Page 6 of 258
Î
Î
ÎÎ
Î
Î
Î
Î
Î
To
use the horn, press the center pad of the steering wheel.
If equipped.
1:
2:
Your
Vehicle at a Glance
4
REAR WINDOW
DEFOGGER WINDSHIELD
WIPERS/WASHERS
HAZARD
WARNING
BUTTON
PASSENGER AIRBAG
OFF INDICATOR
INSTRUMENT
PANEL
BRIGHTNESS
HORN
STEERING WHEEL ADJUSTMENT
HOOD
RELEASE HANDLE
ACCESSORY POWER
SOCKET
CRUISE CONTROL
BUTTONS
(P.156)
(P.71) (P.94) MIRROR CONTROLS
(P.134)
(P.74) (P.127)(P.98)
(P.31)
(P.73)
(P.70)
(P.73)
(P.156)
(P.73)
PADDLE
SHIFTER
(DOWNSHIFT) PADDLE
SHIFTER
(UPSHIFT)
AUXILIARY INPUT JACK
(P.123)
HEADLIGHTS/TURN
SIGNAL/
FOG LIGHTS
1
2
2
2
2
2
2
Page 17 of 258
CONTINUED
After all occupants have adjusted
their seats and put on seat belts, it is
very important that they continue to
sit upright, well back in their seats,
with their feet on the floor, until the
vehicle is parked and the engine is
off.
Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both feet up, the
chance of injury during a crash is
greatly increased.
This could cause
very serious injuries in a crash.
See page f or additional
inf ormation about your seat belts
and how to take care of them. Using a seat
belt that is not working properly can
result in serious injury or death.
Have your dealer check the belt as
soon as possible. If a seat belt does not seem to work
properly, it may not protect the
occupant in a crash.
The front seats have adjustable seat
belt anchors. To adjust the height of
an anchor, squeeze the two release
buttons, and slide the anchor up or
down as needed (it has f our
positions). 18
Protecting A dults and Teens
Maintain a Proper Sitting
Position
6.Never place t he shoulder port ion of a
lap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
Driver and Passenger Saf ety
15
RELEASE BUTTONS
Page 71 of 258
Î
Î
ÎÎ
Î
Î
Î
Î
Î
To use the horn, press the center pad of the steering wheel.
If equipped.
1:
2:
Controls
Near the Steering Wheel
Instru me ntsand Cont ro ls
69
HAZARD WARNING BUTTON
PASSENGER AIRBAG OFF
INDICATOR
INSTRUMENT
PANEL
BRIGHTNESS
HORN
CRUISE CONTROL
BUTTONS REAR
WINDOW
DEFOGGER WINDSHIELD
WIPERS/WASHERS
ACCESSORY
POWER SOCKET
HOOD
RELEASE
HANDLE
STEERING WHEEL
ADJUSTMENT
(P.156) PADDLE
SHIFTER (DOWNSHIFT) PADDLE
SHIFTER (UPSHIFT)
HEADLIGHTS/TURN
SIGNAL/FOG LIGHTS
(P.71)
(P.94)MIRROR
CONTROLS
(P.134)
(P.74) (P.127)AUXILIARY
INPUT JACK(P.98)
(P.31)
(P.73)
(P.70)
(P.73)
(P.156)
(P.73)
(P.123)
12
2
2
2
2
2
Page 107 of 258
Playing the AM/FM Radio
Features
105
AM/FM BUTTONSEEK BAR AUTO SELECT
BUTTON
PRESET BUTTONS
PWR/VOL KNOB
SOUND BUTTON
SEEK BAR AUTO SELECT
BUTTON
PRESET BUTTONS
SOUND BUTTON AM BUTTON
FM BUTTON SCAN BUTTON
PWR/VOL KNOB SCAN BUTTON
TUNE BAR TUNE BAR
All models except Sport
Sport model
Page 108 of 258
µµ µ
µ
µ
µ
If you do nothing, the system will
then scan f or the next strong station
and play it f or 10 seconds. When it
plays a station you want to listen to,
press the SCAN button again.
