mirror HONDA ODYSSEY 1995 Owners Manual

Instruments and Controls

This section gives information about the controls and displays thatcontribute to the daily operation of
your Honda. All the essential controls are within easy reach.
Control Locations............................ 34
Indicator Lights................................ 35
Gauges............................................. 39

Speedometer............................... 39

Trip Meter................................... 39

Odometer..................................... 39

Temperature Gauge................... 40
Fuel Gauge.................................. 40

Maintenance Required
Indicator................................... 40

Controls Near the Steering Wheel...................................... 41

Headlights...................................
42

Daytime Running
Lights............ 42

Instrument Panel Brightness.... 43
Turn Signals................................. 43
Windshield Wipers...................... 44
Windshield Washers................... 44 Rear Window Wiper and Washer...................................... 45

Hazard Warning.......................... 45

Rear Window Defogger.............. 45
Steering Wheel Adjustment....... 46
Steering Wheel Controls ................ 48 Cruise Control.............................. 48

Horn............................................. 51

Keys and Locks................................ 51
Keys............................................... 51
Ignition Switch............................. 52
Power Door Locks....................... 53Remote Transmitter.................... 54
Childproof Door Locks............... 54
Tailgate......................................... 55 Glove Box..................................... 55

Seats................................................. 56
Passenger Seating...................... 56

Seat Adjustments........................ 56

Driver's Seat Power HeightAdjustment.............................. 57
Head Restraints.......................... 58
Third Seat Access....................... 58 Removing the Second Seats
in the Six-Passenger Model.... 59
Folding the Second Seats in the Seven-Passenger

Model................................... 60

Reclining the Second Seat.......... 61
Folding the Third Seat in All Models...........................
62
Power Windows.............................. .
64

Sunroof............................................. 65

Mirrors............................................. 66
Adjusting the Power Mirrors.....

67

Parking Brake.................................
68

Digital Clock..................................... 68
Beverage Holder.............................. 69 Dashboard Compartment............... 70
Center Poket.................................... 71
Coin Box........................................... 71
Vanity Mirror................................... 71
Cigarette Lighter............................. 72

Ashtrays........................................... 72

Interior Lights.................................. 73
Ceiling Lights.............................. 73

Spotlights..................................... 73

Tailgate Light............................... 74 Courtesy Lights........................... 74
Instruments and ControlsProCarManuals.comMain Menu s t

Control Locations

DOOR LOCK
SWITCH
(P.53)

POWER WINDOW
SWITCH

(P.64)

FUEL FILL
DOOR RELEASE
(P.110)

HOOD RELEASE

HANDLE
(P.111)
HEATING/COOLING

CONTROL

(P.78)

AUDIO SYSTEM
(P.84)

Instruments and Controls
MIRROR
CONTROLS

(P.67)
DIGITAL CLOCK

(P.68)ProCarManuals.comMain Menu Table of Contents s t

Sunroof, Mirrors

If yon try to open the sunroof in below-
freezing temperatures, or when it is
covered with snow or ice, yon can
damage the sunroof panel or motor. Mirrors

TAB

Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving. The inside mirror has day and night
positions. The night position reducesglare from headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.

Instruments and Controls

Closing the sunroof on
someone's hands or fingers can
cause serious injury.
Make sure passengers are
clear of the sunroof before
closing it.

NOTICEProCarManuals.comMain Menu Table of Contents s t

Mirrors

Adjusting the Power Mirrors
Adjust the outside mirrors with the adjustment switch on the driver'sdoor armrest:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).
3. Push the appropriate edge of the
adjustment switch to move the
mirror right, left, up or down.
4. When you finish, move the selector switch to the center (off)
position. This turns off the
adjustment switch so you can't
move a mirror out of position by
accidentally bumping it. The outside mirror on the passenger's
side has curved glass. Objects look
farther away than they are. Use this mirror to get a "wide view". Don't
use it to judge the distance of things

behind you.

Instruments and Controls
ADJUSTMENT SWITCH

SELECTOR SWITCHProCarManuals.comMain Menu Table of Contents s t

Center Pocket, Coin Box, Vanity Mirror
Center Pocket
Open the center pocket by pulling
the handle. Close it with a firm push.
The light in the pocket comes on when the instrument panel lights are
on.
Coin Box
COIN BOX
To open the coin box, pull the upper edge. Close it with a firm push.
Vanity Mirror

To use the vanity mirror, pull down either sun visor and swing down the

cover.

