Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
f acility.
Tighten the wheel nuts to:
Remove the center cap from the
flat tire.
Put the flat tire on the spare tire
holder. Put the wheel nuts on
finger-tight, then tighten them
with the wheel nut wrench. Put
the center spacer in the center of
the wheel.
Tighten the wheel nuts to:
Store the jack in its holder. Turn
the jack’s end bracket to lock it in
place. Store the tools, and install
thecoveronthesideof thecargo
area.
Close the tailgate.
Install the spare tire cover.
17.
18.
19.
20.
22.
21.
Changing a Flat T ire
224
CENTER SPACER
80 lbf·ft (108 N·m , 11 kgf·m)
40 lbf·ft (54 N·m , 5.5 kgf·m)
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.

Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action.
Start the engine, and watch the oil
pressure indicator. If it does not go
out within10seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(see on page
).
1.
2.
4. 3.
145
193
242
L ow Oil Pressure Indicator
Charging System Indicator
Emergency T owing
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
233
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.

However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully. Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (seeon page ). If the ABS indicator and the VSA
system indicator come on with the
brake system indicator, have your
vehicle inspected by your dealer
immediately.
The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and as
a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads. 201
242
Brake System Indicator
Emergency
Towing
T aking Care of t he Unexpect ed
235
Canada
U.S.

The operator will load
your vehicle on the back of a truck.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inf orm
them a f lat-bed is required. If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous. Refer to
on page
for non-emergency towing
inf ormation. 177
On 4WD models
The only way you can saf ely tow
your vehicle is with f lat-bed
equipment. Towing Your Vehicle
Behind a Motorhome
Emergency T owing
242
Towing with only two tires on the
ground will damage parts of the 4WD
system. It should be transported on a
f lat-bed truck or trailer.

µThe tires on your vehicle meet all
U.S. Federal Saf ety Requirements.
All tires are also graded f or
treadwear, traction, and temperature
perf ormance according to
Department of Transportation
(DOT) standards. The f ollowing
explains these gradings.
Quality grades can be f ound where
applicable on the tire sidewall
between the tread shoulder and the
maximum section width. For
example:
The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under controlled
conditions on a specif ied government
test course. For example, a tire
graded 150 would wear one and one-
half (1 1/2) times as well on the
government course as a tire graded
100. The relative perf ormance of
tires depends upon the actual condi-
tions of their use, however, and may
depart signif icantly f rom the norm
due to variations in driving habits,
service practices, and dif f erences in
road characteristics and climate.
The traction grades, f rom highest to
lowest, are AA, A, B, and C. Those
grades represent the tire’s ability to
stop on wet pavement as measured
under controlled conditions on
specif ied government test surf aces
of asphalt and concrete. A tire
marked C may have poor traction
perf ormance.
Warning: The traction grade
assignedtothistireisbasedon
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.
All passenger car tires must conf orm
to Federal Saf ety Requirements in
addition to these grades.
DOT T ire Quality Grading (U.S. Vehicles)
T readwear 200
Traction AA
Temperature A
Unif orm T ire Quality Grading
Treadwear Traction AA, A, B, C
248

Customer Service................................
Inf ormation .256
....................
Warranty Coverages .257
Reporting Saf ety Def ects ..........................
(U.S. Vehicles) .258
.....................
Authorized Manuals .259
Warranty and Customer Relations
Warrant y and Cust omer Relat ions
255

Honda dealership personnel are
trained prof essionals. They should
be able to answer all your questions.
If you encounter a problem that your
dealership does not solve to your
satisf action, please discuss it with
the dealership’s management. The
service manager or general manager
can help. Almost all problems are
solved in this way.
U.S. Owners:Canadian Owners:
In Puerto Rico and the U.S. Virgin
Islands:
When you call or write, please give
us this inf ormation:
If you are dissatisf ied with the
decision made by the dealership’s
management, contact your Honda
Customer Service Office. Vehicle Identif ication Number
(see page )
Name and address of the dealer
who services your vehicle
Date of purchase
Mileage on your vehicle
Your name, address, and tele-
phone number
A detailed description of the
problem
Name of the dealer who sold the
vehicle to you244
Cust omer Service Inf ormat ion
256
CUSTOMER RELATIONS
RELATIONS AVEC LA CLIENTÈLE
Honda Canada Inc.
715 Milner Avenue
Toronto, ON
M1B 2K8
Tel: 1-888-9-HONDA-9
Fax: Toll-free 1-877-939-0909 Toronto (416) 287-4776
American Honda Motor Co., Inc.
Automobile Customer Service
Mail Stop 500-2N-7A
1919 Torrance Boulevard
Torrance, California 90501-2746
Tel: (800) 999-1009 Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7098

