Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low, the sensor in that
tire immediately sends a signal that
causes the low tire pressure
indicator to come on.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
If you cannot make the low tire
values, have your dealer check theBecausetirepressurevariesby
temperature and other conditions,
the low tire pressure indicator may
come on unexpectedly.
For example, if you check and f ill
your tires in a warm area, then drive
in extremely cold weather, the tire
pressure will be lower than
measured and could be underinflated
and cause the low tire pressure
check and adjust your tire pressure
maybecomeoverinflated.However,
Refer to page for tire inflation
guidelines.
thetirepressuresmonthly.
222
212
CONT INUED
Tire Pressure Monitoring System (TPMS)

Indicator
Driving
169
\f—\f—y
\fy
(+\fy\f
y

as soon as possible, and inflate them
systemassoonaspossible.
incoolerconditions,anddriveinto
extremelyhotconditions,thetireLowTirePressure
Whenthelowtirepressure indicator
is on, one or more of your tires is
to theproperpressureasindicatedon
signif icantly underinf lated. You
thevehicle’stireinformationplacard.
should stop and check your tires
pressure indicator go out after
inf lating the tires to the specif ied
Under-inflationalsoreducesfuel
indicatortocomeon.Or,ifyou
thelowtirepressure indicator will
not come on if the tires are
monitored,youmustmanuallycheck
overinf lated.
Althoughyourtirepressureis
2008 Element

CONT INUED
The VSA system indicator (see page) comes on and stays on when
there is a problem with the VSA
system. The VSA activation indicator
will also come on.
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on or comes
back on while driving, have the VSA
system inspected by your dealer.
If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehicle as
soon as possible.
The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output and
by selectively applying the brakes. When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.
When VSA activates, you will see the
VSA activation indicator blink (see
page ).
64
64
Changes or modif ications not expressly approved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.Vehicle Stability Assist
(VSA ) System Indicator
VSA A ctivation Indicator
Driving
171
——y
y
(+y
y
Tire Pressure Monitoring System (TPMS), Vehicle Stability A ssist (VSA) System
2008 Element

VSA is turned on every time you
start the engine, even if you turned it
off the last time you drove the
vehicle.
Driving with varying tire or wheel
sizes may cause the VSA to
malf unction. When replacing tires,
make sure they are the same size
and type as your original tires (see
page ).
If you install winter tires, make sure
they are the same size as those that
were originally supplied with your
vehicle. Exercise the same caution
during winter driving as you would if
your vehicle was not equipped with
VSA.
This button is under the driver’s side
vent. Press it to turn the VSA system
on or of f .
When VSA is off, the VSA activation
indicator comes on as a reminder.
Pressing the switch again turns the
system back on.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
In certain unusual conditions when
your vehicle gets stuck in shallow
mud or f resh snow, it may be easier
to free it with the VSA temporarily
switched of f . When the VSA system
is of f , the traction control system is
alsooff.Youshouldonlyattemptto
f ree your vehicle with the VSA of f if
you are not able to f ree it when the
VSA is on.
Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off.
213
VSA and Tire Sizes
VSA Of f Switch
Vehicle Stability Assist (VSA) System
172
VSA OFF SWITCH
\f—\f—y
y
(+\fy\f
y
2008 Element

Your vehicle has been designed
primarily to carry passengers and
their cargo. You can also use it to
tow a trailer if you caref ully observe
the load limits, use the proper
equipment, and f ollow the guidelines
in this section.The weight that
the tongue of a f ully-loaded trailer
puts on the hitch should be
approximately 10 % of the total
trailer weight. Too much tongue
load reduces front-tire traction and
steering control. Too little tongue
load can make the trailer unstable
and cause it to sway.
Be sure to read the
on page
if you plan to tow of f paved
surf aces.
The
maximum allowable weight of the
trailer and everything in or on it
must not exceed 1,500 lbs (680 kg).
Towing a trailer that is too heavy
can seriously af f ect your vehicle’s
handling and perf ormance. It can
also damage the engine and
drivetrain.
179
Driving Of f -
Highway Guidelines section
CONT INUED
Load Limits
Tongue Load:
T otal T railer Weight:
Towing a Trailer
Driving
173
Exceeding any load limit or
improperly loading your vehicle
and trailer can cause a crash in
which you can be seriously hurt
or killed.
Check the loading of your
vehicle and trailer carefully
beforestartingtodrive.
\f—\f—y
\fy
(+\fy\f
y
2008 Element