The passenger's vanity mirror is lighted. The light beside the mirrorcomes on only when the light switch
is turned on.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Preparing to Drive

You should do the following checks and adjustments every day before
you drive your car.
1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,
or ice.
2. Check that the hood and tailgate are fully closed.
3. Visually check the tires. If a tire looks low, use a gauge to check its
pressure.
4. Check that any items you may be carrying with you inside are stored
properly or fastened down
securely. 5. Check the adjustment of the seat
(see page 56).
6. Check the adjustment of the inside and outside mirrors (see
page 66).
7. Check the adjustment of the steering wheel (see page 46).
8. Make sure the doors are securely closed and locked.
9. Fasten your seat belt. Check that your passengers have fastened
their seat belts (see page 7). 10. Turn the ignition ON (II). Check
the indicator lights in the instru-
ment panel.
11. Start the engine (see page 119).
12. Check the gauges and indicator lights in the instrument panel (see
page 35).

DrivingProCarManuals.comMain Menu Table of Contents s t

Towing a Trailer

MirrorsMany states and provinces have laws
requiring special outside mirrors
when you are towing a trailer. Check
the laws in your area. You may want
to install mirrors, even if they are not required. Hook up the trailer and see
how much it obscures your ability to see behind you with the standard
mirrors. If you cannot see directly
behind you, or have a large blind spot next to the trailer or the car,
you should install mirrors intended for towing.
Connecting the Trailer

Most trailers that have a gross
weight of 450 kg (1,000 Ibs) do not have their own braking system. If
you are thinking of getting a trailer that does have brakes, make sure

they are electrically-operated. There
are no provisions in your car to tap
into its hydraulic braking system.
Any attempt to attach the trailer's brakes to your car's hydraulicsystem, no matter how successful it
may seem, will lower braking effectiveness and create a potential

hazard.
Always use a safety chain when
towing a trailer. Connect the safetychain securely at both ends. Makesure the chain crosses under the
tongue so it will catch the trailer if it
becomes unhitched. Leave enough slack in the chain so it can't bind in asharp turn. Do not let it drag on the
ground.
DrivingProCarManuals.comMain Menu Table of Contents s t

Index

Accessories
Installation.................................. 115
ACCESSORY (Ignition Key
Position)....................................... 52
Adding Automatic Transmission

Fluid........................................ 155

Brake Fluid................................. 156

Engine Coolant........................... 150

Engine Oil................................... 146

Power Steering Fluid................. 157
Windshield Washer Fluid......... 154
Additional Safety Information........ 18 Door Locks................................... 19
Driving with Pets......................... 19
Head Restraint Position.............. 18
Seat-back Position........................ 18
Storing Cargo Safely................... 19
Additives, Engine Oil..................... 148
Adjustments
Mirrors.......................................... 67

Head Restraints........................... 58

Seats.............................................. 56

Steering Wheel............................ 46
Airbag (SRS) .................................... 12

Air Cleaner..................................... 157
Air Conditioning............................... 76

Maintenance............................... 168

Usage............................................. 78

Air Outlets (Vents).......................... 76
Air Pressure, Tires........................ 170

Alcohol and Drugs........................... 28

Alcohol in Gasoline........................ 109

Antifreeze....................................... 150

Anti-lock Brakes (ABS)
Description................................. 220

Indicator Light..................... 37, 125
Operation.................................... 125

Anti-theft Steering Column Lock .. 52
Appearance Care........................... 183

Ashtray.............................................. 72

Audio System................................... 84
Automatic Speed Control................ 48

Automatic Transmission............... 120

Capacity, Fluid........................... 218

Checking Fluid Level................ 155
Shifting........................................ 120

Shift Lever Positions................. 120

Shift Lock Release..................... 123
Battery
Charging System Light............... 36
Jump Starting............................. 200 Maintenance............................... 162
Specifications............................. 219
Before Driving............................... 107
Belts, Seat........................................... 5
Beverage Holder.............................. 69
Body Repair.................................... 190

Brakes
Anti-lock System (ABS)............ 125Break-in, New Linings .............. 108

Fluid............................................ 156

Light, Burned-out...................... 179
Parking.......................................... 68
System Indicator.......................... 36
Wear Indicators......................... 124
Brakes, ABS Description................................. 220
Operation.................................... 125
System Indicator................. 37, 125
Braking System.............................. 124
CONTINUEDProCarManuals.comMain Menu s t Main Menu s t

