405
uuOverheatinguHow to Handle Overheating
Handling the Unexpected
■
Next thing to do
1.Check that the cooling fan is operating and
stop the engine once the temperature
gauge needle comes down.
uIf the cooling fan is not operating,
immediately stop the engine.
2.Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.
uIf the coolant level in the reserve tank is
low, add coolant until it reaches the
MAX mark.
uIf there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
radiator cap with a heavy cloth and open
the cap. If necessary, add coolant up to
the base of the filler neck, and put the
cap back on.
■
Last thing to do
Once the engine has cooled sufficiently, restart it and check the temperature gauge.
If the temperature gauge needle has gone down, resume driving. If it has not gone
down, contact a dealer for repairs.
1How to Handle Overheating
If the coolant is leaking, contact a dealer for repairs.
Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.
3
WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.
Always let the engine and radiator cool
down before removing the radiator cap.
MAX
Reserve
Tank
MIN

406Handling the Unexpected
Indicator, Coming On/BlinkingIf the Low Oil Pressure Indicator Comes On
■
Reasons for the indicator to come on
Comes on when the engine oil pressure is low.
■
What to do as soon as the indicator comes on
1.Immediately park the vehicle in a safe place.
2.If necessary, turn the hazard warning lights on.
■
What to do after parking the vehicle
1.Stop the engine and let it sit for about one minute.
2.Open the hood and check the oil level.
uAdd oil as necessary.
3.Start the engine and check the low oil pressure indicator.
uThe light goes out: Start driving again.
uThe light does not go out within 10 seconds: Stop the engine and
contact a dealer for repairs immediately.
If the Charging System Indicator Comes On
■
Reasons for the indicator to come on
Comes on when the battery is not being charged.
■
What to do when the indicator comes on
Turn off the heating and cooling system
*/climate control system
*, rear
defogger, and other electrical systems, and immediately contact a dealer
for repairs.
1If the Low Oil Pressure Indicator Comes On
NOTICERunning the engine with low oil pressure can cause
serious mechanical damage almost immediately.1If the Charging System Indicator Comes On
If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.
* Not available on all models

407
uuIndicator, Coming On/BlinkinguIf the Malfunction Indicator Lamp Comes On or Blinks
Handling the Unexpected
If the Malfunction Indicator Lamp Comes On or Blinks
■
Reasons for indicator lamp to come on or blink
•Comes on when there is a problem with the engine emissions control
system, or the fuel fill cap is missing, or loose.
•Blinks when engine misfiring is detected.
■
What to do when the indicator lamp comes on
Avoid high speeds and immediately get your vehicle inspected at a
dealer.
■
What to do when the indicator lamp blinks
Park the vehicle in a safe place with no flammable items and wait at least
ten minutes or more with the engine stopped until it cools.
■
The message appears on when:
An evaporative system leak is detected. This may be caused by the fuel fill cap being
loose or not being installed.
■
What to do when the message appears:
1.Stop the engine.
2.Check that the fuel fill cap is fully installed.
uIf not, loosen the cap, and then retighten it until it clicks at least once.
3.Drive for several days of normal driving.
uThe message should go off.
■
When the malfunction indicator lamp comes on
Malfunction indicator lamp comes on if the system continues to detect a leak of
gasoline vapor. If this happens, check the fuel fill cap using the procedures described
above.
■
Check/Tighten Fuel Cap Message
1If the Malfunction Indicator Lamp Comes On or Blinks
NOTICEIf you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.
If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

408
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator Comes On
Handling the Unexpected
If the Brake System Indicator Comes On
■
Reasons for the indicator to come on
•The brake fluid is low.
•There is a malfunction in the brake system.
■
What to do when the indicator comes on while driving
Press the brake pedal lightly to check pedal pressure.
•If normal, check the brake fluid level the next time you stop.
•If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.
1If the Brake System Indicator Comes On
Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.
If the brake system indicator and ABS indicator come
on simultaneously, the electronic brake distribution
system is not working. This can result in vehicle
instability under sudden braking.
Have your vehicle inspected by a dealer immediately.
U.S.
Canada