Maketurnsmoreslowlyandwider
than normal. The trailer tracks a
smaller arc than your vehicle, and it
canhitorrunoversomethingthe
vehicle misses. Allow more time and
distance f or braking. Do not brake or
turn suddenly as this could cause the
trailer to jackknif e or turn over.
When climbing hills, closely watch
your temperature gauge. If it nears
the red (Hot) mark, turn the air
conditioning of f , reduce speed and, if
necessary, pull to the side of the
road to let the engine cool.If you must stop when f acing uphill,
use the f oot brake or parking brake.
Do not try to hold the vehicle in
placebypressingontheaccelerator,
as this can cause the automatic
transmission to overheat.
Always drive slowly and have
someone guide you when backing up.
Grip the of the steering
wheel; then turn the wheel to the lef t
to get the trailer to move to the lef t,
andturnthewheelrighttomovethe
trailer to the right.
Follow all normal precautions when
parking, including f irmly setting the
parking brake and putting the
transmission in Park (automatic) or
in 1st or reverse (manual). Also,
place wheel chocks at each of the
trailer’s tires.
If the automatic transmission shif ts
f requently while going up a hill, shif t
to D . When driving down hills, reduce
your speed, and shif t down to second
gear. Do not ‘‘ride’’ the brakes, and
remember, it will take longer to slow
downandstopwhentowingatrailer.
Crosswinds and air turbulence
caused by passing trucks can disrupt
your steering and cause the trailer to
sway. When being passed by a large
vehicle, keep a constant speed, and
steer straight ahead. Do not try to
make quick steering or braking
corrections.
bottom
3
Towing a Trailer
Making T urns and Braking
Driving on Hills Backing Up
Parking
Handling Crosswinds and Buf f et ing
178
\f—\f—y
y
(+\fy\f
y
2008 Element

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.
This section also includes
instructions on how to read the
maintenance minder messages on
the information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .......................
Maintenance Saf ety .184
....................
Maintenance Minder .185
..............................
Fluid Locations .192
........................
Adding Engine Oil .193
Changing the Engine Oil and
...........................................
Filter .194
..............................
Engine Coolant .196
....................
Windshield Washers .197
.......................
Transmission Fluid .198
Automatic Transmission .......................................
Fluid .198
...
Manual Transsmission Fluid .199
.................
Rear Dif f erential Fluid .200
................
Brake and Clutch Fluid .200
....................
Power Steering Fluid .201
............
Cleaning the Body Panels .201
.............................................
Lights .202
................
Cleaning the Seat Belts .209
.....................................
Floor Mats .209
..................
Dust and Pollen Filter .210
.................................
Wiper Blades .210
...........................................
Wheels .212
...............................................
Tires .212
...................
Checking the Battery .218
.............................
Vehicle Storage .219
265
Maintenance
Maint enance
183
\f—\f—y
\f\f
y
(+\fy\f
y
2008 Element

