gas type HONDA CR-V 2013 RM1, RM3, RM4 / 4.G Owners Manual

23
Safe Driving
You can find many safety recommendations throughout this chapter, and throughout this manual.
For Safe Driving
Important Safety Precautions ............. 24
Important Handling Information......... 26
Your Vehicle's Safety Features............ 27
Seat Belts
About Your Seat Belts ........................ 29
Fastening a Seat Belt .......................... 32
Seat Belt Inspection............................ 36
Airbags
Airbag System Components ............... 37
Types of Airbags ................................ 40
Front Airbags (SRS) ............................ 40Side Airbags ...................................... 44
Side Curtain Airbags .......................... 47
Airbag System Indicators.................... 48
Airbag Care ....................................... 51
Child Safety
Protecting Child Passengers ............... 52
Safety of Infants and Small Children ....... 54Safety of Larger Children ................... 63
Exhaust Gas Hazard
Carbon Monoxide Gas ....................... 65
Safety Labels
Label Locations .................................. 66

342
Information
Specifications
■Vehicle Specifications
*1: 16 inch wheel with 2WD models
*2: 17 inch wheel with 2WD models and 16 inch wheel with 4WD
models
*3: 17 inch wheel with 4WD models
ModelHonda CR-V
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating U.S.: 4,332 lbs (1,965 kg)*1 4,464 lbs (2,025 kg)*2 4,564 lbs (2,070 kg)*3Canada: 1,965 kg*1 2,025 kg*2 2,070 kg*3Gross Axle Weight
Rating (Front)U.S.: 2,227 lbs (1,010 kg)*1 2,271 lbs (1,030 kg)*2 2,326 lbs (1,055 kg)*3Canada: 1,010 kg*1 1,030 kg*2 1,055 kg*3Gross Axle Weight
Rating (Rear)U.S.: 2,150 lbs (975 kg)*1 2,238 lbs (1,015 kg)*2 2,282 lbs (1,035 kg)*3Canada: 975 kg*1 1,015 kg*2 1,035 kg*3Air Conditioning:Refrigerant Type HFC-134a (R-134a)Charge Quantity13.6 – 15.4 oz (385 – 435 g)Lubricant TypeSP-10
■Engine Specifications
■Fuel
■Battery
■Washer FluidDisplacement144 cu-in (2,354 cm3)
Spark PlugsNGK ILZKR7B-11S
DENSO SXU22HCR11S
Fuel:
TypeUnleaded gasoline, Pump octane number
of 87 or higher
Fuel Tank Capacity 15.3 US gal (58 ℓ)
Capacity/Type36AH(5)/45AH(20)
36AH(5)/47AH(20)
38AH(5)/47AH(20)
Tank CapacityU.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
■Light Bulbs
*1: Not available on all models
Headlights (High/Low Beams)60/55W (H4/HB2)
Fog Lights 55W (H11)
Front Turn Signal/Parking Lights24/2.2CP
Side Marker Lights 3CP
Upper Rear Side Marker/Taillights3CP
Lower Rear Side Marker/Brake/
Taillights21/5W
Back-Up Lights21W
Rear Turn Signal Lights 21W (Amber)
High-Mount Brake LightLED
Rear License Plate Light 3CP
Cargo Area Light8W
Vanity Mirror Lights*12WInterior LightsMap Lights8WCeiling Light8W