Î
Î
Î
µ
Î 
 $#
Valid only f or sales within the United States. Canadian
owners should contact their authorized Honda dealer.T he publications shown below can be purchased f rom Helm
Incorporated. You can order in any of three ways:
Detach and mail the order f orm on the right half of this page
Call Helm Inc. at 1-800-782-4356
Go online at
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.
(credit card orders only)
Authorized Manuals
Authorized Manuals
Purchasing Factory Authorized Manuals (U.S. only)
259
ORDER TOLL FREE: 1-800-782-4356
OR
(NOTE: For Credit Card Holder Orders Only)
MINIMUM CREDIT CARD PURCHASE $10.00
Publication
Form Number
61S9A04
61S9A03EL
61S9A30
31S9A640
31S9AM10
31S9AQ30
HON-R
Form Description
2006 Honda CR-V
Service Manual
2006 Honda CR-V
Electrical Troubleshooting Manual
2002-06 Honda CR-V
Body Repair Manual
2006 Honda CR-V
Owner’s Manual
2006 Honda CR-V
Honda Service History
2006 Honda CR-V
Quick Start Guide
Order Form for Previous Years-
Indicate Year and Model Desired
Price
Each
$75.00
$50.00
$44.00
$35.00
$12.00
$12.00
FREE
PUBLICATION NUMBER VEHICLE MODEL
Name Year Qty Price
Each
Total
Price
GRAND TOTAL
HANDLING CHARGE
Mich. Purchases Add 6% Sales Tax
TOTAL MATERIAL
$6.95
Prices are subject to change without notice and without incurring obligation.
Monday-Friday 8:00 A.M. 6:00 P.M. EST
By completing this form you can order the materials desired. You can
pay by check or money order, or charge to your credit card. Mail to
Helm Incorporated at the address shown on the back of the order form.
Prices are subject to change without
notice and without incurring obligation.
Orders are mailed within 10 days. Please
allow adequate time for delivery.
www. helminc. com

µ
µ
µ
(


%
)
$
%

.
"

#
)
This manual covers maintenance and recommended
procedures f or repair to engine and chassis components.
It is written f or the journeyman mechanic, but is simple
enough f or most mechanically-inclined owners to under-
stand.
This manual describes the procedures involved in the
replacement of damaged body parts.
This manual complements the service manual by
providing in-depth troubleshooting inf ormation f or each
electrical circuit in your vehicle.
Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
260
NOTE: Dealers and companies, please provide dealer or company name, and the name of the person to whose attention the shipment should besent. For purchases outside U.S.A. please write to the address shownbelow for a quotation.
P.O. BOX 07280·DETROIT, MICHIGAN 48207·1-800-782-4356
Customer Name Attention
Apartment Number
State & Zip Code City
Daytime Telephone Number
Check or money order enclosed payable to Helm Inc U.S. funds only. Do not send cash
Master Card VISA Check here if your billing address is different from the shipping address shown above.
Account Number Expiration: Mo. Yr.
CUSTOMER SIGNATURE DATE
Street Address No P.O. Box Number
()
These publications cannot be returned for credit without receiving advance authorization within 14 days of delivery. On returns, a restocking fee may be applied against the original order.

Î
....................
Cargo, How to Carry .150
Cassette Player ....................................
Care .115, 131
...........................
Operation .113, 129
..............
CAUTION, Explanation of . ii
.........................................
CD Care .134
..........................
CD Changer .111, 125
CD Changer Error ...........................
Messages .112, 128
.....................
CD Error Messages .112
..............................
CD Player .109, 124
.................................
Center Pocket .95
....................................
Center Table .94
........................
Certif ication Label .244
.................................
Chains, Tires .216
....................
Changing a Flat Tire .220
.................................
Changing Oil .194
........................................
How to .194
......................................
When to .187
...
Charging System Indicator . 56,233
..............
Check Fuel Cap Indicator . 63
............
Checklist, Bef ore Driving . 157
.....................................
Child Saf ety .32
..............................
Booster Seats .47
.............................
Child Seats .32, 39
.....
Important Saf ety Reminders . 32..........................................
Inf ants .37
............................
Large Children .46
.........................................
LATCH .41
......................
Risks with Airbags .33
.............................
Small Children .38
.........................................
Tethers .45
...........................
Warning Labels .34
.........
Where Should a Child Sit? . 33
.................................
Child Seats .32, 39
.........................................
LATCH .41
..........
Tether Anchorage Points . 45
..................
Childproof Door Locks . 73
.......................
Cleaning Seat Belts .208
..............................................
Clock .137
...................................
Clutch Fluid .202
........................
CO in the Exhaust .251
.........................................
Coin Tray .93
............
Cold Weather, Starting in . 158
...............
Consumer Inf ormation . 256
.............
Controls, Instruments and . 53
Coolant ........................................
Adding .196
....................................
Checking .146
.........................
Proper Solution .196
...................
Temperature Gauge . 62Crankcase Emissions Control
........................................
System .251
................
Cruise Control Indicator . 58
............
Cruise Control Operation . 138
.....................................
Cup Holders .91
.............
Customer Service Of f ice . 256
................
DANGER, Explanation of . ii
...................................
Dashboard .3, 54
................
Daytime Running Lights . 67
Daytime Running Lights .......................................
Indicator .59
.................................
Dead Battery .229
............
Def ects, Reporting Saf ety . 258
................
Def ogger, Rear Window . 68
..............
Def rosting the Windows . 101
.........................
Detachable Anchor .85
....................................
Dimensions .246
.........
Dimming the Headlights . 66,67
Dipstick ..........
Automatic Transmission . 199
..................................
Engine Oil .145
..........................
Directional Signals .66
........
Disc Brake Wear Indicators . 167
Index
D
II
