Page 2 of 361
Contents
Child Safety P. 52 Exhaust Gas Hazard P. 65 Safety Labels P. 66
Opening and Closing the Tailgate P. 104 Security System P. 106 Opening and Closing the Windows P. 108
Operating the Switches Around the Steering Wheel P. 111 Adjusting the Mirrors P. 120
Interior Lights/Interior Convenience Items P. 132 Heating and Cooling System*
P. 142
Rear Entertainment System *
P. 173 Audio Error Messages P. 185 Audio Remote Controls P. 189
Bluetooth ® HandsFreeLink ® P. 194 Compass P. 223
Off-Highway Driving Guidelines P. 237 When Driving P. 239 Braking P. 253
Refueling P. 259 Fuel Economy P. 262 Accessories and Modifications P. 263
Maintenance Under the Hood P. 273 Replacing Light Bulbs P. 285
Checking and Maintaining Tires P. 296 Battery P. 305 Remote Transmitter Care P. 306
Heating and Cooling System *
/Climate Control System *
Maintenance P. 309 Cleaning P. 310
Engine Does Not Start P. 323 Jump Starting P. 324 Shift Lever Does Not Move P. 326
Fuses P. 333 Emergency Towing P. 336When You Cannot Open the Tailgate P. 337
Devices that Emit Radio Waves P. 343 Reporting Safety Defects P. 344
Authorized Manuals P. 349 Customer Service Information P. 350
Quick Reference GuideP. 2
Safe DrivingP. 23
Instrument PanelP. 67
ControlsP. 95
FeaturesP. 149
DrivingP. 225
MaintenanceP. 265
Handling the UnexpectedP. 315
InformationP. 339
IndexP. 351
Note: All page numbers referenced in this document are hyperlinked.
2012 CR-V Online Reference Owner's Manual
Page 19 of 361
18
Quick Reference Guide
Handling the Unexpected (P 315)
Flat Tire (P 317)
● Park in a safe location and replace the
flat tire with the compact spare tire in the
cargo area.
Indicators Come On
(P 329) ● Identify the indicator and consult the
owner's manual.
Engine Won't Start
(P 323) ●If the battery is dead, jump start using a
booster battery.
Blown Fuse (P 333)
● Check for a blown fuse if an electrical
device does not operate.Overheating (P 327)
● Park in a safe location. If you do not see
steam under the hood, open the hood,
and let the engine cool down.
Emergency Towing
(P 336) ● Call a professional towing service if you
need to tow your vehicle.
Page 316 of 361
315
Handling the UnexpectedThis chapter explains how to h andle unexpected troubles.
Tools
Types of Tools .................................. 316
If a Tire Goes Flat Changing a Flat Tire ......................... 317
Engine Does Not Start Checking the Engine ........................ 323
Jump Starting .................................... 324
Shift Lever Does Not Move .............. 326
Overheating How to Handle Overheating ............. 327 Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes
On ............................................. 329
If the Charging System Indicator Comes
On ................................................. 329
If the Malfunction Indicator Lamp Comes On or Blinks ................................... 330
If the Brake System Indicator Comes On ....... 331If the EPS System Indicator Comes On ......... 331If the Low Tire Pressure Indicator Comes
On ................................................. 332
If the TPMS Indicator Comes On ...... 332 Fuses
Fuse Locations ................................. 333
Inspecting and Changing Fuses ........ 335
Emergency Towing ........................... 336
When You Cannot Open the Tailgate..... 337
Page 324 of 361
323
Handling the Unexpected
Engine Does Not Start
Checking the Engine
If the engine does not start, turn the ignition switch to START
(e and check the
starter.
Starter conditionChecklistStarter doesn’t turn or turns
over slowly.
The battery may be dead. Check
each of the items on the right and respond accordingly.Check brightness of the interior light.
Turn on interior lights and check brightness. ● If the interior lights are dim or do not come on at all
2Battery P. 305
● If the interior lights come on normally 2 Inspecting and Changing Fuses P. 335
The starter turns over normally
but the engine doesn’t start.
There may be a problem with the
fuse. Check each of the items on
the right and respond accordingly.Review the engine start procedure.
Follow its instructions, and try to start the engine again. 2
Starting the Engine P. 239
Check the immobilizer system indicator.
When the immobilizer system indicator is blinking, the engine cannot be started.
2Immobilizer System P. 106
Check the fuel level.
There should be enough fuel in the tank. 2
Fuel Gauge P. 77
Check the fuse.
Check all fuses, or have the vehicle checked by a dealer.
2Inspecting and Changing Fuses P. 335
If the problem continues:
2Emergency Towing P. 336
1Checking the Engine
If you must start the vehicle immediately, use an
assisting vehicle to jump start it.
