Lif t the head restraint (seepage
) , then route the tether strap
through the legs of the head
restraint and over the seat-
back, making sure the
strap is not twisted.
Other LATCH-compatible seats
have a flexible-type connector
as shown above.
Whatever type you have, f ollow
the child seat maker’s instructions
f or adjusting or tightening the f it.
Place the child seat on the vehicle
seat, then attach the seat to the
lower anchors according to the
child seat maker’s instructions.
Some LATCH-compatible seats
have a rigid-type connector as
shown above. 5.
4.
3.
142
Installing a Child Seat
48
ANCHOR
TETHER STRAP HOOK
Flexible type
Rigid type
12/07/13 16:43:01 31TM8630_053
Driver and Passenger Saf etyTOC
2013 Insight

CONT INUED
With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker’s instructions,
then insert the latch plate into the
buckle and remove any slack f rom
the lap portion of the belt.
When not using the LATCH system,
all child seats must be secured to the
vehicle with the lap part of a lap/
shoulder belt.
In addition, the lap/shoulder belts in
all seating positions except the
driver’s have a lockable retractor
that must be activated to secure a
child seat.
Attach the tether strap hook to the
tether anchor, then tighten the
strap as instructed by the child
seat maker.
If the tether strap is too long and
cannot be tightened f irmly, f ind a
route where the strap can be
tightened securely.
Push and pull the child seat
f orward and f rom side-to-side to
verify that it is secure.
1.
6.
7.
Installing a Child Seat
Installing a Child Seat with a L ap/
Shoulder Belt
49
12/07/13 16:43:09 31TM8630_054
Driver and Passenger Saf etyTOC
2013 Insight

Push and pull the child seat
forward and from side-to-side to
verify that it is secure enough to
stay upright during normal
driving maneuvers. If the
child seat is not secure, unlatch
the belt, allow it to retract fully,
then repeat these steps.
To deactivate the lockable retractor
andremoveachildseat,unlatchthe
buckle, unroute the seat belt, and let
the belt fully retract.
To remove slack, it may help to
putweightonthechildseat,or
push on the back of the seat while
pulling up on the belt. Af ter conf irming that the belt is
locked, grab the shoulder part of
the belt near the buckle, and pull
up to remove any slack from the
lap part of the belt. Remember, if
the lap part of the belt is not tight,
the child seat will not be secure.
To activate the lockable retractor,
slowly pull the shoulder part of the
belt all the way out until it stops,
then let the belt feed back into
Af ter the belt has retracted, tug on
it. If the belt is locked, you will not
be able to pull it out. If you can pull
thebeltout,itisnotlocked,and
you will need to repeat these steps. 4.
5.
2.
3.
Installing a Child Seat
50
12/07/13 16:43:16 31TM8630_055
Driver and Passenger Saf etyTOC
the retractor.
2013 Insight

If the tether strap is too long and
cannot be tightened f irmly, f ind a
route where the strap can be
tightened securely. Tighten the strap according to the
seat maker’s instructions.
Af ter properly securing the child
seat (see
page), lif t the head
restraint, then route the tether
strap over the seat-back and
through the head restraint legs.
Attach the tether strap hook to the
anchor, making sure the strap is
not twisted.
A child seat with a tether can be
installed in any seating position in
the back seat, using one of the
anchorage points shown above.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using
a tether whenever one is required
or available. 1.
2.
3.
49
Installing a Child Seat
Installing a Child Seat
with a Tether
51
ANCHOR
ANCHOR Outer Position Center Position
TETHER STRAP HOOK TETHER STRAP HOOK
ANCHOR
ANCHORAGE POINTS
12/07/13 16:43:24 31TM8630_056
Driver and Passenger Saf etyTOC
2013 Insight

