HONDA INSIGHT 2006 1.G Owner's Manual
Manufacturer: HONDA, Model Year: 2006, Model line: INSIGHT, Model: HONDA INSIGHT 2006 1.GPages: 218, PDF Size: 2.72 MB
Page 21 of 218
The dealer should also inspect the
anchors f or damage and replace
them if needed. If the automatic seat
belt tensioners activate during a
crash, they must be replaced.
For inf ormation on how to clean your
seat belts, see page .151
Additional Inf ormation About Your Seat Belts
20
Not checking or maintaining
seat belts can result in serious
injury or death if the seat belts
do not work properly when
needed.
Check your seat belts regularly
and have any problem
corrected as soon as possible.
Page 22 of 218
Your airbag system includes:Automatic seat belt tensioners
(see page ). Two SRS (Supplemental Restraint
System) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the passenger’s
airbag is stored in the dashboard.
Both are marked ‘‘SRS AIRBAG.’’ An indicator on the instrument
panel that alerts you to a possible
problem with your airbags,
sensors, or seat belt tensioners
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
If you ever have a moderate to
severe f rontal collision, sensors will
detect the vehicle’s rapid
deceleration.
If the rate of deceleration is high
enough, the control unit will instantly
inflate the driver’s and passenger’s
f ront airbags.
Sensors that can detect a
moderate to severe frontal impact.
A sophisticated electronic system
that continually monitors and
records inf ormation about the
sensors, the control unit, and the
airbag activators when the ignition
switch is in the ON (II) position. 19
23
CONT INUED
Airbag System Components
How Your Front Airbags Work
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
21
Page 23 of 218
During a f rontal crash, your seat belt
restrains your lower body and torso,
and the airbag helps protect your
head and chest.
This can happen if the severity of a
collision is at the margin, or
threshold, that determines whether
or not the airbags will deploy. In
such cases, the seat belt will provide
suf f icient protection, and the
supplemental protection of f ered by
the airbag would be minimal.The total time for inflation and
def lation is one-tenth of a second, so
f ast that most occupants are not
aware that the airbags deployed until
they see them lying in their laps.After a crash, you may see what
looks like smoke. This is actually
powder f rom the airbag’s surf ace.
Although the powder is not harmf ul,
people with respiratory problems
may experience some temporary
discomf ort. If this occurs, get out of
the vehicle as soon as it is saf e to do
so.
Af ter inf lating, the f ront airbags will
immediately def late, so they won’t
interf ere with the driver’s visibility,
or the ability to steer or operate
other controls.
Although both airbags normally
inf late within a split second of each
other, it is possible f or only one
airbag to deploy.
Additional Inf ormation About Your Airbags
22
Page 24 of 218
The SRS indicator alerts
you to a potential problem
with your airbags or seat belt
tensioners (see page ).
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the indicator stays on after the
engine starts.
When you turn the ignition switch to
the ON (II) position, this indicator
comes on brief ly then goes of f . This
tells you the system is working
properly.
If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
If the indicator comes on or
flashesonandoff whileyoudrive. If you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them.
Your airbag system is virtually
maintenance-f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
Any airbag
that has deployed must be
replaced, along with the control
unit and seat belt tensioner. Do
not try to remove or replace any
airbag by yourself.
This must be done by your dealer
or a knowledgeable body shop.
Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
19
How the SRS Indicator Works
A irbag Service
An airbag ever inf lates.
T he SRS indicat or alert s you t o aproblem.
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
23
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
Page 25 of 218
Together, airbags and
seat belts provide the best
protection.
Tampering could cause
the airbags to deploy, possibly
causing very serious injury.
Additional Inf ormation About Your Airbags
Donotattempttodeactivateyour
airbags.
Do not t amper wit h airbagcomponent s or wiring f or anyreason.
Additional Saf ety Precautions
24
Page 26 of 218
µµ
µ
Children depend on adults to protect
them. However, despite their best
intentions, many adults do not know
how to protect child
passengers.
If you ever need to drive with a child
in your vehicle, be sure to read this
section. It begins with important
general guidelines, then presents
special inf ormation f or inf ants, small
children and larger children.
Each year, many children are injured
or killed in vehicle crashes because
they are either unrestrained or not
properly restrained. In f act, vehicle
accidents are the number one cause
of the death of children ages 12 and
under.
To reduce the number of child
deaths and injuries, every state and
Canadian province requires that
inf ants and children be properly
restrained when they ride in a
vehicle.
(see pages
). (see pages
).
