Each time you pull either paddle
shif ter, the transmission shif ts one
speed up or down. If you want to
shif t up or down more than two
speeds, pull the paddle shif ter twice,
pause, and then pull it again.The automatic transmission (CVT)
will not allow you to shif t if :
The transmission downshif ts to f irst
speed and returns to ordinary
automatic transmission (CVT) when
the vehicle comes to a complete stop
and the vehicle speed is about 6 mph
(10 km/h).
If there is a problem in the
transmission while you are driving
with the paddle shifters, the D
indicator f lashes, the D-paddle shif t
mode is canceled, and the
transmission returns to ordinary
automatic transmission (CVT).
You upshif t bef ore the engine
speed reaches the lowest
threshold of the higher speed. If you try to do this, the shift
indicator will f lash the number of
the lower speed several times,
then return to a higher speed. You downshif t bef ore the engine
speed reaches the highest
threshold of the lower speed.
You pull both paddle shif ters at
thesametime.
You pull one of the two paddle
shifters with another paddle
shif ter being pulled.
Driving with the Paddle Shif ters
278
Page 283 of 411
´µ µ
With the shif t lever in the S position,
you can select the 7-speed manual
shif t mode to shif t speeds; much like
a manual transmission using the
paddle shif ters, but without a clutch
pedal.
When you move the shif t lever f rom
the ‘‘D’’ to the ‘‘S’’ position and pull
either paddle shif ter, the shif t
indicator displays ‘‘M’’ along with the
selected speed number.
To upshif t, pull the (right) paddle
shif ter. To downshif t, pull the
(lef t) paddle shif ter.If you keep depressing the
accelerator pedal without pulling the
paddle shif ter, the speed will be
automatically shifted up just before
the tachometer’s red zone.
The transmission also shif ts
automatically as the vehicle comes to
a complete stop. It downshif ts to f irst
speed when the vehicle speed
reaches 6 mph (10 km/h) or less.
Downshifting with the (left)
paddle shif ter allows you to increase
the engine braking when going down
steep or long hills, and provides
more power when climbing uphills.
You can upshif t the transmission
manually to reduce the rpm.
To enter the 7-speed manual shif t
mode, press the release button on
the front of the shift lever, move the
lever to the S position, then pull
either paddle shif ter. To cancel the
7-speed manual shif t mode and
return to the ordinary automatic
transmission (CVT), move the shif t
lever f rom the S position. When
moving the shif t lever, be caref ul not
to operate incorrectly. While you are
driving in the 7-speed manual shif t
mode, the transmission will not
automatically return to the ordinary
automatic transmission (CVT).
CONT INUED
On EX models
Driving with the Paddle Shif ters
Using the Paddle Shif ters in the S
position (7-Speed Manual Shif t
Mode)
Driving
279
SHIFT INDICATOR ‘‘M’’ INDICATOR
Page 284 of 411
µ
à
à
à
à
à
à
The automatic transmission (CVT)
will not allow you to shif t if :
You downshif t bef ore the engine
speed reaches the highest
threshold of the lower speed.
If you try to do this, the shift
indicator will f lash the number of
the lower speed several times,
then return to a higher speed.
You upshif t bef ore the engine
speed reaches the lowest
threshold of the higher speed. Drive in the highest speed number
that lets the engine run and
accelerate smoothly. This will give
you ef f ective emissions control. The
f ollowing shif t points are
recommended:
To shift to Low,
pull and hold both paddle shif ters
simultaneously until you see L in the
shift indicator. Use Low to get more
power when climbing, and f or
maximum engine braking when
going down steep hills.
Shif t up 12
23
34
45
56
67 Normal acceleration
15 mph (24 km/h)
25 mph (40 km/h)
40 mph (64 km/h)
45 mph (72 km/h)
50 mph (81 km/h)
55 mph (89 km/h)
You pull both paddle shif ters at
thesametime.
You pull one of the two paddle
shifters with another paddle
shif ter being pulled.
Driving with the Paddle Shif ters
Recommended Shif t Points L (L ow) mode
280
Page 285 of 411
To help maximize f uel economy,
your vehicle has an Auto Idle Stop
f unction. Depending on
environmental conditions and vehicle
operation, the engine will shut of f
when you come to a stop.The transmission f luid
temperature is low.
When the vehicle is stopped on an
incline.
The windshield def roster is on.
The f an speed is selected to high
(more than f our steps on the
horizontal f an speed indicators).
The IMA battery charge is low.
While the auto idle stop f unction is
activated, the auto idle stop indicator
in the instrument panel blinks (see
page ).
WhentheECONmodeison,the
engine is more likely to stop than
when it is of f (see page ).
The engine will not stop
automatically under the f ollowing
conditions:
The engine automatically stops when
the vehicle comes to a stop with the
shif t lever in the D position and the
brake pedal pressed.
The engine may also stop when
vehicle speed drops below 7 mph (11
km/h) with the brake pedal pressed. Vehicle speed does not go above 9
mph (15 km/h) af ter starting the
engine.The vehicle is stopped with the
shif t position in P, R, S, or L.
