This allows you to move the shif t
lever out of Park if the normal
method of pushing on the brake
pedal does not work. This procedure
is also used to release the Reverse
Lockout.Put a cloth on the edge of the Shif t
Lock Release slot cover next to
theshiftlever.Useasmallflat-
tipped screwdriver or small metal
plate (neither are included in the
tool kit) to remove the cover.
Caref ully pry on the edge of the
cover. To release the Reverse Lockout,
make sure the ignition switch is in
the ACCESSORY(I) position. Make sure the ignition switch is in
the LOCK (0) position. Set the Parking brake. Insert a screwdriver in the Shif t
Lock Release slot.
Push down on the screwdriver and
move the shift lever out of Park to
Neutral.
To release the Reverse Lockout,
move the shift lever from Neutral
to Reverse, then to Park.Remove the Screwdriver f rom the
Shif t Lock Release slot, then
install a new cover. Make sure the
notchonthecoverisontheright
side. Depress the brake pedal and
restart the engine.
If you need to use the Shif t Lock
Release, it means your vehicle is
developing a problem. Have the
vehicle checked by your Honda
dealer.
1.
2.
3.
4.
5.
6.
Shif t L ock Release
Automatic Transmission
Driving209
COVER
SHIFT LOCK RELEASE SLOT

When the brake pads need replacing,
you will hear a distinctive metallic
‘‘screeching’’ sound when you apply
the brakes. If you do not have the
brake pads replaced, they will begin
screeching all the time.
Your brakes may sometimes squeal
or squeak when you apply them
lightly. Do not conf use this with the
brakewearindicators.Theymakea
very audible ‘‘screeching.’’
Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by downshif ting to a lower
gear and taking your f oot of f the
accelerator pedal.
Check your brakes af ter driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Since a
longer distance is needed to stop
with wet brakes, be extra cautious
and alert in your driving.
Put your f oot on the brake pedal only
when you intend to brake. Resting
your f oot on the pedal keeps the
brakes applied lightly, causing them
to build up heat. Heat build-up can
reduce how well your brakes work. It
also keeps your brake lights on all
the time, conf using drivers behind
you. Your Honda is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The ABS (on
vehicles equipped with ABS) helps
you retain steering control when
braking very hard.
All f our brakes have audible brake
wear indicators. Brake Wear Indicators
The Braking System
Driving211

This section explains why it is
important to keep your vehicle well
maintained and to f ollow basic
maintenance saf ety precautions.
This section also includes
Maintenance Schedules f or normal
driving and severe driving conditions,
a Maintenance Record, and instruc-
tions f or simple maintenance tasks
you may want to take care of
yourself .
If you have the skills and tools to per-
f orm more complex maintenance
tasks on your Honda, you may want
to purchase the Service Manual. See
page f or inf ormation on how to
obtain a copy, or see your Honda
dealer.......................
Maintenance Saf ety .234
.
Important Safety Precautions . 235
.................
Maintenance Schedule . 236 ...
Required Maintenance Record . 243
.......
Owner Maintenance Checks . 245
..............................
Fluid Locations .246
......................................
Engine Oil .247
..................................
Adding Oil .247
....................
Recommended Oil .247
..............................
Synthetic Oil .248
....................................
Additives .248
.....
Changing the Oil and Filter . 249
.............................
Cooling System .251
............
Adding Engine Coolant . 251
.......
Replacing Engine Coolant . 253
....................
Windshield Washers .258
.......................
Transmission Fluid .260
..........
Automatic Transmission . 260
5-speed Manual .........................
Transmission .261
.................
Rear Dif f erential Fluid . 262
................
Brake and Clutch Fluid . 263
............................
Brake System .263
...........................
Clutch System .264
..............................
Power Steering .264
.....................
Air Cleaner Element .265
....................................
Hood Latch .266
....................................
Spark Plugs .267
..............................
Replacement .267 ............................
Specif ications .268
...........................................
Battery .269
.................................
Wiper Blades .271
..............
Air Conditioning System . 274
..................
Dust and Pollen Filter . 275
.......................................
Drive Belt .277
...............................................
Tires .278
......................................
Inf lation .278
Recommended Tire Pressures f or Normal ...........................
Driving .279
Tire Pressure Adjustment f or ..........
High Speed Driving . 279
..................................
Inspection .280
..............................
Maintenance .280
.............................
Tire Rotation .281
...
Replacing Tires and Wheels . 282
......................
Wheels and Tires .283
..........................
Winter Driving .283
.............................
Snow Tires .283
............................
Tire Chains .284
.............................................
Lights .285
.....................
Headlight Aiming .287
........................
Replacing Bulbs .287
....................
Storing Your Vehicle .295
357
Maintenance
Maint enance233