2 Jump Starting P. 324
Page 325 of 361
324
Handling the Unexpected
Jump Starting
Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the hood.1.Connect the first jumper cable to your vehicle's + terminal.
2. Connect the other end of the first jumper
cable to the assisting vehicle's + terminal.
uUse a 12-volt booster battery only.
3. Connect the second jumper cable to the
assisting vehicle's - terminal.
4. Connect the other end of the second
jumper cable to the engine mounting bolt
as shown.
Do not connect this jumper cable to any
other part.
5. If your vehicle is connected to another
vehicle, start the assisting vehicle's engine
and increase its rpm slightly.
6. Attempt to start your vehicle's engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.
■Jump Starting Procedure1Jump Starting
Securely attach the jumper cables clips so that they
do not come off when the engine vibrates. Also be
careful not to tangle the jumper cables or allow the
cable ends to touch each other while attaching or
detaching the jumper cables.
Battery performance degrades in cold conditions and
may prevent the engine from starting.
3WARNING
A battery can explode if you do not follow
the correct procedure, seriously injuring
anyone nearby.
Keep all sparks, open flames, and smoking
materials away from the battery.
Booster Battery
Page 326 of 361
325
uuJump Startingu
Handling the Unexpected
Once your vehicle's engine has started, remove the jumper cables in the following order. 1.Disconnect the jumper cable from your vehicle's ground.
2. Disconnect the other end of the jumper cable from the assisting vehicle's -
terminal.
3. Disconnect the jumper cable from your vehicle's + terminal.
4. Disconnect the other end of the jumper cable from the assisting vehicle's +
terminal.
Have your vehicle inspected by a nearby service station or a dealer.
■What to Do After the Engine Starts
Page 353 of 361
352
Index
Jump Starting .......................................... 324
Maintenance (Checking the Battery) ........ 305
Maintenance (Replacing).......................... 306
Behind a Motorhome ............................... 235
Belts (Seat) .................................................. 29
Beverage Holders ...................................... 134
Bluetooth ® Audio ..................................... 171
Bluetooth ® HandsFreeLink ®..................... 194
Booster Seats (For Children) ....................... 64
Brake System ............................................. 253
Anti-lock Brake System (ABS) ................... 255
Brake Assist System ................................. 256
Fluid ........................................................ 283
Foot Brake ............................................... 254
Indicator ............................................ 68, 331
Parking Brake .......................................... 253
Brightness Control (Instrument Panel) .... 117
Bulb Replacement ..................................... 285
Brake Light, Taillight, Back-Up Light, Rear Turn
Signal Light and Lower Rear Side Marker
Light ...................................................... 288
Fog Lights ................................................ 286
Front Turn Signal/Parking Light ................ 288
Headlights ............................................... 285
High-Mount Brake Light .......................... 291
Rear License Plate Light............................ 291
Side Marker Lights ................................... 287
Upper Rear Side Marker/Taillight .............. 290
Bulb Specifications .................................... 340 C
Carbon Monoxide Gas
............................... 65
Cargo Hook ............................................... 137
Cargo Side Net .......................................... 136
Carrying Cargo ................................. 227, 229
CD Player ................................................... 160
Certification Label .................................... 342
Changing Bulbs ........................................ 285
Charging System Indicator ................. 69, 329
Child Safety ................................................. 52
Childproof Door Locks............................. 102
Child Seat .................................................... 52
Booster Seats ............................................ 64
Child Seat for Infants................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 60
Larger Children ......................................... 63
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Childproof Door Locks ............................. 102
Cleaning the Exterior ............................... 312
Cleaning the Interior ................................ 310
Climate Control System ............................ 145
Changing the Mode ................................ 145
Defrosting the Windshield and Windows ............................................... 146
Dust and Pollen Filter............................... 309
Recirculation/Fresh Air Mode ..... .............. 145
Sensors ................................................... 148
Synchronized Mode................................. 147 Using Automatic Climate Control ............ 145
Clock ........................................................... 96
Coat Hook ................................................ 136
Compact Spare Tire .......................... 317, 341
Compass .................................................... 223
Console Compartment ............................. 133
Controls ...................................................... 95
Coolant (Engine) ...................................... 280
Adding to the Radiator ...... ..................... 281
Adding to the Reserve Tank .................... 280
Overheating ............................................ 327
Creeping (Automatic Transmission) ........ 242
Cruise Control .......................................... 245
Indicator ................................................... 76
Cup Holders .............................................. 134
Customer Service Information ................ 350
Customized Features ................................. 84
D
Daytime Running Lights .......................... 114
Dead Battery ............................................ 324
Defrosting the Windshield and Windows ......................................... 144, 146
Detachable Anchor .................................... 34
Devices that Emit Radio Waves ............... 343
Dimming
Headlights .............................................. 112
Rearview Mirror ...................................... 120
Dipstick (Engine Oil) ................................ 276
Directional Signals (Turn Signal) ............. 112
Page 354 of 361
353
Index
Display Button............................................ 81
Door Mirrors ............................................. 121
Doors .......................................................... 97
Auto Door Locking.................................. 103
Auto Door Unlocking .............................. 103
Door Open Indicator ........................... 28, 72
Keys.......................................................... 97
Locking/Unlocking the Doors from the Inside .................................................... 101
