key HONDA CR-V 2013 RM1, RM3, RM4 / 4.G Owner's Manual

243
uuWhen DrivinguShifting
Continued
Driving
Shifting
Change the shift position in accordance with your driving needs.
■Shift lever positions
1Shifting
You cannot turn the ignition switch to LOCK (0 and
remove the key unless the shift lever is in (P.
The vehicle may move forward very slightly even in
(N while the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.Park
Used when parking or starting the
engine
Reverse
Used when reversing
Neutral
Used when idling
Drive
Used for normal driving (gears change
between 1st and 5th automatically)
Drive (D3)
Press the
(d button while the shift lever
is in (D.
Used when:
●Going up or down hills●Towing a trailer in hilly terrain Second
Used to increase engine braking
(the transmission is locked in 2nd gear)
First
Used to further increase engine braking
(the transmission is locked in 1st gear) Release Button
(d Button

308
Maintenance
Remote Transmitter Care
Replacing the Button Battery
If the indicator does not come on when the button is pressed, replace the battery.
1.Unscrew the cover with a small Phillips-
head screwdriver. Press a button to pry
open the transmitter.
2.Open the keypad.
uWrap the small flat-tip screwdriver with a
cloth to prevent scratching the
transmitter.
3.Make sure to replace the battery with the
correct polarity.1Replacing the Button BatteryNOTICEAn improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.
Replacement batteries are commercially available or
at a dealer.
Keypad
Screw
Battery type: CR1616
Battery

328
Handling the Unexpected
Shift Lever Does Not Move
Follow the procedure below if you cannot move the shift lever out of the (P
position.
1.Set the parking brake.
2.Remove the key from the ignition switch.
3.Wrap a cloth around the tip of a small flat-
tip screwdriver. Put it into the shift lock
release slot as shown in the image, and
remove the cover.
4.Insert the key into the shift lock release slot.
5.While pushing on the key down, press the
shift lever release button and place the shift
lever into
(N.
uThe lock is now released. Have the shift
lever checked by a dealer as soon as
possible.
■Releasing the Lock
Slot
Cover
Release
Button
Shift Lock Release Slot

336
uuFusesuFuse Locations
Handling the Unexpected
Located under the dashboard.
Fuse locations are shown on the label on
the cover.
Locate the fuse in question by the fuse
number and label number.
■Circuit protected and fuse rating
■Interior Fuse Box
Fuse Label
Fuse Box
Circuit ProtectedAmps1−−2ACG10 A3SRS10 A4Fuel Pump15 A5Meter10 A6Power Window7.5 A7VB SOL7.5 A8Door Lock Motor 2 (Unlock)15 A9Door Lock Motor 1 (Unlock)15 A
10Trailer*(7.5 A)
11 Moonroof*(20 A)
12Accessory Power Socket
(Center Console)(20 A)
13 − −
14Seat Heaters*(20 A)
15Driver’s Door Lock Motor
(Unlock)10 A
16Driver's Power Seat Sliding*(20 A)
17Driver's Power Seat
Reclining
*(20 A)
18−−
19 ACC 7.5 A
20ACC Key Lock7.5 A
21 Daytime Running Lights 7.5 A
22A/C7.5 A
23 Rear Wiper 10 A
24ABS/VSA7.5 A
25 Audio 10 A
26−−
27Accessory Power Socket
(Front)20 A
28Washer15 A
29 ODS 7.5 A
30Driver’s Door Lock Motor
(Lock)*10 A
31 − −
Circuit ProtectedAmps32Door Lock Motor 2 (Lock)15 A
33 Door Lock Motor 1 (Lock) 15 A
34Small Lights10 A
35 Illumination 7.5 A
36−−
37 − −
38Left Headlight High Beam10 A
39 Right Headlight High Beam 10 A
40TPMS7.5 A
41 Door Lock 20 A
42Driver’s Power Window20 A
43Rear Passenger’s Side
Power Window20 A
44Front Passenger’s Side
Power Window20 A
45Rear Driver’s Side Power
Window20 A
46−−
Circuit ProtectedAmps
* Not available on all models

