Page 64 of 372
Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
Have the exhaust system inspected
f or leaks whenever:
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the under-
side. With the tailgate/hatch glass open,
air flow can pull exhaust gas into
your vehicle’s interior and create a
hazardous condition. If you must
drive with the tailgate/hatch glass
open, open all the windows and set
the heating and cooling system as
shown below.
If you must sit in your parked vehicle,
even in an unconf ined area, with the
engine running, adjust the heating
and cooling system as f ollows:
Select the Fresh Air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
1.
2.
3.
4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety60
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
Page 188 of 372
Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Your Honda is designed to operate
on unleaded gasoline with a pump
octane number of 86 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy metallic rapping
noise in the engine that can lead to
mechanical damage.
We recommend gasolines containing
detergent additives that help prevent
f uel system and engine deposits.
Using gasoline containing lead will
damage your vehicle’s emissions
controls. This contributes to air
pollution.In Canada, some gasolines contain
an octane-enhancing additive called
MMT. If you use such gasolines,
your emission control system
perf ormance may deteriorate and
the Malfunction Indicator Lamp on
your instrument panel may turn on.
If this happens, contact your
authorized Honda dealer f or service.
Youshouldfollowthesesamere-
commendations with an overhauled
or exchanged engine, or when the
brakes are relined. Do not change the oil until the
recommended time or mileage
intervalshowninthemaintenance
schedule. Avoidhardbraking.Newbrakes
need to be broken-in by moderate
use f or the f irst 200 miles (300
km). Avoid full-throttle starts and rapid
acceleration.
Break-in Period, Gasoline
Bef ore Driving
Break-in Period
Gasoline
184
Page 219 of 372
µµAlways drive
slower than you would in dry
weather. It takes your vehicle longer
to react, even in conditions that may
seem just barely damp. Apply
smooth, even pressure to all the
controls. Abrupt steering wheel
movements or sudden, hard appli-
cation of the brakes can cause loss of
control in wet weather. Be extra
cautious f or the f irst f ew miles
(kilometers) of driving while you
adjust to the change in driving
conditions. This is especially true in
snow. A person can f orget some
snow-driving techniques during the
summer months. Practice is needed
to relearn those skills.
Exercise extra caution when driving
in rain af ter a long dry spell. Af ter
months of dry weather, the f irst
rains bring oil to the surf ace of the
roadway, making it slippery. Being able to see
clearly in all directions and being
visible to other drivers are important
in all weather conditions. This is
more difficult in bad weather. To be
seen more clearly during daylight
hours, turn on your headlights.
Inspect your windshield wipers and
washers f requently. Keep the wind-
shield washer reservoir f ull of the
proper f luid. Have the windshield
wiper blades replaced if they start to
streak the windshield or leave parts
unwiped. Use the def rosters and air
conditioning to keep the windows
f rom f ogging up on the inside (see
page ).
Rain, f og, and snow conditions re-
quire a dif f erent driving technique
because of reduced traction and
visibility. Keep your vehicle well-
maintained and exercise greater
caution when you need to drive in
bad weather. The cruise control
should not be used in these condi-
tions. 134
CONT INUED
Driving T echnique
Visibility
Driving in Bad Weather
Driving215
Page 252 of 372
The oil’s viscosity or weight is
provided on the container’s label.
Select the oil f or your vehicle
according to this chart.You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal,
and it is the proper weight as shown
on the chart. When using synthetic
oil, you must f ollow the oil and f ilter
change intervals given in the
maintenance schedule.
Your Honda does not require any oil
additives. Additives may adversely
af f ect your engine’s or transmission’s
perf ormance and durability.
5W-20 oil is f ormulated f or year-
round protection of your Honda, to
improve cold weather starting, and
to help your engine use less f uel.
If 5W-20 oil is not available, a 5W-30
oil may be used. However, it should
be replaced with 5W-20 at the next
oil change.
Engine Oil
Maint enance
Synthetic Oil
A dditives
248
A A
m
m b
bi
ieen n t
t T
Te
emm p
pe
erraat tuu r
ree
Page 253 of 372
Remove the oil f ilter and let the
remaining oil drain. A special
wrench (available from your
Honda dealer) is required to
remove the f ilter.
Install a new oil f ilter according to
instructions that come with it.
Run the engine until it reaches
normal operating temperature,
then shut it off.
Open the hood and remove the
engine oil f ill cap. Remove the oil
drain bolt and washer f rom the
bottom of the engine. Drain the oil
into an appropriate container.
Always change the oil and f ilter
accordingtothetimeanddistance
(miles/kilometers) recommenda-
tions in the maintenance schedule.
The oil and f ilter collect contami-
nants that can damage your engine if
they are not removed regularly.
Changing the oil and f ilter requires
special tools and access f rom
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lif t f or this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
mechanic.
1.
2.
