2010 Pilot Online Reference Owner's Manual
2010 Pilot

The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.
Your vehicle’s onboard diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the information display.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the select/reset knob.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f .
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
455
522
Gauges
Maintenance MinderCheck Fuel Cap Message
86
——
y
y
(/
y
y
2010 Pilot

Bef ore you begin driving your
vehicle, you should know what
gasoline to use and how to check the
levels of important f luids. You also
need to know how to properly store
luggage or packages. The
inf ormation in this section will help
you. If you plan to add any
accessories to your vehicle, please
read the information in this section
first.
.............................Break-inPeriod.394
.................FuelRecommendation.394
.........ServiceStationProcedures.395
....................................Refueling.395
.....TightenFuelCapMessage.396
OpeningandClosingthe
.......................................Hood.397
...................................OilCheck.398
.............EngineCoolantCheck.398
...............................FuelEconomy.399
...AccessoriesandModifications.402
.............................CarryingCargo.404
Bef ore Driving
Bef ore Driving
393
——
y


y
(/
yy
2010 Pilot

CONT INUED
Remove the f uel f ill cap slowly.
You may hear a hissing sound as
pressure inside the tank equalizes.
Place the cap in the holder on the
fuel fill door.
Stop f illing the tank af ter the f uel
nozzle automatically clicks of f . Do
not try to ‘‘top off’’ the tank. This
leaves some room in the f uel tank
for the fuel to expand with
temperature changes.
even
though the tank is not full, there may
be a problem with your vehicle’s f uel
vapor recovery system. The system
helps keep f uel vapor f rom going
into the atmosphere. Try f illing at
another pump. If this does not f ix the
problem, consult your dealer.
Park with the driver’s side closest
to the service station pump.
Open the f uel f ill door by pulling
on the handle located under the
lower lef t corner of the dashboard.
1.
2.
3.
4.
If the f uel nozzle keeps clicking of fRef ueling
Service Station Procedures
Bef ore Driving
395
HOLDER
FUEL FILL DOOR RELEASE HANDLEFUEL FILL CAP
TETHER
Gasoline is highly flammable
and explosive. You can be
burned or seriously injured
when handling fuel.
Stop the engine, and keep
heat, sparks, and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
——
y

y
(/
yy
2010 Pilot

Screw the fuel fill cap back on
until it clicks at least once.
Push the f uel f ill door closed until
it latches.
If you do not properly tighten the
cap, you will see a ‘‘CHECK FUEL
CAP’’ message on the inf ormation
display (see page ).
If you do not properly tighten the
cap, you will see a ‘‘TIGHTEN
FUEL CAP’’ message on the multi-
inf ormation display (see page
).
If the system still detects a leak in
the vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
Your vehicle’s on board diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘TIGHTEN FUEL CAP’’ message
appears on the multi-inf ormation
display. Turn the engine of f , and
conf irm the f uel f ill cap is installed. If
it is, loosen it, then retighten it until
it clicks at least once. The message
should go of f af ter several days of
normal driving once you tighten or
replace the f uel f ill cap. To scroll to
another message, press the INFO
button. The ‘‘TIGHTEN FUEL CAP’’
message will appear each time you
restart the engine until the system
turns the message of f .
5.
6.
86
396
522
Except Touring models
On Touring models
On Touring models
Tighten Fuel Cap Message
Service Station Procedures
396
——
y

y
(/
y
y
2010 Pilot

µµ
Î
Î
ÎÎ
Î
ÎÎ
Î
ÎÎ
Î Î
Î
Î
Specif ications
538
Seating Capacities
Air Conditioning
Dimensions Capacities
Weights
1.98 US gal (7.5)2.48 US gal (9.4)
4.5 US qt (4.3)
4.2 US qt (4.0)
5.3 US qt (5.0)
190.9 in (4,850 mm) 78.5 in (1,995 mm)70.9 in (1,802 mm)21.00 US gal (79.5)
TotalFrontSecondThird 33 28
Refrigerant type Charge quantityLubricant type ND-OIL821.2 22.9 oz (600 650 g)HFC-134a (R-134a)
The GCWR must be reduced 2 percent for every 1,000 feet (305meters) of elevation.
See the tire information label atta-ched to the driver’s doorjamb.8,466 lbs (3,840 kg)
LengthWidthHeight
Wheelbase Track67.5 in (1,715 mm) 67.7 in (1,720 mm)109.3 in (2,775 mm)
Excluding the oil remaining in the engine0.196 US gal (0.74)
Including the coolant in the reserve tank and that remaining in the engineReserve tank capacity:
4.2 US qt (4.0)
Fuel tank
Engine coolantEngine oil
Automatic transmissionfluid
Rear differentialfluid (4WD)Transferassemblyfluid (4WD)Windshieldwasherreservoir6.9 US qt (6.5)
72.7 in (1,846 mm)
9,579 lbs (4,345 kg)
3.6 US qt (3.4)8.6 US qt (8.1)3.6 US qt (3.4)8.6 US qt (8.1)2.96 US qt (2.80)3.01 US qt (2.85)
0.45 US qt (0.43)0.48 US qt (0.45)
Gross vehicle weight rating
Gross combined weight rating (GCWR)
Approx.
FrontRear
1:
2:
U.S. vehicles Canadianvehicles
1 :2 : Except U.S. LX modelsU.S. LX models
2WD models
1:
2:3: 4WDmodels
2WD
4WD
Change TotalChangeIncludingfilterWithoutfilterTotalChangeTotalChangeTotalChangeTotal
Change Total
1
1 2
2 3
1
2
——
y
y
(/
yy
2010 Pilot

