HONDA ODYSSEY 2003 RB1-RB2 / 3.G Owners Manual

Turn the ignition switch ON (II).
Move the selector switch to L
(driver’s side) or R (passenger’s
side).Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.
Adjust the outside mirrors with the
adjustment switch on the lef t side of
the dashboard:
1.
2.
3.
4.
Adjusting the Power Mirrors
Mirrors
Inst rument s and Cont rols128
TAB
SELECTOR SWITCH
ADJUSTMENT SWITCH

Canadian Models
The outside mirrors are heated to re-
move fog and frost. With the ignition
switchON(II),turnontheheaters
by pressing the button. The light in
the button comes on as a reminder.
Press the button again to turn the
heaters off.To apply the parking brake, push the
parking brake pedal down with your
f oot. To release the parking brake,
push on the pedal again. The parking
brake light on the instrument panel
should go out when the parking
brake is f ully released with the
engine running. (see page .)
72
Parking Brake
Mirrors, Parking Brake
Inst rument s and Cont rols129
HEATED MIRROR BUTTON
PARKING BRAKE PEDAL
Driving the vehicle with the parking
brake applied can damage the rear
brakes and axles.

Press and hold the H button until
the hour advances to the desired
time.
You can use R to quickly set the time
to the nearest hour. If the displayed
time is before the half hour, pressing
Rsetstheclockbacktotheprevious
hour. If the displayed time is af ter
the half hour, pressing R sets the
clock f orward to the beginning of the
next hour.
For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00. To use the center table, pull up the
outside edge of the table until it
latches. To store it, pull the lever and
lower the table.
Press and hold the M button until
the numbers advance to the
desired time.
To set the clock: The digital clock displays the time
with the ignition switch in any
position. Turn the ignition switch ON (II). 2.
3.
1.
On models without navigation system
Digital Clock Center Table
Digital Clock, Center Table
Inst rument s and Cont rols130
HM R

Thecentertablecanbeextendedby
pulling on the rear.
Sitting on or getting under the table,
or putting heavy objects on the table,
may damage or deform it.
Do not put any items on the table
while driving. They may f all down or
f ly around when you go around
corners or brake hard.
Inst rument s and Cont rols
Center Table
131

To use the f ront beverage holder,
pull on the bottom edge. Push the
holder all the way in to close it.Additional beverage holders f or the
f ront seat passengers, and beverage
holders f or the passengers in the
second row, are in the center table.
Inst rument s and Cont rols
Beverage Holders
132

Each second row seat has a
beverage holder on the outside of
the seat cushion. To use the
beverage holder, push on the tab.
The beverage holder will swing open.
To close, pivot it up and push it in
until it latches.The beverage holders f or the third
seat passengers are located in the
armrests on the rear side panels.
To protect the beverage holder, the
bottom tray is designed to break
away if you try to place a heavy
object on it. If this happens, hold the
edge of the bottom tray and pull it up
until you f eel a detent.
Be caref ul not to damage an open
beverage holder when you get into
or out of the vehicle. Be caref ul when you are using the
beverage holder. A spilled liquid that
is very hot can scald you or your
passengers. Spilled liquids can also
damage the upholstery, carpeting,
and electrical components in the
interior. The inner liner can be removed if
youwanttoholdalargercup.
Inst rument s and Cont rols
Beverage Holders
133
TAB

To open the sunglasses holder, push
on the f ront edge. It will unlatch and
swing down. To close it, push it until
it latches. Make sure the holder is
closed while you are driving.To use the sun visor, pull it down.
You can also use the sun visor at the
side window. Remove the support
rod f rom the clip and swing the sun
visor toward the side window. In this
position, the sun visor can be
extended by sliding out the
extension.
Some larger styles of sunglasses
may not f it in the holder.
Inst rument s and Cont rols
Sunglasses Holder, Sun Visor
Sunglasses Holder
Sun Visor
134
EXTENSION
SUN VISOR

Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle. Do not use
the sun visor extension over the rear
view mirror.Touseavanitymirroronthebackof
the sun visor, pull up the cover.
The lights beside the mirror come
on only when the parking lights are
on.A storage compartment is located by
the third seat on the driver’s side. To
open the compartment, pull the lever
and lif t the lid. To close, lower the lid
and push it down until it latches.
Inst rument s and Cont rols
Vanity Mirror
Rear Compartment
Sun Visor, Vanity Mirror, Rear Compartment
135
REAR COMPARTMENTLEVER

The coin holder is located in the
f ront beverage holder. To open it,
pull on the bottom edge. Close it
with a firm push.
Open the center pocket by pulling
thehandle.Closeitwithafirmpush.
The light in the pocket comes on
when the instrument panel lights are
on. Push up the handle to open the
center pocket.
On EX and EX-L models
On U.S. EX-L with optional
Rear Entertainment System
Inst rument s and Cont rols
Coin Holder
Center Pocket
Center Pocket, Coin Holder
136
CENTER
POCKET COIN
HOLDER

To remove the box for cleaning,
push on the lock tab under the seat
bottom and pull the tray out. Do not
try to f orce the box. You could
damage it.To use a coat hook, push on the lid.
Close it with a f irm push.
Make sure the coat hook is closed
when you are not using it. This hook
is not designed f or large or heavy
items.
A storage box is located under the
f ront passenger’s seat. To use it, pull
the handle and slide the box out.On EX and EX-L models
(Except f or vehicles with navigation
System)
St orage Box, Coat Hook
Inst rument s and Cont rols
Storage Box Coat Hook
137
STORAGE BOXLOCK TAB
LID
