Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components.Pour coolant into the reserve tank.
Fill it half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.
Make sure the engine and radiator
are cool. The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Pourthecoolantslowlyand
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.
Put the radiator cap back on, and
tighten it fully.
Relieve any pressure in the cooling
system by turning the radiator cap
counterclockwise, without
pressing down.
Remove the radiator cap by
pushingitdownandturningit
counterclockwise.
3. 4.
2. 1. 5.6.
Engine Coolant
Maint enance
271
RADIATOR CAP

Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
(Driver’s side)
Reinstall the coolant reserve tank.
Open the hood.
To change the turn signal bulb on
the driver’s side, remove the
engine coolant reserve tank by
pulling it out of its holder. Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
1. 2.
3.4.
5.
6.
Lights
Replacing a Front T urn Signal
Light Bulb
Maint enance
279

Look for any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you find a leak, it
must be repaired before you
continue driving (see
on page ).
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the first stop. After the
pressure releases, push down on
the cap, and turn it until it comes
off. Put
the radiator cap back on
tightl y. Run the engine, and check
the temperatu re gauge. If it goes
back to the red mark, the engine
needs repair (see on page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly. Start the engine, and set the
temperature control dial to
maximum heat. Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as you
can.
If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the reading
reaches the middle of the
temperature gauge or lower
bef ore checking the radiator. 9.
8.
7. 6. 5.
10.
11.
317
317
Emergency
Towing
Emergency
Towing
If theEngineOverheats
308
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.

ÎÎ
Î
Î
Specif ications
322
Dimensions
Weights
Engine
Capacities
Capacities
177.9 in (4,518 mm)
Length
Width
Height
Wheelbase
Track 66.1 in (1,680 mm)
103.1 in (2,620 mm)
61.6 in (1,565 mm)
61.6 in (1,565 mm)
Gross vehicle weight rating See the certification label attached to the driver’s doorjamb.
Type
BorexStroke
Displacement
Compression ratio
Spark plugs Water cooled 4-stroke DOHC
i-VTEC 4-cylinder gasoline engine 3.43 x 3.90 in (87.0 x 99.0 mm) 144 cu-in (2,354 cm
)
9.7 : 1
IZFR6K-11
SKJ20DR-M11
Fuel tank
Engine oil 15.3 US gal (58
)
4.4 US qt (4.2
)
4.2 US qt (4.0)
5.6 US qt (5.3) 1.32 US gal (5.0
)
1.88 US gal (7.1)
Engine
coolant
Automatic
transmission
fluid
Rear
differential
fluid (4WD)
Windshield
washer
reservoir 2.6 US qt (2.5
)
7.6 US qt (7.2
)
2.7 US qt (2.6
)
1.3 US qt (1.2
)
1.5 US qt (1.4)
7.4 US qt (7.0
)
Excluding the oil remaining in the engine
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:
0.16 US gal (0.6
) 2.6 US qt (2.5
)
4.8 US qt (4.5)
Approx.
Front
Rear
Change
Without filter
Total 1:
2:
(NGK) (DENSO) Change
Total
Change
4WD
2WD
Total 4WD
2WD
Change
Total
U.S. Vehicles
Canada
Vehicles
71.6 in (1,820 mm)
1 2
Including filter

