This system uses the same sensors
as the front airbags to monitor
whether the f ront seat belts are
latched or unlatched, and how much
weight is on the f ront passenger’s
seat (see pages and ).If either the driver or a f ront
passenger does not f asten their seat
belt while driving, the beeper will
sound and the indicator will f lash
again at regular intervals.
The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you and your passengers to
f asten your seat belts.
This system monitors the f ront seat
belts. If you turn the ignition switch
to the ON (II) position bef ore your
seat belt is f astened, the beeper will
sound and the indicator will f lash. If
your seat belt is not f astened bef ore
the beeper stops, the indicator will
stop f lashing but remain on.
If a f ront passenger does not f asten
their seat belt, the indicator will
come on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.
Your seat belt system includes lap/
shoulder belts in all seating positions.
The f ront seat belts are also
equipped with automatic seat belt
tensioners.
When no one is sitting in the f ront
passenger’s seat, or a child or small
adult is riding there, the indicator
should not come on and the beeper
should not sound. You will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message on the multi-
inf ormation display (see page ).
29 30 93
On Touring models
Additional Inf ormation About Your Seat Belts
Seat Belt System Components
20
——
y


y
(/yy
2009 Pilot

Automatic front seat belt
tensioners (see page ).An indicator on the instrument
panel that alerts you to a possible
problem with your airbags,
sensors, or seat belt tensioners
(see page ).
An indicator on the instrument
panel that alerts you that the
passenger’s side airbag has been
turned of f (see page ).
An indicator on the dashboard that
alerts you that the passenger’s
f ront airbag has been turned of f
(see page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
Weight sensors that monitor the
weight on the f ront passenger’s
seat. If the weight is about 65 lbs
(29 kg) or less (the weight of an
inf ant or small child), the
passenger’s f ront airbag will be
turned of f (see page ).
A rollover sensor that can detect if
your vehicle is about to roll over
and signal the control unit to
deploy both side curtain airbags
and f ront seat belt tensioners (see
page ).
A sophisticated electronic system
that continually monitors and
records inf ormation about the
sensors, the control unit, the
airbag activators, the seat belt
tensioners, and driver and f ront
passenger seat belt use when the
ignition switch is in the ON (II)
position.
Sensors that can detect a
moderate to severe front impact,
side impact, or if your vehicle is
about to rollover.
Sensors that can detect whether a
child is in the passenger’s side
airbag path and signal the control
unit to turn the airbag of f (see
page ).
Sensors that can detect whether
the driver’s seat belt and the f ront
passenger’s seat belt are latched
or unlatched (see page ).
A driver’s seat position sensor that
monitors the distance of the seat
from the front airbag. If the seat is
too f ar f orward, the airbag will
inf late with less f orce (see page
). 22
29 29
33
31 32 33
34
20
Additional Inf ormation About Your Airbags
26
——
y
y
(/y
y
2009 Pilot

During a f rontal crash, your seat belt
restrains your lower body and torso,
and the f ront airbag helps protect
your head and chest.
Although both airbags normally
inf late within a split second of each
other, it is possible f or only one
airbag to deploy.
This can happen if the severity of a
collision is at the margin, or
threshold, that determines whether
or not the airbags will deploy. In
such cases, the seat belt will provide
suf f icient protection, and the
supplemental protection of f ered by
the airbag would be minimal.
If you ever have a moderate to
severe f rontal collision, sensors will
detect the vehicle’s rapid
deceleration.
If the rate of deceleration is high
enough, the control unit will instantly
inf late the driver’s and f ront
passenger’s airbags, at the time and
with the f orce needed. Only the driver’s airbag can deploy if
there is no passenger in the f ront
seat, or if the advanced airbag
system has turned the passenger’s
airbag off (see page ).Af ter inf lating, the f ront airbags
immediately def late, so they won’t
interf ere with the driver’s visibility,
or the ability to steer or operate
other controls.
34
CONT INUED
How Your Front Airbags Work
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
27
——
y