Locking/Unlocking the Doors from the
Outside ................................................... 99
Lockout Prevention System ..................... 100
DOT Tire Quality Grading ........................ 299
Driver’s Seat Lumbar Support ................. 122
Driving ...................................................... 225
Automatic Transmission .......................... 242
Braking ................................................... 253
Cruise Control ........................................ 245
Off-Highway Driving Guidelines .............. 237
Shifting Gear .......................................... 243
Starting the Engine ................................. 239
Dust and Pollen Filter .............................. 309
DVD Player ............................................... 173
E
Eco Assist System .......................................... 7
ECON Button ............................................ 119
Elapsed Time .............................................. 82
Electric Power Steering (EPS) System
Indicator ........................................... 73, 331 Electronic Stability Control (ESC)
............. 248
Emergency ................................................ 336
Emissions Testing (Readiness Codes) ....... 345
Engine ....................................................... 342
Coolant ................................................... 280
Jump Starting .......................................... 324
Oil ........................................................... 275
Starting ................................................... 239
Switch Buzzer .......................................... 111
Engine Coolant ......................................... 280
Adding to the Radiator ............................ 281
Adding to the Reserve Tank ..................... 280
Overheating ............................................ 327
Temperatue Guage.................................... 77
Engine Oil ................................................. 275
Adding .................................................... 277
Checking ................................................. 276
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator.................. 68, 329
Recommended Engine Oil........................ 275
EPS (Electric Power Steering)
System ............................................... 73, 331
Exhaust Gas Hazard (Carbon Monoxide) ................................................. 65
Exterior Care (Cleaning) ........................... 312
Exterior Mirrors ........................................ 121
F Features ..................................................... 149
Filters Dust and Pollen ....................................... 309
Oil ........................................................... 278
Flat Tire ..................................................... 317
Floor Mats ................................................. 311
Fluids Automatic Transmission .......................... 282
Brake ...................................................... 283
Engine Coolant ....................................... 280
Windshield Washer ................................. 284
Fog Light Indicator ..................................... 74
Folding Down the Rear Seats .................. 129
Foot Brake ................................................ 254
Front Airbags (SRS) ..................................... 40
Front Seats ................................................ 122
Adjusting ................................................ 122
Fuel ...................................................... 16, 259
Economy ................................................. 262
Gauge ....................................................... 77
Low Fuel Indicator ..................................... 70
Range ................................................. 79, 82
Recommendation .................................... 259
Refueling................................................. 259
Fuel Economy ........................................... 262
Fuel Fill Cap ........................................ 16, 261
Message.................................................. 330
Fuel Fill Door ...................................... 16, 260
Fuses .......................................................... 333
Inspecting and Changing........ ............... .. 335
Locations......................................... 333, 334
Page 356 of 361
355
Index
Information.............................................. 339
Information Display ................................... 78
Instrument Panel ........................................ 67
Brightness Control .................................. 117
Interior Lights ........................................... 132
Interior Rearview Mirror ......................... 120
iPod ®......................................................... 163
J
Jack (Wheel Nut Wrench) ........................ 320
Jump Starting ........................................... 324
K
Key Number Tag ........................................ 98
Keyless Lockout Prevention ..................... 100
Keys ............................................................. 97
Lockout Prevention ................................. 100
Master Keys .............................................. 97
Number Tag.............................................. 98
Rear Door Won’t Open ........................... 102
Remote Transmitter .................................. 99
Types and Functions.................................. 97
Valet Key .................................................. 98
Won’t Turn ............................................... 19
Kickdown (Automatic Transmission) ...... 242
L
Language (HFL) ........................................ 195
LATCH (Child Seats) ............................. 57, 61 Lights
................................................. 112, 285
Automatic ............................................... 113
Bulb Replacement.................................... 285
Daytime Running Lights ........................... 114
Fog Lights................................................ 114
High Beam Indicator .................................. 74
Interior .................................................... 132
Light Switches ......................................... 112
Lights On Indicator .................................... 74
Turn Signals............................................. 112
Load Limits ................................................ 229
Locking/Unlocking ...................................... 97
Auto Door Locking/Unlocking .................. 103
Childproof Door Locks ............................. 102
From Inside.............................................. 101
From Outside............................................. 99
Keys .......................................................... 97
Using a Key ............................................. 100
Lockout Prevention System ...................... 100
Low Battery Charge .................................. 329
Low Fuel Indicator ...................................... 70
Low Oil Pressure Indicator ................. 68, 329
Lower Anchors ...................................... 57, 61
Luggage (Maximum Load Limit) ............. 229
M