Î
...............
DANGER, Explanation of .iii
...................................
Dashboard . 4, 72
................
Daytime Running Lights .75
Daytime Running Lights
.......................................
Indicator .63
.................................
Dead Battery .305
............
Def ects, Reporting Saf ety .336
................
Def ogger, Rear Window .77
..............
Def rosting the Windows .128
.......................
Detachable Anchor .104
....................................
Dimensions .322
.........
Dimming the Headlights . 74, 75
Dipstick ..........
Automatic Transmission .273
..................................
Engine Oil .218
..........................
Directional Signals .74
........
Disc Brake Wear Indicators .237
.....................
Disposal of Used Oil .269
..............................................
Cargo .222
...........................
Cargo area Light .121
.................................
Cargo Hooks .225
.............................
Carrying Cargo .222
....................
Cargo, How to Carry .222
.............
CAUTION, Explanation of .iii
.........................................
CD Care .202
..........................
CD Changer . 154, 181
CD Changer Error ...........................
Messages . 159, 187
.............
CD Error Messages . 159, 187
......................
CD Player . 135, 152, 172
...............................
Center Pocket .110
..................................
Center Table .114
........................
Certif ication Label .320
.................................
Chains, Tires .292
....................
Changing a Flat Tire .299
.................................
Changing Oil .267
........................................
How to .267
......................................
When to .263
....
Charging System Message . 60,309
............
Check Fuel Cap Indicator . 216
............
Checklist, Bef ore Driving . 229
.....................................
Child Saf ety . 34
..............................
Booster Seats .51
.............................
Child Seats . 34, 39 .....
Important Saf ety Reminders . 34
..........................................
Inf ants .39
............................
Large Children .50
.........................................
LATCH .43
......................
Risks with Airbags .35
.............................
Small Children .40
.........................................
Tethers .48
...........................
Warning Labels .36
.........
Where Should a Child Sit? . 35
.................................
Child Seats . 34, 39
.........................................
LATCH .43
..........
Tether Anchorage Points . 48
..................
Childproof Door Locks . 88
.......................
Cleaning Seat Belts .283
..............................................
Clock .206
........................
CO in the Exhaust .329
............
Cold Weather, Starting in . 230
...............
Consumer Inf ormation . 334
.............
Controls, Instruments and . 57
....................
Conversation Mirror .117
Coolant ........................................
Adding .270
....................................
Checking .218
.........................
Proper Solution .270
...................
Temperature Gauge . 69
..............................
Courtesy Light .121 Crankcase Emissions Control
........................................
System .329
................
Cruise Control Indicator . 62
............
Cruise Control Operation . 209
.............
Customer Service Of f ice . 334
Index
D
II

CONT INUED
Doors..........................
Auto Door Lock .84
.......................
Auto Door Unlock .86
..............
Childproof Door Locks .88
..............
Locking and Unlocking .84
......................
Power Door Locks .82
..........
DOT Tire Quality Grading .324
...........
Driver and Passenger Safety. 5
...........................................
Driving .227
....................................
Economy .219
........................
Driving Guidelines .228
.........................................
D Mode .233
................
Dual Deck Cargo Shelf .111
..................
Dust and Pollen Filter .284
..............................
Economy, Fuel .219
..................................
Emergencies .297
.............
Battery, Jump Starting .305
...........
Brake System Indicator .311
................
Changing a Flat Tire .299
.....
Charging System Indicator .309
..................
Checking the Fuses .312
.........
Hazard Warning Flashers . 76
............................
Jump Starting .305 .....
Low Oil Pressure Indicator .309
...
Malf unction Indicator Lamp .310
..................
Overheated Engine .307
.......................................
Towing .317
...........................
Emergency Brake .78
......................
Emergency Flashers .76
......................
Emergency Towing .317
.......................
Emissions Controls .329
.............
Emissions Testing, State .332
Engine
............
Adding Engine Coolant .270
....
Coolant Temperature Gauge .69
.........................
If It Won’t Start .303
Malf unction Indicator
................................
Lamp . 60, 310
........
Oil Pressure Indicator . 60, 309
..............
Oil, What Kind to Use . 267
...............................
Overheating .307
............................
Specif ications .322
............................
Speed Limiter .234
.......................................
Starting .230
......................
Ethanol in Gasoline .214
.
Evaporative Emissions Controls . 329
...............................
Exhaust Fumes .54
Expectant Mothers, Use of Seat ........................................
Belts by .16 ...................................
Fan, Interior .125
.........................................
Features .123
....................
Filling the Fuel Tank . 215
Filters .........................
Dust and Pollen .284
...............................................
Oil .268
.............
Flashers, Hazard Warning . 76
...................
Flat Tire, Changing a . 299
Fluids ..........
Automatic Transmission . 273
..........................................
Brake .275
..........................
Power Steering .276
..................
Windshield Washer . 272
...................
Folding Rear Seat . 99, 102
..........................
Four-way Flashers .76
..............................
Front Airbags . 9, 25
Front Seat ......................................
Adjusting .94
.......................................
Heaters .105
.....................................
Airbags . 9, 25
3
Index
E F
INDEX
III

