To use the horn, press the center pad of the steering wheel.
:
Your Vehicle at a Glance
3
HEADLIGHTS/TURN SIGNALS
REAR WINDOW
DEFOGGER
A/T model is shown. HORN
HAZARD WARNING
BUTTON
STEERING WHEEL ADJUSTMENT SHIFT LEVERAUDIO SYSTEM
WINDSHIELD WIPERS/WASHERS
DIGITAL CLOCK
(P.62)
(P.107)
CRUISE CONTROL
MASTER SWITCH
(P.64) (P.63)
(P.127)
(P.63) (P.94)
(P.105)
(P.61)
—
—y
y
(+
yy

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your Honda. All the essential
controls are within easy reach............................
Control Locations . 52
............................
Instrument Panel . 53
.............................................
Gauges . 58
...................................
Trip Meter . 58
.....................................
Odometer . 58
..................................
Fuel Gauge . 58
...................
Temperature Gauge . 59
Controls Near the Steering .......................................
Wheel . 60
......................
Wipers and Washers . 61
...........
Turn Signal and Headlights . 62
........
Instrument Panel Brightness . 63
.................
Hazard Warning Button . 63
.................
Rear Window Def ogger . 63
..........
Steering Wheel Adjustment . 64
...............................
Keys and Locks . 65
........................
Immobilizer System . 66
.......................
Remote Transmitter . 67
................................
Ignition Switch . 69
......................................
Door Locks . 70
......................
Power Door Locks . 70
..................................
Rear Doors . 70
............................................
Hatch . 71
........................................
Tailgate . 72
.................................................
Seats . 73
........................
Seat Adjustments . 73 Driver’s Seat Height
..............................
Adjustment . 74
...................
FrontSeatArmrests .74
..........................
Head Restraints . 75
........................
Rear Seat Access . 75
..........
Reclining the Front Seats . 76
...............
Folding the Rear Seats . 77
..........
Removing the Rear Seats . 79
..............................
Power Windows . 81
.............................................
Mirrors . 82
....
Adjusting the Power Mirrors . 82
.................................
Rear Windows . 83
.................................
Parking Brake . 83
............................................
Skylight . 83
...........
Interior Convenience Items . 86
.......................
Beverage Holders . 87
..........
Accessory Power Sockets . 87
....................................
Glove Box . 87
.................................
Interior Lights . 88
................................
Ceiling Light . 88
........................
Cargo Area Light . 88
.....................................
Spotlights . 88
..................
Ignition Switch Light . 88
Instruments and Controls
Inst rument s and Cont rols51
—
—y
y
(+
yy

On Canadian models, this indicator
comes on with reduced brightness
when the Daytime Running Lights
(DRL) are on (see page ).
This comes on with the high beam
headlights. See page f or
inf ormation on the headlight
controls.
Thiscomesonasareminderthat
you must ref uel soon.
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If the indicator does not
blink or blinks rapidly, it usually
means one of the turn signal bulbs is
burned out (see page ). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
This indicator comes on when you
turn the ignition switch to ON (II)
with the headlight switch off and the
parking brake set. It should go of f if
youturnontheheadlightsorrelease
the parking brake. If it comes on at
any other time, it means there is a
problem with the DRL. There may
also be a problem with the high
beam headlights.
Thiscomesonwhenyousetthe
cruise control. See page f or
inf ormation on operating the cruise
control.
WhenyouturnontheHazard
Warning button, both turn signal
indicators blink. All turn signals on
the outside of the vehicle should
flash. 167
10762
62
Canadian models only
On EX models
Inst rument s and Cont rols
Instrument Panel
Turn Signal and Hazard Warning
Indicators ‘‘Daytime Running
Lights’’ Indicator
High Beam Indicator
Low Fuel Indicator
Cruise Control Indicator
56
—
—y
y
(+
y
y

Î
Î
To use the horn, press the center pad of the steering wheel.
:
Controls Near the Steering Wheel
Inst rument s and Cont rols60
HEADLIGHTS/TURN SIGNALS
REAR WINDOW
DEFOGGER
SHIFT LEVER (A/T)
WINDSHIELD WIPERS/WASHERS
STEERING WHEEL ADJUSTMENT HAZARD WARNING BUTTON
A/T model is shown. HORN
(P.62)
(P.107) (P.64)(P.61)
(P.127)
(P.63)
(P.63)
CRUISE CONTROL
MASTER SWITCH
—
—y
y
(+
yy

Push the button next to the shift
levertoturnonthehazardwarning
lights (f our-way f lashers). This
causes all f our outside turn signals
and both turn indicators in the
instrument panel to f lash. Use the
hazard warning lights if you need to
park in a dangerous area near heavy
traf f ic, or if your vehicle is disabled.
Push the knob in the speedometer
repeatedly to adjust the brightness
of the instrument panel lights. There
are six brightness levels. A segment
display shows the current brightness
level.
The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and off. The indicator in
the button lights to show the
def ogger is on. If you do not turn it
of f , the def ogger will shut itself of f
af ter about 15 minutes. It also shuts
of f when you turn of f the ignition.
You have to turn it on again when
you restart the vehicle.
CONT INUED
Instrument Panel Brightness
Rear Window Def ogger
Hazard Warning Button
Instrument Panel Brightness, Hazard Warning Button, Rear Window Def ogger
Inst rument s and Cont rols63
—
—y
y
(+
yy

