogger is
on.Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
Thedefoggerwiresontheinsideof
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side to side.
Controls Near the Steering Wheel
Inst rument s and Cont rols
Hazard Warning
Rear Window Def ogger
81

To release the parking brake, push
andholdthereleasebuttononthe
side of the parking brake lever, pull
the lever toward you slightly, then
push the lever f orward.
The parking brake light on the
instrument panel should go out when
the parking brake is fully released
(see page ).
To apply the parking brake, f irmly
pull the parking brake lever toward
you.
66
Controls Near the Steering Wheel
Inst rument s and Cont rols
Parking Brake
82
P PA
A R
RKKIINNG G B
BRRAA K
KEE
L
LE E V
V E
ER
R R
RE
EL
LEE A
A S
SEE B
BUUT TT
TO
ON N
Driving the vehicle with the parking
brake applied can damage the rear
brakes and axles.

Push the lever up to lock the
steering wheel in that position.
Make sure you have securely
locked the steering wheel in place
by trying to move it up and down.
Push the lever under the steering
column all the way down.
Move the steering wheel to the
desired position, making sure the
wheel points toward your chest,
not toward your f ace. Make sure
you can see the instrument panel
gauges and the indicator lights.
To adjust the steering wheel upward
or downward:
Make any steering wheel adjustment
bef ore you start driving.
1.
2.3.
4.
See page f or important saf ety
inf ormation about how to properlyposition the steering wheel. 20
Inst rument s and Cont rols
Controls Near the Steering Wheel
Steering Wheel A djustment
83
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.

These keys contain electronic
circuits that are activated by the
Immobilizer System. They will not
work to start the engine if the
circuits are damaged.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
The keys do not contain batteries.
Do not try to take them apart. Keep the keys away f rom liquids.
If they get wet, dry them immedi-
ately with a soft cloth. Donotdropthekeysorsetheavy
objects on them.
Your vehicle comes with two master
keys and a valet key.
The master key fits all the locks on
your vehicle:
 Ignition
 Doors
GloveBox
 Tailgate The valet key works only in the
ignition, the door locks and the
tailgate. You can keep the glove box
locked when you leave your vehicle
and the valet key at a parking f acility.
Youshouldhavereceivedakey
number plate with your set of keys.
You will need this key number if you
ever have to get a lost key replaced.
Keep the plate stored in a saf e place.
When replacing keys, use only
Honda-approved key blanks.
Keys
Keys and Locks
Inst rument s and Cont rols84
V V
A
AL
LEE T
T
K
KE EY
Y
(
( G
Gr raay y))
K
KE
EY
Y
N
NU UMM B
BEER
R
P
P L
LAA T
TE
E M
M
A
AS
STTE
ER
R
K
KE EY
YS S
(
( B
Bl laac ckk) )

Some models also come with two
remote transmitters; see page for
an explanation of their operation.When you turn the ignition switch to
ON (II), the Immobilizer System
indicator should come on f or a f ew
seconds, then go out. If the indicator
starts to blink, it means the system
does not recognize the coding of the
key. Turn the ignition switch to
LOCK (0), remove the key, reinsert
it, and turn the switch to ON (II)
again.The system may not recognize your
key’s coding if another immobilizer
key or other metal object is near the
ignition switch when you insert the
key. To make sure the system
recognizes the key code:
The Immobilizer System protects
your vehicle f rom thef t. A properly-
coded master or valet key must be
used in the ignition switch f or the
engine to start. If an improperly-
coded key (or other device) is used,
the engine’s f uel system is disabled. Do not keep other immobilizer
keys on the same key ring.
Use a plastic or leather key f ob,
not metal.
Keep other keys away f rom your
vehicle’s key and the ignition
switch while trying to start the
engine.
If the system repeatedly does not
recognize the coding of your key,
contact your Honda dealer.
89
CONT INUED
Remote TransmitterImmobilizer System
Keys and Locks
Inst rument s and Cont rols85

The Immobilizer System indicator
will also blink several times when
you turn the ignition switch f rom ON
(II) to ACCESSORY (I) or LOCK (0).
If you have lost your key and you
cannot start the engine, contact your
Honda dealer. Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle undriveable.The ignition switch is on the right
side of the steering column. It has
f our positions:
LOCK(0)
 ACCESSORY (I)
 ON (II)
 START (III)As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Keys and Locks
Inst rument s and Cont rols
Ignition Switch
