If this indicator comes on when the
ignition switch is turned to the ON
(II) position and the parking brake is
rele ased, it means there is a problem
in a circuit. Have your vehicle
checked by your dealer.
This indicator comes on when you
set the cruise control. See page
for information on operating the
cruise control.
The
left or right turn signal indicator
blinks when you signal a lane change
or turn. If the indicato rs do not blink
or they blink rapidly, it usu ally
means one of the turn signal bulbs is
burned out (see page ). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
When you press the hazard warning
button, both turn signal indicato rs
and all turn signals on the outside of
the vehicle flash.
This
indicator comes on for a few
seconds when you turn the ignition
switch to the ON (II) position. It will
then go off if you have inserted a
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink, and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch f rom the ON (II) position to
the ACCESSORY (I) or LOCK (0)
position. 76
133
200
Canadian models only
Instrument Panel Indicators
Turn Signal and Hazard Warning
Indicators
Cruise Control Indicator ‘‘Daytime Running
Lights’’ Indicator
Immobilizer System
Indicator
62

This shows how much fuel you have.
It may show slightly more or less
th an the actual amount. The needle
returns to the bottom after you turn
off the ignition. Your
vehicl e’s on board diagnostic
system will detect a loose or missing
fu el fill cap as an evaporative system
leak. The first time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the information display. If
the system still detects a leak in
your vehicle’s evaporative emissions
system, the malfunction indicator
lamp (MIL) comes on. If the fuel fill
cap was not already tightened, turn
the engine off, and check or
retighten the fuel fill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the select/reset knob.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f . 232
Gauges
Fuel Gauge
Check Fuel Cap Message
Inst rument s and Cont rols
67
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.

Check the seat adjustment (see
page ).
Check the adjustment of the
inside and outside mirrors (see
page ).
Check the steering wheel
ad justment (see page ). Make
sure the doors, hatch, and
tailgate are secu rely closed and
locked.
Fasten your seat belt. Check that
your passengers have fastened
their seat belts (see page ).
When you start the engine, check
the gauges and indicators in the
instrument panel (see page ).
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure. Check that the hood is f ully closed. Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.
Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.
Check that any items you may be
carrying are stored properly or
f astened down securely.
1.
2.
3.
4. 5.
6.
7.
8.
9.
10. 59
15
74
92
83
Preparing to Drive
Driving Guidelines
Driving
151

Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.The hydraulic system that operates
the brakes has two separate circuits.
Each circuit works diagonally across
the vehicle (the lef t-f ront brake is
connected with the right-rear brake,
etc.). If one circuit should develop a
problem, you will still have braking
at two wheels.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, and reduces their ef f ectiveness.
It also keeps your brake lights on all
the time, conf using drivers behind
you. Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The anti-lock
brake system (ABS) helps you retain
steering control when braking very
hard.
Check your brakes af ter driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious and alert in your driving.Braking System Design
Braking System
160

This section explains why it is
important to keep your vehicle well
maintained and how to follow basic
maintenance safety precautions.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer. This section also includes
instructions on how to read the
maintenance minder messages on
the information display, a
maintenance record, and instructions
for simple maintenance tasks you
may want to take care of yourself. ......................
Maintenance Saf ety .178
....................
Maintenance Minder .179
....................
Maintenance Record .186
..............................
Fluid Locations .188
........................
Adding Engine Oil .189
Changing the Engine Oil and
...........................................
Filter .190
..............................
Engine Coolant .192
....................
Windshield Washers .193
.......................
Transmission Fluid .194
Automatic Transmission .......................................
Fluid .194
...
Manual Transsmission Fluid .195
.................
Rear Dif f erential Fluid .196
................
Brake and Clutch Fluid .196
....................
Power Steering Fluid .197
............
Cleaning the Body Panels .197
.............................................
Lights .198
................
Cleaning the Seat Belts .205
.....................................
Floor Mats .205
..................
Dust and Pollen Filter .206
.................................
Wiper Blades .206
...........................................
Wheels .208
...............................................
Tires .208
...................
Checking the Battery .214
.............................
Vehicle Storage .215
261
Maintenance
Maint enance
177

̵
µµ
µ
µ
µ
However,
service at a dealer is not
mandato ry to keep your warranties
in effect. Maintenance may be done
by any qualified service facility or
person who is skilled in this type of
automotive service. Make sure to
have the service facility or person
reset the display as previously
describe d. Keep all receipts as proof
of completion, and have the person
who does the work fill out the
maintenance record. Check your
warranty booklet for more
info rmation.
We recommend using Honda parts
and fluids whenever you have
maintenance done. These are
manufactu red to the same high
quality standards as the original
components, so you can be confident
of their perfo rman ce and durability. U.S.
Vehicles:
According to state and federal
regulations, failure to perform
maintenance on the items marked
with will not void your emissions
warranties. However, all
maintenance services should be
pe rformed in accordance with the
intervals indicated by the
information display.
Youshouldcheckthefollowing
items at the specified interval s. If
you are unsure of how to perform
any check, turn to the appropriate
page listed. Engine
oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you fill the fuel tank. See page .
Automatic transmission Check
the fluid level monthly. See page
.
Brakes Check the fluid level
monthly. See page .
Tires Check the tire pressure
monthly. Examine the tread for
wear and foreign objects. See page
.
Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and licen se plate lights monthly.
See page . 198
209
196
141
141
194
Maintenance Minder
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Owner’s Maintenance Checks
184

