snow chains HONDA ELEMENT 2007 1.G Owners Manual

´Because your vehicle has limited tire
clearance, Honda strongly
recommends using the chains listed
below, made by Security Chain
Company (SCC).
Because your vehicle has limited tire
clearance, use only SAE Class ‘‘S’’
cable-type traction devices, with
rubber chain tensioners, on the f ront
tires. Use traction devices only when
required by driving conditions or
local laws. Make sure they are the
correct size f or your tires. Metal link-
type ‘‘chains’’ should not be used.
When installing cables, f ollow the
manuf acturer’s instructions, and
mount them as tight as you can.
Make sure they are not contacting
the brake lines or suspension. Drive
slowly with them installed. If you
hear them coming into contact with
the body or chassis, stop and
investigate. Remove them as soon as
youbegindrivingonclearedroads.
Tires marked ‘‘M S’’ or ‘‘All
Season’’ on the sidewall have an all-
weather tread design suitable for
most winter driving conditions.
For the best perf ormance in snowy
or icy conditions, you should install
snow tires or tire chains. They may
be required by local laws under
certain conditions.
If you mount snow tires on your
vehicle, make sure they are radial
tires of the same size and load range
as original tires. Mount snow tires on
all f our wheels. The traction
provided by snow tires on dry roads
maybelowerthanyouroriginaltires.
Check with the tire dealer f or
maximum speed recommendations.
Cable-type:SCC Super Z6 SZ 139
SC model
On all models except SCTire Chains
Winter Driving
Snow T ires
Tires
Maint enance
213
Traction devices that are the wrong
size or improperly installed can
damage your vehicle’s brake lines,
suspension, body, and wheels. Stop
driving if they are hitting any part of
the vehicle.

Check the inflation pressure of the
compact spare tire every time you
check the other tires. It should be
inflated to: Follow
these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surfaces. Use greater caution
while driving.
Use
the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Replace the tire when you can see
the tread wear indica tor bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed for mounting a regular tire.
Do
not mount snow chains on the
compact spare tire.
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
Turn of f the VSA system (see
page ). Driving with the
compact spare tire may activate
the VSA system. 166
Compact Spare Tire
218
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)

ÎÎ
CONT INUED
Tailgete............................................
Locks .82
..............................
Open Monitor .63
..........
Taillights, Changing Bulbs .203
.
Taking Care of the Unexpected .217
Technical Descriptions
......
DOT Tire Quality Grading .246
.....
Emissions Control Systems .251
..........
State Emissions Testing .254
Three Way Catalytic
...............................
Converter .253
.....................
Tensioners, Seat Belt .22
.......................
Temperature Gauge .68
..............
Tether Anchorage Points .50 Tire Pressure Monitoring System
..................................
(TPMS) .163
.......................................
Indicator .65
................
Thef t Protection, Radio .129
..
Three Way Catalytic Converter .253
..................
Tilt the Steering Wheel .74
..........................
Time, Setting the .130
....................................
Tire Chains .213
.........
Tire, How to Change a Flat .219
...........................
Tire Inf ormation .246
.................................
Tire Labeling .248
...............................................
Tires .208
..............................
Air Pressure .209
.........................
Checking Wear .210
..........................
Compact Spare .218
....
DOT Tire Quality Grading .246
......................................
Inf lation .208
..................................
Inspection .210
.....
Low Pressure Indicator . 64, 163
..............................
Maintenance .211
...................................
Replacing .211
......................................
Rotating .211
...........................................
Snow .213
............................
Specif ications .245
................................
Tire Chains .213
...................
VSA and Tire Sizes .166 ...................
Tools, Tire Changing .219
Towing
.....................................
A Trailer .167
................................
Emergency .239
...
Equipment And Accessories .169
.............................
Weight Limit .167
.....
Trailer, Driving Saf ely With a .171
.............................
Trailer Loading .168
...........................
Traction Devices .213
Transmission
Checking Fluid Level, ..............................
Automatic .194
Checking Fluid Level, ...................................
Manual .195
..................
Fluid Selection . 194, 195
..............
Identif ication Number .243
.............
Shif ting the Automatic . 155
..................
Shif ting the Manual . 153
......................
Transmitter, Remote .77
...................................
Treadwear .246
.......................................
Trip Meter .66
....................................
Turn Signals .71
...................
Stereo Sound System . 107
....................
Storing Your Vehicle .215
Supplemental Restraint ................................
System . 11, 24
......................................
Servicing .35
.........................
SRS Indicator . 33, 61
...................
System Components . 24
..................................
Synthetic Oil .190
Index
T
VIII
Turn Signal and Hazard
Warning Indicators .................. 62