The engine coolant temperature is
low. The pointer of the charge/assist
gauge does not move when
accelerating or decelerating. 127
283
CONT INUED
Auto Idle Stop
Driving
281
Page 286 of 411
The engine coolant temperature
becomes low.
Thepressureonthebrakepedalis
repeatedly applied and released
slightly during a stop.
The ECON button is off, and the
dif f erence between the ambient
temperature and the temperature
setting of the climate control
system becomes signif icant.
Theclimatecontrolsystemstarts
to dehumidif y the interior
The engine automatically restarts
when:
The brake pedal is released.
Under the f ollowing conditions, the
engine restarts even if the brake
pedal is pressed:
The shif t position is changed to R
or L.
The accelerator pedal is pressed
The pressure to the brake pedal is
reduced and the vehicle starts
moving while stopped on an incline.
The IMA battery charge becomes
low.
The engine may not stop
automatically under the f ollowing
conditions:
The windshield def roster button is
pressed.
TheECONbuttonisoff,andthere
is a signif icant dif f erence between
the ambient temperature and the
temperature setting of the climate
control system.
The climate control system is
dehumidif ying the air.
The vehicle is stopped by braking
suddenly.
When the ECON button is on, the
engine is more likely to stop. See
page f or the ECON button. 127
Auto Idle Stop
282
Page 287 of 411
If the auto idle stop function turns
of f the engine f or a long time, the
charge of the IMA and 12 volt
batteries becomes low, and the
engine may not restart automatically.
Always turn the ignition switch to
the LOCK (0) position, set the
parking brake, and remove the key if
you are getting out of the vehicle.Thetimethatautoidlestopis
activated may be reduced if you
operate the windshield wipers with
the climate control system on.
This indicator blinks when the auto
idle stop system is in operation. If
the driver’s door is opened while the
indicator is blinking, the buzzer
sounds to notif y that the auto idle
stop system is active. A uto Idle Stop Indicator
Auto Idle Stop
Driving
283
AUTO IDLE STOP INDICATOR
Page 289 of 411
Your vehicle is equipped with f ront
disc brakes. The brakes on the rear
wheels are drum. A power assist
helps reduce the ef f ort needed on
thebrakepedal.TheABShelpsyou
retain steering control when braking
very hard.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, reduces their ef f ectiveness and
reduces brake pad lif e. In addition,
f uel economy can be reduced. It also
keeps your brake lights on all the
time, conf using drivers behind you.Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
Constant application of the brakes
when going down a long hill builds
up heat and reduces their
ef f ectiveness. Use the engine to
assist the brakes by taking your f oot
of f the accelerator and downshif ting
to a lower speed.
Braking System
Driving
285
Page 293 of 411
If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly. If the tire is flat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see a ‘‘CHECK
TIRE PRESSURE’’ message on the
multi-inf ormation display.
If you cannot make the low tire
pressure/TPMS indicator and
message on the multi-inf ormation
display go out af ter inf lating the tires
to the specified values, have your
dealer check the system as soon as
possible. 348
CONT INUED
U.S. models onlyLow Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
Driving
289
Page 297 of 411
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on or comes
back on while driving, have the VSA
system inspected by your dealer.
If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehicle as
soon as possible. When VSA activates, you will see the
VSA system indicator blink.
The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output and
by selectively applying the brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. There may also
be some noise f rom the VSA
hydraulic system. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety. When VSA is off, the VSA OFF
indicator comes on as a reminder.
The VSA system indicator will also
come on when there is a problem in
the hill start assist system. For more
inf ormation, see page .
The main f unction of the
VSA system is generally known as
Electronic Stability Control (ESC).
The system also includes a traction
control f unction.
When the VSA system indicator
comes on, you will also see a
‘‘CHECK VSA SYSTEM’’ or
‘‘CHECK HILL START ASSIST
SYSTEM’’ message on the multi-
inf ormation display. 295
Vehicle Stability Assist
(VSA ) System Indicator VSA OFF Indicator
Vehicle St abilit y A ssist (VSA), aka Electronic Stability Control (ESC), System
Driving
293
NOTE:
Page 298 of 411
Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off. In certain unusual conditions when
your vehicle gets stuck in shallow
mud or f resh snow, it may be easier
to free it with the VSA temporarily
switched of f . When the VSA system
is of f , the traction control system is
alsooff.Youshouldonlyattemptto
f ree your vehicle with the VSA of f if
you are not able to f ree it when the
VSA is on. VSA is turned on every time you
start the engine, even if you turned it
off the last time you drove the
vehicle.
When VSA is off, the VSA activation
indicator comes on as a reminder.
Press and hold the switch again. It
turns the system back on. This switch is under the driver’s side
vent. To turn the VSA system on and
of f , press and hold it until you hear a
beep.
If the low tire pressure/TPMS
indicator comes on (see page ),
or the multi-information display
shows a ‘‘CHECK TPMS SYSTEM’’
message with the indicator flashing
(see page ), the VSA system
automatically turns on even if the
VSA system is turned off with the
VSA OFF switch. In this case, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
289
290
On U.S. models
Vehicle St abilit y A ssist (VSA), aka Electronic Stability Control (ESC), System
VSA OFF Switch
294
VSA OFF
SWITCH
