uuOverheatinguHow to Handle Overheating
328
Handling the Unexpected
■ Next thing to do
1.Check that the cooling fan is operating and
stop the engine once the temperature
gauge needle comes down.
uIf the cooling fan is not operating,
immediately stop the engine.
2. Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.
uIf the coolant level in the reserve tank is
low, add coolant until it reaches the
MAX mark.
uIf there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
radiator cap with a heavy cloth and open
the cap. If necessary, add coolant up to
the base of the filler neck, and put the
cap back on.
■ Last thing to do
Once the engine has cooled sufficiently, restart it and check the temperature gauge.
If the temperature needle has gone down, resume driving. If it has not gone down,
contact a dealer for repairs.
1How to Handle Overheating
If the coolant is leaking, contact a dealer for repairs.
Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.
3WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.
Always let the engine and radiator cool
down before removing the radiator cap.
Reserve
Tank
MAX
MIN

329
Handling the Unexpected
Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes On■Reasons for the indicator to come on
Comes on when the engine oil pressure is low.
■ What to do as soon as the indicator comes on
1. Immediately park the vehicle in a safe place.
2. If necessary, turn the hazard warning lights on.
■ What to do after parking the vehicle
1. Stop the engine and let it sit for about one minute.
2. Open the hood and check the oil level.
uAdd oil as necessary.
3. Start the engine and check the low oil pressure indicator.
uThe light goes out: Start driving again.uThe light does not go out within 10 seconds: Stop the engine and
contact a dealer for repairs immediately.
If the Charging System Indicator Comes On
■Reasons for the indicator to come on
Comes on when the battery is not being charged.
■ What to do when the indicator comes on
Turn off the heating and cooling system *
/climate control system *
, rear
defogger, and other electrical systems, and immediately contact a dealer for repairs.
1If the Low Oil Pressure Indicator Comes On
NOTICERunning the engine with low oil pressure can cause
serious mechanical damage almost immediately.
1If the Charging System Indicator Comes On
If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge the battery.
* Not available on all models

330
uuIndicator, Coming On/BlinkinguIf the Malfunction Indicator Lamp Comes On or Blinks
Handling the Unexpected
If the Malfunction Indicator Lamp Comes On or
Blinks■Reasons for indicator lamp to come on or blink
• Comes on when there is a problem with the engine emissions control
system, or the fuel fill cap is missing, or loose.
• Blinks when engine misfiring is detected.
■ What to do when the indicator lamp comes on
Avoid high speeds and immediately get your vehicle inspected at a
dealer. ■ What to do when the indicator lamp blinks
Park the vehicle in a safe place with no flammable items and wait at least
ten minutes or more with the engine stopped until it cools.
■ The message appears on when:
An evaporative system leak is detected. This may be caused by the fuel fill cap being
loose or not being installed.
■ What to do when the message appears:
1. Stop the engine.
2. Check that the fuel fill cap is fully installed.
uIf not, loosen the cap, and then retighten it until it clicks at least once.
3. Drive for several days of normal driving.
uThe message should go off.
■ When the malfunction indicator lamp comes on
Malfunction indicator lamp comes on if the system continues to detect a leak of
gasoline vapor. If this happens, check the fuel fill cap using the procedures described above.
■Check/Tighten Fuel Cap Message
1If the Malfunction Indicator Lamp Comes On or Blinks
NOTICEIf you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be damaged.
If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