The seek f unction
searches up and down from the
current f requency to f ind a station
with a strong signal. To activate it,
press the or side of the
SEEK bar, then release it.
The scan f unction samples
all stations with strong signals on the
selected band. To activate it, press
the SCAN button, then release it.
You will see SCAN in the display.
The system will scan f or a station
with a strong signal. When it f inds
one, it will stop and play that station
f or about 10 seconds. Repeat steps 1 through 3 to store a total of six stations on AM and
twelve stations on FM. Pick a preset number (1 6), and
hold it until you hear a beep. Usethetune,seek,orscan
function to tune the radio to a
desired station. Select the desired band, AM or
FM. FM1 and FM2 let you store
twelve stations.
Use the TUNE bar to tune
to a desired f requency. Press the side of the bar to tune to a
higher f requency, and the side
to tune to a lower f requency.
Each preset button
(1 6) can store one station on AM,
and two stations on FM.
The ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Turn the system on by pushing the
PWR/VOL knob or the AM/FM
button (AM or FM button except
Sport model). Adjust the volume by
turning the same knob.
The band and f requency that the
radio was last tuned to is displayed.
To change bands, press the AM/FM
button (AM or FM button). On the
FM band, ST will be displayed if the
stationisbroadcastinginstereo.
Stereo reproduction in AM is not
available.
You can use any of f ive methods to
f ind radio stations on the selected
band: tune, seek, scan, the preset
buttons, and auto select. 1.
2.
3.
4.
SEEK
SCAN
To Play the AM/FM Radio
TUNE
PRESET
To Select a Station
Playing the AM/FM Radio
106
Page 109 of 258
µµµ
µ
µ
To turn of f auto select,pressthe
A. SEL button. This restores the
presets you originally set.
If you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area.
Press the A. SEL button. ‘‘A. SEL’’
f lashes in the display, and the system
goes into scan mode f or several
seconds. It stores the f requencies of
six AM and twelve FM stations in
the preset buttons. You will see a ‘‘0’’ displayed af ter
pressing a preset button if auto
select cannot f ind a strong station f or
that preset button.
If you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons as previously described.
Press the SOUND button repeatedly
to display the equalizer (EQ) [Sport
only], bass, treble, fader, balance,
and speed-sensitive volume
compensation (SVC) settings.
Adjusts the bass.Adjusts the treble.
Adjusts the front-to-back
strength of the sound.
Adjusts the side-to-
side strength of the sound.
Eachmodeisshowninthedisplayas
it changes. Turn the PWR/VOL
knob to adjust the setting to your
liking. When the level reaches the
center, you will see a ‘‘ ’’ in the
display.
CONT INUED
Adjusting the Sound
AUTO SELECT
BASS
TREBLE
FADER
BAL ANCE
Playing the AM/FM Radio
Features
107
Page 126 of 258
Your vehicle’s audio system will
disable itself if it is disconnected
f rom electrical power f or any reason.
To make it work again, you must
enter a specif ic f ive-digit code in the
preset buttons. Because there are
hundreds of number combinations
possible f rom f ive digits, making the
system work without knowing the
exact code is nearly impossible.
Youshouldhavereceivedacardthat
lists your audio system’s code and
serial numbers. It is best to store this
card in a saf e place at home. In
addition, you should write the audio
system’s serial number in this owner’s
manual.
If you lose the card, you must obtain
the code number f rom a dealer. To
do this, you will need the system’s
serial number.If your vehicle’s battery is
disconnected or goes dead, or the
radio f use is removed, the audio
system will disable itself . If this
happens,you will see ‘‘ENTER
CODE’’ in the f requency display the
nexttimeyouturnonthesystem.
Use the preset buttons to enter the
code. The code is on the radio code
card included in your owner’s
manual kit. When it is entered
correctly, the radio will start playing.
If you make a mistake entering the
code, do not start over; complete the
f ive-digit sequence, then enter the
correct code. You have 10 tries to
enter the correct code. If you are
unsuccessf ul in 10 attempts, you
must then leave the system on for 1
hour bef ore trying again.
