clock reset HONDA CR-V 2013 RM1, RM3, RM4 / 4.G Owners Manual

13
Quick Reference Guide
Climate Control System* (P 145)
●Press the AUTO button to activate the climate control system.
●Press the button to turn the system on or off.
●Press the button to defrost the windshield.
The climate control system is voice operable. See the navigation system manual for complete
details.
Models with navigation system
Driver's Side
Temperature
Control Dial
/ (Fan Control) Buttons
(Windshield
Defroster) Button
A/C (Air Conditioning)
Button
Air flows from floor and
windshield defroster vents. Air flows from floor vents. Air flows from floor and
dashboard vents. Air flows from dashboard
vents.
SYNC (Synchronized) Button
(Recirculation) Button
AUTO Button Passenger's Side
Temperature
Control Dial
(Rear Window Defogger/
Heated Mirror
*) Button
MODE Control Button (On/Off) Button
Clock (P 96)
aPress the CLOCK (AUX) button until the
displayed time begins flashing.
bPress Preset (4 (Hour) or (5 (Minute)
to set the time. Press Preset (6 (Reset)
to set the time to the nearest hour.
cPress the CLOCK button again to set
the time.
To set the time to the nearest hour:
Press and hold the CLOCK button until the
clock display begins to blink, then press the
(6 (Reset) button.
Depending on the displayed time, the clock
sets forward or backward.
Example:
1:06 will reset to 1:00
1:53 will reset to 2:00
The navigation system receives signals from
GPS satellites, updating the clock
automatically.
Models without navigation system
Models with navigation system
* Not available on all models

87
uuGauges and DisplaysuMulti-Information Display
Continued
Instrument Panel
■List of customizable options
*1: Default Setting
*2: See the Navigation System ManualSetup Group Customizable Features Description Selectable settings
Vehicle
InformationMaintenance infoReset the Maintenance MinderTM.No/Yes
Adjust Clock*Selects the 12 hour or 24 hour clock display, and adjusts
the time.12 h*1/24 h
Customize
SettingsDisplay
Setup
Select
WallpaperSelects the full-size analogue clock or the wallpaper.Clock*1/Image 1/Image 2/
Image 3
Import
WallpaperImports an image file for a new wallpaper.Three images can be stored.2Importing wallpapers
from USB P. 90
Delete
WallpaperDeletes an image file for a wallpaper.Image 1/Image 2/Image 3
Trip Meter
Item to DisplaySelects an item to be displayed along with average
fuel economy.Range*1/Elapsed time/
Average speed
Welcome
ScreenSelects whether the welcome screen comes on or
not when you turn the ignition switch to ON (w.On*1/Off
Color ThemeChanges the color of the screen.Blue*1/Red/Amber/Gray
Turn by Turn
Display *, *2Select whether the turn-by-turn display comes on or
not during the route guidance.On*1/Off
Language
SelectionChanges the displayed language.English*1/Francais/Español
* Not available on all models

96
Controls
Clock
Adjusting the Clock
You can adjust the time in the clock display with the ignition switch in ON (w.
■Using the MENU button
1.Press the MENU button.
2.Select Adjust Clock with the
(+ / (- button, then press the SOURCE button.
3.Press the (+ / (- button to change the
setting between 12 h and 24 h.
4.Select hour or minute with the /
button.
5.Press the
(+ / (- button to adjust the
numbers up or down.
6.Select Set with the / button, then
press the SOURCE button to enter your
selection.
uThe display will return to the Adjust
Clock display.
■Using the SETUP button
1.Press the SETUP button.
2.Rotate to select Adjust Clock, then press .
3.Rotate to select the item you want to change (12/24 hour mode, hour,
minute). Then press .
4.Rotate to make the adjustment.
5.Press to enter your selection. The display returns to Adjust Clock. Repeat steps
4 to 6 to adjust other items.
6.To enter the selection, Rotate and select Set, then press .
7.Press the SETUP button to go back to the normal display.
1Adjusting the Clock
These indications are used to show how to operate
the selector knob.
Rotate to select.
Press to enter.
To set the time to the nearest hour:
Press and hold the CLOCK button until the clock
display begins to blink, then press the
(6 (Reset)
button.
Depending on the displayed time, the clock sets
forward or backward.
Example:
1:06 will reset to 1:00
1:53 will reset to 2:00
The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.
Models with navigation system