If you have a f lat tire while driving,
stop in a saf e place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.Park the vehicle on f irm, level and
non-slippery ground. Put the
transmission in Park (automatic)
or Reverse (manual). Apply the
parking brake.
If you are towing a trailer, unhitch
the trailer.
Turn on the hazard warning lights,
and turn the ignition switch to
LOCK (0). Have all the
passengers get out of the vehicle
while you change the tire.
Open the hatch and the tailgate.
The spare tire, jack, and tools are
under the cargo area f loor.
1. 2.
3. 4.
CONT INUED
Changing a Flat T ire
T aking Care of t he Unexpect ed181
TOOLS
SPARE TIRE
JACK
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by thejack.
—
—y

y
(+
y
y

If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.If you do not see steam or spray,
leave the engine running, and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
If the temperature gauge stays at
the red mark, turn of f the engine.
The pointer of the vehicle’s
temperature gauge should stay in
the midrange. If it climbs to the red
mark, you should determine the
reason (hot day, driving up a steep
hill, etc.).
Saf ely pull to the side of the road.
Put the transmission in Neutral or
Park, and set the parking brake.
Turn of f all accessories, and turn
on the hazard warning lights.
If the vehicle overheats, you should
take immediate action. The only
indication may be the temperature
gauge climbing to or above the red
mark. Or you may see steam or
spray coming f rom under the hood.
1. 2.3. 4.
If theEngineOverheats
T aking Care of t he Unexpect ed190
Steam and spray from an
overheated engine can
seriously scald you.
Do not open the hood if steam
is coming out.
Driving with the temperature gauge
pointer at the red mark can cause
serious damage to your engine.
—
—y

y
(+
y
y

Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).If the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
This light should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low. Serious engine damage is
possible and you should take
immediate action. Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning lights.
Start the engine, and watch the oil
pressure light. If it does not go out
within ten seconds, turn off the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving.
(See on page
).
1. 2. 4.
3. 113
157
195
L ow Oil Pressure Indicator
Emergency T owingCharging System Indicator
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed192
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.
—
—y

y
(+
y
y

.........................................
Gasoline . 110
...............
Fuel Reserve Indicator . 56
...........................................
Gauge . 58
................
Octane Requirement . 110
........................
Tank, Filling the . 111
................
Gas Station Procedures . 111
Gauges
...
Engine Coolant Temperature . 59
...............................................
Fuel . 58
Gearshif t Lever Positions ..........
Automatic Transmission . 127
5-speed Manual
.........................
Transmission . 126
........................................
Glove Box . 87
.............
Halogen Headlight Bulbs . 166
................................................
Hatch . 71
..............
Hazard Warning Flashers . 63
Headlights
........................................
Aiming . 166
............
Daytime Running Lights . 62
..................
High Beam Indicator . 56
........................
Reminder Beeper . 62
........
Replacing Halogen Bulbs . 166 ...................................
Turning on . 62
..............................
Head Restraints . 75
.......................
Heating and Cooling . 90
.................
High-Low Beam Switch . 62
.......................
Hood, Opening the . 112
..............................................
Horn .3,60
...........................
Hydraulic Clutch . 164
...
Identif ication Number, Vehicle . 202
Ignition
..............................................
Keys . 65
...........................................
Switch . 69
............
Timing Control System . 210
........................
Immobilizer System . 66
.........
Important Safety Precautions . 6
Indicators
..............
ABS (Anti-Lock Brake) . 55
Brake (Parking and Brake
............................
System) . 54, 194
........................
Charging System . 54
.............................
Cruise Control . 56
DRL (Daytime Running
......................................
Lights) . 56
...................................
High Beam . 56 ........
Key (Immobilizer System) . 55
......................................
Low Fuel . 56
........................
Low Oil Pressure . 54
...........................
Side Airbag Of f . 55
...............................................
SRS . 55
Turn Signal and Hazard
...................................
Warning . 56
..............................
Washer Level . 57
.........
Indicators, Instrument Panel . 53
...............................
Inf ant Restraint . 34
......................................
Inf ant Seats . 34
......
LATCH Anchorage System . 39
...........................
Lower Anchors . 39
..........
Tether Anchorage Points . 43
...................
Inf lation, Proper Tire . 172
.........................
Normal Driving . 173
...................................
Inside Mirror . 82
.............................
Inspection, Tire . 174
............................
Instrument Panel . 53
........
Instrument Panel Brightness . 63
........................................
Introduction . i
.................
Jacking up the Vehicle . 183
.......................................
Jack, Tire . 181
