186
Features
Audio Error Messages
CD Player
If a disc error occurs, you may see the following error messages.
Error MessageCauseSolution
HEAT ERRORHigh temperature●Turn the audio system off and allow the player to cool down until
the error message is cleared.
UNPLAYABLE/UnsupportedTrack/file format not supported●Current track/file will be skipped. The next supported track/file
plays automatically.
BAD DISC
PLEASE CHECK OWNERS
MANUAL
PUSH EJECT
Mechanical error
●Press the (eject) button and remove the disc, and check that the
error message is cleared.
●Check that the disc is not damaged or deformed, and insert the
disc again.
2Protecting CDs P. 192●If the error message reappears, press the button, and pull out
the disc.
●Insert a different disc.
If the new disc plays, there is a problem with the first disc.
●If the error message repeats, or the disc cannot be removed,
contact a dealer.
Do not try to force the disc out of the player.
MECH ERROR
BAD DISC
PLEASE CHECK OWNERS
MANUALServo error
CHECK DISCDisc error●Check that the disc is not damaged or deformed.2Protecting CDs P. 192

189
uuAudio Error MessagesuDVD Player Error Messages
Features
DVD Player Error Messages
Error MessageCauseSolution
Disc ErrorFOCUS ErrorPress the disc eject button, and remove the disc. Check for an error indication.
Insert the disc again. If the code does not disappear or the disc cannot be
removed, consult a dealer.
MECH ErrorMechanical Error
Region ErrorInvalid region codeThe disc is not playable in this unit. Eject the disc, and insert a disc compatible
with this system.
Heat ErrorHigh temperatureTurn the system off and allow the player to cool down until the error message
is cleared.
Format ErrorTrack/file format not
supportedCurrent track/file will be skipped. The next supported track/file plays
automatically.
Models with rear entertainment system

uuGeneral Information on the Audio SystemuRecommended CDs
192
Features
■Protecting CDs
Follow these precautions when handling or storing CDs:
•Store a CD in its case when it is not being played.
•When wiping a CD, use a soft clean cloth from the center to the outside edge.
•Handle a CD by its edge. Never touch either surface.
•Never insert foreign objects into the CD player.
•Keep CDs out of direct sunlight and extreme heat.
•Do not place stabilizer rings or labels on the CD.
•Avoid fingerprints, liquids, and felt-tip pens on the CD.1Protecting CDsNOTICEDo not insert a damaged CD. It may be stuck inside
and damage the audio unit.
Examples:
●Damaged CDsBubbled/
WrinkledWith Label/
StickerUsing
Printer Label
Kit
Sealed With Plastic Ring●Poor quality
CDs
Chipped/
CrackedWarped Burrs
●Small CDs
3-inch
(8-cm)
CD
●Bubbled, wrinkled, labeled, and
excessively thick CDs

193
uuGeneral Information on the Audio SystemuCompatible iPod®, iPhone® and USB Flash Drives
Features
Compatible iPod®, iPhone® and USB Flash Drives
•Use a recommended USB flash drive of 256 MB or higher.
•Some digital audio players may not be compatible.
•Some USB flash drives (e.g., a device with security lockout) may not work.
•Some software files may not allow for audio play or text data display.
•Some versions of MP3, WMA, or AAC formats may be unsupported.
■iPod® and iPhone® Model Compatibility
ModeliPod (5th generation)iPod classic 80/160 GB (launched in 2007)iPod classic 120 GB (launched in 2008)iPod classic 160 GB (launched in 2009)iPod nano (launched in 2011)iPod touch (launched in 2011)iPhone 3G/iPhone 3GS/iPhone 4/iPhone 4S
■USB Flash Drives
1iPod® and iPhone® Model Compatibility
This system may not work with all software versions
of these devices.
1USB Flash Drives
Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.

