engine coolant HONDA ELEMENT 2007 1.G Owners Manual

The information display in the
instrument panel shows you the
engine oil life and maintenance
service items when the ignition
switch is in the ON (II) position. This
information helps to keep you aware
of the periodic maintenance your
vehicle needs for continued trouble-
free driving. Refer to page for
more information.
This
shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. Turn to
page f or instructions and
precautions on checking the engine’s
cooling system. 229
179
Gauges
Maintenance Minder
Temperature Gauge
68

Air flows from the defroster
vents at the base of the windshield. The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes before you
feel warm air coming from the
system.
When
you select or ,
the system automatically switches to
fresh air mode and turns on the A/C.
The A/C indicator does not come on.
Select and fresh air mode.
Set the fan to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
The flow-through ventilation system
draws in outside air, circulates it
through the interior, then discharg es
it through vents near the tailgate. Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page ). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
Set the temperature to the lower
limit.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
Turn on the A/C by pressing the
button. The indicator in the button
comesonwhenafanspeedis
selected.
Set the temperature to the lower
limit.Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed.
Set the mode control dial to MAX
A/C.
The system automatically turns on
the A/C, selects and
switches to recirculation mode.
Set the temperature to the lower
limit.
Set the f an to the desired speed.
you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in f resh air mode.
1.
2.
3.
4. 1.
2.
3.
1.
2.
3.
68
1.
2. 3.
4.
5.
To cool the interior with MAX A/C:
If the interior is very warm,
Vents, Heating, and A/C
Using the A/C Using the Heater
Ventilation
(f resh air mode)
104

Bef ore you begin driving your
vehicle, you should know what
gasoline to use and how to check the
levels of important f luids. You also
need to know how to properly store
luggage or packages. The
inf ormation in this section will help
you. If you plan to add any
accessories to your vehicle, please
read the information in this section
first..............................
Break-in Period .138
.................
Fuel Recommendation .138
.........
Service Station Procedures .139
....................................
Ref ueling .139
Opening and Closing the
.......................................
Hood .140
...................................
Oil Check .141
.............
Engine Coolant Check .141
...............................
Fuel Economy .142
...
Accessories and Modif ications .143
.............................
Carrying Cargo .145
Bef ore Driving
Bef ore Driving
137

Wait a few minutes after turning the
engine off before you check the oil.
Remove the dipstick (orange tab).
Wipe the dipstick with a clean
cloth or paper towel.
Insert it all the way back in its tube. Remove
the dipstick again, and
check the level. It should be
between the upper and lower
marks. Look
at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page for
info rmation on adding the proper
coolan t.
Refer to
on page for information
about checking other items on your
vehicle.
If
it is near or below the lower mark,
see on page .
1.
2.
3. 4.
189 192
184
Oil Check
Engine Coolant Check
A dding
Engine Coolant
Owner’s Maintenance
Checks
A dding Engine Oil
Service Station Procedures
Bef ore Driving
141
DIPSTICK
UPPER MARKLOWER MARK RESERVE TANK
MAX
MIN

This section explains why it is
important to keep your vehicle well
maintained and how to follow basic
maintenance safety precautions.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer. This section also includes
instructions on how to read the
maintenance minder messages on
the information display, a
maintenance record, and instructions
for simple maintenance tasks you
may want to take care of yourself. ......................
Maintenance Saf ety .178
....................
Maintenance Minder .179
....................
Maintenance Record .186
..............................
Fluid Locations .188
........................
Adding Engine Oil .189
Changing the Engine Oil and
...........................................
Filter .190
..............................
Engine Coolant .192
....................
Windshield Washers .193
.......................
Transmission Fluid .194
Automatic Transmission .......................................
Fluid .194
...
Manual Transsmission Fluid .195
.................
Rear Dif f erential Fluid .196
................
Brake and Clutch Fluid .196
....................
Power Steering Fluid .197
............
Cleaning the Body Panels .197
.............................................
Lights .198
................
Cleaning the Seat Belts .205
.....................................
Floor Mats .205
..................
Dust and Pollen Filter .206
.................................
Wiper Blades .206
...........................................
Wheels .208
...............................................
Tires .208
...................
Checking the Battery .214
.............................
Vehicle Storage .215
261
Maintenance
Maint enance
177