Radio T hef t Protection
124
Page 205 of 258
µIf
your vehicle’s battery is
disconnected, or goes dead, the
audio system will disable itsel f. The
nexttimeyouturnontheradio,you
will see ‘‘ENTER CODE’’ in the
frequency display. Use the preset
buttons to enter the code (see page
).
Check
the condition of the battery
monthlybylookingatthetest
indicator window. The label on the
battery explains the test indicato r’s
colors. The test indicator window’s
location differs according to the
battery manufacturer.
Check the terminals for corrosion (a
white or yellowish powder). To
remove it, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When this
stops, wash it off with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
future corrosion.
If additional battery maintenance is
needed, see your dealer or a
qualified technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehic le’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
If your vehicle’s battery is
disconnected, or goes dead, the time
setting is lost. To reset the time, see
page . 124
125
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
203
TEST INDICATOR WINDOW
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
mechanic do the battery
maintenance.
Page 225 of 258
If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
ch ecked by a qualified mechanic.
If the radio fuse is removed, the
audio system will disable itsel f. The
nexttimeyouturnontheradioyou
will see ‘‘ENTER CODE’’ in the
frequency display. Use the preset
buttons to enter the five-digit code
(see page ).
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
f use. If it is blown, replace it with
oneof thesparefusesof thesame
rating or lower. 6.
5.
124
Fuses
T aking Care of t he Unexpect ed
223
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
Page 256 of 258
ÎÎ
How Your Side Curtain Airbags
.........................................
Work .30
.............................
SRS Indicator . 30, 61
....
START (Ignition Key Position) . 77
.......................
Starting the Engine .148
In Cold Weather at High ..................................
Altitude .148
................
With a Dead Battery . 214
..............
State Emissions Testing . 240
........
Steam Coming f rom Engine . 216
Steering Wheel ..................................
Adjustment .74
.............
Anti-theft Column Lock . 77
...............
Steering Wheel Buttons . 127
...................
Stereo Sound System . 105
....................
Storing Your Vehicle .204
..........................................
Sun Visor .98
Supplemental Restraint ..................................
System .9,22
......................................
Servicing .32
.........................
SRS Indicator . 30, 61
...................
System Components . 22
..................................
Synthetic Oil .178 Tailgate
............................
Open Indicator .62
.................................
Opening the .80
..........
Taillights, Changing Bulbs . 191
.
Taking Care of the Unexpected . 205
Technical Descriptions ....
DOT Tire Quality Grading . 234
.....
Emissions Control Systems . 237
.....................
Oxygenated Fuels .132
Three Way Catalytic ...............................
Converter .238
...................
Temperature Indicator . 63
..............
Tether Anchorage Points . 47
................
Thef t Protection, Radio . 124
..
Three Way Catalytic Converter . 238
..................
Tilt the Steering Wheel . 74
..........................
Time, Setting the .125
....................................
Tire Chains .202
.........
Tire, How to Change a Flat . 207
...........................
Tire Inf ormation .236
...............................................
Tires .197
..............................
Air Pressure .198
........................................
Chains .202
.........................
Checking Wear .199 ....
DOT Tire Quality Grading . 234
......................................
Inf lation .197
..................................
Inspection .199
.....................................
Labeling .236
..............................
Maintenance .199
...................................
Replacing .200
......................................
Rotating .200
...........................................
Snow .201
............................
Specif ications .233
...................
Tools, Tire Changing . 207
Towing .....................................
A Trailer .164
................
Emergency Wrecker . 226
Transmission Checking Fluid Level, ..............................
Automatic .183
Checking Fluid Level, ...................................
Manual .184
..................
Fluid Selection . 183, 184
..............
Identif ication Number . 231
.............
Shif ting the Automatic . 151
..................
Shif ting the Manual . 149
.....................................
Treadwear .234
.......................................
Trip Meter .66
....................................
Turn Signals .71
Index
T
VIII