411
Continued
Handling the Unexpected
FusesFuse LocationsIf any electrical devices are not working,
turn the ignition switch to LOCK
(0
and
check to see if any applicable fuse is blown.
Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.
Located on the passenger’s side, near the
windshield washer reservoir. Push the tabs
to open the box.
■
Engine Compartment Fuse Box
(Primary)
■
Circuit protected and fuse rating
Circuit Protected
Amps
1
−
−
2− −
3
ACG FR
15 A
4Washer 15 A
5
VB SOL
7.5 A
6 ECU FR 7.5 A
7
−
−
8FI Sub 15A
9
DBW
15 A
10 FI Main 15 A11
Ignition Coil
15 A
12 − −13
FI ECU
7.5 A
14 − −15
Radio
20 A
16 Back Up 10 A17
MG Clutch
7.5 A
18 Front Fog Lights
*
20 A
19
−
−
20 Right Headlight High Beam 10 A
21
−
−
22 Small Lights 10 A
23
−
−
24 Left Headlight High Beam 10 A
25
−
−
26 Right Headlight Low Beam 15 A27
Left Headlight Low Beam
15 A
28 IGPS Oil Level 7.5 A
29
Cooling Fan
30 A
30 Sub Fan 30 A
31
Wiper Main
30 A
Circuit Protected
Amps
* Not available on all models

416
uuFusesuInspecting and Changing Fuses
Handling the Unexpected
Inspecting and Changing Fuses
1.Turn the ignition switch to LOCK
(0
. Turn
headlights and all accessories off.
2.Remove the fuse box cover.
3.Check the large fuse in the engine
compartment.
uIf the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.
4.Inspect the small fuses in the engine
compartment and the vehicle interior.
uIf there is a burned out fuse, remove it
with the fuse puller and replace it with a
new one.
1Inspecting and Changing Fuses
NOTICEReplacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.
Replace fuse with a spare fuse of the same specified
amperage.
Use the charts to locate the fuse in question and
confirm the specified amperage on the fuse label.
2Fuse Locations P. 411
There is a fuse puller on the back of the engine
compartment fuse box (primary) cover.
Blown FuseBlown
FuseFuse Puller

425
Continued
Information
Emissions TestingTesting of Readiness CodesYour vehicle uses "readiness codes," as part of its onboard self diagnostic system.
Some states refer to these codes during testing to see if your vehicle's emissions
components are working properly.
The codes may not be read if you go through the testing just after the battery has
gone dead or been disconnected.
To check if they are set, turn the ignition switch to ON
(w
, without starting the
engine. The malfunction indicator lamp will come on for several seconds. If it then
goes off, the readiness codes are set. If it blinks five times, the readiness codes are
not set.
If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:
1.Fill the gas tank to approximately 3/4 full.
2.Park the vehicle and leave the engine off for 6 hours or more.
3.Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).
4.Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.
5.Keep the vehicle in
(P
. Increase the engine speed to 2,000 rpm, and hold it there
until the temperature gauge rises to at least 1/4 of the scale (about 3 minutes).
6.Let the engine idle with your foot off the accelerator for 20 seconds.
1Testing of Readiness Codes
The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.
If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.
If the testing facility determines the readiness codes
are still not set, see a dealer.