Diagnosing why the engine won’t
start falls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position: Wh
en you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all. Turn
the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the fuses. If the fuses
areOK,thereisprobably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualified technician to
determine the problem. See
on page .
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of the
battery and terminal connections
(see page ). You can then try
jump starting the vehicle from a
booster battery (see page ).
You
hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
faster than normal, but the engine
does not start up and run.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged (see on page ).
Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, the shif t
lever must be in Park or neutral.
Check these things:
227 227
214 239
CONT INUED
Nothing Happens or the Starter
Motor Operates Very Slowly
Emergency T owing
Jump Starting
If theEngineWon’tStart
T aking Care of t he Unexpect ed
225

Let the vehicle sit for a minute.
Op en the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipsti ck (see page ). If
the charging system
indicator comes on brightly
when the engine is running, the
battery is not being charged.
Immediately turn off all electri cal
accessories. Try not to use other
electrically operated controls such as
the power windows. Keep the engine
running; starting the engine will
discharge the battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Safely
pull off the road, and shut
off the engine. Turn on the hazard
warning lights.
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn off the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(see on page
).
This indicator should never
come on when the engine is
running. If it starts f lashing or stays
on, the oil pressure has dropped very
low or lost pressure. Serious engine
damage is possible, and you should
take immediate action. 1.
2.
4. 3.
141
189
239
L ow Oil Pressure Indicator
Charging System Indicator
Emergency T owing
L ow Oil Pressure Indicator, Charging System Indicator
T aking Care of t he Unexpect ed
231
Running the engine with low oil
pressure can cause serious mechanical
damage almost immediately. Turn of f
the engine as soon as you can saf ely get
the vehicle stopped.

Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all oth er
accessories are off.
If
something electrical in your
vehicle stops working, check for a
blown fuse first. Determine from the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
The interior f use box is underneath
the steering column. To remove the
f use box lid, turn the knobs
counterclockwise and pull the lid out
of its hinges.
The vehicle’s f uses are located in
two f use boxes. The under-hood f use
box is located in the engine
compartment on the driver’s side. To
open it, push the tabs as shown.
Remove the cover f rom the f use
box.
1.
2. 237 238
Checking and Replacing Fuses
Fuses
234
TAB
UNDER-HOOD
INTERIOR
KNOBS

CONT INUED
....................................
Accessories .143
ACCESSORY (Ignition Key
.......................................
Position) .79
..............
Accessory Power Sockets .97
....................
Additives, Engine Oil .190
.........
Advice f or Pregnant Women .18
.............................
Airbag (SRS) . 11, 24
...
Airbags, Additional Information .24
...
Additional Safety Precautions .36
.............................
Airbag Service .35
How the Passenger Airbag Of f
......................
Indicator Works .34
How the Side Airbag Of f ......................
Indicator Works .34
..
How the SRS Indicator Works .33
How Your Front Airbags
.........................................
Work .27
...
How Your Side Airbags Work .31
How Your Side Curtain Airbags
.........................................
Work .32
........................
SRS Components .24
..............
Air Conditioning System .102
.........................................
Usage .103
.......................
Air Pressure, Tires .209 ......................................
Alignment .245
......................................
Antif reeze .192
Anti-lock Brakes (ABS)
...............................
Indicator . 61, 162
...................................
Operation .161
..............
Anti-thef t, Audio System . 129
.
Anti-thef t Steering Column Lock . 79
......................
Armrests, Front Seat .84
................................
Audio System .107
...
Automatic Seat Belt Tensioners . 22
.............
Automatic Speed Control . 133
..............
Automatic Transmission . 155
..........................
Capacity, Fluid .244
...............
Checking Fluid Level . 194
.......................................
Shif ting .155
.
Shif t Lever Position Indicator . 155
................
Shif t Lever Positions . 155
....................
Shif t Lock Release . 158
......................
Auxiliary Input Jack .125
Battery Charging System ...........................
Indicator . 60, 231
............................
Jump Starting .227 ..............................
Maintenance .214
............................
Specif ications .245
..............................
Bef ore Driving .137
..................................
Belts, Seat . 10, 20
...........................
Beverage Holders .97
...................................
Body Panels .197
..................................
Booster Seats .52
Brakes ...........
Anti-lock System (ABS) . 161
.............
Break-in, New Linings . 138
....................
Bulb Replacement . 203
...........................................
Fluid .196
.........................................
Parking .93
.................
System Indicator . 60, 233
........................
Wear Indicators .161
.............................
Braking System .160
.................
Break-in, New Vehicle . 138
..
Brightness Control, Instruments . 72
........................
Brights, Headlights .72
Index
A
B
INDEX
I