y
(/yy
2009 Pilot

Be aware that objects placed on the
passenger’s seat can also cause the
airbag to be turned off.
When the airbag is turned of f , a
‘‘passenger airbag of f ’’ indicator in
the center of the dashboard comes
on (see page ).
If the weight sensors detect there is
no passenger in the f ront seat, the
airbag will be off. However, the
passenger airbag of f indicator will
not come on.
To ensure that the passenger’s
advanced front airbag system will
work properly,
This includes:A second-row passenger pushing
or pulling on the back of the f ront
passenger’s seat. Moving the f ront seat f orcibly
back against cargo on the seat or
f loor behind it.
Hanging heavy items on the f ront
passenger seat, or placing heavy
items in the seat-back pocket.
Moving the f ront passenger’s seat
or seat-back forcibly back against
the f olded right-side second-row
seat.
Also,makesurethefloormatbehind
the f ront passenger’s seat is hooked
to the floor mat anchor (see page ). If it is not, the mat may
interf ere with the proper operation
of the sensors and operation of the
seat. If you ever have a moderate to
severe side impact, sensors will
detect rapid acceleration and signal
the control unit to instantly inf late
either the driver’s or the passenger’s
side airbag.
34
495 How Your Side A irbags Work
Additional Inf ormation About Your Airbags
do not do anyt hing
t hat would increase or decrease t he weight on the f ront passenger’s seat.
30
——
y

y
(/yy
2009 Pilot

µ
Front airbags have been designed to
help protect adults in a moderate to
severe f rontal collision. To do this,
the passenger’s f ront airbag is quite
large, and it can inflate with enough
f orce to cause very serious injuries.
According to accident statistics,
children of all ages and sizes are
saf er when they are restrained in a
back seat.
If the vehicle seat is
too far forward, or the child’s head is
thrown f orward during a collision, an
inflating front airbag can strike the
child with enough f orce to kill or
very seriously injure a small child.
Whenever possible,
larger children should sit in the back
seat, on a booster seat if needed, and
be properly restrained with a seat
belt. (See page f or important
inf ormation about protecting larger
children.)
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
aged 12 and under be properly
restrained in a back seat. Some
states have laws restricting where
children may ride.
Children who ride in the back are
less likely to be injured by striking
interior vehicle parts during a
collision or hard braking. Also,
children cannot be injured by an
inflating front airbag when they ride
in the back.
Even though your vehicle has an
advanced front airbag system that
automatically turns the passenger’s
f ront airbag of f (see page ),
please f ollow these guidelines:
If
the airbag inf lates, it can hit the back
of the child seat with enough force
to kill or very seriously injure an
inf ant. 34
55
The Passenger’s Front Airbag
Can Pose Serious Risks
All Children Should Sit in a Back
Seat
Protecting Children General Guidelines
Small Children
Placing a f orward-f acing child seat inthe f ront seat of a vehicle equippedwit h a passenger’s f ront airbag canbe hazardous.
Larger ChildrenChildren who have outgrown childseat s are also at risk of being injuredor killed by an inf lat ing passenger’sfront airbag.
Inf ant s
Never put a rear-f acing child seat inthe f ront seat of a vehicle equippedwit h a passenger’s f ront airbag.
38
——
y
y
(/yy
2009 Pilot

If placed
f acing f orward, an inf ant could be
very seriously injured during a
f rontal collision.
An inf ant must be properly
restrained in a rear-f acing, reclining
child seat until the child reaches the
seat maker’s weight or height limit
f or the seat, and the child is at least
one year old.
Only a rear-f acing child seat provides
proper support f or a baby’s head,
neck, and back. If the passenger’s front airbag
inflates, it can hit the back of the
child seat with enough f orce to kill or
seriously injure an inf ant.
Two types of seats may be used: a
seat designed exclusively f or inf ants,
or a convertible seat used in the rear-
f acing, reclining mode.
When properly installed in the
second row, a rear-f acing child seat
maypreventthedriverorafront
passenger f rom moving their seat as
f ar back as recommended, or f rom
locking their seat-back in the desired
position. A rear-f acing child seat can be placed
in any seating position in the back
seat, but not in the f ront.
It could also interf ere with proper
operation of the passenger’s
advanced front airbag system.
Protecting Inf ants and Small Children
Protecting Inf ants
Child Seat T ypeDo not put a rear-f acing child seat in
a f orward-f acing position. Never put a
rear-f acing child seat in t he f ront seat .
Rear-f acing Child Seat Placement
42
——
y