µ
Î
Ì
Ì
ÌÎ
Maint enance238
Service at the indicated distance or time whichever comes first.miles x 1,000
km x 1,000
months 10
16
50
8070
112 110
176
Check oil and coolant at each fuel stop
Replace at 120,000 miles (192,000 km) or 6 years, then every 90,000 miles (144,000 km) or 5 years.
See information on maintenance and emissions warranty, last column, page .
Service the following items at the recommended intervals.
Inspect every 110,000 miles (176,000 km), otherwise adjust only if noisy Every 110,000 miles (176,000 km)Every 30,000 miles (48,000 km)
Check engine oil and coolant
Replace engine oil
Rotate tires (Check tire inflation and condition at least once per month)
Replace engine oil filter
Inspect front and rear brakes
Check parking brake adjustment
Visually inspect the following items:
Tie rod ends, steering gear box and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluidsExhaust system
Fuel lines and connections
Inspect and adjust drive belts
Replace dust and pollen filter
Replace transmission fluid
Replace rear differential fluid ( 4WD)
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Inspect idle speed
Replace engine coolant
Replace brake fluid Every 160,000 miles (256,000 km) or 8 years
At 120,000 miles (192,000 km) or 10 years,
then every 60,000 miles (96,000 km) or 5 years Every 3 years (independent of mileage)
20
32
30
4840
64 60
9680
128 100
160120
192
90
144
24 4872
12 3660
M/T
A/T 237
:
:
Maintenance Schedule for Normal Conditions

µµ
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ì
Ì
Ì
:
Maint enance239
U.S. Owners
Canadian Owners
A, B, C, D
A
B
C
D
Refer to page to determine which schedule to use.
Use the Maintenance Schedule for Severe Conditions.
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time.
Replace engine oil.
Rotate tires (follow pattern on page281).
Replace engine oil filter.
Inspect front and rear brakes.
Check parking brake adjustment.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks. Inspect exhaust system.
Inspect fuel lines and connections.
Inspect and adjust drive belts.
Replace dust and pollen filter.
Replace air cleaner element every 30,000 mi/48,000 km
(independent of time).
10,000 mi/16,000 km/1 yr
20,000 mi/32,000 km/1 yr
30,000 mi/48,000 km
30,000 mi/48,000 km/2 yrs
40,000 mi/64,000 km/2 yrs
3yrs
50,000 mi/80,000 km/3 yrs
60,000 mi/96,000 km
60,000 mi/96,000 km/3 yrs
70,000 mi/112,000 km/4 yrs
80,000 mi/128,000 km/4 yrs
90,000 mi/144,000 km
90,000 mi/144,000 km/5 yrs
100,000 mi/160,000 km/5 yrs
110,000 mi/176,000 km
6yrs
110,000 mi/176,000 km/6 yrs
120,000 mi/192,000 km
120,000 mi/192,000 km/6 yrs
120,000 mi/192,000 km/10 yrs
160,000 mi/256,000 km/8 yrs Do items in A.
Do items in A, B.
Do item in D.
Do items in A, C.
Do items in A, B.
Replace brake fluid (independent of mileage).
Do items in A.
Do item in D.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do item in D.
Do items in A, C. Replace rear differential fluid (4WD).
Do items in A, B. Inspect valve clearance, cold engine.
Replace spark plugs.
Replace brake fluid (independent of mileage).
Do items in A.
Do item in D. Replace transmission fluid (M/T).
Replace transmission fluid (A/T), then
replace every 90,000 mi/144,000 km/5 yrs.
DoitemsinA,B,C. Replace engine coolant, then replace every
60,000 mi/96,000 km/5 yrs. Inspect idle speed.
236
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
See information on maintenance and emissions warranty,
last column, page .
237
NOTE:
Maintenance Schedule for Normal Conditions (listed by distance/time)