30 32 34
37
properly
All Children Must Be Restrained
Anychildwhoistoosmalltoweara
seat belt must be restrained in anapproved child seat t hat is properlysecured t o t he vehicle A larger child must be restrained
wit h a lap/shoulder belt and ride ona boost er seat unt il t he seat belt f it shim or her properly
Protecting Children General Guidelines
Driver and Passenger Saf ety
25
Children who are unrestrained
or improperly restrained can be
seriously injured or killed in a
crash.
Any child too small for a seat
belt should be properly
restrained in a child seat. A
larger child should be properly
restrained with a seat belt and
use a booster seat if necessary.
Page 27 of 218
µ
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
Since this vehicle does not have a
back seat, we strongly recommend
that you do not carry any child who
is not large enough or mature
enough to ride in f ront (see page ).Front airbags have been designed to
help protect adults in a moderate to
severe f rontal collision. To do this,
the passenger’s airbag is quite large,
and it can inflate with enough force
to cause very serious injuries.
If the airbag inf lates, it
can hit the back of the child seat
with enough f orce to kill or very
seriously injure an inf ant. If the vehicle seat is too
farforward,orthechild’sheadis
thrown f orward during a collision, an
inflating front airbag can strike the
child with enough f orce to kill or
very seriously injure a small child.
If a larger child must
ride in this vehicle, see page f or
important guidelines on how to
decide when a child is ready to ride
in f ront and how to properly protect
the child.
36
36
Protecting Children General Guidelines
Your Vehicle is Not
Recommended f or Child
PassengersThe Passenger’s Front Airbag
Poses Serious Risks
Inf ant s
Never put a rear-f acing child seat int his vehicle. Small Children
Placing a f orward-f acing child seat int he passenger’s seat can behazardous.
Larger ChildrenChildren who have outgrown childseat s are also at risk of being injuredor killed by an inf lat ing passenger’sfront airbag.
26
Page 28 of 218
µ
To remind you of the passenger’s
airbag hazards, your vehicle has
warninglabelsonthedashboard
(U.S. models) and on the driver’s and
passenger’s visors. Please read and
f ollow the instructions on these
labels.U.S. ModelsCanadian Models
Protecting Children General Guidelines
Driver and Passenger Saf ety
Sun Visor
Sun Visor Dashboard
27
Page 29 of 218
µ
If you are not wearing a seat
belt in crash, you could be thrown
f orward and crush the child
against the dashboard. If you are
wearing a seat belt, the child can
be torn f rom your arms and be
seriously hurt or killed.
If they do, they
could be very seriously injured in a
crash. Leaving children without
adult supervision is illegal in most
states and Canadian provinces,
and can be very hazardous.
For example, a small child lef t in a
vehicle on a hot day can die f rom
heatstroke. A child lef t alone with
the key in the ignition switch can
accidentally set the vehicle in
motion, possibly injuring
themselves or others.
During a crash, the
belt could press deep into the child
and cause serious or fatal injuries.
Children who play in vehicles can
accidentally get trapped inside.
Teach your children not to play in
or around vehicles. Even very young
children learn how to unlock
vehicle doors, turn on the ignition
switch, and open the hatch, which
can lead to accidental injury or
death.
Additional Saf ety Precautions
Protecting Children General Guidelines
Never hold a small child on your
lap.
Never let two children use thesame seat belt . Do not leave children alone in a
vehicle.
Never put a seat belt over yourself and a child.
Lock both doors and the hatchwhen your vehicle is not in use. K eep vehicle keys and remot e
transmitters out of the reach ofchildren.
28
Page 30 of 218
Because an inf lating airbag can
seriously injure or kill small children,
we recommend that you do not carry
a small child as a passenger in this
vehicle.
If you decide to transport a small
child in this vehicle, be sure to move
the passenger seat as far to the rear
as possible, and follow the
instructions and guidelines in the
f ollowing pages.We also recommend that a small
child use the child seat as long as
possible, until the child reaches the
weight or height limit f or the seat.
A child who is at least one year old,
and who fits within the child seat
maker’s weight and height limits,
should be restrained in a f orward-
f acing, upright child seat.
Of the different seats available, we
recommend those that have a f ive-
point harness system as shown.
Protecting Small Children
Driver and Passenger Saf ety
29
Placing a forward-facing child
seat in the passenger’s seat
can result in serious injury or
death if the airbag inflates.
Ifyoumustplaceaforward-
facing child seat in the
passenger’s seat, move the
vehicle seat as far back as
possible and properly restrain
the child.
