CD Changer (Models with navigation system)
Features
181
JOYSTICK
POWER/VOLUME
KNOB
CD BUTTON
RANDOM
BUTTON
REPEAT BUTTON
REWIND BUTTONSKIP BUTTON
SKIP BUTTON
CD ICON
TUNE BAR
U.S. EX-L model
CD CHANGER ICON
OPEN
BUTTON AUDIO
BUTTON SCAN
BUTTON Canadian EX-L model
FAST FORWARD
BUTTON POWER/VOLUME
KNOB
CD BUTTON
REPEAT BUTTONTUNE BAR
OPEN
BUTTON
AUDIO
BUTTON
SCAN
BUTTON JOYSTICK
RANDOM
BUTTON REWIND BUTTON SKIP BUTTON
SKIP BUTTON
CD CHANGER ICON
FAST FORWARD
BUTTON
CD ICON

Î
Î PresstheAM/FMorCD/XM
buttontoswitchtotheradioor
satellite radio while a CD is playing.
If there is a PC card in the audio unit,
touch the CARD icon to switch to
the PC card while a CD is playing.
Touch the CDC icon again to play
the CD in the CD changer.
If you turn the system of f while a CD
in the CD changer is playing, the CD
will stay in the drive. When you turn
the system back on, the CD will be in
pause mode. Touch the CDC icon on
the audio screen. The CD will begin
playing where it lef t of f .:OnU.S.EX-Lmodelonly
To Stop Playing a CD
CD Changer (Models with navigation system)
186

Insert a dif f erent disc. If the new
disc plays, there is a problem with
the f irst disc. If the error message
cycle repeats and you cannot clear it,
take your vehicle to a dealer. If you see an error message in the
display while playing a disc, f ind the
cause in the chart to the right. If you
cannot clear the error message, take
your vehicle to your dealer.
Thechartontherightexplainsthe
error messages you may see in the
display while playing a disc.
If you see an error message in the
display while playing a disc, press
the eject button. After ejecting the
disc, check it for damage or
deformation. If there is no damage,
insert the disc again.
Theaudiosystemwilltrytoplaythe
disc. If there is still a problem, the
error message will reappear. Press
the eject button, and pull out the disc.Cause Solution
Error
Message
FOCUS Error
Mechanical Error The disc is pulled out.
Check if it is inserted correctly in the disc
player.
Make sure the disc is not scratched or damaged.
Press the eject button, and pull out the disc.
Check the disc for damage or deformation.
If the disc cannot be pulled out, or the error
message does not disappear after the disc is
ejected, see your dealer.
CD Changer (Models with navigation system)
Features
187
DISC ERROR
MECH ERROR

µµ
´
´
Playing a PC card (Models with navigation system)
188
REPEAT BUTTON RANDOM
BUTTON
REWIND BUTTON JOYSTICK
TUNE BAR PC CARD ICON
TRACK LIST ICON
U.S. EX-L model
Canadian EX-L model
OPEN
BUTTON
CD/XM
BUTTON
SCAN
BUTTON
AUDIO BUTTON
SKIP
BUTTON
FAST
FORWARD
BUTTON
POWER/VOLUME
KNOB
REPEAT BUTTON
TUNE BAR OPEN
BUTTON
SCAN
BUTTON POWER/VOLUME
KNOB
RANDOM
BUTTON SKIP
BUTTON
FAST
FORWARD
BUTTON
REWIND BUTTON TRACK LIST ICON
PC CARD ICON
PLAY
MODE
ICON AUDIO BUTTON PLAY
MODE
ICON
SKIP
BUTTON
SKIP
BUTTON JOYSTICK
CD/AUX
BUTTON

µ
µ
µ
µCompatible with variable bit rate
and multi-session
Maximum layers
(including ROOT): 8 layers
In WMA f ormat, DRM (digital rights
management) f iles cannot be played.
If the system finds a DRM file, it
skips that f ile and plays the next
available f older or f ile. The PC card slot is behind the
navigation screen. To use the PC
card player, press the OPEN button
beside the screen. The screen f olds
back, and the PC card slot appears.Insert a PC card straight into the slot.
The drive will read the PC card and
begin to play it.
Return the screen to the upright
position by pressing the CLOSE
button on the edge of the screen
panel.
Push the AUDIO button beside the
screen to show the audio display and
operate the PC card player.
You can also operate the audio
system without using the control
icons on the audio screen. Press any
of the appropriate control buttons.
The status bar appears on the
bottom of the screen. On the
navigation screen, you can see the
audio inf ormation whenever you
touch the AUDIO INFO icon on the
screen.
The specif ications f or compatible
WMA f iles are:
Sampling f requency:
32/44.1/48 kHz
Bit rate:
48/64/80/96/128/160/192 kbps
Loading a PC Card
Playing a PC card (Models with navigation system)
190
PC CARD SLOT