µ
Î
Ì
ÌÌÎ
Maint enance240
Service at the indicated distance or time whichever comes first. miles x 1,000
km x 1,000
months
Replace every 5,000 miles (8,000 km) or 6 monthsCheck oil and coolant at each fuel stop
At 120,000 miles (192,000 km) or 10 years,
then every 60,000 miles (96,000 km) or 5 years Every 3 years (independent of mileage)
At 60,000 miles (96,000 km) or 3 years, then every 30,000 miles
(48,000 km) or 2 years
Inspect every 110,000 miles (176,000 km), otherwise adjust only if noisy Every 110,000 miles (176,000 km)
Every 15,000 miles (24,000 km) in dusty conditions,
otherwise use normal schedule
Service the following items at the recommended intervals.
See information on maintenance and emissions warranty, last column, page . See dust and pollen filter on page for replacement information under special driving conditions.
Check engine oil and coolant
Replace engine oil
Rotate tires (Check tire inflation and condition at least once per month)
Replace engine oil filter
Inspect front and rear brakes
Lubricate door hinges, lo
cks, and latches
Visually inspect the following items: Tie rod ends, steering gear box and boots
Suspension components
Driveshaft boots
Check parking brake adjustment
Visually inspect the following items: Brake hoses and lines (including ABS)
All fluid levels and condition of fluidsExhaust system, Fuel lines and connections
Lights and controls, Vehicle underbody
Inspect and adjust drive belts
Replace dust and pollen filter
Replace transmission fluid
Replace rear differential fluid (4WD)
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Inspect idle speed
Replace engine coolant
Replace brake fluid 10
16
20
3230
4840
6450
8060
9670
112 80
128 90
144 100
160110
176120
192
Every 160,000 miles (256,000 km) or 8 years 24
4872
12 3660
M/T
A/T
:
: 237
275
Maintenance Schedule for Severe Conditions

µµ
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ì
Ì
Î
CONT INUED
Maint enance241
U.S. Owners
Canadian Owners A, B, C, D, E
A
B
C
D
E
Refer to page to determine which schedule to use.
Use the Maintenance Schedule for Severe Conditions.
Service at the indicated distance or time, whichever comes first. Do the items in
as required for each distance/time.
Replace engine oil.
Replace engine oil filter.
Inspect front and rear brakes.
Rotate tires (follow pattern on page 281).
Lubricate door hinges, lo cks, and latches with
multipurpose grease.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Check parking brake adjustment.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks. Inspect exhaust system.
Inspect fuel lines and connections.
Check all lights.
Inspect the underbody.
Inspect and adjust drive belts.
Replace dust and pollen filter .
Replace air cleaner element every 15,000 mi/
24,000 km (independent of time) under dusty
conditions, otherwise use Normal Conditions
schedule.
5,000 mi/8,000 km/½ yr
10,000 mi/16,000 km/1 yr
15,000 mi/24,000 km
15,000 mi/24,000 km/1-½ yrs
20,000 mi/32,000 km/1 yr
20,000 mi/32,000 km/2 yrs
25,000 mi/40,000 km/2-½ yrs
30,000 mi/48,000 km
30,000 mi/48,000 km/2 yrs
30,000 mi/48,000 km/3 yrs
35,000 mi/56,000 km/3-½ yrs
40,000 mi/64,000 km/2 yrs
40,000 mi/64,000 km/4 yrs
45,000 mi/72,000 km
45,000 mi/72,000 km/4-½ yrs
3yrs
50,000 mi/80,000 km/3 yrs
50,000 mi/80,000 km/5 yrs
55,000 mi/88,000 km/5-½ yrs
60,000 mi/96,000 km
60,000 mi/96,000 km/3 yrs
60,000 mi/96,000 km/6 yrs Do item in A.
Do items in A, B.
Do item in E.
Do item in A.
Do items in B, C.
Do item in A.
Do item in A.
Do item in E.
Do items in B, D.
Do item in A.
Do item in A.
Do items in B, C.
Do item in A.
Do item in E.
Do item in A.
Replace brake fluid (independent of mileage).
Do item in B.
Do item in A.
Do item in A.
Do item in E. Replace transmission fluid (M/T).
Replace transmission fluid (A/T).
DoitemsinB,C,D.
Do item in A.
236Maintenance Schedule for Severe Conditions (listed by distance/time)

Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
ØÎ
Ì
Maint enance242
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
See dust and pollen filter on page for replacement information
under special driving conditions.
See information on maintenance and emissions warranty, last
column, page .
NOTE: 275
237
65,000 mi/104,000 km/6-½ yrs
70,000 mi/112,000 km/4 yrs
70,000 mi/112,000 km/7 yrs
75,000 mi/120,000 km
75,000 mi/120,000 km/7-½ yrs
80,000 mi/128,000 km/4 yrs
80,000 mi/128,000 km/8 yrs
85,000 mi/136,000 km/8-½ yrs
90,000 mi/144,000 km
90,000 mi/144,000 km/5 yrs
90,000 mi/144,000 km/9 yrs
95,000 mi/152,000 km/9-½ yrs
100,000 mi/160,000 km/5 yrs
100,000 mi/160,000 km/10 yrs
105,000 mi/168,000 km
105,000 mi/168,000 km/10-½ yrs
6yrs
110,000 mi/176,000 km
110,000 mi/176,000 km/6 yrs
110,000 mi/176,000 km/11 yrs
115,000 mi/184,000 km/11-½ yrs
120,000 mi/192,000 km
120,000 mi/192,000 km/6 yrs
120,000 mi/192,000 km/7 yrs
120,000 mi/192,000 km/10 yrs
120,000 mi/192,000 km/12 yrs
160,000 mi/256,000 km/8 years Do item in A.
Do item in B.
Do item in A.
Do item in E.
Do item in A.
Do items in B, C.
Do item in A.
Do item in A.
Do item in E.
Replace transmission fluid (A/T).
Replace rear differential fluid (4WD).
Do items in B, D.
Do item in A.
Do item in A.
Do items in B, C.
Do item in A.
Do item in E.
Do item in A. Replace brake fluid (independent of mileage).
Inspect valve clearance, cold engine.
Replace spark plugs.
Do item in B.
Do item in A.
Do item in A.
Do item in E. Replace transmission fluid (M/T).
DoitemsinB,C,D. Replace transmission fluid (A/T).
Replace engine coolant, then replace every
60,000 mi/96,000 km/5 yrs.
Do item in A. Inspect idle speed. :
:
Maintenance Schedule for Severe Conditions (listed by distance/time)

µµµ µ
µ
µ µ
Engine oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you f ill the f uel tank. See page .
Windshield washer f luid Check
the level in the reservoir monthly.
If weather conditions cause you to
use the washers f requently, check
the reservoir each time you stop
f or f uel. See page .
Youshouldcheckthefollowing
items at the specif ied intervals. If
you are unsure of how to perf orm
any check, turn to the page given.
Tires Check the tire pressure
monthly. Examine the tread f or
wear and foreign objects. See page
.
Automatic transmission Check
the f luid level monthly. See page .
Brakes Check the f luid level
monthly. See page . Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
turn signals, brake lights, and
license plate light monthly. See
page .
188
189
258
260 278
285
263
Owner Maintenance Checks
Maint enance245

To add oil, unscrew and remove the
engine oil f ill cap on top of the valve
cover. Pour in the oil, and install the
engine oil f ill cap. Tighten it securely.
Wait a f ew minutes and recheck the
oil level. Do not f ill above the upper
mark; you could damage the engine.Make sure the API Certif ication Seal
says ‘‘For Gasoline Engines.’’
Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade 5W-20
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements.
Pour the oil slowly and caref ully so
you do not spill. Clean up any spills
immediately. Spilled oil could
damage components in the engine
compartment. Honda Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. It is
highly recommended that you use
Honda Motor Oil in your vehicle f or
optimum engine protection.
CONT INUED
Recommended Oil
A dding Oil
Engine Oil
Maint enance247
ENGINE OIL FILL CAP
API CERTIFICATION SEAL
