However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired as
soon as possible (see
on page ). If the ABS indicator and the VSA
system indicator come on with the
brake system indicator, have your
vehicle inspected by your dealer
immediately.
The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and as
a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads. 357
403Emergency
Towing
Brake System Indicator
396
Canada
U.S.
Table of Contents

The interior f use box is located
under the dashboard on the driver’s
side. The f use label is attached
under the steering column.The under-hood f use box is on the
driver’s side. To open it, push the
tabs as shown.
The vehicle’s f uses are contained in
threefuseboxes.
The auxiliary f use box is located
next to the interior f use box.
To open the f use box lid, pull the tab
in the direction as shown in the
illustration.
Fuses
T aking Care of t he Unexpect ed
397
TAB
INTERIOR
UNDER-HOOD
FUSE LABEL TAB
FUSELID
FUSES INTERIOR (Auxiliary)
Table of Contents

If something electrical in your
vehicle stops working, check f or a
blown f use f irst. Determine f rom the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Remove the cover f rom the f use
box.
Check each of the large f uses in
the under-hood f use box by
looking through the side window
at the wire inside. Removing these
f uses requires a Phillips-head
screwdriver.
1. 2.
3.
401 402
Fuses
Checking and Replacing Fuses
398
FUSE BLOWN
Table of Contents

Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse box by
pulling out each one with the f use
pullerprovidedonthebackof the
under-hood f use box cover.Look f or a blown wire inside the
f use. If it is blown, replace it with
one of the spare f uses of the same
rating or lower.
Your vehicle has spare fuses on
the back of the under-hood f use
box cover.
4.
5.
CONT INUED
Fuses
T aking Care of t he Unexpect ed
399
BLOWN
FUSE PULLER BLOWN
FUSE
Table of Contents

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
checked by a qualif ied technician.
If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
may see ‘‘ENTER CODE’’ in the
f requency display. Use the preset
buttons to enter the digit code (see
page ).
On vehicles with a navigation system,
touch the appropriate icon to enter
the code number (see page ).
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
6.
258 258
Fuses
400
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
Table of Contents

µ µµµ
µµ
µ
Î
Î
Î Î
No. Amps.
No. Amps. Circuits Protected
Circuits Protected Circuits Protected
No. Amps. Circuits Protected
No. Amps.
1234567
7.5 A
15 A
10 A
7.5 A
(15 A) 89
1011121314151617181920212223242526 10 A
7.5 A
7.5 A 10 A
10 A
10 A
7.5 A
7.5 A 10 A
10 A
20 A
15 A
7.5 A
20 A
(20 A) 20 A
20 A Rear Wiper
ODS (Occupant Detection
System)
Meter
SRS
Right Headlight High Beam
Left Headlight High Beam
Small Light (Interior)
Small Light (Exterior)
Right Headlight Low Beam
Left Headlight Low Beam
Main Headlight High Beam
Small Lights MAIN
TPMS
Main Headlight Low Beam
Not used
Not used
Moonroof
Door Lock
Front Left Power Window
Power Window Relay
Fuel Pump
ACG
ABS/VSA
Heated Seats
Not used
Not used Not used
Rear Accessory Power Socket
Front Accessory Power Socket
Front Right Power Window
Accessory Power Socket
(in the Console Compartment/
on the Center Table)
Rear Right Power Window
Rear Left power window
ACC Radio
ACC Key lock
HAC
Daytime Running Lights
Front Wiper
A B 10 A VB SOL
27282930 3132 333435363738
15 A
15 A
20 A
(15 A) 20 A
20 A
7.5 A
7.5 A 10 A
7.5 A 30 A
: If equipped
Fuse Locations
T aking Care of t he Unexpect ed
401
INTERIOR FUSE BOX
AUXILIARY
Auxiliary
Table of Contents

µ µµ
ÎÎ Î
Î
No. Amps. Circuits Protected Circuits Protected No. Amps.
1 2345 6789
101112 100 A
80 A
50 A
20 A
40 A
50 A
40 A
20 A
20 A
30 A
40 A
15 A
15 A
15 A Battery
Not used
Option Main
Ignition Switch Main
ABS/VSA FSR
ABS/VSA Motor
Headlight Main
Power Window Main
Not used
Sub Fan Motor
Main Fan Motor
Rear Defogger
Blower
HazardLAF
Stop and Horn PowerSeatDRRRHI/
Reclining
Power Seat DR FR HI/Sliding
IGPS OIL LEVEL
Not used
High Power Sound /
Windshield Defroster
IG Coil
FI Main
MG Clutch
DBW
Interior Light
Back Up
13 14 151617 18 1920212223 (20 A)
(20 A)
7.5 A
(15 A) 15 A
15 A
7.5 A 15 A
7.5 A 10 A
: If equipped
Fuse Locations
402
UNDER-HOOD FUSE BOX
Table of Contents

µµ
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inf orm
them a f lat-bed is required.
The operator will load
your vehicle on the back of a truck. Therearetwowaystotowyour
vehicle:
The operator
loads your vehicle on the back of a
truck.
The tow
truck uses two pivoting arms that go
under the f ront tires and lif t them of f
the ground. The rear tires remain on
the ground. If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
Start the engine.
Shif t to D position and hold f or 5
seconds, then to N.
Turn of f the engine.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Release the parking brake.
On 4WD models On 2WD models
CONT INUED
Emergency T owing
The only way you can saf ely tow
your vehicle is with f lat-bed
equipment.
T his is the best way to
transport your vehicle.
This is an acceptable
way to tow your vehicle.
Flat -bed Equipment
Wheel-lif t Equipment
T aking Care of t he Unexpect ed
403
Towing with only two tires on the
ground will damage parts of the 4WD
system. It should be transported on a
f lat-bed truck or trailer. Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine, your vehicle must be
transported with the all f our wheels of f
the ground.
Table of Contents

With the f ront wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).Refer to
on page
for non-emergency towing
inf ormation. 334
Emergency T owing
Towing Your Vehicle
Behind a Motorhome
404
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
Table of Contents

On 4WD model only
Service Inf ormat ion Summary
Gasoline:
Fuel Tank Capacity:
Recommended Engine Oil:
Automatic Transmission Fluid:Brake Fluid:
Tire Pressure (measured cold):
Power Steering Fluid:
Rear Differential Fluid:
15.3 US gal (58
) 30 psi (210 kPa , 2.1 kgf/cm
)
4.4 US qt (4.2
)
Unleaded gasoline, pump octane
number of 87 or higher.
Oil change capacity (including
filter):
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page ).
Honda Genuine ATF-Z1
(automatic transmission fluid)
(see page ). Front/Rear:
60 psi (420 kPa , 4.2 kgf/cm
)
Compact Spare Tire:
Honda Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page ).
1.3 US qt (1.2
)
Capacity:
Honda Dual Pump Fluid II. Do not
use ATF.
API Premium grade 0W-20
detergent oil (see page ). 349
355 358357