Maintenance ............................................. 265
Battery .................................................... 305
Brake Fluid .............................................. 283
Cleaning.................................................. 310 Climate Control System ........................... 309
Coolant ................................................... 280
Heating and Cooling System ................... 309
Maintenance Minder™ ........................... 269
Oil ........................................................... 276
Precautions ............................................. 266
Radiator .................................................. 281
Remote Control....................................... 307
Remote Transmitter ................................. 306
Replacing Light Bulbs .............................. 285
Safety...................................................... 267
Service Items ........................................... 271
Tires ........................................................ 296
Transmission Fluid ................................... 282
Under the Hood ...................................... 273
Wireless Headphone................................ 308
Malfunction Indicator Lamp .............. 69, 330
Map Lights ................................................ 132
Maximum Load Limit ............................... 229
Meters, Gauges ........................................... 77
Mirrors ...................................................... 120
Adjusting ................................................ 120
Door ....................................................... 121
Exterior ................................................... 121
Interior Rearview ..................................... 120
Modifications (and Accessories) .............. 263
Moonroof ................................................. 110
MP3 ................................................... 160, 168
Multi-Information Display ......................... 81
Multi-View Rear Camera .......................... 258
Page 358 of 361
357
Index
Seats.......................................................... 122
Adjusting ................................................ 122
Driver’s Seat Lumbar Support .................. 122
Front Seats.............................................. 122
Rear Seats ............................................... 129
Seat Heaters ........................................... 139
Security System ........................................ 106
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 75
SEL/RESET Knob .................................... 78, 81
Select Lever ........................................ 15, 243
Operation ......................................... 15, 244
Releasing ................................................ 326
Won’t Move ........................................... 326
Selecting a Child Seat ................................ 56
Selector Knob (Audio) ............................. 153
Setting the Clock ........................................ 96
Shift Lever .......................................... 15, 243
Shift Lever Position Indicator ............ 69, 244
Shifting (Transmission) ............................ 243
Shoulder Anchor ........................................ 33
Side Airbags ............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags .................................. 47
SMS Text Message ............................ 206, 218
Snow Tires ................................................ 304
Spare Tire ......................................... 317, 341
Spark Plugs ............................................... 340
Specifications ........................................... 340
Specified Fuel ................................... 259, 340 Speedometer
.............................................. 77
SRS Airbags (Airbags) ................................. 40
Starting the Engine .................................. 239
Does Not Start ......................................... 323
Engine Switch Buzzer .............................. 111
Jump Starting .......................................... 324
Steering Wheel ......................................... 119
Adjusting................................................. 119
Stopping .................................................... 257
Summer Tires ............................................ 304
Sunglasses Holder ..................................... 138
Supplemental Restraint System (SRS) ........ 40
Switches (Around the Steering
Wheel) ............................................. 2, 3, 111
Synchronized Mode .................................. 147
T
Tachometer ................................................. 77
Tailgate ..................................................... 104
Unable to Open ....................................... 337
Temperature Gauge ................................... 77
Temperature Sensor ................................. 148
Text Message .................................... 206, 218
Time (Setting) ............................................. 96
Tire Pressure Monitoring System (TPMS) ..................................................... 250
Indicator ............................................ 73, 332
Tires ........................................................... 296
Air Pressure ..................................... 297, 341
Checking and Maintaining....................... 296 Inspection ............................................... 296
Labeling .................................................. 297
Puncture (Flat Tire) .................................. 317
Regulations ............................................. 299
Rotation .................................................. 303
Spare Tire ........................................ 317, 341
Summer .................................................. 304
Tire Chains .............................................. 304
Wear Indicators ....................................... 301
Winter..................................................... 304
Tonneau Cover ......................................... 140
Tools .......................................................... 316
Towing a Trailer ....................................... 231
Equipment and Accessories ..................... 232
Load Limits .............................................. 231
Towing Your Vehicle ................................ 235
Behind a Motorhome .............................. 235
Emergency .............................................. 336
TPMS (Tire Pressure Monitoring
System) .................................................... 250
Indicator............................................ 73, 332
Transmission ............................................. 243
Automatic ............................................... 243
Fluid ........................................................ 282
Number................................................... 342
Shift Lever Position Indicator.............. 69, 244
Trip Meter ................................................... 79
Troubleshooting ....................................... 315
Blown Fuse...................................... 333, 334
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door.......... 20