To determine if a lap/shoulder
belt properly fits a child, have the
child put on the seat belt,
then ask yourself:Does the child sit all the way back
against the seat?
Do the child’s knees bend
comfortably over the edge of
the seat?
The f ollowing pages give
instructions on how to check proper
seat belt f it, what kind of booster
seat to use if one is needed, and
important precautions f or a child
who must sit in f ront. When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear the lap/
shoulder belt.
1.
2. Checking Seat Belt Fit
Protecting L arger Children
52
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger’s front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.
12/07/13 16:43:31 31TM8630_057
Driver and Passenger Saf etyTOC
2013 Insight

Does the shoulder belt cross
between the child’s neck and arm?
Is the lap part of the belt as low as
possible, touching the child’s
thighs?
Will the child be able to stay
seated like this f or the whole trip?
If you answer yes to all these
questions, the child is ready to wear
the lap/shoulder belt correctly. If
you answer no to any question, the
child needs to ride on a booster seat. A child who has outgrown a f orward- f acing child seat should ride in a
back seat and use a booster seat
until the lap/shoulder belt f its them
properly without the booster.Booster seats can be high-back or
low-back. Whichever style you select,
make sure the booster seat meets
f ederal s
af ety standards (see
page ) and that you follow the
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat. If a child who uses a booster seat
must ride in f ront, move the vehicle
seat as far back as possible, and be
sure the child is wearing the seat
belt properly.
Some states, Canadian provinces and
territories also require children to
use a booster seat until they reach a
given age or weight (e.g., 6 years or
60lbs).Besuretocheckcurrent laws in the states, provinces or
territories where you intend to drive.
3.
4.
5.
46
Using a Booster Seat
Protecting L arger Children
53
12/07/13 16:43:40 31TM8630_058
Driver and Passenger Saf etyTOC
booster seat maker’s instructions.
2013 Insight

If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If
any part of a larger child’s body
is in the path of a deploying side
airbag, the child could receive
possibly serious injuries.Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.If you decide that a child can saf ely
ride up f ront, be sure to:
Carefully read the owner’s
manual, and make sure you
understand all seat belt instructions
and all safety information.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly.
17 52
When Can a Larger
Child Sit in Front
Physical Size
Maturity
Protecting L arger Children
54
12/07/13 16:43:50 31TM8630_059
Driver and Passenger Saf etyTOC
2013 Insight

This could result
in serious neck injuries during
This could
cause very serious injuries during
a crash. It also increases the
chance that the child will slide
under the belt in a crash and
If they do, they
could be very seriously injured in Devices intended to
improve a child’s comf ort or
reposition the shoulder part of a
seat belt can make the belt less
ef f ective and increase the chance
of serious injury in a crash.
Additional Saf ety Precautions
Do not let a child wear a seat belt
across t he neck.
Do not let a child put the shoulderpart of a seat belt behind t he backor under t he arm.
T wo children should never use thesame seat belt . Do not put any accessories on a
seat belt.
Protecting L arger Children
55
12/07/13 16:43:55 31TM8630_060
Driver and Passenger Saf etyTOC
a crash.
a crash. be injured.
2013 Insight

Your vehicle’s exhaust contains
carbon monoxide gas. Carbon
monoxide should not enter the
vehicle in normal driving if you
maintain your vehicle properly and
f ollow the inf ormation on this page.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
Have the exhaust system inspected
f or leaks whenever:
Select the f resh air mode.
Select the mode.
Set the f an speed to high.
Set the temperature control to a
comfortable setting.
With the hatch open, airflow can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
hatch open, open all the windows,
and set the climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconfined area, adjust the climate
control system as f ollows:
The vehicle is raised for an
oil change.
You notice a change in the sound
of the exhaust.
The vehicle was in a crash that
may have damaged the underside. 1.
2.
3.
4.
Carbon Monoxide Hazard
56
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.
12/07/13 16:44:03 31TM8630_061
Driver and Passenger Saf etyTOC
2013 Insight

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.
CONT INUED
U.S. modelsCanadian models
U.S. models only
Saf ety L abels
57
DASHBOARD
RADIATOR CAP SUN VISORS
12/07/13 16:44:17 31TM8630_062
Driver and Passenger Saf etyTOC
2013 Insight