331
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator Comes On
Handling the Unexpected
If the Brake System Indicator Comes On■Reasons for the indicator to come on
• The brake fluid is low.
• There is a malfunction in the brake system.
■ What to do when the indicator comes on while driving
Press the brake pedal lightly to check pedal pressure. • If normal, check the brake fluid level the next time you stop.
• If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.
If the EPS System Indicator Comes On
■Reasons for the indicator to come on
• Comes on when there is a problem with EPS.
• If you depress the accelerator pedal repeatedly to increase the engine
speed while the engine is idling, the indicator comes on, and
sometimes the steering wheel becomes harder to operate.
■ What to do when the indicator comes on
Stop the vehicle in a safe place and restart the engine.
If the indicator comes on and stays on, immediately have your vehicle
inspected by a dealer.
1If the Brake System Indicator Comes On
Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.
If the brake system indicator and ABS indicator come
on simultaneously, the electronic brake distribution
system is not working. This can result in vehicle
instability under sudden braking.
Have your vehicle inspected by a dealer immediately.U.S.
Canada
1If the EPS System Indicator Comes On
NOTICEIf you repeatedly turn the steering wheel at an
extremely low speed, or hold the steering wheel on
the full left or right position for a while, the system
heats up. The system goes into a protective mode,
and limits its performance. The steering wheel
becomes harder and harder to operate. Once the
system cools down, EPS is restored. Repeated
operation under these conditions can eventually
damage the system.

333
Continued
Handling the Unexpected
Fuses
Fuse Locations
If any electrical devices are not working,
turn the ignition switch to LOCK
(0
and
check to see if any applicable fuse is blown.
Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.
Located near the brake fluid reservoir. Push
the tabs to open the box.
■Engine Compartment Fuse Box
■ Circuit protected and fuse rating
Circuit ProtectedAmps
1
EPS70 A−−ABS/VSA Motor40 AABS/VSA FSR20 AE-DPS *(30 A)Main Fuse100 A
2
IG Main50 A
Fuse Box Main 60 A
Fuse Box Main 260 A
Headlight Main 30 A
−−
Rear Defogger 30 A −−
Blower 40 A
Front Wiper Main 30 A Sub Fan Motor 20 A
Main Fan Motor 20 A
3−−
4− −
5−−
6− −
7−−
8 Sub Fan Rly CL 7.5 A
9−−
10 Heated Door Mirror *
(7.5 A)
11STRLD7.5 A
12 Fog Lights *
(20 A)
13Premium Amp *(20 A)
14 Horn 10 A
15Hazard10 A
16 Stop 10 A
17IG Coil15 A
18 IGP2 15 A
19−−
20 − −
21−−
22 DBW 15 A
23IGP15 A
24 Left Headlight Low Beam 10 A
25Right Headlight Low Beam10 A
26 SMALL 20 A
27MG Clutch7.5 A
28 Interior Lights 7.5 A
29Backup10 A
Circuit ProtectedAmps
* Not available on all models

335
uuFusesuInspecting and Changing Fuses
Handling the Unexpected
Inspecting and Changing Fuses1.Turn the ignition switch to LOCK
(0 . Turn
headlights and all accessories off.
2. Remove the fuse box cover.
3. Check the large fuse in the engine
compartment.
uIf the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.
4. Inspect the small fuses in the engine
compartment and the vehicle interior.
uIf there is a burned out fuse, remove it
with the fuse puller and replace it with a
new one.
1Inspecting and Changing Fuses
NOTICEReplacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.
Replace fuse with a spare fuse of the same specified
amperage.
Confirm the specified amperage using the charts on
P. 333 to 334.
There is a fuse puller on the back of the engine compartment fuse box cover.
Combined
Fuse Blown Fuse
Fuse Puller

345
Continued
Information
Emissions Testing
Testing of Readiness Codes
Your vehicle uses "readiness codes," as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle's emissions
components are working properly.
The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.
To check if they are set, turn the ignition switch to ON
(w
, without starting the
engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are not set.
If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following: 1. Fill the gas tank to approximately 3/4 full.
2. Park the vehicle and leave the engine off for 6 hours or more.
3. Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4. Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5. Keep the vehicle in
(P . Increase the engine speed to 2,000 rpm, and hold it there
for about 3 minutes.
6. Let the engine idle with your foot off the accelerator for 20 seconds.
1Testing of Readiness Codes
The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.
If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.
If the testing facility determines the readiness codes
are still not set, see a dealer.