4. 3.
CONT INUED
Changing the Oil and Filter
Engine Oil
Maint enance249
O OIILL D
DR
RAA I
INN B
BOOL LTT W
WA
AS
SHH E
ER
R
O
OIILL F
FIILLT T E
ER
R
Page 254 of 372
Put a new washer on the drain bolt,
then reinstall the drain bolt.
Tighten it to:Replace the engine oil f ill cap.
Start the engine. The oil pressure
indicator light should go out within
f ive seconds. If it does not, turn of f
the engine and reinspect your
work.
Let the engine run f or several
minutes and check the drain bolt
and oil f ilter f or leaks.
Turn of f the engine, let it sit f or
several minutes, then check the oil
level. If necessary, add oil to bring
the level to the upper mark on the
dipstick.
Refill the engine with the recom-
mended oil.
Engine oil change capacity
(including f ilter):
5.
6.
7.
8.
9.
Engine Oil
Maint enance250
33 lbf·ft (44 N·m , 4.5 kgf·m)
4.4 US qt (4.2
, 3.7 Imp qt) Improper disposal of engine oil can be
harmf ul to the environment. If you
change your own oil, please dispose of
the used oil properly. Put it in a sealed
container and take it to a recycling
center. Do not discard it in a trash bin
or dump it on the ground.
Page 299 of 372
If you need to park your vehicle f or
an extended period (more than one
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).Cover the vehicle with a
‘‘breathable’’ cover, one made
f rom a porous material such as
cotton. Nonporous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.
Fill the f uel tank.
Change the engine oil and f ilter
(see page ).
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc. are
completely dry. To minimize sticking, apply a
silicone spray lubricant to all door
and tailgate seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and tailgate seals. Support the f ront and rear wiper
blade arms with a f olded towel or
ragsotheydonottouchthe
windshield. Disconnect the battery.
Leave the parking brake off. Put
the transmission in Reverse
(5-speed manual) or Park
(automatic). If possible, run the engine f or a
while periodically (pref erably once
amonth).
If you store your vehicle f or 12
months or longer, have your Honda
dealer perf orm the inspections called
f or in the 24 months maintenance
schedule (Normal Conditions) as
soon as you take it out of storage
(see page ). The replacements
called f or in the maintenance
schedule are not needed unless the
vehicle has actually reached that
time or mileage.
249
238
Maint enance
St oring Your Vehicle
295
Page 346 of 372
ÎÎ
ÎÎ
Î
Specif ications
T echnical Inf ormation342
Dimensions
Weights
Engine
Capacities
178.6 in (4,537 mm)
70.2 in (1,782 mm)
66.2 in (1,682 mm)
103.1 in (2,620 mm)
60.4 in (1,533 mm)
60.6 in (1,538 mm)
3.43 x 3.90 in (87.0 x 99.0 mm) 144 cu-in (2,354 cm
)
9.6 : 1
15.3 US gal (58
, 12.8 Imp gal)
4.4 US qt (4.2
, 3.7 Imp qt)
4.2 US qt (4.0, 3.5 Imp qt)
5.6 US qt (5.3, 4.7 Imp qt) 1.43 US gal (5.4
, 1.19 Imp gal)
1.88 US gal (7.1, 1.56 Imp gal)
1.45 US gal (5.5
, 1.21 Imp gal)
1.90 US gal (7.2, 1.58 Imp gal)
3.3 US qt (3.1
, 2.7 Imp qt)
3.1 US qt (2.9, 2.6 Imp qt)
7.6 US qt (7.2
, 6.3 Imp qt)
6.9 US qt (6.5, 5.7 Imp qt)
2.0 US qt (1.9, 1.7 Imp qt)
2.4 US qt (2.3, 2.0 Imp qt)
1.1 US qt (1.0
, 0.9 Imp qt)
1.3 US qt (1.2, 1.1 Imp qt)
Length
Width
Height
Wheelbase
Track
Gross vehicle weight rating See the certification label attached
to the driver’s doorjamb.
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
Fuel tank
Engine oil See spark plug maintenance
section page 268 .Water cooled 4-stroke DOHC
VTEC 4-cylinder gasoline engine
4.8 US qt (4.5
, 4.0 Imp qt)
2.6 US qt (2.5, 2.2 Imp qt)
2.2 US qt (2.1
, 1.8 Imp qt)
Engine
coolant
Automatic
transmission
fluid
Manual
transmission
fluid
Rear
differential
fluid (4WD)
Windshield
washer
reservoir
Excluding the oil remaining in the engine.
Including the coolant in the reserve tank and that remaining in the
engine.
Reserve tank capacity:
0.16 US gal (0.6
, 0.13 Imp gal)
Approx.