Index

Flashers, Hazard Warning.............. 45
Flat Tire, Changing a.................... 193
Fluids Automatic Transmission........... 155
Brake........................................... 156
Power Steering........................... 157
Windshield Washer................... 154
FM Stereo Radio Reception...................................... 87
Folding the Second Seats ............... 60
Folding the Third Seats.................. 62
Foreign Countries, Driving in...... 109
Four-way Flashers........................... 45
Front End, Towing by Emergency Wrecker................. 213

Fuel.................................................. 108
Fill Door and Cap....................... 110
Gauge............................................ 40Octane Requirement................. 108
Oxygenated................................ 108
Tank, Filling the......................... 110
Fuses, Checking the...................... 209 Gas Mileage, Improving................ 114
Gasohol........................................... 108
Gasoline.......................................... 108
Gauge............................................ 40
Octane Requirement................. 108
Tank, Filling the......................... 110
Gas Station Procedures................. 110

Gauges
Engine Coolant Temperature .... 40
Fuel................................................ 40
Gearshift Lever Positions............. 120
Glass Cleaning............................... 188
Glove Box......................................... 55
Halogen Headlight Bulbs.............. 177
Hazard Warning Flashers............... 45
Headlights......................................... 42 Aiming......................................... 175
Daytime Running Lights............. 42
High Beam Indicator................... 38
High Beams, Turning on............ 42
Low Beams, Turning on ............. 42
Reminder Chime.......................... 42

Replacing Halogen Bulbs ......... 177

Turning on.................................... 42

Head Restraints............................... 58

Heating and Cooling........................ 76

High Altitude, Starting at.............. 119

High-Low Beam Switch .................. 42
Hood, Opening the ........................ 111

Horn.................................................. 51

Hot Coolant, Warning about........ 151

Hydroplaning.................................. 127

Identification Number, Vehicle.... 216

If Your Car Has to be Towed....... 213

Ignition
Keys............................................... 51

Switch............................................ 52

Timing Control System............. 225

Indicator Lights, Instrument
Panel.............................................. 35

Infant Restraint................................ 22

Inflation, Proper Tire .................... 170

Inside Mirror.................................... 66

Inspection, Tire.............................. 171ProCarManuals.comMain Menu s t Main Menu s t

Index

Instrument Panel............................. 34
Instrument Panel Brightness......... 43 Interior Cleaning............................ 187
Interior Lights.................................. 73
Introduction....................................... i

Jacking up the Car......................... 195

Jack, Tire........................................ 193

Jump Starting................................. 200

Keys................................................... 51

Label, Certification........................ 216

Lane Change, Signaling.................. 43

Lap Belt............................................... 7

Lap/Shoulder Belts........................... 6
Leaking of Exhaust into Car.......... 29
Lighter, Cigarette............................ 72
Lights Headlight Aiming...................... 175 Bulb Replacement..................... 177

Indicator........................................ 35
Parking.......................................... 42

Turn Signal................................... 43

Loading Cargo................................ 116
LOCK (Ignition Key Position)....... 52
Locks Anti-theft Steering Column........ 52
Fuel Fill Door............................. 110
Glove Box..................................... 55
Power Door.................................. 53
Tailgate......................................... 55
Low Coolant Level......................... 150
Low Oil Pressure Indicator.... 36, 204
Lubricant Specifications Chart.... 218
Luggage.......................................... 116
Maximum Speeds.......................... 123

Meters, Gauges................................ 39

Methanol in Gasoline.................... 109

Mirrors, Adjusting........................... 66

Neutral Gear Position.................... 122

New Vehicle Break-in ................... 108

NOTICE, Explanation of................... ii

Numbers, Identification................ 216
Occupant Protection System............ 4
Octane Requirement, Gasoline.... 108
Odometer.......................................... 39

Odometer, Trip................................ 39

Oil
Change, How to ......................... 148

Change, When to....................... 140

Checking Engine....................... 146
Pressure Indicator....................... 36
CONTINUED

Maintenance................................... 135

Periodic Items............................ 144

Record.................................142 - 143

Required Indicator....................... 40

Safety........................................... 136

Schedule............................ 138 - 141

Malfunction Indicator Lamp .. 37, 206ProCarManuals.comMain Menu s t
