HONDA ELEMENT 2006 1.G Owners Manual

Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
adjustment (see page ).Make sure the doors, hatch, and
tailgate are securely closed and
locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ).
Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.
Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice. When you start the engine, check
the gauges and indicators in the
instrument panel (see page ).
Check that the hood is f ully closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying with you inside are stored
properly or f astened down
securely.
1.
2.
3.
4. 5.
6.
7.
8.
9.
10.
73
82 15
53
64
Preparing to Drive
Driving
139

Apply the parking brake.
In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery.
Push the clutch pedal down all the
way.
Make sure the shif t lever is in
Park. Press on the brake pedal.
Without touching the accelerator
pedal, turn the ignition key to the
START (III) position. Do not hold
the key in the START (III)
position f or more than 15 seconds
at a time. If the engine does not
start right away, pause for at least
10 seconds bef ore trying again.If the engine does not start within
15 seconds, or starts but stalls
right away, repeat step 4 with the
accelerator pedal pressed halfway
down. If the engine starts, release
pressure on the accelerator pedal
so the engine does not race.
If the engine fails to start, press
the accelerator pedal all the way
down, and hold it there while
starting to clear flooding. If the
engine still does not start, return
to step 5.
1.
2.
3.
4.
6. 5.
Manual transmission:
Automatic transmission: 66
Starting the Engine
140
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
T he immobilizer system protects your
vehicle f rom thef t. If an improperly-
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page .

When slowing down, you can get
extra braking f rom the engine by
shifting to a lower gear. This extra
braking can help you maintain a safe
speed and prevent your brakes f rom
overheating while going down a
steep hill. Bef ore downshif ting,
make sure the engine speed will not
go into the tachometer’s red zone in
the lower gear.
The manual transmission is
synchronized in all f orward gears f or
smooth operation. It has a lockout so
you cannot shift directly from fifth to
reverse. When shif ting up or down,
make sure you push the clutch pedal
down all the way, shift to the next
gear, and let the pedal up gradually.
When you are not shif ting, do not
rest your f oot on the clutch pedal.
This can cause your clutch to wear
out f aster. Come to a full stop before you shift
into reverse. You can damage the
transmission by trying to shif t into
reverse with the vehicle moving.
Push down the clutch pedal, and
pause f or a f ew seconds bef ore
shif ting into reverse, or shif t into one
of the f orward gears f or a moment.
This stops the gears so they won’t
‘‘grind.’’
Manual T ransmission
Driving
141
Rapid slowing or speeding-up
can cause loss of control on
slippery surfaces. If you crash,
you can be injured.
Use extra care when driving on
slippery surfaces.

Normal acceleration15 mph (24 km/h)
25 mph (40 km/h)
40 mph (64 km/h)
48 mph (77 km/h)
Shif t up
1st to 2nd
2nd to 3rd 3rd to 4th4th to 5th If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone.
Bef ore downshif ting, make sure the
engine will not go into the
tachometer’s red zone.
Drive in the highest gear that lets
the engine run and accelerate
smoothly. This will give you good
f uel economy and ef f ective
emissions control. The f ollowing
shif t points are recommended: Recommended Shif t Points Engine Speed L imiter
Manual T ransmission
142

µ
These indicators on the instrument
panel show which position the shif t
lever is in. To shif t f rom any position, press
f irmly on the brake pedal, push the
release button, and pull the lever
toward you. You cannot shif t out of
Park when the ignition switch is in
the LOCK (0) or ACCESSORY (I)
position. This position mechani-
cally locks the transmission. Use
Park whenever you are turning of f or
starting the engine. To shif t out of
Park, you must press on the brake
pedal and have your f oot of f the
accelerator pedal.
If you have done all of the above and
still cannot move the lever out of
Park, see on
page .
The ‘‘D’’ indicator comes on f or a
f ew seconds when you turn the
ignition switch to the ON (II)
position. If it f lashes while driving (in
any shif t position), it indicates a
possible problem in the transmission.
Avoid rapid acceleration, and have
thetransmissioncheckedbyyour
dealer as soon as possible.
146
CONT INUED
To shift from:
PtoR
RtoN
NtoD Dto2 2to1
1to2
2toD
DtoN NtoR RtoP Do this:
Press the brake pedal, and
press the release button.
Press the release button.
Move the lever.Shif t L ever Position Indicators Shif ting
Park (P)Shif t L ock Release
Automatic Transmission
Driving
143
SHIFT LEVER

