audio HONDA CR-V 2010 RD1-RD5, RE7 / 3.G Technology Reference Guide

Voice Command/HFL/Navigation
Using the Voice Command System
• Speak in a clear, natural voice.
• Reduce all background noise.
• Adjust the dashboard and sidevents away from the microphone
in the ceiling.
• Close the windows.
Voice Command
To reduce driver distraction, use voice commands for hands-free calling, \
navigation, climate control, and
audio functions. A full list of these commands is in the navigation system manual.
Voice Command Tips:
• Press and release the HFL or NAVI Talk button, wait for a
beep, then give a command.
• For a list of available HFL commands, press and release the HFL Talk button and say “Hands-free help.”
• For a list of available navigation commands, press and release the NAVI Talk button and say “Voice command help.”
HFL Talk button: Give HFL commands
or answer incoming calls.
HFL Back button: End a call, go back to
the previous command, or cancel an
operation. NAVI Talk button:
Give navigation,
climate control, and
audio commands.
NAVI Back button:
Cancel a command or
return to the previous
screen.
10 CRV TRG_Base:Base 7/10/2009 1:58 PM Page 5 2010 CR-V

Commonly Used Voice Commands
Here are some examples of commonly used voice commands. Try some of these to familiarize yourself with
the voice command system.
Press and release the NAVI Talk button before you give a command.
Look for Restaurants in Your Location
Say a command like “Display restaurants” to see
restaurant icons appear on the map.
Make Audio Selections
Say a command like “Radio 97.1 FM” or “CD play
track 5” to select that station or song.
Get Estimated Distance to Destination
After a destination is entered, say“How far to
destination?” to hear the remaining distance.
Adjust the Vehicle’s Climate Setting
Saya command like “Air conditioner on” and “Fan
speed 4” to adjust the setting to your liking.
10 CRV TRG_5abc:ExtraPages.qxd 7/30/2009 2:53 PM Page e5 2010 CR-V

Commonly Used Voice Commands (continued)Navigation Commands
(Accepted on Map screen
after a destination is entered)
• How long/far to the destination?
• Display destination
• Display entire route
• Find nearest: - ATM
- gas station
- Mexican restaurant
- post office - bank
- Honda dealer
- airport
- hospital
Display Commands(Accepted on Map screen)
• Display (or hide):
- ATM
- gas station
- restaurant
- post office • Display north up/
heading up
• Zoom in/out
• Go home
• Display current location
• Display map
• Display menu
• Setup
• Information
• Display audio screen
• What time is it?
Press and release the NAVI Talk button before you give a command.
General Commands
(Accepted on most screens to change displays)
Find Place Commands(Accepted on Map screen)
10 CRV TRG_5abc:ExtraPages.qxd 7/30/2009 2:53 PM Page f5 2010 CR-V

• Brightness up/down
• Volume up/down/min/max/off • Guidance prompts
min/max/normal
Setup Commands(Accepted on the Setup screen)
Help Commands(Accepted on most screens)
• Help (list of available commands for currentscreen)
• Voice command help (list of all available navigation, audio, and climate control
commands)
Voice Command/
HFL/Navigation
Commonly Used Voice Commands (continued)
Press and release the NAVI Talk button before you give a command.
Audio Commands
(Accepted on most screens)
• Radio on
• Radio # FM/AM
• Radio preset 1/2/3/4/5/6
• XM channel # • XM preset 1/2/3/4/5/6
• CD play
• CD play track/disc #
• CD skip forward/back
• Auxiliary (AUX) play
Climate Control Commands(Accepted on most screens)
• Air conditioner
on/off
• Rear defrost on/off
• Climate control recirculate/fresh air • Fan speed up/down
• Temperature #
degrees (# = 57–87)
• Temperature max hot/cold
10 CRV TRG_Base:Base 7/10/2009 1:58 PM Page 6 2010 CR-V

Audio
Components
Playing an iPod®or USB Flash Memory Device (if equipped)
2. Connect your USB connector to your flash
drive or iPod dock connector.
3. Press AUX or touch the AUX icon to play.
USB Adapter Cable
EX without Navigation with Navigation
USB Connector
Some of the same controls used to operate your in-dash CD player are use\
d to operate an iPod or USB
flash memory device.
iPod is a registered trademark of Apple Computer, Inc.,
registered in the U.S. and other countries. iPod not included.
Connecting and Beginning Play
1. Open the upper glove box, and pull outthe
USB adapter cable.
10 CRV TRG_Base:Base 7/30/2009 2:12 PM Page 7 2010 CR-V

Audio
Components
Connecting and Beginning Play
1. Press OPEN.
PC Card Instructions (models with navigation)
2. If necessary, insertyour PC card into a PC
card adapter.4. Press AUDIO to show the audio display. Use
the |

and |buttons to skip through
tracks on the card.
3. Insert the PC card into the slot and press
CLOSE.
CLOSE
Button
PC card
slot
10 CRV TRG_Inside Back:Inside Back 7/10/2009 2:07 PM Page 8 2010 CR-V
