The vehicle's fuses are located in two
fuse boxes. The under-hood fuse box
is located in the engine compartment
on the driver's side. To open it, push
the tabs as shown.
The interior fuse box is underneath
the steering column. To remove the
fuse box lid, turn the knobs
clockwise and pull the lid out of its
hinges.Checking and Replacing Fuses
If something electrical in your
vehicle stops working, check for a
blown fuse first. Determine from the
chart on pages 242 and 243, or the
diagram on the fuse box lid, which
fuse or fuses control that device.
Check those fuses first, but check all
the fuses before deciding that a
blown fuse is the cause. Replace any
blown fuses, and check if the device
works.
1. Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are off.
2. Remove the cover from the fuse box.
UNDER-HOOD
TAB
INTERIOR
KNOBS
CONTINUED
Fuses
239
Taking Care of the Unexpected
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

The diagrams in this section give you
the dimensions and capacities of
your vehicle and the locations of the
identification numbers. It also
includes information you should
know about your vehicle's tires and
emissions control systems.Identification Numbers
...............
248
Specifications
..............................
250
DOT Tire Quality Grading (U.S. Vehicles)
.............................
253
Uniform Tire Quality Grading
...............................
253
Treadwear
...............................
253
Traction
..................................
253
Temperature
...........................
254
Tire Labeling
..............................
255
Tire Pressure Monitoring System
(TPMS) －Required Federal
Explanation
.........................
256
Emissions Controls
.....................
258
The Clean Air Act
....................
258
Crankcase Emissions Control System
................................
258
Evaporative Emissions Control
System
................................
258
Onboard Refueling Vapor
Recovery
.............................
258
Exhaust Emissions
Controls
..............................
259 Three Way Catalytic
Converter
................................
260
Emissions Testing
.......................
261
Technical Information
247
Technical Information