To select a play mode, push the
AUDIO button to show the audio
display, then touch the PLAY MODE
icon on the display.Select the desired mode by touching
the appropriate icon, or move the
joystick, then press the ENT.
After you select the play mode, the
display changes to the selectable
playing menu. If you select
‘‘Continue playing the Current Song,’’
the system goes into the selected
play mode af ter playing the current
f ile.
Playing a PC card (Models with navigation system)
192
PLAY MODE ICON
U.S. EX-L model is shown

To go back to the previous screen,
presstheCANCELbuttononthe
rightsideofthescreen.Toexitthe
play mode screens, press the AUDIO
button.You can use the preset buttons while
a card is playing to select or change
f iles. Each preset button’s f unction is
shownonthebottomof thescreen.Iconsonthescreencanalsobe
selected with the joystick. Move the
joystick lef t or right and up or down
until the icon is highlighted, then
press the ENT on the top of the
joystick to select the icon.
If you select ‘‘Play a New Track List,’’
the system goes into the selected
play mode immediately and begins to
play the new track list.
CONT INUED
T o Change or Select T racks/Files
Playing a PC card (Models with navigation system)
Features
193
PRESET BUTTONS
PRESET BUTTON’S FUNCTION
U.S. EX-L model is shown

ÛÝ
You can also select a f ile directly
f rom a track list on the audio display.
Press the AUDIO button to show the
audio display, then touch the Track
List icon. The track list menu
appears on the display. To scroll through the display, touch
the or icononthesideof the
screen.Togobacktotheprevious
display, touch the Return icon.
To play a f ile, touch its icon on the
screen. In f older mode, touch the
f older icon on the upper lef t of the
screen to move to the parent folder.
The current f older is highlighted in
blue.In artist mode, the artist name is also
displayed on the right side of each
selectable icon. Select the desired
f ile.
Using a T rack L ist
Playing a PC card (Models with navigation system)
196
RETURN ICON
FOLDER ICON
TRACK LIST ICON ARTIST NAME
U.S. EX-L model is shown

Î
Î
Î
Searching
for a Song by Album Name
: U.S. EX-L model
Select the Album icon, and the
album list appears. Select the desired
album, and its song list is displayed.
You can then select the desired song
from the list. To
remove a PC card from the audio
unit, fold back the screen by
pressing the OPEN button (see page ). Press the eject button ( )
to remove the card. If you do not
remove it f rom the slot, you cannot
return the screen to the upright
position.
To return the screen to the upright
position, press the CLOSE button.
You can also eject a card when the
ignition switch is of f .
If there is a problem with the PC
card player, see your dealer.
To play the radio when a PC card is
playing, press the AM/FM button or
touch the FM1, FM2, AM, XM1 , or
XM2 icon. If a disc is in the audio
unit, press the CD button or touch
theCDicontoplaythedisc.If aCD
or CDs are in the CD changer, touch
the CDC icon to play the disc(s).
Touch the CARD icon to switch back
to the PC card player.
If you turn the system of f while a PC
card is playing, either with the
power/volume knob or by turning
of f the ignition switch, the card will
stay in the drive. When you turn the
system back on, the card will begin
playing where it lef t of f .
When you leave the vehicle, always
remove the PC card from the audio
unit. 174
T o Stop Playing a PC card
PC Card Player Malf unction
Removing a PC Card
Playing a PC card (Models with navigation system)
Features
199
ALBUM LIST

Handle a disc by its edges; never
touch either surf ace. Do not place
stabilizer rings or labels on the disc.
These, along with contamination
f rom f ingerprints, liquids, and f elt-tip
pens, can cause the disc to not play
properly, or possibly jam in the drive.
When using CD-R or CD-RW discs,
use only high quality discs labeled
f or audio use.
When recording a CD-R or
CD-RW, the recording must be
closedforittobeusedbythe
system.
Play only standard round discs.
Odd-shaped discs may jam in the
driveorcauseotherproblems.
Handle your discs properly to
prevent damage and skipping.
When a disc is not being played,
store it in its case to protect it f rom
dust and other contamination. To
prevent warpage, keep discs out of
direct sunlight and extreme heat.
To clean a disc, use a clean sof t cloth.
Wipe across the disc f rom the center
to the outside edge.
A new disc may be rough on the
inner and outer edges. The small
plastic pieces causing this roughness
can f lake of f and f all on the
recording surf ace of the disc,
causing skipping or other problems.
Remove these pieces by rubbing the
inner and outer edges with the side
of a pencil or pen.
Never try to insert f oreign objects in
the system or the magazine.
General Inf ormation Protecting Discs
Protecting Your Discs
202
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
