HONDA ODYSSEY 2011 RB3-RB4 / 4.G Owners Manual

µµ
Insert a DVD into the lower DVD/
CD slot in the audio unit.
Push the DVD in half way, the drive
will pull it in the rest of the way.
When you insert a DVD, the system
automatically starts to play. To turn
this f eature of f , see pages
.
Press the button if
the DVD does not start playing
automatically.
Press the button to
pause the DVD. Press the button
again or press PLAY to resume.
Pause works only with the DVD
player. 420
Rear Entertainment System
PL AY
PAUSE
418PLAY/PAUSE BUTTONSKIP BAR
PLAY/PAUSE BUTTONSKIP BAR EJECT BUTTON
EJECT BUTTON
On vehicles without navigation system On vehicles with navigation system
CD SLOT
CD SLOT
DVD/CD SLOT DVD/CD SLOT
10/07/17 10:29:59 31TK8600_423
and423
2011 Odyssey

µ
µ Press the eject button to
remove the DVD from the drive.
Pressandholdthe
side of the SKIP bar to move
f orward. Press and hold the side of the SKIP bar to move
backward. Release the bar when the
system reaches the point you want.
Each time you press the side of
the SKIP bar and release it, the
system skips f orward to the
beginning of the next track or
chapter. Press and release the side of the SKIP bar to skip
backward to the beginning of the
current track. Press and release it
again to skip to the beginning of the
previous track or chapter.
Audio
SubtitleAuto Play On
Search
Press the REAR SOURCE button of
the f ront panel while the DVD is
playing on the overhead screen. The
f ront screen shows ‘‘REAR MENU.’’
Turn the selector knob to ‘‘DVD
Setup,’’ then press the selector knob.
You can choose DVD setup f rom
these selections:
CONT INUED
On vehicles without navigation system
EJECT
SEEK /SK IP
Rear Entertainment SystemDVD Set up
Features
419
10/07/17 10:30:07 31TK8600_424
2011 Odyssey

Audio
Turn the selector knob to ‘‘Audio,’’
then press the selector knob. Turn
the selector knob to select the
language you want f or DVD audio,
then press the selector knob. The
languages that appear on the screen
are limited to the language choices
available on the DVD.Turn the selector knob to ‘‘Subtitle,’’
then press the selector knob. Turn
the selector knob to select the
language you want f or subtitles, then
press the selector knob. The
languages that appear on the screen
are limited to the language choices
available on the DVD. Subtitle
Auto Play ON
Turn the selector knob to ‘‘Auto Play
ON,’’ then press the selector knob.
When the check mark disappears
from the check box, the auto play
function also turns off.
Each time you press and release the
selector knob, this f eature turns ON
and OFF.Rear Entertainment System420
CHECK BOX
10/07/17 10:30:15 31TK8600_425
2011 Odyssey

Title or Chapter Search
Turn the selector knob to ‘‘Title
Search,’’ or ‘‘Chapter Search,’’ then
press the selector knob. Turn the
selector knob to a title or chapter
number, then press the selector
knob. The DVD skips to the selected
title or chapter.Press the REAR SOURCE button
while a DVD is playing. Turn the
interface dial to ‘‘DVD Setup,’’ then
press ENTER on the interf ace
selector. You can choose DVD setup
f rom these selections:
Title Search
Chapter Search
Audio Subtitle
Repeat
Auto PlayTitle or Chapter Search
Turn the interf ace dial to ‘‘Title
Search’’ or ‘‘Chapter Search,’’ then
press ENTER on the interf ace
selector. Turn the dial again to select
a title or chapter number, then press
ENTER on the interf ace selector.
The DVD skips to the selected title
or chapter.
On vehicles with navigation system
CONT INUED
Rear Entertainment System
Features
421
10/07/17 10:30:24 31TK8600_426
2011 Odyssey

Audio
Turn the interf ace dial to ‘‘Audio,’’
then press ENTER on the interf ace
selector. Turn the dial to select the
language you want f or DVD audio,
then press ENTER on the interf ace
selector. The languages that appear
on the screen are limited to the
language choicesavailable on Subtitle
Turn the interf ace dial to ‘‘Subtitle,’’
then press ENTER on the interf ace
selector. Turn the dial to select the
language you want f or subtitles, then
press ENTER on the interf ace
selector. The languages that appear
on the screen are limited to the
language choices
available on Turn the interf ace dial to ‘‘Repeat,’’
then press ENTER on the interf ace
selector. Select the icon in the center
( ) to repeat the current chapter,
theiconontheright( )to
repeat the current title, or select
OFF to turn of f repeat. If your DVD
does not support titles or chapters,
you cannot use this f eature. RepeatRear Entertainment System422
10/07/17 10:30:33 31TK8600_427
the DVD.
the DVD.
2011 Odyssey