Index
433
Index
Index
AABS (Anti-lock Brake System).................. 316
AC Power Outlet...................................... 177
Accessories and Modifications................ 329
Accessory Power Sockets......................... 176
Additives
Coolant .................................................. 350
Engine Oil ............................................... 345
Washer ................................................... 354
Additives, Engine Oil............................... 345
Adjusting
Armrest .................................................. 168
Front Seats.............................................. 154
Head Restraints ....................................... 157
Mirrors.................................................... 152
Rear Seats ............................................... 162
Steering Wheel ....................................... 151
Temperature ........................................... 100
Air Conditioning System
(Climate Control System)....................... 187
Changing the Mode................................ 187
Defrosting the Windshield
and Windows........................................ 188
Dust and Pollen Filter .............................. 384
Recirculation/Fresh Air Mode................... 187
Sensors ................................................... 192
Using Automatic Climate Control............ 187
Air Conditioning System (Heating and
Cooling System)...................................... 183
Cooling................................................... 185Defrosting the Windshield
and Windows ........................................ 185
Dust and Pollen Filter ............................... 384
Heating ................................................... 184
Air Pressure....................................... 371, 421
Airbags........................................................ 39
Advanced Airbags ..................................... 45
After a Collision ......................................... 43
Airbag Care ............................................... 53
Event Data Recorder .................................. 23
Front Airbags (SRS) .................................... 42
Indicator ........................................ 50, 76, 80
Passenger Airbag Off Indicator .................. 51
Sensors ...................................................... 39
Side Airbag Cutoff System ......................... 48
Side Airbag Off Indicator ........................... 52
Side Airbags .............................................. 46
Side Curtain Airbags .................................. 49
AM/FM Radio.................................... 198, 205
Anti-lock Brake System (ABS).................. 316
Indicator .................................................... 75
Armrest..................................................... 168
Audio Remote Controls............................ 203
Audio System............................................ 194
Adjusting the Sound ........................ 197, 204
Auxiliary Input Jack .................................. 195
Error Messages ........................................ 235
General Information ................................ 237
MP3/WMA/AAC ...................................... 226
Reactivating ............................................. 196
Recommended CDs ................................. 238Recommended Devices............................ 240
Remote Controls ..................................... 203
Security Code .......................................... 196
Theft Protection ...................................... 196
USB Adapter Cable.................................. 195
USB Flash Drives ...................................... 240
Audio/Information Display........................ 91
Authorized Manuals................................ 429
Auto Door Locking/Unlocking................. 116
Customize ............................................... 117
Automatic Lighting.................................. 143
Automatic Transmission........................... 300
Creeping ................................................. 300
Fluid ........................................................ 352
Kickdown ................................................ 300
Operating the Shift Lever................... 17, 302
Shift Lever Does Not Move ...................... 403
Shifting ................................................... 301
Auxiliary Input Jack.................................. 195
Average Fuel Economy.................. 88, 92, 99
Average Speed................................... 92, 100
BBattery...................................................... 379
Charging System Indicator................. 73, 406
Jump Starting .......................................... 401
Maintenance (Checking the Battery) ........ 379
Maintenance (Replacing) ................. 380, 382
Belts (Seat).................................................. 30
Beverage Holders..................................... 174

435
Index
Keys........................................................ 110
Locking/Unlocking the Doors
from the Inside...................................... 114
Locking/Unlocking the Doors
from the Outside................................... 112
Lockout Prevention System ..................... 113
DOT Tire Quality Grading........................ 373
Driving...................................................... 285
Automatic Transmission .......................... 300
Braking ................................................... 314
Cruise Control ........................................ 303
Shifting Gear .......................................... 301
Starting the Engine ................................. 297
Driving Position Memory System............ 149
Dust and Pollen Filter.............................. 384
EElapsed Time........................................ 92, 99
Electronic Stability Control (ESC)............ 306
Emergency................................................ 417
Emissions Testing (Readiness Codes)...... 425
Engine....................................................... 422
Coolant .................................................. 350
Jump Starting ......................................... 401
Oil .......................................................... 345
Starting................................................... 297
Switch Buzzer ......................................... 141
Engine Coolant........................................ 350
Adding to the Radiator ........................... 351
Adding to the Reserve Tank .................... 350Overheating ............................................ 404
Temperature Gauge .................................. 86
Engine Oil................................................. 345
Adding .................................................... 347
Checking ................................................. 346
Displaying Oil Life ............................ 335, 339
Low Oil Pressure Indicator .................. 72, 406
Recommended Engine Oil ........................ 345
Exhaust Gas Hazard
(Carbon Monoxide).................................. 68
Exterior Care (Cleaning)........................... 387
Exterior Mirrors........................................ 153
FFeatures..................................................... 193
Filters
Dust and Pollen ....................................... 384
Oil ........................................................... 348
Flat Tire..................................................... 391
Flip-up Trash Bag Ring............................. 172
Floor Mats................................................. 386
Fluids
Automatic Transmission ........................... 352
Brake ....................................................... 353
Engine Coolant ........................................ 350
Power Steering ........................................ 354
Windshield Washer .................................. 354
Fog Light Indicator..................................... 80
Folding Down the Rear Seats.......... 162, 166
Foot Brake................................................. 315Front Airbags (SRS)..................................... 42
Front Seats................................................ 154
Adjusting ................................................ 154
Fuel...................................................... 18, 325
Economy ................................................. 328
Gauge ....................................................... 86
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Range ........................................... 88, 92, 99
Recommendation .................................... 325
Refueling................................................. 325
Fuel Economy........................................... 328
Fuel Fill Cap........................................ 18, 327
Message.................................................. 407
Fuel Fill Door...................................... 18, 326
Fuses.......................................................... 411
Inspecting and Changing......................... 416
Locations................. 411, 412, 413, 414, 415
GGasoline (Fuel)
Economy ................................................. 328
Gauge ....................................................... 86
Information ............................................. 325
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Refueling................................................. 325
Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 301