ExpectantMothers,UseofSeat
........................................Beltsby.20
..........................Fan,Interior.193,202
Features,Comfortand
..............................Convenience.191
....................FillingtheFuelTank.395
Filters
.........................DustandPollen.490
...............................................Oil.473
...........Flashers,HazardWarning.130
...................FlatTire,Changinga.509
.....................................FloorMats.491
Fluids
..........AutomaticTransmission.478
..........................................Brake.481
..........................PowerSteering.482
.......................RearDifferential.480
...................TransferAssembly.480
..................WindshieldWasher.477
FMStereoRadio
...................................Reception.308
.....................................FogLights.128
..............FoldingtheSecondSeat.160
.................FoldingtheThirdSeat.161
........................Four-wayFlashers.130
............................FrontAirbags.11,29
......................................FrontSeat.154
....................................Adjusting.154
...................................Airbags.11,29
.......................................Heaters.164
.................................................Fuel.394
......................FillDoorandCap.395
...........................................Gauge.82
................OctaneRequirement.394
...............................Oxygenated.394
........................ReserveIndicator.80
........................Tank,Fillingthe.395
......................TightenFuelCap.396
...............................FuelEconomy.399
.....................Fuses,Checkingthe.525
.............HalogenHeadlightBulbs.483
...........................HandsFreeLink.361
..............................HFLButtons.361
............HazardWarningFlashers.130
...............GasMileage,Improving.400
.........................................Gasoline.394
...........................................Gauge.82
.....................LowFuelIndicator.80
................OctaneRequirement.394
........................Tank,Refueling.395
................GasStationProcedures.395
Gauges
...EngineCoolantTemperature.82
...............................................Fuel.82
...............................Speedometer.82
.................................Tachometer.82
GAWR(GrossAxleWeight
.......................................Rating).435
GCWR(GrossCombinedWeight
.......................................Rating).436
............GearshiftLeverPositions.413
...................................GlassHatch.148
......................................GloveBox.183
GVWR(GrossVehicleWeight
.......................................Rating).435
Index
G
H
F
IV
——
y
y
(/
yy
2010 Pilot

4WD models only
4WD models only
Service Inf ormation Summary
Gasoline:Brake Fluid:
Tire Pressure (measured cold):
Rear Differential Fluid:
Automatic Transmission Fluid:
Recommended Engine Oil:
Fuel Tank Capacity:
Transfer Assembly Fluid:
Power Steering Fluid:
Honda Heavy Duty Brake Fluid
DOT 3 preferred, or a DOT 3 or
DOT 4 brake fluid as a temporary
replacement (see page ).
Front/Rear:
32 psi (220 kPa , 2.2 kgf/cm)
Compact Spare Tire:
60 psi (420 kPa , 4.2 kgf/cm)
Unleaded gasoline, pump octane
number of 87 or higher.Honda VTM-4 Differential Fluid
(see page ).
Honda Genuine ATF-Z1
(automatic transmission fluid)
(see page ).
4.5 US qt (4.3)
Oil change capacity (including
filter):
API Premium grade 5W-20
detergent oil (see page ).
21.00 US gal (79.5)
SAE 90 or SAE 80W-90 viscosity
hypoid gear oil, API service
classified GL4 or GL5 only.
Honda Power Steering Fluid
preferred, or another brand of
power steering fluid as a
temporary replacement. Do not
use ATF (see page ).
Premium fuel is recommended
when towing in certain conditions
(see page ).
472
480
479
482
481
446
——yy
(/
yy
2010 Pilot