Front
Rear
Change
Without filter
Total 1:
2:Change
Total
Change
Total
Change
4WD
2WD
Total 4WD
2WD
Change
Total
Change
Total
U.S. Vehicles
Canada
Vehicles 4WD
2WD
Automatic Transmission
Manual Transmission
1 2
2
Including filter
Page 364 of 372
ÎBulb Replacement.........
Rear Side Marker Lights . 290
............................
Specif ications .343
...................................
Spotlights .293
....................
Turn Signal Lights . 288
..............................
Bulbs, Halogen .287
................
DANGER, Explanation of . ii
.......................................
Dashboard .64
................
Daytime Running Lights . 77
............
Def ects, Reporting Saf ety . 356
........................
Def og and Def rost .134
................
Def ogger, Rear Window . 81
..............
Def rosting the Windows . 134
.......................
Detachable Anchor .108
....................................
Dimensions .342
...............
Dimming the Headlights . 76
............................
Capacities Chart .342
.............
Carbon Monoxide Hazard . 60
..........................
Cargo Area Light .125
.................................
Cargo Hooks .195
.............................
Carrying Cargo .193
Cassette Player ............................................
Care .168
...........................
Operation .151, 164
..............
CAUTION, Explanation of . ii
..........................
CD Changer .149, 169
.......................................
CD Player .146
...............................
Center Pocket .119
..................................
Center Table .115
........................
Certif ication Label .340
............................................
Chains .284
....................
Changing a Flat Tire .308
............
Changing Engine Coolant . 253.................................
Changing Oil .249
........................................
How to .249
......................................
When to .238
...
Charging System Indicator . 66,326
............
Checklist, Bef ore Driving . 199
.....................................
Child Saf ety .24
.......................................
Child Seats .29
......
LATCH Anchorage System . 48
...........................
Lower Anchors .48
............
Tether Anchorage Point . 46
..................
Childproof Door Locks . 93
....................
Cleaner Element, Air . 265
Cleaning ....................
Aluminum Wheels .299
...................................
Carpeting .301
......................................
Exterior .298
.........................................
Fabric .302
.......................................
Interior .301
.......................................
Leather .302
...................................
Seat Belts .302
...........................................
Vinyl .302
....................................
Windows .303
.................
Clock, Setting the . 144,162
...................................
Clutch Fluid .264
........................
CO in the Exhaust .348
............
Cold Weather, Starting in . 201...............
Consumer Inf ormation . 354
.............
Controls, Instruments and . 63
Coolant ........................................
Adding .251
....................................
Checking .189
.........................
Proper Solution .251
...................................
Replacing .253
...................
Temperature Gauge . 74
....................
Corrosion Protection .304
Crankcase Emissions Control ........................................
System .348
............
Cruise Control Operation . 179
..........
Customer Relations Of f ice . 354
Index
C
D
II
Page 367 of 372
CONT INUED
.......................
Label, Certif ication .340
.................
Lane Change, Signaling . 77
..................
Lap/Shoulder Belts . 17,50
...........
LATCH Anchorage System . 48
Lights ....................
Bulb Replacement .287
.......................................
Indicator .65
.........................................
Parking .76
..................................
Turn Signal .77
.....................................
Load Limit .194
......
LOCK (Ignition Key Position) . 87
Locks .......
Anti-thef t Steering Column . 87
............................
Fuel Fill Door .185
....................................
Glove Box .96
.................................
Power Door .88
........................................
Tailgate .93
........................
Low Coolant Level .189
.........................
Low Fuel Indicator .69
...
Low Oil Pressure Indicator . 66,325
................................
Lower Anchors .48
...
Lubricant Specif ications Chart . 342
.........................................
Luggage .193 ..................................
Maintenance .233
...
Owner Maintenance Checks . 245
.................................
Record .243-244
......................
Required Indicator .70
..........................................
Saf ety .234
.............................
Schedule .238-242
.
Malf unction Indicator Lamp . 66,327
...................
Manual Transmission . 202
........
Manual Transmission Fluid . 261
.........................
Meters, Gauges .65, 72
...................
Methanol in Gasoline . 346
........................
Mirrors, Adjusting .114
.......................................
Moonroof .113
......................
Closing Manually .330
...................................
Operation .113
...............................
Inf ant Restraint .34
......................................
Inf ant Seats .34
......
LATCH Anchorage System . 48
...........................
Lower Anchors .48
..........
Tether Anchorage Points . 46
...................
Inf lation, Proper Tire . 278
.................
High Speed Driving . 279
.........................
Normal Driving .279
.................................
Inside Mirror .114
.............................
Inspection, Tire .280
............................
Instrument Panel .65
........
Instrument Panel Brightness . 77
...........................
Interior Cleaning .301
...............................
Interior Lights .124
........................................
Introduction .i
..................................................
Keys .84
..................
Jacking up the vehicle . 312
.......................................
Jack, Tire .309
................................
Jump Starting .320
Index
LM
K J
V
