Indicators/InfoDisplay/TPMS
Instrument Panel Indicators
Indicators briefly appear with each engine start. Red and amber indicators are most critical. Blue and green indicators are used for general information.
DRL
ABS (anti-lock brake system)
DRL (daytime running lights)
Malfunction lamp (check engine light)
TPMS (tire pressure monitoring system)
VSA (vehicle stability assist)
Malfunction Indicators:If an indicator remains on, there may be a problem; see your dealer.
Charging system
Low oil pressure
SRS (supplemental restraint system)
Low brake fluid
10 Element TRG_Inside Front:Inside Cvr 8/24/2009 2:46 PM Page 1
2010 Element

Information DisplayConsists of several displays that provide you with useful information.
When you start the engine, the information display shows your last active selection from theprevious drive cycle.
To toggle between the different displays, pressand releasethe select/reset knob repeatedly.
Information DisplaysAccessing the Information Display
Oil life, Outside temperature*
Trip B, Outsidetemperature*
Trip A, Outsidetemperature*
Odometer, Outsidetemperature*
* if equipped