352
Index
Jump Starting .......................................... 324
Maintenance (Checking the Battery) ........ 305
Maintenance (Replacing).......................... 306
Behind a Motorhome ............................... 235
Belts (Seat) .................................................. 29
Beverage Holders ...................................... 134
Bluetooth ® Audio ..................................... 171
Bluetooth ® HandsFreeLink ®..................... 194
Booster Seats (For Children) ....................... 64
Brake System ............................................. 253
Anti-lock Brake System (ABS) ................... 255
Brake Assist System ................................. 256
Fluid ........................................................ 283
Foot Brake ............................................... 254
Indicator ............................................ 68, 331
Parking Brake .......................................... 253
Brightness Control (Instrument Panel) .... 117
Bulb Replacement ..................................... 285
Brake Light, Taillight, Back-Up Light, Rear Turn
Signal Light and Lower Rear Side Marker
Light ...................................................... 288
Fog Lights ................................................ 286
Front Turn Signal/Parking Light ................ 288
Headlights ............................................... 285
High-Mount Brake Light .......................... 291
Rear License Plate Light............................ 291
Side Marker Lights ................................... 287
Upper Rear Side Marker/Taillight .............. 290
Bulb Specifications .................................... 340 C
Carbon Monoxide Gas
............................... 65
Cargo Hook ............................................... 137
Cargo Side Net .......................................... 136
Carrying Cargo ................................. 227, 229
CD Player ................................................... 160
Certification Label .................................... 342
Changing Bulbs ........................................ 285
Charging System Indicator ................. 69, 329
Child Safety ................................................. 52
Childproof Door Locks............................. 102
Child Seat .................................................... 52
Booster Seats ............................................ 64
Child Seat for Infants................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 60
Larger Children ......................................... 63
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Childproof Door Locks ............................. 102
Cleaning the Exterior ............................... 312
Cleaning the Interior ................................ 310
Climate Control System ............................ 145
Changing the Mode ................................ 145
Defrosting the Windshield and Windows ............................................... 146
Dust and Pollen Filter............................... 309
Recirculation/Fresh Air Mode ..... .............. 145
Sensors ................................................... 148
Synchronized Mode................................. 147 Using Automatic Climate Control ............ 145
Clock ........................................................... 96
Coat Hook ................................................ 136
Compact Spare Tire .......................... 317, 341
Compass .................................................... 223
Console Compartment ............................. 133
Controls ...................................................... 95
Coolant (Engine) ...................................... 280
Adding to the Radiator ...... ..................... 281
Adding to the Reserve Tank .................... 280
Overheating ............................................ 327
Creeping (Automatic Transmission) ........ 242
Cruise Control .......................................... 245
Indicator ................................................... 76
Cup Holders .............................................. 134
Customer Service Information ................ 350
Customized Features ................................. 84
D
Daytime Running Lights .......................... 114
Dead Battery ............................................ 324
Defrosting the Windshield and Windows ......................................... 144, 146
Detachable Anchor .................................... 34
Devices that Emit Radio Waves ............... 343
Dimming
Headlights .............................................. 112
Rearview Mirror ...................................... 120
Dipstick (Engine Oil) ................................ 276
Directional Signals (Turn Signal) ............. 112