355
Index
Display Button............................................ 81
Door Mirrors............................................. 121
Doors.......................................................... 97
Auto Door Locking.................................. 103
Auto Door Unlocking .............................. 103
Door Open Indicator ........................... 28, 72
Keys.......................................................... 97
Locking/Unlocking the Doors from the
Inside .................................................... 101
Locking/Unlocking the Doors from the
Outside ................................................... 99
Lockout Prevention System ..................... 100
DOT Tire Quality Grading........................ 301
Driver’s Seat Lumbar Support................. 122
Driving...................................................... 225
Automatic Transmission .......................... 242
Braking ................................................... 254
Cruise Control ........................................ 246
Off-Highway Driving Guidelines .............. 237
Shifting Gear .......................................... 243
Starting the Engine ................................. 239
Dust and Pollen Filter.............................. 311
DVD Player............................................... 174
EEco Assist System.......................................... 7
ECON Button............................................ 245
Elapsed Time.............................................. 82
Electric Power Steering (EPS) System
Indicator ........................................... 73, 333Electronic Stability Control (ESC)............. 249
Emergency................................................ 338
Emissions Testing (Readiness Codes)....... 347
Engine....................................................... 344
Coolant ................................................... 282
Jump Starting .......................................... 326
Oil ........................................................... 277
Starting ................................................... 239
Switch Buzzer .......................................... 111
Engine Coolant......................................... 282
Adding to the Radiator ............................ 283
Adding to the Reserve Tank ..................... 282
Overheating ............................................ 329
Temperature Gauge .................................. 77
Engine Oil................................................. 277
Adding .................................................... 279
Checking ................................................. 278
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator.................. 68, 331
Recommended Engine Oil........................ 277
EPS (Electric Power Steering)
System............................................... 73, 333
Exhaust Gas Hazard (Carbon Monoxide).. 65
Exterior Care (Cleaning)........................... 314
Exterior Mirrors........................................ 121FFeatures..................................................... 149
Filters
Dust and Pollen ....................................... 311Oil ........................................................... 280
Flat Tire..................................................... 319
Floor Mats................................................. 313
Fluids
Automatic Transmission .......................... 284
Brake ...................................................... 285
Engine Coolant ....................................... 282
Windshield Washer ................................. 286
Fog Light Indicator..................................... 74
Folding Down the Rear Seats.................. 129
Foot Brake................................................ 255
Front Airbags (SRS)..................................... 40
Front Seats................................................ 122
Adjusting ................................................ 122
Fuel...................................................... 16, 260
Economy ................................................. 263
Gauge ....................................................... 77
Low Fuel Indicator ..................................... 70
Range ................................................. 79, 82
Recommendation .................................... 260
Refueling................................................. 260
Fuel Economy........................................... 263
Fuel Fill Cap.............................................. 262
Message.................................................. 332
Fuel Fill Door............................................ 261
Fuses.......................................................... 335
Inspecting and Changing......................... 337
Locations......................................... 335, 336

