Your Vehicle at a Glance
Your Vehicle at a Glance
3
POWER WINDOW
SWITCHESDRIVER’S FRONT
AIRBAG
FUEL FILL DOOR
RELEASE HANDLE HOOD RELEASE HANDLE PASSENGER’S FRONT
AIRBAG
MIRROR CONTROL INSTRUMENT PANEL
INDICATORS
GAUGES AUDIO SYSTEM
HEATING/COOLING
CONTROLS
AUTOMATIC
TRANSMISSION
POWER DOOR LOCK
MASTER SWITCHES
U.S. EX-L without navigation system is shown. (P.59)
(P.66) (P.129)
(P.9, 25)
(P.124)
(P.231)
(P.217)
(P.215)
(P.106)
(P.82)
(P.109)
(P.9,
25)
ACCESSORY POWER
SOCKETS
(P.117)
Page 62 of 352
Î
ÎÎ
Control Locations
58
POWER WINDOW
SWITCHES
HOOD RELEASE
HANDLE MIRROR
CONTROLS
GAUGES
AUDIO SYSTEM
CLOCK HAZARD
WARNING
BUTTON PASSENGER
AIRBAG
OFF INDICATOR
INSTRUMENT
PANEL
INDICATORS
AUTOMATIC
TRANSMISSION
FUEL FILL DOOR
RELEASE HANDLE
HEATING/COOLING
CONTROLS
PARKING BRAKE PEDAL MOONROOF
SWITCH
SEAT HEATER
SWITCHES
EX-L without navigation system is shown ACCESSORY
POWER SOCKETS
(P.59)
(P.66)
(P.109)
(P.82)
(P.106)
(P.215)
(P.217)
(P.78) (P.117) (P.105)(P.124) (P.231)
(P.206) (P.129)
(P.76)
(P.32)
(P.107)
POWER DOOR LOCK
MASTER SWITCH
Page 78 of 352
Turn Signal
OFF
Parking and interior lights
Headlights on
High Beams
Flashhighbeams
Rotate the switch
counterclockwise also to spray the
window washer and turn the wiper
on.
Hold past ON to activate the rear
window wiper a f ew times and to
spray the rear window washer. Rotate the switch clockwise to
turn the rear window wiper ON.
The wiper operates every 7
seconds af ter completing two
sweeps. When you turn the wiper switch to
the ‘‘OFF’’ position, the wiper will
return to its parked position. OFF Therearwindowwasherusesthe
same f luid reservoir as the wind-
shield washer. When you shif t the transmission to
the reverse position with the f ront
windshield wiper activated, the rear
wiper operates automatically even if
the rear wiper switch is of f .
1.
2.
3.
4.
5.
6.
4.
3. 1.
2. Turn Signal and Headlights
Rear Window Wiper and Washer
Windshield Wipers and Washers, Turn Signal and Headlights
74
Page 214 of 352
You can increase the set cruising
speed in any of these ways:You can decrease the set cruising
speed in any of these ways:
When climbing a steep hill, the
automatic transmission may
downshif t to hold the set speed. Press and hold the RES/ACCEL
button. When you reach the
desired cruising speed, release the
button.
To increase the speed in very
small amounts, tap the RES/
ACCEL button. Each time you do
this, your vehicle will speed up
about 1 mph (1.6 km/h).
Cruise control may not hold the set
speed when you are going up and
down hills. If your vehicle speed
increases going down a hill, use the
brakes to slow down. This will cancel
thecruisecontrol.Toresumetheset
speed, press the RES/ACCEL button.
The CRUISE CONTROL indicator
on the instrument panel will come
back on.
To slow down in very small
amounts, tap the SET/DECEL
button. Each time you do this,
your vehicle will slow down about
1 mph (1.6 km/h). Press and hold the SET/DECEL
button. Release the button when
you reach the desired speed.If you need to decrease your
speed quickly, use the brakes as you
normally would.
Push on the accelerator pedal.
Accelerate to the desired cruising
speed, then press the SET/
DECEL button.
Tap the brake pedal lightly with
your f oot. The CRUISE
CONTROL indicator on the
instrument panel goes out. When
the vehicle slows to the desired
speed, press the SET/DECEL
button.
Changing the Set Speed
Cruise Control
210
NOTE:
Page 231 of 352
This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the vehicle stability assist
(VSA) system, the tire pressure
monitoring system (TPMS) and f acts
you need if you are planning to tow a
trailerordriveoff-highway.........................
Driving Guidelines .228
....................
Preparing to Drive .229
.......................
Starting the Engine .230
..............
Automatic Transmission .231
...........................................
Parking .236
.............................
Braking System .237
...............
Anti-lock Brakes (ABS) .238
Vehicle Stability Assist
............................
(VSA) System .240
Tire Pressure Monitoring System ......................................
(TPMS) .242
...........................
Towing a Trailer .245
Towing Your Vehicle Behind a
................................
Motorhome .250
Of f -Highway Driving ..................................
Guidelines .252
Driving
Driving
227
Page 235 of 352
These indicators on the instrument
panel show which position the shif t
lever is in.The ‘‘D’’ indicator comes on f or a
f ew seconds when you turn the
ignition switch to the ON (II)
position. If it f lashes while driving (in
any shif t position), it indicates a
possible problem in the transmission.