353
Index
Display Button............................................ 81
Door Mirrors ............................................. 121
Doors .......................................................... 97
Auto Door Locking.................................. 103
Auto Door Unlocking .............................. 103
Door Open Indicator ........................... 28, 72
Keys.......................................................... 97
Locking/Unlocking the Doors from the Inside .................................................... 101
Locking/Unlocking the Doors from the
Outside ................................................... 99
Lockout Prevention System ..................... 100
DOT Tire Quality Grading ........................ 299
Driver’s Seat Lumbar Support ................. 122
Driving ...................................................... 225
Automatic Transmission .......................... 242
Braking ................................................... 253
Cruise Control ........................................ 245
Off-Highway Driving Guidelines .............. 237
Shifting Gear .......................................... 243
Starting the Engine ................................. 239
Dust and Pollen Filter .............................. 309
DVD Player ............................................... 173
E
Eco Assist System .......................................... 7
ECON Button ............................................ 119
Elapsed Time .............................................. 82
Electric Power Steering (EPS) System
Indicator ........................................... 73, 331 Electronic Stability Control (ESC)
............. 248
Emergency ................................................ 336
Emissions Testing (Readiness Codes) ....... 345
Engine ....................................................... 342
Coolant ................................................... 280
Jump Starting .......................................... 324
Oil ........................................................... 275
Starting ................................................... 239
Switch Buzzer .......................................... 111
Engine Coolant ......................................... 280
Adding to the Radiator ............................ 281
Adding to the Reserve Tank ..................... 280
Overheating ............................................ 327
Temperatue Guage.................................... 77
Engine Oil ................................................. 275
Adding .................................................... 277
Checking ................................................. 276
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator.................. 68, 329
Recommended Engine Oil........................ 275
EPS (Electric Power Steering)
System ............................................... 73, 331
Exhaust Gas Hazard (Carbon Monoxide) ................................................. 65
Exterior Care (Cleaning) ........................... 312
Exterior Mirrors ........................................ 121
F Features ..................................................... 149
Filters Dust and Pollen ....................................... 309
Oil ........................................................... 278
Flat Tire ..................................................... 317
Floor Mats ................................................. 311
Fluids Automatic Transmission .......................... 282
Brake ...................................................... 283
Engine Coolant ....................................... 280
Windshield Washer ................................. 284
Fog Light Indicator ..................................... 74
Folding Down the Rear Seats .................. 129
Foot Brake ................................................ 254
Front Airbags (SRS) ..................................... 40
Front Seats ................................................ 122
Adjusting ................................................ 122
Fuel ...................................................... 16, 259
Economy ................................................. 262
Gauge ....................................................... 77
Low Fuel Indicator ..................................... 70
Range ................................................. 79, 82
Recommendation .................................... 259
Refueling................................................. 259
Fuel Economy ........................................... 262
Fuel Fill Cap ........................................ 16, 261
Message.................................................. 330
Fuel Fill Door ...................................... 16, 260
Fuses .......................................................... 333
Inspecting and Changing........ ............... .. 335
Locations......................................... 333, 334

356
Index
N
Numbers (Identification).......................... 342
O
Odometer .................................................... 78
Off-Highway Driving Guidelines .............. 237
Oil (Engine) ............................................... 275
Adding .................................................... 277
Checking ................................................. 276
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator .................. 68, 329
Recommended Engine Oil ....... ................. 275
Viscosity .................................................. 275
Opening/Closing
Hood ....................................................... 274
Moonroof ................................................ 110
Power Windows ...................................... 108
Tailgate ................................................... 104
Outside Temperature ................................. 80
Adjusting ................................................... 80
Overheating .............................................. 327
P
Pandora ®................................................... 166
Panic Mode ............................................... 107
Parking ...................................................... 257
Parking Brake ............................................ 253
Parking Brake and Brake System Indicator ............................................ 68, 331 Passenger Airbag Off Indicator
................. 49
Passing Indicators ..................................... 112
Power Windows ....................................... 108
Precautions While Driving ....................... 241
Driving Guidelines for Your Utility Vehicle .................................................. 241
Rain ........................................................ 241
Pregnant Women ....................................... 35
Puncture (Tire) .......................................... 317
R
Radiator .................................................... 281
Radio (AM/FM) ......................................... 155
Radio (XM ®).............................................. 158
Radio Data System (RDS) ......................... 157
Range .................................................... 79, 82
RDS (Radio Data System) ......................... 157
Readiness Codes (Emissions Testing) ....... 345
REAL TIME AWD with Intelligent Control System