y
(/yy
2009 Pilot

If a child who uses a booster seat
must ride in f ront, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat
belt properly.
A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat.The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see pages and ). If
the seat belt does not f it properly,
with or without the child sitting on a
booster seat, the child should not sit
in f ront.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride.
15
55
CONT INUED
When Can a L arger Child Sit in
Front
Physical Size
Maturity
Protecting L arger Children
Driver and Passenger Saf ety
57
——
y

y
(/yy
2009 Pilot

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury or death. Read these labels
caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which may be
removed by the owner), contact your
dealer f or a replacement.U.S. models only
U.S. models Canadian models
Saf ety L abels
60
RADIATOR CAP DASHBOARD
BATTERY LABEL
HOOD
——
y
y
(/yy
2009 Pilot

Î
Î
Î
Î
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text. 4WD models only If equipped
1:
2:
Instrument Panel
LX, EX, and EX-L models
Inst rument s and Cont rols
65
HIGH BEAM INDICATOR
LIGHTS ON INDICATOR
CRUISE CONTROL INDICATOR
CRUISE MAIN INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATORSEAT BELT REMINDER
INDICATOR
TIRE PRESSURE MONITORING SYSTEM (TPMS) INDICATOR
SIDE AIRBAG OFF
INDICATOR
FOG LIGHT
INDICATOR
ANTI-LOCK BRAKE SYSTEM INDICATOR
MAINTENANCE MINDER INDICATOR
CHARGING SYSTEM INDICATOR
LOW OIL PRESSURE INDICATOR
VTM-4 INDICATOR
LIGHT CONTROL INDICATOR
DAYTIME RUNNING LIGHTS INDICATOR
MALFUNCTION INDICATOR LAMP
FUEL ECONOMY INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
LOW TIRE PRESSURE INDICATOR
INFORMATION DISPLAY VSA ACTIVATION INDICATOR
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR A/T TEMPERATURE INDICATOR
STARTER SYSTEM INDICATORDOOR-OPEN INDICATOR
SUPPLEMENTAL RESTRAINT SYSTEM
INDICATOR
SECURITY SYSTEM INDICATOR WASHER LEVEL INDICATORLOW FUEL INDICATOR
(P.75)
(P.68)
(P.75) (P.68)
(P .77)
(P.77)
(P.74)
(P.71) (P.77)
(P.72)
(P.71)
(P.76)
(P.81) (P.
73)
(P.76)
(P.70) (P.
76)
(P. 76)
(P.70) (P.76)
(P.76)
(P.69)
(P. 67)
(P. 70)
(P.78)(P.79)
(P.78)
(P.
77)
(P.68)
(P.73)
1
2
2
1
——
y
y
(/yy
2009 Pilot

Î
ÎÎ
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.: 4WD models only
Instrument Panel
T ouring models
66
ANTI-LOCK BRAKE SYSTEM
INDICATOR
HIGH BEAM INDICATOR
SIDE AIRBAG OFF INDICATOR
CRUISE MAIN INDICATOR
FOG LIGHT
INDICATOR
PARKING BRAKE AND BRAKE
SYSTEM INDICATORSEAT BELT REMINDER
INDICATOR
SUPPLEMENTAL
RESTRAINT SYSTEM
INDICATOR
DOOR-OPEN INDICATOR
MESSAGE INDICATOR
SECURITY SYSTEM INDICATOR
LOW OIL PRESSURE INDICATOR
VTM-4 INDICATOR
CHARGING SYSTEM INDICATOR
MALFUNCTION INDICATOR LAMP
FUEL ECONOMY INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
MULTI-INFORMATION DISPLAY LOW FUEL INDICATOR
LIGHTS ON INDICATOR
CRUISE CONTROL INDICATOR
(P.68)
(P.75) (P.68)
(P.68)
(P.77)
(P.71) (P.70)
(P.76) (P.76)
(P.76)
(P.70)
(P.76)
(P. 76)
(P. 70)
(P. 78)
(P.77)
(P.75)
(P.79)
(P.85)
(P.71)
(P.76) (P.
69)
VSA ACTIVATION
INDICATOR
VEHICLE STABILITY ASSIST
(VSA) SYSTEM INDICATOR LOW TIRE PRESSURE
INDICATOR (P.72)
A/T TEMPERATURE INDICATOR
(P.74)
(P.67)
——
y
y
(/y
y
2009 Pilot