.................................................
Fuel .214
........
Check Fuel Cap Message .216
......................
Fill Door and Cap .215
.....................
Low Fuel Indicator .63
...........................................
Gauge .66
................
Octane Requirement .214
...............................
Oxygenated .214
........................
Tank, Ref ueling .215
...............................
Fuel Economy .219
.....................
Fuses, Checking the .312
...............
Gas Mileage, Improving .219
..........................................
Gasohol .214
.........................................
Gasoline .214
.....................
Low Fuel Indicator. 63
...........................................
Gauge .69
................
Octane Requirement .214
........................
Tank, Ref ueling .215
................
Gas Station Procedures .215
Gauges
...
Engine Coolant Temperature .69
...............................................
Fuel .69
Gearshif t Lever Positions ..........
Automatic Transmission .231 ......................................
Glove Box .114
Gross Vehicle Weight Rating
.............................
(G VWR) . 246, 322
.............
Halogen Headlight Bulbs . 277
..............
Hazard Warning Flashers . 76
Headlights ........................................
Aiming .277
............
Daytime Running Lights . 75
..................
High Beam Indicator . 63
.........................
Reminder Chime .75
........
Replacing Halogen Bulbs . 277
...................................
Turning on .74
..............................
Head Restraints .97
.............................
Heated Mirrors .109
...................................
Heater, Seat .105
.....................
Heating and Cooling .124
............................
High Beam Lever .74
.......................
Hood, Opening the .217
..............................................
Horn .4,72
...
Identif ication Number, Vehicle . 320Ignition
..............................................
Keys .79
...........................................
Switch .81
............
Timing Control System . 330
........................
Immobilizer System .80
.........
Important Safety Precautions . 6
Indicators ......
ABS (Anti-Lock Brake) . 61, 238
Brake (Parking and Brake ............................
System) . 60, 311
................
Charging System . 60, 309
.............................
Cruise Control .62
DRL (Daytime Running ......................................
Lights) .63
...................................
High Beam .63
........
Key (Immobilizer System) . 61
......................................
Low Fuel .63
................
Low Oil Pressure . 60, 309
..............
Low Tire Pressure . 64, 242
..........
Maintenance Minder . 65,257
Malf unction Indicator ................................
Lamp . 60, 310
.................
Passenger Airbag Of f . 32
...........................
Side Airbag Of f .61
...............................................
SRS .61
...................................
TPMS . 64, 243
Index
G H
I
IV

ÎÎ Î
CONT INUED
................
Engine Oil and Filter .268
..........................................
Fuses .312
................................
Light Bulbs .277
....................................
Schedule .263
...........................................
Tires .288
.............................
Wiper Blades .285
Replacing Seat Belts Af ter a ............................................
Crash .21
..........
Reporting Saf ety Def ects .336
Reserve Tank, Engine
...............................
Coolant . 218, 270
...............................
Restraint, Child .34
..................
Reverse Gear Position .232
...........................
Reverse Lockout .235
......................................
Roof Rack .224
................................
Rotation, Tire .291
..................................
Safety Belts . 8, 18
.........
Safety Defects, Reporting .336
.................................
Saf ety Features .7
...........................................
Airbags .9
.......................................
Seat Belts .8
.............
Saf ety Labels, Location of .55
..............................
Saf ety Messages .iii .....................................
Seat Belts . 8, 18
...............
Additional Information .18
.....
Advice f or Pregnant Women .16
Automatic Seat Belt
...............................
Tensioners .20
.....................................
Cleaning .283
...................
Detachable Anchor .104
................
Lap/Shoulder Belt . 14, 19
................................
Maintenance .20
Reminder Indicator and
......................................
Beeper .60
...................
System Components .18
...............
Use During Pregnancy .16
...
Wearing a Lap/Shoulder Belt .14
..................................
Seat Heaters .105
........................
Seats, Adjusting the .94
.......................
Select/Reset Button .66
...............................
Serial Number .320
...........................
Service Intervals .263
...........................
Service Manual .337
.........
Service Station Procedures .215
..........................
Setting the Clock .206
...
Shif t Lever Position Indicators .231
........................
Shif t Lock Release .235
................................
Side Airbags .9,28
...
How Your Side Airbags Work .28 How the Side Airbag Of f
......................
Indicator Works .31
..................
Side Curtain Airbags .9,30
How Your Side Curtain Airbags .........................................
Work .30
Side Marker Lights, Bulb ..............................
Replacement .280
...............................
Signaling Turns .74
.....................................
Snow Tires .292
................................
Sound System .129
......................................
Spare Tire .298
....................................
Spark Plugs .322
........................
Specific ations . 322, 323
................................
Speed Control .209
................................
Speed Limiter .234
Index
S
INDEX
VII