To eliminate potential hazards, read
the instructions bef ore you begin,
and make sure you have the tools
and skills required.To clean parts, use a commercially
available degreaser or parts
cleaner, not gasoline.
To reduce the possibility of f ire or
explosion, keep cigarettes, sparks,
and flames away from the battery
and all f uel-related parts.
Make sure your vehicle is parked
on level ground, the parking brake
is set, and the engine is of f .
All service items not detailed in this
section should be perf ormed by a
certif ied technician or other qualif ied
mechanic.
Wear eye protection and
protective clothing when working
with the battery or compressed air.
Let the
engine and exhaust system cool
down bef ore touching any parts.
Do
not run the engine unless
instructed to do so.
Some of the most important saf ety
precautions are given here. However,
we cannot warn you of every
conceivable hazard that can arise in
perf orming maintenance. Only you
can decide whether or not you
should perf orm a given task.
Be sure there is
adequate ventilation whenever you
operate the engine.
Maintenance Saf ety
Important Saf ety Precautions Burns f rom hot parts.
Injury f rom moving parts.
Carbon Monoxide poison f rom
engine exhaust.
Potential Vehicle Hazards
184
Failure to properly follow
maintenance instructions and
precautions can cause you to
be seriously hurt or killed.
Always follow the procedures
and precautions in this owner’s
manual.
Improperly maintaining this
vehicle, or failing to correct a
problem before driving can
cause a crash in which you can
be seriously hurt or killed.
Always follow the inspection
and maintenance
recommendations and
schedules in this owner’s
manual.
\f—\f—y
\f\fy
(+\fy\f
y
2008 Element

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
CONT INUED
Calculated Engine Oil Lif e (%)
100 % 91 % 90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %10 % 6 % 5% 1% 0% Displayed
Engine Oil Lif e (%) 100 %90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %5%
0%
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e and displays it as a
percentage. The remaining engine oil lif e is
shownonthedisplayaccordingto
this table:
To see the current engine oil lif e,
turn the ignition switch to the ON
(II) position, then press and release
the select/reset knob repeatedly
until the engine oil lif e indicator
appears (see page ).
Your vehicle displays engine oil lif e
and maintenance service items on
the inf ormation display to show you
when you should have your dealer do
engine oil replacement and indicated
maintenance service.
68
Maintenance Minder
Engine Oil L if e Display
Maint enance
185
ENGINE OIL LIFE INDICATORSELECT/RESET KNOB
\f—\f—y
\f\fy
(+\fy\f
\fy
2008 Element

When the remaining engine oil lif e is
5 to 1 percent, you will see a
‘‘SERVICE’’ message along with the
same maintenance item code(s),
everytimeyouturntheignition
switch to the ON (II) position.
The 15 and 10 percent oil lif e
indicator reminds you that the time
is coming soon to take your vehicle
in f or the required maintenance.
If the remaining engine oil lif e is 15
to 6 percent, you will see the engine
oil lif e indicator every time you turn
the ignition switch to the ON (II)
position. The maintenance minder
indicator will also come on, and the
maintenance item code(s) for other
scheduled maintenance items
needing service will be displayed
above the ‘‘OIL LIFE’’ message.
Maintenance Minder
186
MAINTENANCE
ITEM CODE(S)
ENGINE OIL LIFE
INDICATOR
MAINTENANCE MINDER INDICATOR
\f—\f—y
\f\fy
(+\fy\f

y
2008 Element

If you do not perf orm the indicated
maintenance, negative mileage is
displayed and begins to blink af ter
the vehicle has been driven 10 miles
(10 km) or more.
When the remaining engine oil lif e is
0 percent, the engine oil lif e indicator
will blink. The display comes on
everytimeyouturntheignition
switch to the ON (II) position. The
maintenance minder indicator
( ) also comes on and remains
on in the instrument panel. When
you see this message, immediately
have the indicated maintenance done
by your dealer.
The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page ).
You can switch the information
display f rom the engine oil lif e
display to the odometer or the trip
meter. Press and release the select/
reset knob on the instrument panel.
Whentheengineoillifeis15to1
percent, the maintenance minder
indicator ( ) comes on every
time you turn the ignition switch to
the ON (II) position, then it goes out
if you switch the inf ormation display.
When you see this message, have
the indicated maintenance
perf ormed by your dealer as soon as
possible.
Negative mileage means your
vehicle has passed the maintenance
required point.
Immediately have the indicated
maintenance done by your dealer.
188
CONT INUED
Maintenance Minder
Maint enance
187
NEGATIVE MILEAGE
\f—\f—y
\f\f
y
(+\fy\f
y
2008 Element