307
Maintenance
Battery
Checking the Battery
Check the battery condition monthly. Look at
the test indicator window and check the
terminals for corrosion.
If your vehicle's battery is disconnected or goes dead:
•The audio system is disabled.
2Reactivating the audio system P. 152•The clock resets.2Clock P. 96•The navigation system* is disabled.2Refer to the navigation system manual
Charging the Battery
Disconnect both battery cables to prevent damaging your vehicle's electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.
1Battery
WARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.
The test indicator's color information is on the
battery.
When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean terminals with a damp towel. Cloth/towel dry
the battery. Coat the terminals with grease to help
prevent future corrosion.
3WARNINGThe battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.
When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.
Test Indicator Window
* Not available on all models

359
Index
Seats.......................................................... 122
Adjusting ................................................ 122
Driver’s Seat Lumbar Support .................. 122
Front Seats.............................................. 122
Rear Seats ............................................... 129
Seat Heaters ........................................... 139
Security System........................................ 106
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 75
Select Lever........................................ 15, 243
Operation ......................................... 15, 244
Releasing ................................................ 328
Won’t Move ........................................... 328
Select/Reset Knob...................................... 78
Selecting a Child Seat................................ 56
Selector Knob (Audio)............................. 153
Setting the Clock........................................ 96
Shift Lever.......................................... 15, 243
Shift Lever Position Indicator............ 69, 244
Shifting (Transmission)............................ 243
Shoulder Anchor........................................ 33
Side Airbags............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags.................................. 47
SMS Text Message............................ 206, 218
Snow Tires................................................ 306
Spare Tire......................................... 319, 343
Spark Plugs............................................... 342
Specifications........................................... 342
Specified Fuel................................... 260, 342Speedometer.............................................. 77
SRS Airbags (Airbags)................................. 40
Starting the Engine.................................. 239
Does Not Start ......................................... 325
Engine Switch Buzzer .............................. 111
Jump Starting .......................................... 326
Steering Wheel......................................... 119
Adjusting................................................. 119
Stopping.................................................... 258
Summer Tires............................................ 306
Sunglasses Holder..................................... 138
Supplemental Restraint System (SRS)........ 40
Switches (Around the Steering
Wheel)............................................. 2, 3, 111
Synchronized Mode.................................. 147
TTachometer................................................. 77
Tailgate..................................................... 104
Unable to Open ....................................... 339
Temperature Gauge................................... 77
Temperature Sensor................................. 148
Text Message.................................... 206, 218
Time (Setting)............................................. 96
Tire Pressure Monitoring System
(TPMS)..................................................... 251
Indicator ............................................ 73, 334
Tires........................................................... 298
Air Pressure ..................................... 299, 343
Checking and Maintaining....................... 298Inspection ............................................... 298
Labeling .................................................. 299
Puncture (Flat Tire) .................................. 319
Regulations ............................................. 301
Rotation .................................................. 305
Spare Tire ........................................ 319, 343
Summer .................................................. 306
Tire Chains .............................................. 306
Wear Indicators ....................................... 303
Winter..................................................... 306
Tonneau Cover......................................... 140
Tools.......................................................... 318
Towing a Trailer....................................... 231
Equipment and Accessories ..................... 232
Load Limits .............................................. 231
Towing Your Vehicle................................ 235
Behind a Motorhome .............................. 235
Emergency .............................................. 338
TPMS (Tire Pressure Monitoring
System).................................................... 251
Indicator............................................ 73, 334
Transmission............................................. 243
Automatic ............................................... 243
Fluid ........................................................ 284
Number................................................... 344
Shift Lever Position Indicator.............. 69, 244
Trip Meter................................................... 79
Troubleshooting....................................... 317
Blown Fuse...................................... 335, 336
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door.......... 20