If the malf unction indicator lamp
comes on along with the ‘‘D’’
indicator, there is a problem with the
automatic transmission control
system. Avoid rapid acceleration, and
have the transmission checked by
your dealer as soon as possible.
To shif t f rom any position, press
f irmly on the brake pedal and press
the release button on the side of the
shiftlever.Youcannotshiftoutof
Park when the ignition switch is in
the LOCK (0) or ACCESSORY (I)
position.
CONT INUED
Shif t L ever Position Indicators Shif ting
Automatic Transmission
Driving
231
SHIFT LEVER
U.S. model is shown RELEASE
BUTTON
Page 236 of 352
µµ
If you have done all of the above and
still cannot move the lever out of
Park, see on
page . This position mechani-
cally locks the transmission. Use
Park whenever you are turning of f or
starting the engine. To shif t out of
Park, you must press on the brake
pedal and have your f oot of f the
accelerator pedal. Press the release
button on the side of the shift lever
to move it.
To avoid transmission damage, come
to a complete stop bef ore shif ting
into Park. You must also press the
release button to shift into Park. The
shif t lever must be in Park bef ore
you can remove the key f rom the
ignition switch. Press the brake
pedal and press the release button
on the side of the shif t lever to shif t
f rom Park to reverse. To shif t f rom
reverse to neutral, come to a
completestopandthenshift.Press
the release button bef ore shif ting
into reverse f rom neutral.
235To shift from: PtoR
RtoP
NtoR Dto2 2to1
1to2
2toD
DtoN
NtoD RtoN
DtoD
DtoD Do this:
Press the brake pedal and
press the shift lever release
button.
Press the shift lever release
button.
Move the shift lever.
Press the D button.
3
3 3
Automatic Transmission
Shif t L ock Release
Park (P) Reverse (R)
232
Page 237 of 352
µ
µ Use neutral if you
need to restart a stalled engine, or if
it is necessary to stop brief ly with
the engine idling. Shif t to the Park
position if you need to leave your
vehicle for any reason. Press on the
brake pedal when you are moving
the shift lever from neutral to
another gear.
Use this position f or
your normal driving. The
transmission automatically selects a
suitable gear (1 through 5) f or your
speed and acceleration. You may
notice the transmission shif ting up at
higher engine speeds when the
engine is cold. This helps the engine
warm up f aster. Press the D3 switch on the side of
the shif t lever to turn this mode on
or of f ; the D3 mode indicator comes
on whenever the D3 mode is
selected.
D3 mode can be turned on or of f
only when the ignition switch is in
the ON (II) position and the shif t
lever is in the D position.WhentheD3modeison,the
transmission selects only the f irst
three gears. Use D3 mode when
towing a trailer, or to provide engine
braking when going down a steep hill.
D3 mode can also keep the
transmission f rom cycling between
third and f ourth gears in stop-and-go
driving.
CONT INUED
Neutral (N)
Drive (D)
Automatic Transmission
D3 Mode
Driving
233
D3 MODE INDICATOR
D3 SWITCH
Page 238 of 352
µµ
Turning the ignition switch to the
LOCK (0) position turns this mode
of f . When you restart the engine,
select the D position and press the
D3 mode switch again to use this
mode.
TheD3modeindicatoralsocomes
on f or a f ew seconds when you turn
the ignition switch to the ON (II)
position. If you shif t into f irst position when
the vehicle speed is above 31 mph
(50 km/h), the transmission shif ts
into second gear first to avoid
sudden engine braking.
If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone.
Use second gear:
For more power when climbing.
To increase engine braking when
going down steep hills.
For starting out on a slippery
surf ace or in deep snow.
To help reduce wheel spin.
When driving downhill with a
trailer.
To shif t to second,
pressthereleasebuttonontheside
of the shif t lever. This position locks
the transmission in second gear. It
does not downshif t to f irst gear
when you come to a stop. To shif t f rom second to
first, press the release button on the
side of the shif t lever. This position
locks the transmission in f irst gear.
By upshif ting and downshif ting
through 1, 2, D , and D, you can
operate the transmission much like a
manual transmission without a
clutch pedal.
Shif ting out f rom the D position will
canceltheD3mode,andtheD3
indicator will go out. Selecting the D
position again will resume the D3
mode and the indicator comes on.
3
Automatic Transmission
Engine Speed L imiter
Second (2) First (1)
234
Page 239 of 352
If you need to use the shif t lock
release, it means your vehicle is
developing a problem. Have the
vehicle checked by your dealer.
This allows you to move the shif t
lever out of Park if the normal
method of pushing on the brake
pedal and pressing the release
button does not work.
Set the parking brake.
Remove the key from the ignition
switch.
Put a cloth on the edge of the shif t
lock release slot cover. Using a
small f lat-tipped screwdriver or
metal f ingernail f ile, caref ully pry
on the edge of the cover to remove
it. Insert the key in the shift lock
release slot.
Push down on the key while you
pressthereleasebuttononthe
shif t lever and move the shif t lever
out of Park to neutral.Remove the key from the shift
lock release slot, then reinstall the
cover. Make sure the notch on the
cover is on the right side. Press
the brake pedal, and restart the
engine.
6.
1.
2.
3.
4.
5.
Automatic Transmission
Shif t L ock Release
Driving
235
SHIFT LOCK RELEASE SLOTRELEASE BUTTON
COVER