438Index
NNumbers (Identification).......................... 422OOdometer.............................................. 87, 99
Oil (Engine)............................................... 345
Adding .................................................... 347
Checking ................................................. 346
Displaying Oil Life ............................ 335, 339
Low Oil Pressure Indicator .................. 72, 406
Recommended Engine Oil ........................ 345
Viscosity .................................................. 345
Opening/Closing
Hood ....................................................... 344
Moonroof ................................................ 140
Power Windows ...................................... 137
Sliding Door............................................. 126
Tailgate ................................................... 120
Outside Temperature Display............ 89, 100
Overheating.............................................. 404PPanic Mode............................................... 136
Parking...................................................... 318
Parking Brake............................................ 314
Parking Brake and Brake System
Indicator............................................ 72, 408
Parking Sensor System.............................. 319
Passenger Airbag Off Indicator................. 51Passing Indicators..................................... 142
Power Sliding Door.................................. 128
Power Tailgate......................................... 122
Power Windows....................................... 137
Precautions While Driving....................... 299
Rain ........................................................ 299
Pregnant Women....................................... 37
Puncture (Tire).......................................... 391
RRadiator.................................................... 351
Radio (AM/FM)................................. 198, 205
Radio Data System (RDS)................. 199, 208
Range.............................................. 88, 92, 99
RDS (Radio Data System)................. 199, 208
Readiness Codes (Emissions Testing)....... 425
Rear Defogger/Heated Door Mirror
Button..................................................... 148
Rear Entertainment System..................... 241
Rear Seats (Folding Down).............. 162, 166
Rearview Camera..................................... 323
Rearview Mirror....................................... 152
Refueling.................................................. 325
Fuel Gauge................................................ 86
Gasoline .......................................... 325, 420
Low Fuel Indicator ..................................... 75
Regulations............................... 309, 373, 423
Remote Transmitter................................. 112
Removable Center Console...................... 171
Removing a Second Row Outer Seat...... 163Removing the Second Row
Center Seat............................................. 165
Replacement
Battery ............................................ 380, 382
Bulbs ...................................................... 355
Fuses ...................... 411, 412, 413, 414, 415
Tires........................................................ 376
Wiper Blade Rubber ................................ 366
Reporting Safety Defects......................... 424
Resetting a Trip Meter......................... 88, 99
SSafe Driving................................................ 25
Safety Check............................................... 29
Safety Labels.............................................. 69
Safety Message.......................................... 24
Seat Belts.................................................... 30
Adjusting the Shoulder Anchor ........... 34, 35
Automatic Seat Belt Tensioners ................. 32
Checking .................................................. 38
Fastening .................................................. 33
Installing a Child Seat
with a Lap/Shoulder Seat Belt .................. 62
Pregnant Women...................................... 37
Reminder .................................................. 31
Warning Indicator ............................... 31, 75
Seat Heaters............................................. 181
Seats.......................................................... 154
Adjusting ................................................ 154
Front Seats.............................................. 154