354
Index
Maintenance (Checking the Battery) ........ 307
Maintenance (Replacing).......................... 308
Behind a Motorhome............................... 235
Belts (Seat).................................................. 29
Beverage Holders...................................... 134
Bluetooth® Audio..................................... 172
Bluetooth® HandsFreeLink®..................... 194
Booster Seats (For Children)....................... 64
Brake System............................................. 254
Anti-lock Brake System (ABS) ................... 256
Brake Assist System ................................. 257
Fluid ........................................................ 285
Foot Brake ............................................... 255
Indicator ............................................ 68, 333
Parking Brake .......................................... 254
Brightness Control (Instrument Panel).... 117
Bulb Replacement..................................... 287
Brake Light, Taillight, Back-Up Light, Rear
Turn Signal Light and Lower Rear Side
Marker Light ........................................ 290
Fog Lights ................................................ 288
Front Turn Signal/Parking Light ................ 290
Headlights ............................................... 287
High-Mount Brake Light .......................... 293
Rear License Plate Light............................ 293
Side Marker Lights ................................... 289
Upper Rear Side Marker/Taillight .............. 292
Bulb Specifications.................................... 342CCarbon Monoxide Gas............................... 65
Cargo Hook............................................... 137
Cargo Side Net.......................................... 136
Carrying Cargo................................. 227, 229
CD Player................................................... 161
Certification Label.................................... 344
Changing Bulbs........................................ 287
Charging System Indicator................. 69, 331
Child Safety................................................. 52
Childproof Door Locks............................. 102
Child Seat.................................................... 52
Booster Seats ............................................ 64
Child Seat for Infants................................. 54
Child Seat for Small Children ..................... 55
Installing a Child Seat with a Lap/Shoulder
Seat Belt .................................................. 60
Larger Children ......................................... 63
Rear-facing Child Seat ............................... 54
Selecting a Child Seat ................................ 56
Childproof Door Locks............................. 102
Cleaning the Exterior............................... 314
Cleaning the Interior................................ 312
Climate Control System............................ 145
Changing the Mode ................................ 145
Defrosting the Windshield and
Windows ............................................... 146
Dust and Pollen Filter............................... 311
Recirculation/Fresh Air Mode ................... 145
Sensors ................................................... 148
Synchronized Mode................................. 147Using Automatic Climate Control ............ 145
Clock........................................................... 96
Coat Hook................................................ 136
Compact Spare Tire.......................... 319, 343
Compass.................................................... 223
Console Compartment............................. 133
Controls...................................................... 95
Coolant (Engine)...................................... 282
Adding to the Radiator ........................... 283
Adding to the Reserve Tank .................... 282
Overheating ............................................ 329
Creeping (Automatic Transmission)........ 242
Cruise Control.......................................... 246
Indicator ................................................... 76
Cup Holders.............................................. 134
Customer Service Information................ 352
Customized Features................................. 84
DDaytime Running Lights.......................... 114
Dead Battery............................................ 326
Defrosting the Windshield and
Windows......................................... 144, 146
Detachable Anchor.................................... 34
Devices that Emit Radio Waves............... 345
Dimming
Headlights .............................................. 112
Rearview Mirror ...................................... 120
Dipstick (Engine Oil)................................ 278
Directional Signals (Turn Signal)............. 112

355
Index
Display Button............................................ 81
Door Mirrors............................................. 121
Doors.......................................................... 97
Auto Door Locking.................................. 103
Auto Door Unlocking .............................. 103
Door Open Indicator ........................... 28, 72
Keys.......................................................... 97
Locking/Unlocking the Doors from the
Inside .................................................... 101
Locking/Unlocking the Doors from the
Outside ................................................... 99
Lockout Prevention System ..................... 100
DOT Tire Quality Grading........................ 301
Driver’s Seat Lumbar Support................. 122
Driving...................................................... 225
Automatic Transmission .......................... 242
Braking ................................................... 254
Cruise Control ........................................ 246
Off-Highway Driving Guidelines .............. 237
Shifting Gear .......................................... 243
Starting the Engine ................................. 239
Dust and Pollen Filter.............................. 311
DVD Player............................................... 174
EEco Assist System.......................................... 7
ECON Button............................................ 245
Elapsed Time.............................................. 82
Electric Power Steering (EPS) System
Indicator ........................................... 73, 333Electronic Stability Control (ESC)............. 249
Emergency................................................ 338
Emissions Testing (Readiness Codes)....... 347
Engine....................................................... 344
Coolant ................................................... 282
Jump Starting .......................................... 326
Oil ........................................................... 277
Starting ................................................... 239
Switch Buzzer .......................................... 111
Engine Coolant......................................... 282
Adding to the Radiator ............................ 283
Adding to the Reserve Tank ..................... 282
Overheating ............................................ 329
Temperature Gauge .................................. 77
Engine Oil................................................. 277
Adding .................................................... 279
Checking ................................................. 278
Displaying Oil Life .................................... 269
Low Oil Pressure Indicator.................. 68, 331
Recommended Engine Oil........................ 277
EPS (Electric Power Steering)
System............................................... 73, 333
Exhaust Gas Hazard (Carbon Monoxide).. 65
Exterior Care (Cleaning)........................... 314
Exterior Mirrors........................................ 121FFeatures..................................................... 149
Filters
Dust and Pollen ....................................... 311Oil ........................................................... 280
Flat Tire..................................................... 319
Floor Mats................................................. 313
Fluids
Automatic Transmission .......................... 284
Brake ...................................................... 285
Engine Coolant ....................................... 282
Windshield Washer ................................. 286
Fog Light Indicator..................................... 74
Folding Down the Rear Seats.................. 129
Foot Brake................................................ 255
Front Airbags (SRS)..................................... 40
Front Seats................................................ 122
Adjusting ................................................ 122
Fuel...................................................... 16, 260
Economy ................................................. 263
Gauge ....................................................... 77
Low Fuel Indicator ..................................... 70
Range ................................................. 79, 82
Recommendation .................................... 260
Refueling................................................. 260
Fuel Economy........................................... 263
Fuel Fill Cap.............................................. 262
Message.................................................. 332
Fuel Fill Door............................................ 261
Fuses.......................................................... 335
Inspecting and Changing......................... 337
Locations......................................... 335, 336