µ
µ
µ
To avoid transmission damage, come
to a complete stop bef ore shif ting
into Park. The shif t lever must be in
Park bef ore you can remove the key
from the ignition switch.
Use this position f or
your normal driving. The
transmission automatically selects a
suitable gear for the vehicle speed
and acceleration. You may notice the
transmission shif ting up at higher
speeds when the engine is cold. This
helps the engine warm up f aster.
Press the brake
pedal and press the release button to
shif t f rom Park to reverse. To shif t
f rom reverse to neutral, come to a
completestop,andthenshift. Your vehicle has a reverse lockout so
you cannot accidentally shif t to
reverse when the vehicle speed
exceeds 5 mph (8 km/h).
If you cannot shif t to reverse when
the vehicle is stopped, press the
brake pedal and slowly shift to
neutral. Then press the release
button, and shift to reverse.
If there is a problem in the reverse
lockout system, or your vehicle’s
battery is disconnected or goes dead,
you cannot shif t to reverse. (Ref er to
on page ).
Use neutral if you
need to restart a stalled engine, or if
it is necessary to stop brief ly with
the engine idling. Shif t to the Park
position if you need to leave your
vehicle for any reason. Press on the
brake pedal when you are moving
the shift lever from neutral to
another gear. 146
Automatic Transmission
Drive (D)
Reverse (R)
Shif t L ock Release
Neutral (N)
144

µµ
This position locks
the transmission in second gear. It
does not downshif t to f irst gear
when you come to a stop. This position locks the
transmission in f irst gear. By
upshif ting and downshif ting through
1, 2, and D, you can operate this
transmission much like a manual
transmission without a clutch pedal.
For more power when climbing.
To increase engine braking when
going down steep hills.
For starting out on a slippery
surf ace or in deep snow.
To help reduce wheel spin.
When driving downhill with a
trailer. If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone.
Overdrive (O/D) is on whenever you
turn the ignition to ON (II). Press
theO/Dswitchonthesideof the
shift lever to turn it off; the O/D
OFF indicator comes on.
Overdrive can be turned on or of f
only when the ignition switch is in
the ON (II) position. When overdrive is of f , the
transmission selects only the f irst
three gears. Use it to provide engine
braking when going down a steep hill,
or to keep the transmission f rom
cycling between third and f ourth
gear in stop-and-go driving.
Use second gear:
If you shif t into f irst when the
vehiclespeedisabove31mph(50
km/h), the transmission shif ts into
second gear f irst to avoid sudden
engine braking.
Automatic Transmission
Overdrive (O/D) Mode
Second (2)First (1)
Engine Speed L imiter
Driving
145

Do this if pushing on the brake pedal
and pulling the shif t lever does not
shif t the transmission out of Park:Set the parking brake.
Make sure the ignition switch is in
the LOCK (0) position.
To release the reverse lockout,
make sure the ignition switch is in
the ACCESSORY(I) position.
Put a cloth on the edge of the shif t
lock release slot cover next to the
shif t lever. Using a f lathead
screwdriver, caref ully pry on the
edge of the cover to remove it. Insert the flat-tip screwdriver into
the shif t lock release slot.
Remove the screwdriver f rom the
shif t lock release slot, then replace
thecover.Makesurethenotchon
the cover is on the right side.
Press the brake pedal and restart
the engine.
Push down on the screwdriver
while you press the release button
and move the shif t lever out of
Park to neutral.
To release the reverse lockout,
move the shift lever from neutral
to reverse, then to Park. If you need to use the shif t lock
release, it means your vehicle is
developing a problem. Have it
checked by your dealer.
1.
2.
3.
4.
5.6.
Automatic Transmission
Shif t L ock Release
146
COVER
SHIFT LOCK RELEASE SLOT

Always use the parking brake when
you park your vehicle. Make sure
the parking brake is set f irmly, or
your vehicle may roll if it is parked
on an incline.
If your vehicle has an automatic
transmission, set the parking brake
bef ore you put the transmission in
Park. This keeps the vehicle f rom
moving and putting pressure on the
parking mechanism in the
transmission.Make sure the windows are closed.
Turn of f the lights.
Place any packages, valuables, etc.
in the cargo area or take them
with you.
Lock the doors and the hatch with
the key.
Never park over dry leaves, tall
grass, or other f lammable
materials. The hot three way
catalytic converter could cause
these materials to catch on fire.If the vehicle is f acing uphill, turn
the front wheels away from the
curb. If you have a manual
transmission, put it in f irst gear.
Make sure the parking brake is
f ully released bef ore driving away.
Driving with the parking brake
partially set can overheat or
damage the rear brakes. If the vehicle is f acing downhill,
turn the front wheels toward the
curb. If you have a manual
transmission, put it in reverse gear.
Parking T ips
Parking
Driving
147

Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.
Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, and reduces their ef f ectiveness.
It also keeps your brake lights on all
the time, conf using drivers behind
you. Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The anti-lock
brake system (ABS) helps you retain
steering control when braking very
hard. Braking System Design
Braking System
148