̵
µµ
µ
µ
µ
However,
service at a dealer is not
mandato ry to keep your warranties
in effect. Maintenance may be done
by any qualified service facility or
person who is skilled in this type of
automotive service. Make sure to
have the service facility or person
reset the display as previously
describe d. Keep all receipts as proof
of completion, and have the person
who does the work fill out the
maintenance record. Check your
warranty booklet for more
info rmation.
We recommend using Honda parts
and fluids whenever you have
maintenance done. These are
manufactu red to the same high
quality standards as the original
components, so you can be confident
of their perfo rman ce and durability. U.S.
Vehicles:
According to state and federal
regulations, failure to perform
maintenance on the items marked
with will not void your emissions
warranties. However, all
maintenance services should be
pe rformed in accordance with the
intervals indicated by the
information display.
Youshouldcheckthefollowing
items at the specified interval s. If
you are unsure of how to perform
any check, turn to the appropriate
page listed. Engine
oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you fill the fuel tank. See page .
Automatic transmission Check
the fluid level monthly. See page
.
Brakes Check the fluid level
monthly. See page .
Tires Check the tire pressure
monthly. Examine the tread for
wear and foreign objects. See page
.
Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and licen se plate lights monthly.
See page . 198
209
196
141
141
194
Maintenance Minder
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Owner’s Maintenance Checks
184

Î
Î
Ì Ì
Î
Ì
ÎÎ
Maintenance Minder
185
: See information on maintenance and emissions warranty on page .
Inspect idle speed every 160,000 miles (256,000 km).
Adjust the valves during services A, B, 1, 2, or 3 only if they are noisy.
If the message ‘‘SERVICE’’ does not appear more than 12 months after the
display is reset, change the engine oil every year.
Independent of the maintenance items in the information display, replace
the brake fluid every 3 years.
NOTE: 1:
2:
186
Maintenance Main Items
Replace engine oil
Replace engine oil and oil filter
Inspect front and rear brakes
Check parking brake adjustment
Inspect these items: Tie rod ends, steering gear box, and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluids
Exhaust system
Fuel lines and connections Maintenance Sub Items
Rotate tires
Replace air cleaner element If you drive in dusty conditions, replace
every 15,000 miles (24,000 km).
Replace dust and pollen filter If you drive primarily in urban areas that have high
concentrations of soot in the air from industry and
from diesel-powered vehicles, replace every 15,000
miles (24,000 km).
Inspect drive belt
Replace transmission fluid Driving in mountainous areas at very low vehicle
speeds results in higher transmission temperatures.
This requires transmission fluid changes more
frequently than recommended by the maintenance
minder. If you regularly drive your vehicle under
these conditions, have the transmission fluid
changed at 60,000 miles (100,000 km), then every
30,000 miles (48,000 km) .
Replace spark plugs
Inspect valve clearance
Replace engine coolant
Replace rear differential fluid (4WD models only)
A
B
Symbol
Symbol
1
2
3
4
5
Automatic transmission
61
1
2
Maintenance Minder

Fluid Locations
188
RADIATOR CAP
ENGINE
COOLANT
RESERVOIR WASHER FLUID
(Blue cap)
ENGINE OIL
FILL CAP
POWER
STEERING FLUID
(Red cap) ENGINE OIL
DIPSTICK
(Orange tab)
BRAKE FLUID
(Gray cap)
CLUTCH FLUID
(Manual
Transmission only)
(Gray cap)
AUTOMATIC
TRANSMISSION
FLUID DIPSTICK
(Yellow loop)

If Honda antif reeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporaryreplacement.Makesureit
is a high-quality coolant
recommended f or aluminum engines.
Continued use of any non-Honda
coolant can result in corrosion,
causing the cooling system to
malf unction or f ail. Have the cooling
system f lushed and ref illed with
Honda antif reeze/coolant as soon as
possible.If the reserve tank is completely
empty, you should also check the
coolant level in the radiator.
Always use Honda Long-lif e Anti-
f reeze/Coolant Type 2. This coolant
is pre-mixed with 50 percent
antif reeze and 50 percent water.
Never add straight antifreeze or
plain water.
If the coolant level in the reserve
tank is at or below the MIN line, add
coolant to bring it up to the MAX line.
Inspect the cooling system f or leaks. A dding Engine Coolant
Engine Coolant
192
RESERVE TANK
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.

The coolant level should be up to
the base of the filler neck. Add
coolant if it is low.
Pourthecoolantslowlyand
carefully so you do not spill any.
Clean up any spill imme diately; it
could damage componen ts in the
engine compartm ent.
Put the radiator cap back on and
tighten it.
Pour coolant into the reserve tank.
Fill it to halfway between the MAX
and MIN marks. Put the cap back
on the reserve tank.
Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components. Fill
the reservoir with a good-quality
windshield washer fluid. This
increases the cleaning capability and
prevents freezing in cold weather.
Check
the fluid level in the
windshield washer reservoir at least
monthly during normal use.
The low washer
level indicator comes on when the
level is low (see page ).
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition them.
Remove the radiator cap by
pushing down and turning
counterclockwise. Make sure the engine and radiator
are cool.
Relieve any pressure in the cooling
system by turning the radiator cap
counterclockwise, without
pressing down. 4.
5.
2. 1.
3. 6.
63
On Canadian models:
Windshield Washers
Engine Coolant, Windshield Washers
Maint enance
193
RADIATOR CAP
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