357
Index
Washer Level ............................................ 76
Information.............................................. 341
Information Display................................... 78
Instrument Panel........................................ 67
Brightness Control .................................. 117
Interior Lights........................................... 132
Interior Rearview Mirror......................... 120
iPod®......................................................... 164
JJack (Wheel Nut Wrench)........................ 322
Jump Starting........................................... 326
KKey Number Tag........................................ 98
Keyless Lockout Prevention..................... 100
Keys............................................................. 97
Lockout Prevention ................................. 100
Master Keys .............................................. 97
Number Tag.............................................. 98
Rear Door Won’t Open ........................... 102
Remote Transmitter .................................. 99
Types and Functions.................................. 97
Valet Key .................................................. 98
Won’t Turn ............................................... 19
Kickdown (Automatic Transmission)...... 242
LLanguage (HFL)........................................ 195LATCH (Child Seats).............................. 57, 61
Lights................................................. 112, 287
Automatic ............................................... 113
Bulb Replacement.................................... 287
Daytime Running Lights ........................... 114
Fog Lights................................................ 114
High Beam Indicator .................................. 74
Interior .................................................... 132
Light Switches ......................................... 112
Lights On Indicator .................................... 74
Turn Signals............................................. 112
Load Limits................................................ 229
Locking/Unlocking...................................... 97
Auto Door Locking/Unlocking .................. 103
Childproof Door Locks ............................. 102
From Inside.............................................. 101
From Outside............................................. 99
Keys .......................................................... 97
Using a Key ............................................. 100
Lockout Prevention System...................... 100
Low Battery Charge.................................. 331
Low Fuel Indicator...................................... 70
Low Oil Pressure Indicator................. 68, 331
Lower Anchors...................................... 57, 61
Luggage (Maximum Load Limit)............. 229
MMaintenance............................................. 265
Battery .................................................... 307
Brake Fluid .............................................. 285Cleaning ................................................. 312
Climate Control System ........................... 311
Coolant ................................................... 282
Heating and Cooling System ................... 311
Maintenance Minder™ ........................... 269
Oil ........................................................... 278
Precautions ............................................. 266
Radiator .................................................. 283
Remote Control....................................... 309
Remote Transmitter ................................. 308
Replacing Light Bulbs .............................. 287
Safety...................................................... 267
Service Items ........................................... 272
Tires ........................................................ 298
Transmission Fluid ................................... 284
Under the Hood ...................................... 275
Wireless Headphone................................ 310
Malfunction Indicator Lamp.............. 69, 332
Map Lights................................................ 132
Maximum Load Limit............................... 229
Meters, Gauges........................................... 77
Mirrors...................................................... 120
Adjusting ................................................ 120
Door ....................................................... 121
Exterior ................................................... 121
Interior Rearview ..................................... 120
Modifications (and Accessories).............. 264
Moonroof................................................. 110
MP3................................................... 161, 169
Multi-Information Display......................... 81
Multi-View Rear Camera.......................... 259

360
Index
Emergency Towing .................................. 338
Engine Won’t Start .................................. 325
Noise When Braking .................................. 20
Overheating............................................. 329
Puncture/Flat Tire ..................................... 319
Rear Door Won’t Open ...................... 19, 102
Select Lever Won’t Move ......................... 328
Warning Indicators .................................... 68
Turn Signals............................................... 112
Indicators (Instrument Panel) ...................... 74
UUnlocking the Doors................................... 99
Unlocking the Front Doors from the
Inside......................................................... 11
USB Adapter Cable........................... 150, 151
USB Flash Drives........................................ 193
VValet Key..................................................... 98
Vanity Mirrors............................................... 5
Vehicle Identification Number................. 344
Vehicle Stability Assist (VSA®).................. 249
Off Button ............................................... 250
Off Indicator .............................................. 72
System Indicator ........................................ 72
Viscosity (Oil)..................................... 277, 343
VSA® (Vehicle Stability Assist).................. 249
WWallpaper................................................... 90
Warning Indicator On/Blinking............... 331
Warning Labels........................................... 66
Warranties (Warranty Manual provided
separately).............................................. 349
Watts......................................................... 342
Wear Indicators (Tire).............................. 303
Wheel Nut Wrench (Jack Handle)........... 322
Window Washers..................................... 115
Adding/Refilling Fluid .............................. 286
Switch ..................................................... 115
Windows (Opening and Closing)............ 108
Windshield................................................ 115
Cleaning ................................................. 315
Defrosting/Defogging ...................... 144, 146
Washer Fluid ........................................... 286
Wiper Blades ........................................... 294
Wipers and Washers................................ 115
Winter Tires.............................................. 306
Snow Tires .............................................. 306
Tire Chains .............................................. 306
Wipers and Washers................................. 115
Checking and Replacing Wiper Blades ..... 294
Front ....................................................... 115
Rear ........................................................ 116
WMA................................................. 161, 169
Worn Tires................................................ 298XXM® Radio................................................ 159