Auto Play
Turn the interf ace dial to ‘‘Auto Play,’’
then press ENTER on the interf ace
selector. Select ON to play the DVD
automatically, or select OFF to play
the DVD manually.To return f ront panel control to the
f ront audio system, press the REAR
SOURCE button. You will hear a
beep and the indicator in the button
goes of f . The indicator also goes of f
automatically when you do not
operate the rear entertainment
system f or 20 seconds.
To turn on the rear entertainment
system f rom the rear control panel,
press the (power) button. Use
the FM/AM button, XM button,
CD/CDL or CD/HDD button, or
DVD/AUX button to select the
entertainment source. The selected
source will be shown in the display.
Make sure the rear control operation
has not been disabled. When the
f ront audio system is of f or the f ront
panel’s Rear Power is of f , the rear
control panel cannot be turned on.
Rear Entertainment System
To Return to Front Audio
Controls
Using the Rear Control Panel
Features
423
10/07/17 10:30:40 31TK8600_428
2011 Odyssey

424
10/07/17 10:30:33 31TK8600_427
Rear Entertainment SystemPress the FM/AM button to listen to
the radio.
Press the MENU button to display
theAudioMenuontheoverhead
screen. You can enter the
highlighted f unction by pressing the
ENTER button. These f unctions
have the same features as those of
the f ront audio system. You can
press and hold either side ( or)of theTUNE/SKIPbarto
skip (seek) up/down, and press
either side ( or ) of the
TUNE/SKIP bar to tune up/down.
To Play the Radio f rom the Rear
Control Panel
Press the XM button to listen to the
XM Radio. You can press either side
(or)oftheTUNE/SKIP
bar to scroll up/down and select
channels within a category (in
CATEGORY mode), or to scroll up/
down and select f rom among all
available channels (in CH mode).
Press the MENU button to display
theaudiomenuontheoverhead
screen. You can enter the
highlighted f unction by pressing the
ENTER button. These f unctions
have the same features as those of
the f ront audio system.
Pressing and holding the TITLE/
SCROLL button f or 5 seconds
enables you to switch between
search modes.
To Play the XM Radio f rom the
Rear Control Panel
OVERHEAD SCREEN REAR CONTROL PANEL
On vehicles with navigation system On vehicles without navigation system
2011 Odyssey

Usethe,,,orbutton to highlight Repeat,
Random, or Scan on the screen. You
can enter the highlighted f unction by
pressing the ENTER button. These
functions have the same features as
those of the f ront audio system.
When the TITLE/SCROLL button is
pressed, the title scrolls. When it is
pushed again, scrolling stops. Pressthe buttontoskiptothe
beginning of the next chapter. Press
the button to return to the
beginning of the current chapter.
Press the button again quickly
to go to the previous chapter.
To move rapidly within a chapter,
press and hold the or
button. The system will
continue to move through the
chapter. Press the button to
move forward, or the button to
move backward. Release the button
when the system reaches the point
you want.
ToselectthemenuontheDVD,
press the MENU button. Use the , , , and button
to move to the desired menu
selection, then press the ENTER
button to enter your selection.
The video screen is f or use by rear
seat passengers only. The driver and
f ront seat passenger should not try
to view the screen while driving.
Open the overhead screen by pulling
down the bottom edge of the screen
until it locks into place when f ully
extended. If you pull down the
screen too far forward, past the
second detent, the display will turn
off. Push the screen up to the second
or first detent to turn the display
back on. To close the screen, push it
up until it locks into place when f ully
closed.
Press the button when you
want to pause the DVD. Press this
button again to go back to PLAY.
To Play a Disc, CD L ibrary, HDD,
USB, or iPod
from the Rear
Control Panel To Play a DVD from the Rear
Control Panel
Rear Entertainment System
Features
425
10/07/17 10:30:58 31TK8600_430
2011 Odyssey

Top Menu
When you press the TITLE/
SCROLL button while a DVD is
playing, the current status of title,
chapter, elapsed time, angle, subtitle,
audio, and sound characteristics are
displayed. To return to the DVD
video screen, press the TITLE/
SCROLL button again. When you press the MENU button
while a DVD is playing, the DVD
Menu appears. The menu options
are TOP MENU, MENU, PLAY
MODE, SEARCH/NUMINPUT,
REPEAT, PAUSE/PLAY, and STOP.
When you select ‘‘TOP MENU,’’ the
screen changes to the DVD’s title
menu. This menu also appears when
you press the MENU button while a
DVD is not playing. To go back to
play, press the MENU or CANCEL
button.
To go to your selected menu, use the ,,,orbuttonto
highlight the icon and press the
ENTER button. To return to the
DVD video screen, select RETURN.
TITLE/SCROLL Button
MENU Button
Rear Entertainment System426
10/07/17 10:31:08 31TK8600_431
2011 Odyssey

ÛÝ
Menu
Play Mode
To change the Audio setting,
highlight ‘‘Audio’’ f rom the play
mode menu with the orbutton. A submenu of dubbed
languages appears. You can select
another language by pressing the or button. The sound
characteristics (Dolby Digital,
LPCM, MPEG Audio, dts) recorded
with the selected language is also
displayed next to the language.
When you select ‘‘MENU’’ with the
, , , or button,
the screen changes to the DVD’s
title menu. When you select ‘‘PLAY MODE’’
with the , , , or
button, you can change the
DVD’s Audio, Subtitle or Angle
setting.‘‘Audio’’
CONT INUED
Rear Entertainment System
Features
427
10/07/17 10:31:19 31TK8600_432
2011 Odyssey
