lock HONDA CR-V 2010 RD1-RD5, RE7 / 3.G Technology Reference Guide

Indicators/InfoDisplay/TPMS
Instrument Panel Indicators
Indicators briefly appear with each engine start. Red and amber indicators are most critical. Blue and
green indicators are used for general information.
ABS (anti-lock brake system)
DRL (daytime running lights)
Malfunction lamp (check engine light)
TPMS (tire pressure monitoring system)
VSA (vehicle stability assist)
Malfunction Indicators: If an indicator remains on, there may be a problem; see your dealer.
Charging system
Low oil pressure
SRS (supplemental restraint system)
Low brake fluid
10 CRV TRG_Inside Front:Inside Cvr 7/10/2009 1:57 PM Page 1 2010 CR-V

Auto Door Locks/
Rearview Camera
Auto Door Locking/Unlocking
Default Lock Setting
The doors are preset to
lock when your vehicle
reaches about 9 mph. Default Unlock SettingOnly the driver’s door
is preset to unlock
when you shift into
Park (P).
Modifying the Auto Door Unlock Setting
Follow these steps to program all doors to unlock when you shift to Park:
1. Close the driver’s
door. Shift into
Park. 2.
Turn the ignition
to the ON (II)
position. 3.
Press and hold the unlock side of
the master lock switch for about 10
seconds. In that time, you will hear
three clicks. 4. Within 5 seconds, turn
the ignition to the LOCK
(0) position.
10 CRV TRG_Base:Base 7/10/2009 1:58 PM Page 3 2010 CR-V

Auto Door Locks/
Rearview Camera
Programmable Auto Door Lock/Unlock Settings
Below are several programmable options you can choose. See Auto Door Locking/Unlockingin your
owner's manual for instructions on all the programmable settings.
AUTO DOOR UNLOCK
Auto Unlock
(only driver’s door)
When you turn
the ignition OFFWhen you shift into Park
Turn off
Auto Unlock
Operate manually
AUTO DOOR LOCK
Auto Lock
When you
reach 9 mphWhen you shift out of Park
Turn off
Auto Lock
Operate manually
Rearview Camera (models with navigation)
The display shows a
view behind the vehicle
while in Reverse (R).
To turn the camera on:
Shift into Reverse.
To turn the camera off:
Shift out of Reverse.
10 CRV TRG_Base:Base 7/10/2009 1:58 PM Page 4 2010 CR-V
